Blazing Trails

1
Blazing Trails

• Project Proposal
• Brad Poirier, Bryce Everist, Colin Gillis, Justin
  Clifton, Shoneth MacInnis

2
Problem

• The trail system in Antigonish is poorly
  developed
• Obesity is at an all-time high and the need for
  exercise is on the rise
• Bicycles and Pedestrian interfere with traffic on
  Main Street
• There exists two trails separated by Brierly
  Brook

3
Objective

• Provide an alternate route for walkers, cyclists
  and runners
• Improve current trails and design a bridge to
  span Brierly Brook
• Enhance accessibility to Columbus Field and Main
  Street from the Mall area

4
Trails and Antigonish

• Relatively new to the town
• - Walking Trails Proposal
• (Darren G. Todd, 1999)
• Developed Trails
• - Hawthorne to Arbor Dr.
• - The Landing
• - Columbus Field

5

Hawthorne to Arbor Drive Bridge
6
Project Justification

• Aid in trail development
• - Antigonish to Pictou
• - Pathways, Cape Breton
• Economic/Town development
• - Events (4 concerts Highland Games)
• Promote Healthy Living
• GO GREEN

7
Location

• Brierly Brook Columbus Field towards Mall (Key
  Junction)

8
Types of Bridges

• Truss

9
Types of Bridges

• Suspension

10
Types of Bridges

• Arched

11
Types of Bridges

• Cable stayed

12
Materials

• Aesthetics
• It is important for the bridge to not look out of
  place
• Some materials rust or corrode

13
Materials

• Mechanics
• The structure must be suitable for the desired
  conditions
• Cost
• People want the cheapest structure that wont fail

14
Materials

• The most common types of pedestrian bridges are
• Hewn timber beams
• Glued and laminated wooden beams
• Steel
• Concrete
• Each type has its pros and cons

15
Materials

• Weathering and galvanized steel is more costly
  than regular steel but doesnt need to be painted
• Weathering and galvanized steel doesnt need the
  maintenance that regular steel does
• Each type of steel has similar yield strengths

16

17
Materials

• Concrete bridges cost more
• High compressive strength, but low tensile
  strength
• Not aesthetically pleasing

18
Materials

• Glulam beams are pound for pound stronger than
  steel beams
• Aesthetically pleasing

19

• Regular timber beams can support large short term
  loads with minimal consequences
• Price of wood is cheap but on the rise

20
Concerns/Problems

• Political
• Property Easements, Funding, Trails Act, Building
  Codes
• Accommodating for multiple uses
• Walking, running, wheelchair and stroller use,
  and cycling

21
Concerns/Problems

• Flooding
• Due to excess precipitation, surrounding areas
  become flooded
• The riverbanks are often marshy, posing a problem
  for the base of the bridge

22
Schedule
23
Schedule
24

Questions?
