Title: Microwave Induced Thermoacoustic Tomography


1
Microwave Induced Thermoacoustic Tomography
  • By Zaid Al-Husseini

2
Sections
  • Introduction to MITT (Microwave Induced
    Thermoacoustic Tomography)
  • Experimental Set up (Apparatus)
  • Discussion of Results
  • Advantages
  • Disadvantages

3
Introduction to MITT
  • Method to Image biological tissue
  • Electromagnetic microwaves are pulsated towards a
    biological material resulting in the absorption
    of heat and hence a mechanical expansion of the
    material.
  • Acoustic waves are created by thermal expansion
    of material which propagate throughout the
    material in all directions in the form of sound.
  • Increasing the pulsation of the electromagnetic
    waves induces a higher rate of expansion and
    contraction in the material resulting in higher
    frequencies in the acoustic waves ie. Ultrasound.
  • The higher the acoustic frequency produced, the
    lower the wavelength of the acoustic waves which
    results in a higher resolution of images. Since
  • ? vsound / fsound
  • Unlike conventional acoustic imaging MITT depends
    on the difference in dielectric constants between
    tissues whereas ultrasound imaging depends on
    acoustic impedance between tissues. This gives
    MITT the potential for imaging objects invisible
    to ultrasound (due to equal impedancesetc)

4
Apparatus and Experimental Setup
  • General Apparatus simulating a biological
    material (usually animal fat tissue w/muscle)
    enclosed in mineral oil and is exposed to
    microwave generator.
  • Within the apparatus is an ultrasonic transducer
    which detects Ultrasonic Thermoacoustic waves.
  • Data is collected from several angles of the
    object and is processed by a computer.
  • The data is collected through linear scanning of
    the ultrasonic transducer which results in
    multiple one-dimensional images.
  • The computer uses the obtained one-dimensional
    images to reconstruct the data into
    two-dimensional images.
  • Time delay and velocity manipulation of produced
    acoustic waves are used to obtain distance
    variations of the material and reconstruct/image
    the material sample.

5
Sample Experimental Set Up
6
Discussion of Results
  • Microwave induced acoustic pressure is
    proportional to the intensity of the incidental
    microwaves. The different dialectic constants
    between different tissues provides good imaging
    in MITT which is fundamentally different than
    ultrasounds reliance on acoustic impedance
    differences.
  • Using a non-focused transducer allows for a
    larger reception angle than focused one allowing
    for a wider ranged data set.
  • Higher frequencies of microwave pulses (e.g. 9
    GHz) resulted in higher resolution but less depth
    penetration than low frequencies due to large
    attenuation of signal at higher frequencies.
  • Lower frequencies allowed for much more depth
    penetration due to higher wavelengths but a lower
    Signal noise ratio (SNR) than higher frequencies.
  • Strong microwave absorption results in decreased
    clarity of produced images (eg. High muscle
    tissue absorption).
  • Broadening of the pulse signal proportionally to
    the transducer surface allowed for better
    optimization of image depiction at boundaries.
  • Axial resolution (alleviate stretching problems)
    by reducing transducer diameter at the cost of a
    lower SNR.

7
Images from Thermoacoustic Tomography
8
Advantages
  • Takes advantage of Microwave imagings
    non-ionizing radiation and high imaging contrast
    benefits due to the use of dielectric property
    differences of materials
  • Benefits from Ultrasounds exceptional spatial
    resolution.
  • Low Power emissions make it acceptable for use on
    humans and biological tissue and thus make them
    harmless (based on IEEE standards).
  • High Depth penetration, spatial resolution and
    contrast at low/high frequencies allows detection
    of tumors at earlier stages.

9
Disadvantages
  • Limited Depth Recognition and high frequencies
    due to large attenuation resulting in sacrifice
    between resolution and depth.
  • Most Depth is limited to about 40-45 mm which is
    impractical for most breast tumor detection.
  • Sacrifice between axial resolution improvement at
    the cost of lower SNR due to widening of
    transducer reception
