The Bradford White

1
The Bradford White
TM
Safety System
2
Flammable Vapor Ignition Resistant Residential
Gas Products

• July 1, 2003 Conventional 30,40,50 gallon models
• July 1, 2004Power Vent 30,40,50 gallon models
• July 1, 2005All other gas products 75,000 BTUs
  and less

3
Why?

• The CPSC (Consumer Product Safety Commission)
  looked for ways to reduce injuries and deaths
  from gas fired water heaters
• June of 1994 CPSC advised the water heater
  industry it wanted a solution to the problem
• Water Heater Joint Research and Development
  Consortium was formed

4
Ignition of Flammable Vapors and Gas Water
Heaters-Standard Change

• ANSI Z21.10.1 will be amended to include testing
  for flammable vapor ignition resistance and the
  accumulation for Lint, Dust and Oil.

• Design Criteria
• Gasoline Spill Test
• Lint, Dust and Oil

5
Flame Arrestor
6
As air enters through the ScreenLokTM Flame
Arrestor, the up to 18,000 geometrically
oriented, micro-dimensioned louvers increase the
velocity of incoming air into the combustion
chamber.
Arrestor
The combination of high velocity air entering the
chamber and the vector effect caused by
combustion will prevent any flames present in the
chamber from traveling backwards through the
arrestor plate and outside of the water heater.
7
Scrubbing the Air
During normal operation, combustion air is drawn
into the water heater through openings in the
jacket.
8
Scrubbing the Air
The combustion air enters through holes in the
very bottom of the chamber.
9
Scrubbing the Air
10
Maintenance FREE!

• No Regular cleaning of air inlet openings
• or flame arrestor is required.

11
Design Features

• Resettable Thermal Switch
• Proven, reliable, bi-metallic switch will
  interrupt gas supply to the pilot and main burner.

Sealed inner door
12
Keys to Safe Operation

• Seal Integrity
• There are several screws on the inner combustion
  chamber door. When working on the heater, it is
  important the gasket be intact when reinstalling
  the door and all screws are re-installed.
• If the gasket is damaged, you must replace it
  with a new one.

13
Design Features

• Piezo Igniter
• Easy and quick lighting of the pilot burner by
  push button.

14
Design Features

• Standard Thermocouple
• Conventional off-the shelf replacement parts for
  quick service.
• Controlled Combustion System
• Added strength with lower noise. Assures
  combustion air is directed through the
  ScreenLokTM Technology flame arrestor.

15
Design Features

• Proven Burner Design
• Used for many years to allow off-the-shelf
  replacement if necessary.
• Low NOx Standard
• Efficient and clean combustion on all models and
  sizes.
• Meets or exceeds all air quality emission
  regulations.

16
Design Features

• Site Window
• Offers a view into the combustion chamber to view
  pilot and burner operation.

17
Design Features

• Advanced ScreenLokTM Technology Flame Arrestor
  Design
• Constructed of 304L stainless steel for
  outstanding impact, heat, crack and corrosion
  resistance.

Combustion air entry holes
18
Pedestal Base
19
No Added Height!

• Same compact and efficient dimensions

20
How It Affects The Trade

• No dimensional changes
• No additional installation steps required
• No water heater stand required for garage
  installations
• Minimal additional troubleshooting required
• Additional cost for heater

Local codes may still require stands
