Kelly S. Davis

1
Quality Issues for Ethanol as a Fuel

• Kelly S. Davis
• director of Technical Customer services
• Hawkeye Gold, LLc
• Ames, Iowa

2
U.S. Fuel Ethanol Production
3
Fuel Ethanol Products

• For blending with
• gasoline at a 10
• maximum volume

• Alternative Fuel

E-95
4
ASTM Standards for Fuel EthanolPerformance
Specifications

• ASTM D 4806-07a Standard Specification for
  Denatured Fuel Ethanol for Blending with
  Gasoline's for use as Automotive Spark-Ignition
  Engine Fuel
• ASTM D 5798-07 Standard Specification for Fuel
  Ethanol (Ed75-Ed85) for Automotive Spark-Ignition
  Engines

5
ASTM D 4806-07a
6
ASTM D 4806-07a
7
Workmanship Free of known adulterants Denaturant
Specifications ASTM specifies what cannot be
used, example kerosene or diesel, must be TTB
approved denaturant, with ASTM D86 lt225 F and
pass copper strip corrosion test, typically
acceptable is natural gasoline, unleaded
gasoline or straight run gasoline Filtration (10
microns) Corrosion Inhibitors are added
8
California Specifications
9
Gasoline Standard D 4814 Ethanol Impacts

• Increases Octane
• Increases RVP1 psi waiver granted by EPA
• T50 decreases 10 30 F
• T V/L 20 volatility parameter decreases
• States adopt D4814 as law, recently due to
  increases RFS states had to quickly change some
  of these parameters before ASTM in order to
  accommodate E10 blending.

10
E85 is getting attention
Now that it is being used auto manufacturers
getting feedback on quality performance
parameters ASTM has formed a task force to
update the Standard Specification D 5798 Test
methods scope issues Volatility issues,
current RVP for Class 3 difficult to meet with
available hydrocarbons CRC research completed
for Class 1 and 2 and Class 3 to be determined to
address RVP issues
11
E85 ASTM D 5798
12
Higher Blends E11 and Beyond

• In 2005 State of Minnesota passed legislation
  requiring E20 by 2013
• Minnesota and RFA pushing ahead with plans to
  seek a waiver from EPA
• Clean Air Act Waiver have to be satisfied in
  order to register and make available commercial
  blends with greater than 10 ethanol content for
  non-FFVs

13
Clean Air Act Process

• Section 211(b) Health Effects Testing Tier 1
  complete and Tier 2 underway for E10. Some
  speculation this will be sufficient for E20.
• Section 211(f) Substantially Similar E20 will
  not cause or contribute to the failure of any
  vehicle or engine to meet emissions standards.
  Any waiver is nationwide. Application on public
  notice.

14
Section 211(f) Testing Requirements

• E20 waiver will need data to support three major
  areas
• Emissions evaporative, exhaust and permeation
• Includes small engines including lawn mowers,
  motorcycles, snowmobiles etc.
• Material Compatibility and Durability
• Driveability

15
Other Issues

• UL Listing of E85 Retail Pumps
• Blender Pumps have no ASTM Specifications
• International Trade of Ethanol for Fuel
• ASTM working on an International Undenatured
  Standard Specification

16
The Road Ahead

•
  Thank You
