Hunting for Chameleons

1
Hunting for Chameleons
Amanda Weltman
Centre for Theoretical Cosmology University of
Cambridge Moriond 2008
astro-ph/0309300 PRL J. Khoury and A.W
astro-ph/0309411 PRD J. Khoury and
A.W astro-ph/0408415 PRD P. Brax, C. van de
Bruck, J.Khoury, A. Davis and A.W hep-ph in
progress A. Chou, J. Steffen, W. Wester, A.
Uphadye and A.W astro-ph in progress A. Uphadye
and A. W
2
Plan

• Motivation - Theoretical Observational
• Chameleon idea and thin shell effect
• Predictions for tests in space
• Dark Energy Candidate
• Quantum vacuum polarisation experiments
• The GammeV experiment and Chameleons

See Mota talk
See Mota talk
See Mota talk
We can learn about fundamental physics using low
energy and low cost techniques.
3
Motivation

• Massless scalar fields are abundant in String
  and SUGRA
• theories

• Massless fields generally couple directly to
  matter with
• gravitational strength

• Unacceptably large Equivalence Principle
  violations
• Coupling constants can vary
• Masses of elementary particles can vary

Gravitational strength coupling
Light scalar field
?

Tension between theory and observations
Opportunity! - Connect to Cosmology
4
Solutions?
1. Suppress the coupling strength

• String loop effects Damour Polyakov
• Approximate global symmetry Carroll

2. Field acquires mass due to some mechanism

• Invoke a potential

• Chameleon Mechanism Khoury A.W
• Flux Compactification KKLT
• Special points in moduli space - new d.o.f
  become
• light Greene, Judes, Levin, Watson A.W

5
Chameleon Effect

Mass of scalar field depends on local matter
density
In region of high density ? mass is large ? EP
viol suppressed
In solar system ? density much lower ? fields
essentially free
On cosmological scales ? density very low ? m
H0

Field may be a candidate for acc of universe
6
Ingredients
Reduced Planck Mass
Coupling to photons
Matter Fields
Einstein Frame Metric
Conformally Coupled
Potential is of the runaway form
7
Effective Potential
Energy density in the ith form of matter
Equation of motion
Dynamics governed by Effective potential
8
Predictions for Tests in Space
Different behaviour in space
New Feature !!
Eöt-Wash Bound ? lt 10-13
Tests for UFF
Near- future experiments in space
STEP ? 10-18 GG
? 10-17 MICROSCOPE ? 10-15
We predict
SEE Capsule
lt 10-7
?RE/RE
10-15 lt

Corrections of O(1) to Newtons Constant
9
Strong Coupling
Strong coupling not ruled out by local
experiments!
Mota and Shaw
Thin shell suppression ?
Remember
?
Effective coupling is independent of ?!!
If an object satisfies thin shell condition - the
? force is ? independent
Lab experiments are compatible with large ? -
strong coupling!
? gtgt 1 ? more likely to satisfy thin shell
condition
? Thin shell possible in space ?
suppress signal
Strong coupling is not ideal for space tests -
loophole
10
Coupling to Photons
Introduces a new mass scale
Effective potential
We can probe this term in quantum vacuum
experiments

• Use a magnetic field to disturb the vacuum
• Probe the disturbance with photons
• Expect small birefringence
• Polarisation Linear
  elliptical

11
PVLAS
(Polarizzazione del Vuoto con LASer)
To explain unexpected birefringence and dichroism
results
requires
and
(g 1/M)
Conflicts with astrophysical bounds e.g. CAST
(solar cooling)
?

But
Too heavy to produce ? CAST bounds easily
satisfied
Chameleons - naturally evade CAST bounds and
explain PVLAS
Davis, Brax, van de Bruck
12
GammeV
A. Chou, J. Steffen, A. Uphadye, A.W. and W.
Wester
Photon-dilaton-like chameleon particle
regeneration using a "particle trapped in a jar"
technique - http//gammev.fnal.gov
Idea

• Send a laser through a magnetic field

• Photons turn into chameleons via F2 coupling

• Turn of the laser

• Chameleons turn back into photons

• Observe the afterglow

Failing which - at least rule out chunks of
parameter space!
See also - Gies et. Al. Ahlers et. Al.
Alps at DESY, LIPSS at JLab, OSQAR at CERN, BMV,
PVLAS
13
GammeV
NdYAG laser at 532nm, 5ns wide pulses, power
160mJ, rep rate 20Hz
Glass window
Tevatron dipole magnet at 5T
PMT with single photon sensitivity

• Chameleon production phase photons propagating
  through a region
• of magnetic field oscillate into chameleons

• Photons travel through the glass

• Chameleons see the glass as a wall - trapped

b) Afterglow phase chameleons in chamber
gradually decay back into photons and are
detected by a PMT
14
Afterglow
B 5T, L 6M, E 2.3eV
Transition probability
Flux of photons
Integration time
Afterglow rate
Decay time vs coupling
Afterglow vs time
15
Complications

• Not longitudinal motion - chameleons and photons
  bounce
• absorption of photons by the walls
• reflections dont occur at same place

• Photon penetrates into wall by skin depth
• Chameleon bounces before it reaches the wall

Phase difference at each reflection. V dependent

• Other loss modes. Chameleon could decay to other
  fields?
• Fragmentation? ?? ? ????

• Bounds from Astrophysics and Cosmology

A.W and A. Uphadye in progress
Data Analysis is under way!
16
Conclusions/Outlook

• Chameleon fields Concrete, testable predictions

• Space tests of gravity

• Lab tests can probe a range of parameter space
  that
• is complementary to space tests (qm vacuum and
  casimir)

• Intriguing cosmological consequences chameleon

• could be causing current accelerated expansion

• Complementary tools of probing fundamental
• physics

A lot to learn from probes of the low energy
frontier using spare parts from the high energy
frontier
17
Supplementary
18
Constraints on Model Parameters

Coincides with Energy scale of Dark Energy
19
Fifth Force
5th Force
Range of interaction
Potential
Separation
Hoskins et. Al. ? lt 10-3
Strength of interaction, ?
Require both earth and atmosphere display thin
shell effect
Thin shell ?
20
Quantum Vacuum
Classical Vacuum
Quantum Vacuum

• Use a magnetic field to disturb the vacuum
• Probe the disturbance with photons

21
Birefringence
Quantum vacuum behaves like a birefringent medium

• Different index of refraction for different
  components of polarisation

Elliptically polarised light
Linearly polarised light
Vacuum region
http//www.ts.infn.it/physics/experiments/pvlas/

• Different components of polarisation vector
  travel with different velocity
• Result same amplitude but out of phase
• Polarisation Linear
  elliptical

22
Dichroism
Differential absorption of polarisation components

• One component of polarisation vector
  preferentially absorbed
• Result same phase but different amplitude
• Polarisation Rotation in polarisation plane

In vacuum

• Birefringence expected to be v. small
• No dichroism expected

PVLAS anomolous signals for both rotation and
ellipticity
New Physics?
23
PVLAS
(Polarizzazione del Vuoto con LASer)
ALP interpretation photon splits into
neutral scalar
pseudoscalar
scalar
or
Ellipticity
? Angle betw pol and B
Rotation
Extract information about m? and g and about
parity!
24
Cosmological Evolution
Davis, Brax, van de Bruck, Khoury and A.W.
What do we need?

• attractor solution

?
If field starts at min, will follow the min
?

• ? must join attractor before current epoch

?

• ? Slow rolls along the attractor

• Variation in m ? is constrained to be less than
  10.
• Constrains ?BBN ? the initial energy density
  of the field.

Weaker bound than usual quintessence
