Clustering, Self_Organizing Feature Map

1
Clustering, Self_Organizing Feature Map

• 2003. 11.3
• Yoonyoung Nam
• Shakeel,M.
• YoungIn Yeo

2
Clustering
3
Introduction

• Cluster
• Group of the similar objects
• Clustering
• Special method of classification
• Unsupervised learning no predefined classes

4
What is Good Clustering?

• High Intra-cluster similarity
• Dissimilar to the objects in other clusters
• Low Inter-cluster similarity
• Similar to one another within the same cluster
• ?Depending on the similarity measure

5
The problem of unsupervised clustering

• Nearly identical to that of distribution
  estimation for classes with multi-modal features

Example of 4 data sets with the same mean and
covariance
6
Similarity Measures

• The distance between them
• If the Euclidean distance between them is less
  than some threshold distance d0,
• same cluster

7

• A simple scaling of the coordinate axes can
  result in a different grouping of the data into
  clusters

8

• To achieve invariance, normalize the data
• Subtracting the mean and dividing by the standard
  deviation
• Inappropriate if the spread is due to the
  presence of subclasses

9
Mahalanobis distance

• Similarity function s(x, x)
• Using the angle between two vectors, normalized
  inner product may be an appropriate similarity
  function.

10
Tanimoto coefficient

• Using binary values
• The ratio of the number of shared attributes to
  the number possessed by x or x

11
Category of Clustering Method

• Hierarchical Clustering
• Group objects into a tree of clusters
• AGNES(Agglomerative Nesting)
• DIANA(Divisible Analysis)
• Partitioning Clustering
• Construct a partition of a object V into a set of
  k clusters (k user input parameter)
• K-means
• K-medoids

12
Hierarchical Method
13
Hierarchical Method

• Algorithm for Agglomerative
• Input Set V of objects
• Put each object in a cluster
• Loop until the number of cluster is one
• Calculate the set of inter-cluster similarity
• Form merge by the fusion of the most similar
  pair of current clusters

14
Hierarchical Method

• Similarity Method
• Single-Linkage
• Complete-Linkage
• Average-Linkage

15
K-means

• Use gravity center of the objects
• Algorithm
• Input k(the number of cluster), Set V of n
  objects
• Output A set of k clusters which
  minimizes the sum of distance error criterion
• Method
• Choose k objects as the initial cluster centers
  set i0
• Loop
• For each object v
• Find the NearestCenter(i)(p), and assign p
  to it
• Compute mean of cluster as center
• Pro quick convergence
• Con sensitive to noise, outlier and initial
  seed selection

16
K-means
17
K-means clustering

• Choose k and v

18
K-means clustering

• Assign each object to the cluster to which it is
  the closest
• Compute the center
• of each cluster

19
K-means clustering

• Reassign subjects to the cluster whose centroid
  is nearest

20
K-medoids

• Medoid the object whose average dissimilarity
  to all the objects in the cluster is minimal.
• Algorithm
• Input k (the number of cluster), Set V of n
  objects
• Output A set of k clusters which minimizes the
  sum of distance error criterion
• Method
• Choose k objects as the initial cluster centers
  set i0
• Loop
• For each object v
• Find the NearestCenter(i)(p), and assign p
  to it
• Randomly select a non-centre object orandom
• Compute the total cost S of swapping oj with
  orandom to form new set
• If Slt0, swap oj with orandom
• Break when threshold is met

21
K-medoids

• Swapping cases

orandom
1.re-assigned to oi
2.re-assigned to orandom
4.re-assigned to orandom
3.no change
data object
cluster center
before swapping
afterswapping
22
K-medoids

• PAM(Partition Around Method)
• Algorithm
• 5) for each of the k-centre oj
• 6) examines all of the non-centre n-k object
• 7) swap oj with onew s.t. Enew min Ei in all
  n-k
• Complexity
• O(k(n-k)2) very costy
• Good to small database

23
Clustering Example

• http//www.rzuser.uni-heidelberg.de/mmaier4/clust
  eringdemo/applet.shtml

24
Self Organizing Feature Map
25
Self Organizing Maps

• Based on competitive learning(Unsupervised)
• Only one output neuron activated at any one time
• Winner-takes-all neuron or winning neuron
• In a Self-Organizing Map
• Neurons placed at the nodes of a lattice
• one or two dimensional
• Neurons selectively tuned to input patterns
• by a competitive learning process
• Locations of neurons so tuned to be ordered
• formation of topographic map of input patterns
• Spatial locations of the neurons in the lattice
  -gt intrinsic statistical features contained in
  the input patterns

26
Self Organizing Maps

• Topology-preserving transformation

27
SOM as a Neural Model

• Distinct feature of human brain
• Organized in such a way that different sensory
  inputs are represented by topologically ordered
  computational maps
• Computational map
• Basic building block in information-processing
  infrastructure of the nervous system
• Array of neurons representing slightly
  differently tuned processors, operate on the
  sensory information-bearing signals in parallel

28
Basic Feature-mapping models

• Willshaw-von der Malsburg Model(1976)
• Biological grounds to explain the problem of
  retinotopic mapping from the retina to the visual
  cortex
• Two 2D lattices presynaptic, postsynaptic
  neurons
• Geometric proximity of presynaptic neurons is
  coded in the form of correlation, and it is used
  in postsynaptic lattice
• Specialized for mapping for
  same dimension of

  input and output

29
Basic Feature-mapping models

• Kohonen Model(1982)
• Captures essential features of computational maps
  in Brain
• remains computationally tractable
• More general and more attention than
  Willshaw-Malsburg model
• Capable of dimensionality
  reduction
• Class of vector coding
  algorithm

30
Formation Process of SOM

• After initialization for synaptic weights, three
  essential processes
• Competition
• Largest value of discriminant function selected
• Winner of competition
• Cooperation
• Spatial neighbors of winning neuron is selected
• Synaptic adaptation
• Excited neurons adjust synaptic weights

31
Competitive Process

• Input vector, synaptic weight vector
• x x1, x2, , xmT
• wjwj1, wj2, , wjmT, j 1, 2,3, l
• Best matching, winning neuron
• i(x) arg min x-wj, j 1,2,3,..,l
• Determine the location where the topological
  neighborhood of excited neurons is to be centered

32
Cooperative Process

• For a winning neuron, the neurons in its
  immediate neighborhood excite more than those
  farther away
• topological neighborhood decay smoothly with
  lateral distance
• Symmetric about maximum point defined by dij 0
• Monotonically decreasing to zero for dij ? 8
• Neighborhood function Gaussian case
• Size of neighborhood shrinks with time

33
Adaptive process

• Synaptic weight vector is changed in relation
  with input vector
• wj(n1) wj(n) ?(n) hj,i(x)(n) (x - wj(n))
• Applied to all neurons inside the neighborhood of
  winning neuron i
• Upon repeated presentation of the training data,
  weight tend to follow the distribution
• Learning rate ?(n) decay with time
• May decompose two phases
• Self-organizing or ordering phase topological
  ordering of the weight vectors
• Convergence phase after ordering, for accurate
  statistical quantification of the input space

34
Summary of SOM

• Continuous input space of activation patterns
  that are generated in accordance with a certain
  probability distribution
• Topology of the network in the form of a lattice
  of neurons, which defines a discrete output space
• Time-varying neighborhood function defined around
  winning neuron
• Learning rate decrease gradually with time, but
  never go to zero

35
SOFM Example(1) 2-D Lattice by 2-D distribution
36
SOFM Example(2)Phoneme Recognition

• Phonotopic maps

• Recognition result for humppila

37
SOFM Example(3)

• http//www-ti.informatik.uni-tuebingen.de/goepper
  t/KohonenApp/KohonenApp.html
• http//davis.wpi.edu/matt/courses/soms/applet.htm
  l
