CS 363 Comparative Programming Languages

1
CS 363 Comparative Programming Languages

• Names, Type Checking, and Scopes

2
Names

• User-defined names include variables, functions,
  classes, types
• Design issues for names
• Maximum length?
• Are connector characters (_,-,) allowed?
• Are names case sensitive?
• Are special words reserved words or keywords?

3
Names

• Length
• If too short, they cannot be connotative
• Language examples
• FORTRAN I maximum 6
• COBOL maximum 30
• FORTRAN 90 and ANSI C maximum 31
• Ada and Java no limit, and all are significant
• C no limit, but implementers often impose one

4
Names

• Case sensitivity
• Disadvantage readability (names that look alike
  are different)
• In C /Java because predefined names are mixed
  case (e.g. IndexOutOfBoundsException)
• C, C, and Java names are case sensitive (b and
  B are different variables)
• The names in some languages are not

5
Names

• Special words keywords, reserved words
• Ex while, for,
• An aid to readability used to delimit or
  separate statement clauses
• Def A keyword is a word that is special only in
  certain contexts
• Disadvantage poor readability, compiling
• Def A reserved word is a special word that
  cannot be used as a user-defined name

6
Variables

• A variable is an abstraction of a memory cell(s)
• Variables can be characterized as a sextuple of
  attributes
• (name, address, value, type, lifetime, and scope)
• Not all variables have names (anonymous)

7
Variables

• Address - the memory address with which a
  variable is associated
• A variable may have different addresses at
  different times during execution (variable local
  to a function)
• A variable may have different addresses at
  different places in a program (variable name used
  in multiple scopes)
• l-value of a variable (x )

8
Variables

• If two variable names can be used to access the
  same memory location, they are called aliases
• Aliases are harmful to readability (program
  readers must remember all of them)
• How aliases can be created
• Pointers, reference variables, C and C unions,
  (and through parameters - discussed in Chapter 9)
• Some of the original justifications for aliases
  are no longer valid e.g. memory reuse in FORTRAN
• Replace them with dynamic allocation

9
Variables

• Type - determines the size of memory location,
  range of values of variables and the set of
  operations that are defined for values of that
  type, precision (floating point)
• Value - the contents of the location with which
  the variable is associated
• r-value of a variable ( x )

10
Binding

• A binding is an association, such as between an
  attribute and an entity, or between an operation
  and a symbol
• Binding time is the time at which a binding takes
  place.

11
Possible Binding Times

• Language design time e.g., operator symbols to
  operations
• Language implementation time e.g., bind
  floating point type to a representation
• Compile time e.g., bind a variable to a type
• Load time e.g., bind a FORTRAN 77 variable to a
  memory cell (or a C static variable)
• Runtime e.g., bind a local variable to a memory
  cell
• Different languages make different choices about
  binding times.

12
The Concept of Binding

• Def A binding is static if it first occurs
  before run time and remains unchanged throughout
  program execution.
• Def A binding is dynamic if it first occurs
  during execution or can change during execution
  of the program.

13
Overloading

• More than one binding for a name in a given
  scope.
• All languages offer limited overloading ( for
  example)
• Subroutine names (Ada, C, Java)
  differentiated by the arguments
• Built-in Operators (Ada, C, Fortran 90)

14
Type Bindings

• How is a type specified?
• When does the binding take place?
• If static, the type may be specified by either an
  explicit or an implicit declaration

15
Types

• Def An explicit declaration is a program
  statement used for declaring the types of
  variables
• Def An implicit declaration is a default
  mechanism for specifying types of variables (the
  first appearance of the variable in the program)
• FORTRAN, PL/I, BASIC, and Perl provide implicit
  declarations
• Advantage writability
• Disadvantage reliability (less trouble with Perl)

16
Types

• Dynamic Type Binding (JavaScript and PHP)
• Specified through an assignment statement
  e.g., JavaScript
• list 2, 4.33, 6, 8
• list 17.3
• Advantage flexibility (generic program units)
• Disadvantages
• High cost (dynamic type checking and
  interpretation)
• Type error detection by the compiler is difficult

17
Types

• Type Inferencing (ML, Miranda, and Haskell)
• Rather than by assignment statement, types are
  determined from the context of the reference

18
Type Checking

• Generalize the concept of operands and operators
  to include subprograms and assignments
• Def Type checking is the activity of ensuring
  that the operands of an operator are of
  compatible types
• Def A compatible type is one that is either
  legal for the operator, or is allowed under
  language rules to be implicitly converted, by
  compiler- generated code, to a legal type. This
  automatic conversion is called a coercion.
• Def A type error is the application of an
  operator to an operand of an inappropriate type

19
Type Checking

• If all type bindings are static, nearly all type
  checking can be static
• If type bindings are dynamic, type checking must
  be dynamic
• Def A programming language is strongly typed if
  type errors are always detected

20
Strong Typing

• Advantage of strong typing allows the detection
  of the misuses of variables that result in type
  errors
• What languages are strongly typed?
• FORTRAN 77 is not parameters, EQUIVALENCE
• Pascal is not variant records
• C and C are not parameter type checking can be
  avoided unions are not type checked
• Ada is, almost (UNCHECKED CONVERSION is explicit
  loophole) (Java is similar)

21
Strong Typing

• Coercion rules strongly affect strong
  typing--they can weaken it considerably (C
  versus Ada)
• Although Java has just half the assignment
  coercions of C, its strong typing is still far
  less effective than that of Ada

22
Type Compatibility

• Our concern is primarily for structured types
• Def Name type compatibility means the two
  variables have compatible types if they are in
  either the same declaration or in declarations
  that use the same type name
• Easy to implement but highly restrictive
• Subranges of integer types are not compatible
  with integer types
• Formal parameters must be the same type as their
  corresponding actual parameters (Pascal)

23
Type Compatibility

• Def Structure type compatibility means that two
  variables have compatible types if their types
  have identical structures
• More flexible, but harder to implement

24
Type Compatibility

• Consider the problem of two structured types
• Are two record types compatible if they are
  structurally the same but use different field
  names?
• Are two array types compatible if they are the
  same except that the subscripts are different?
• (e.g. 1..10 and 0..9)
• Are two enumeration types compatible if their
  components are spelled differently?
• With structural type compatibility, you cannot
  differentiate between types of the same structure
  (e.g. different units of speed, both float)

25
Type Compatibility

• Language examples
• Pascal usually structure, but in some cases name
  is used (formal parameters)
• C structure, except for records
• Ada restricted form of name
• Derived types allow types with the same structure
  to be different
• Anonymous types are all unique, even in
• A, B array (1..10) of INTEGER

26
Variable Lifetime

• Storage Bindings Lifetime
• Allocation - getting a cell from some pool of
  available cells
• Deallocation - putting a cell back into the pool
• Def The lifetime of a variable is the time
  during which it is bound to a particular memory
  cell
• Lifetime dictated by the type of variable
  static, stack, explicit heap, implicit heap.

27
Lifetime Categories

• Static--bound to memory cells before execution
  begins and remains bound to the same memory cell
  throughout execution.
• e.g. all FORTRAN 77 variables, C static
  variables
• Advantages efficiency (direct addressing),
  history-sensitive subprogram support
• Disadvantage lack of flexibility (no recursion)

28
Lifetime Categories

• Stack-dynamic--Storage bindings are created for
  variables when their declaration statements are
  elaborated.
• If scalar, all attributes except address are
  statically bound e.g. local variables in C
  subprograms and Java methods
• Advantage allows recursion conserves storage
• Disadvantages
• Overhead of allocation and deallocation
• Subprograms cannot be history sensitive
• Inefficient references (indirect addressing)

29
Lifetime Categories

• Explicit heap-dynamic--Allocated and deallocated
  by explicit directives, specified by the
  programmer, which take effect during execution
• Referenced only through pointers or references
• e.g. dynamic objects in C (via new and delete)
• all objects in Java
• Advantage provides for dynamic storage
  management
• Disadvantage inefficient and unreliable

30
Lifetime Categories

• Implicit heap-dynamic--Allocation and
  deallocation caused by assignment statements
• e.g. all variables in APL all strings and
  arrays in Perl and JavaScript
• Advantage flexibility
• Disadvantages
• Inefficient, because all attributes are dynamic
• Loss of error detection

31
Scope

• Def The scope of a variable declaration is the
  range of program statements over which it is
  visible
• The scope rules of a language determine how
  references to names are associated with variables
• The terms scope and name space are sometimes
  used interchangably.
• Two approaches static and dynamic

32
Fortran 77 Name Space
Global
common block a
Global scope holds procedure names and common
block names. Procedures have local variables
parameters, labels and can import common blocks
common block b
f1() variables parameters labels
f2() variables parameters labels
f3() variables parameters labels
33
Scheme Name Space
Global

• All objects (built-in and user-defined) reside in
  single global namespace
• let expressions create nested lexical scopes

map
cons
var
2
f1()
f2()
let
let
let
34
C Name Space

• Global scope holds variables and functions
• No function nesting
• Block level scope introduces variables and labels
• File level scope with static variables that are
  not visible outside the file (global otherwise)

Global a,b,c,d,. . .
File scope static names w,x,y
File scope static names x,y,z
f2()
f1()
variables
variables parameters labels
f3()
variables, param
Block scope
Block Scope variables labels
Block scope
35
Java Name Space
Public Classes

• Limited global name space with only public
  classes
• Fields and methods in a public class can be
  public ? visible to classes in other packages
• Fields and methods in a class are visible to all
  classes in the same package unless declared
  private
• Class variables visible to all objects of the
  same class.

package p2
package p1
public class c1
fields f1,f2 method m1 locals method
m2 locals
package p3
class c2
fields f3 method m3
36
Scope

• Understanding scope rules of a given language
  allows us to answer the following
• Where is a given variable visible?
• What variables are visible at a given statement
  in the program?

37
Static Scope

• Based on program text
• To connect a name reference to a variable, you
  (or the compiler) must find the declaration
• Search process search declarations, first
  locally, then in increasingly larger enclosing
  scopes, until one is found for the given name
• A variable is local to a procedure if the
  declaration occurs in that procedure
• A variable is nonlocal to a procedure if it is
  visible in the procedure but not declared there

38
Scope

• Variables can be hidden from a unit by having a
  "closer" variable with the same name
• C and Ada allow access to these "hidden"
  variables
• In Ada unit.name
• In C class_namename

39
Referencing Environments

• Def The referencing environment of a statement
  is the collection of all names that are visible
  to the statement
• In a static-scoped language, it is the local
  variables plus all of the visible variables in
  all of the enclosing scopes

40
Example Pascal-like language

• Program main
• a,b,c real
• procedure sub1(a real)
• d int
• procedure sub2(c int)
• d real
• body of sub2
• procedure sub3(aint)
• body of sub3
• body of sub1
• body of main

Main
sub1
sub2
sub3
41
Example

• Program main
• a,b,c real
• procedure sub1(a real)
• d int
• procedure sub2(c int)
• d real
• body of sub2
• procedure sub3(aint)
• body of sub3
• body of sub1
• body of main

Main has local variables a,b,c, and sub1
42
Example

• Program main
• a,b,c real
• procedure sub1(a real)
• d int
• procedure sub2(c int)
• d real
• body of sub2
• procedure sub3(aint)
• body of sub3
• body of sub1
• body of main

sub1 has local variables a,d, sub2 and sub3, as
well as non-local variables b and c
43
Example

• Program main
• a,b,c real
• procedure sub1(a real)
• d int
• procedure sub2(c int)
• d real
• body of sub2
• procedure sub3(aint)
• body of sub3
• body of sub1
• body of main

sub2 has local variables c,d and non-local
variables a,b and sub1 (and potentially sub3
depending on the rules of the language)
44
Example

• Program main
• a,b,c real
• procedure sub1(a real)
• d int
• procedure sub2(c int)
• d real
• body of sub2
• procedure sub3(aint)
• body of sub3
• body of sub1
• body of main

sub3 has local variable a and non-local
variables b,c,d,sub2, and sub1
45
Static Scope

• Advantages
• Readability
• Based on program text ? can be evaluated by a
  compiler
• Constant time implementation
• Disadvantages
• Encourages global variables

46
Dynamic Scope

• Based on calling sequences of program units, not
  their textual layout (temporal versus spatial)
• References to variables are connected to
  declarations by searching the chain of subprogram
  calls (runtime stack) that forced execution to
  this point

47
Scope Example

• MAIN
• - declaration of x
• SUB1
• - declaration of x -
• ...
• call SUB2
• ...
• SUB2
• ...
• - reference to x -
• ...
• ...
• call SUB1

MAIN calls SUB1 SUB1 calls SUB2 SUB2 uses x
Which x??

48
Scope Example

• MAIN
• - declaration of x
• SUB1
• - declaration of x -
• ...
• call SUB2
• ...
• SUB2
• ...
• - reference to x -
• ...
• ...
• call SUB1

MAIN calls SUB1 SUB1 calls SUB2 SUB2 uses x
For static scoping, it is mains x

49
Scope Example

• In a dynamic-scoped language, the referencing
  environment is the local variables plus all
  visible variables in all active subprograms.
• A subprogram is active if its execution has begun
  but has not yet terminated.

50
Scope Example

• MAIN
• - declaration of x
• SUB1
• - declaration of x -
• ...
• call SUB2
• ...
• SUB2
• ...
• - reference to x -
• ...
• ...
• call SUB1

MAIN (x) SUB1 (x) SUB2
MAIN calls SUB1 SUB1 calls SUB2 SUB2 uses x
For dynamic scoping, it is sub1s x

51
Dynamic Scoping

• Evaluation of Dynamic Scoping
• Advantage convenience (easy to implement)
• Disadvantage poor readability, unbounded search
  time

52
Scope and Lifetime

• Scope and lifetime are closely related, but are
  different concepts
• Consider a static variable in a C or C function
• Lifetime entire program execution
• Scope limited to statements in the function

53
Static Scope Runtime

• Activation record keep information associated
  with each procedure call instance parameters,
  local variables, return address, return values
• Procedure call time new activation pushed onto
  runtime stack
• Procedure return time activation popped off
  runtime stack

54
Static Scope Runtime

• At runtime, we need to be able to find the
  correct instance of a variable being used.
• Additional field in activation record a pointer
  (static link) to the activation record for the
  closest instance of enclosing scope.
• Pointers form a static chain back to the main.
• Search back along these enclosing link pointers
  to find non-local variables
• Chain never gets longer than the scope depth.

55
Static links

• Program main
• a,b,c real
• procedure sub1(a real)
• d int
• procedure sub2(c int)
• d real
• body of sub2
• procedure sub3(aint)
• call sub2
• if E call sub1 else call sub3
• call sub1

Main a,b,c
56
Static links

• Program main
• a,b,c real
• procedure sub1(a real)
• d int
• procedure sub2(c int)
• d real
• body of sub2
• procedure sub3(aint)
• call sub2
• if E call sub1 else call sub3
• call sub1

Main
Main a,b,c
sub1 a,d
57
Static links

• Program main
• a,b,c real
• procedure sub1(a real)
• d int
• procedure sub2(c int)
• d real
• body of sub2
• procedure sub3(aint)
• call sub2
• if E call sub1 else call sub3
• call sub1

Main
Main a,b,c
sub1
sub1 a,d
sub1 a,d
58
Static links

• Program main
• a,b,c real
• procedure sub1(a real)
• d int
• procedure sub2(c int)
• d real
• body of sub2
• procedure sub3(aint)
• call sub2
• if E call sub1 else call sub3
• call sub1

Main
Main a,b,c
sub1
sub1
sub1 a,d
sub1 a,d
sub1 a,d
59
Static links

• Program main
• a,b,c real
• procedure sub1(a real)
• d int
• procedure sub2(c int)
• d real
• body of sub2
• procedure sub3(aint)
• call sub2
• if E call sub1 else call sub3
• call sub1

Main
Main a,b,c
sub1 a,d
sub1 a,d
sub1 a,d
sub3 a
60
Static links

• Program main
• a,b,c real
• procedure sub1(a real)
• d int
• procedure sub2(c int)
• d real
• body of sub2
• procedure sub3(aint)
• call sub2
• if E call sub1 else call sub3
• call sub1

Main
Main a,b,c
sub1 a,d
sub1
sub1
sub3 a
sub2 c,d
sub1 a,d
sub1 a,d
61
Static Scope Runtime

• Static Chain.
• Chain never gets longer than the maximum scope
  depth.
• For a given function, the compiler can compute
• the exact number of links to traverse to find the
  required instance and
• The variable offset (location) in the given
  activation record

62
Static links

• Program main
• a,b,c real
• procedure sub1(a real)
• d int
• procedure sub2(c int)
• d real
• body of sub2
• procedure sub3(aint)
• call sub2
• if E call sub1 else call sub3
• call sub1

In sub2, variable a is always 1 link back
and variable b is always 2 links back.
Main
Main a,b,c
sub1 a,d
sub1
sub1
sub3 a
sub2 c,d
sub1 a,d
sub1 a,d
