Lesson Two

1
Indiana Water Operator Training
Lesson Two
2
Indiana Water Operator Training
Indiana Department of Environmental Management
Indiana Rural Water Association
American Water Works Association
3
Lesson Two DSS Operators

• DSS systems and operators
• Pressure tanks
• Storage tanks
• Cross connection control
• Coliform and nitrate monitoring
• Lead and copper monitoring
• Chemical contaminant monitoring

4
Classification of water distribution systems and
water treatment plants
Distribution systems
DSSClass DSS (distribution system small)
includes systems that (A) serve a population of
less than three thousand three hundred one
(3,301) and (B) have no components other
than (i) pressure tanks or (ii) storage tanks
5
Classification of water system operators
Water operator certification qualifications
DSS Grade DSS is a certified operator qualified
to operate a Class DSS water distribution system
after having fulfilled the following requirements
(A) Possess a high school diploma or its
equivalent (B) Meet the qualifications of the
certification rule (C) Attain a minimum of one
(1) year of acceptable work experience in
the operation of a Class DSS water distribution
system
6
Pressure tanks Types
Standard galvanized pressure tank
Type oneIncrease in waterheight compressesair
in tank
Type twoAir compressoradds pressure to tank
High absorption of air and gases
7
Pressure tanks Types
Precharged pressure tank
Rigid float
Air compressorneeded to rechargea few times
per year
Increase in waterheight compressesair in tank
Much lower absorption of air and gases
8
Pressure tanks Types
Sealed diaphragm pressure tank
Increase in waterheight compressesair in tank
Sealed bladderexpands and contractsas water
volumechanges
Eliminates absorption of air and gases
9
Pressure tank Sizing
Size tank to avoid excessive cycling of pump

• Figure 10 Gallons per 1 GPM of pump capacity
• Examples
• If well pumps 20 GPM, then tank 200 gallons(10
  x 20 200)
• If well pumps 30 GPM, then tank 300 gallons(10
  x 30 300)

10
Pressure tanks Multiple tanks
From pump
To system
11
Storage tanksGround level
Top of hill
Tank
Good Village, Indiana
12
Storage tanksFiguring pressure
Tank
1 foot of head .4333 pounds pressure2.31
feet 1 pound pressure
100 feet high
100 x .4333 43.33 pounds per square inch (PSI)
13
Storage tanksElevated
Good Village, Indiana
Legged tank
Standpipe
14
Storage tanksComponents
Vent
Tank
Overflow pipe
Altitudevalve
15
Storage tanksFiguring pressure
Tank
100 feet high
141 feet total height
Hill
41 feet high
141 x .4333 61 PSI
16
Cross connection control

• A cross connection is any actual or potential
  connection between a public water supply and a
  source of contamination or pollution
• Examples
• Factories
• Hospitals
• Cooling water tanks
• Mortuaries
• Lawn irrigation systems
• Fire suppression systems
• Mop sinks

17
Cross connection control Backflow
Top of Hill
Water main
Bottom of hill
18
Cross connection control Air gap
2 timespipediameterair gap1 minimum
Coolingwater orotherprocesstank
Public water supply
19
Coliform and Nitrate monitoring Coliform
Population Served Minimum Number of Samples
Monthly 25 to 1,000 1 1,001 to
2,500 2 2,501 to 3,300 3 3,301 to 4,100
4 4,101 to 4,900 5 4,901 to 5,800 6
20
Coliform and Nitrate monitoring Coliform

• If any routine sample is unsatisfactory
  (positive),
• repeat samples must be taken within 24 hours of
  notification
• Normal samples per month Number of repeat
  samples
• 1 at least 4
• 2 or more at least 3
• 1 sample from location that produced positive
• 1 sample within 5 connections upstream
• 1 sample within 5 connections downstream
• 4th sample (if required) anywhere else from system

21
Coliform and Nitrate monitoring Coliform
If any repeat sample is positive,you must issue
a public notification for MCL violation Tier 1
(immediate)
22
Coliform and Nitrate monitoring Coliform
All public water systems are required to collect
5 distribution samples the month after any
unsatisfactory total Coliform sample Example 1
sample in May OK 1 sample in June Positive 4
more samples in June All OK 5 samples in
July All OK 1 sample in August OK
23
Coliform and Nitrate monitoring Nitrate

• Monitoring for Nitrate by community public water
  supplies is based upon water source (ground or
  surface) and the levels of Nitrate that have been
  previously detected in the system's water
• Samples are obtained from the first place water
  can be drawn after any treatment, or the tap
  closest to the well if there is not any treatment

24
Coliform and Nitrate monitoring Nitrate

• MCL is 10 mg/l
• If 10 20 mg/l, children 6 months and
  youngermay not drink the water
• continuous public posting with health
  warningsmust be made
• If gt 20 mg/l, system must remediate the
  contamination

25
Coliform and Nitrate monitoring Nitrate
Appendix B 1
26
Lead and Copper monitoring

• Monitoring required for
• Community systems
• Nontransient noncommunity systems

27
Lead and Copper monitoring Lead

• Drinking water corrodes lead-containingplumbing
  materials
• Faucets
• Solder
• Short-term health effects include interference
  with red
• blood cell chemistry, delays in normal physical
  and mental
• development in babies and young children,
  deficits inattention span, hearing, and learning
  abilities of children
• and slight increases in the blood pressure of
  some adultsLong-term exposure can cause stroke,
• kidney disease, and cancer

28
Lead and Copper monitoring Copper

• Drinking water corrodes copper-containingplumbing
  materials
• Pipes
• Valves
• Copper is a nutrient that is metabolized
• by the body
• Copper can cause the following
• Health effects stomach and intestinal distress,
  liver andkidney damage, and anemia. Persons with
  WilsonsDisease may be more sensitive than
  others tothe effects of copper contamination

29
Lead and Copper monitoring Action levels
An action level is is a level, when the water is
sampled,that ninety percent (90) of samples
must be below Action level for lead (Pb) is
0.015 mg/L Action level for copper (Cu) is 1.3
mg/L
30
Lead and Copper monitoring Sampling

• Collected at kitchen or bath cold water tap in
  homes
• Collected at drinking water taps in businesses
• Water must have been in contact with plumbingfor
  at least 6 hours (first draw)
• Initially, samples are collected for 2
  consecutive six-monthmonitoring periods (January
  to June and July to December)
• Sampling is reduced to once per year for 3 years
• Then once every 3 years

31
Lead and Copper monitoring Sampling
32
Lead and Copper monitoring If action level
exceeded

• Contact DWB immediately
• Water quality testing will be required
• Install treatment to reduce the corrosivity of
  the water
• Public education (lead)

33
Chemical contaminant monitoring

• Monitoring required for
• Community systems
• Nontransient noncommunity systems

34
Chemical contaminant monitoring

• Inorganic chemicals (IOCs)
• naturally occurring contaminants
• Volatile organic compounds (VOCs)
• industrial solvents
• Synthetic organic compounds (SOCs)
• pesticides and herbicides
• Contact DWB for the required monitoringschedule
  for your system

35
Chemical contaminant monitoring Waivers

• DWB may grant a public water system a
  chemicalmonitoring waiver if the system meets
  establishedcriteria for source type,
  nondetection, vulnerability,population, and use
  of contaminants in the area
• Use waiver for VOCs and SOCs
• Use waiver for Asbestos
• Statewide waiver for PCBs and Dioxin
• Susceptibility waiver for Glyphosate and Cyanide

36
Distribution system chlorine
If your system chlorinates

• free chlorine residual at all points in the water
  system
• of at least .25 mg/l and no less than 1 mg/l
  total
• chlorine throughout the system
• If .25 mg/l free chlorine cannot be obtained
  withoutgoing a lot over 1 mg/l total chlorine,
  say gt 2 mg/l,look into possible problems such as
  iron bacteria,ammonia or other organics.

37
Ok, there is a light at the end of the
tunnel. Were about done. Are there any
questions?
38
Lesson Two DSS Operators
Self Graded Examination
39
Lesson Two DSS Operators
Self Graded Examination
10 Minutes
40
Lesson Two DSS Operators
Self Graded Examination
5 Minutes
41
Lesson Two DSS Operators
Self Graded Examination
Times Up
OK
42
Lesson Two DSS Operators
Answers
X
Population Served Minimum Number of Samples
Monthly 25 to 1,000 1 1,001 to
2,500 2 2,501 to 3,300 3 3,301 to 4,100
4 4,101 to 4,900 5 4,901 to 5,800 6
43
Lesson Two DSS Operators
Answers
X
1 foot of head .4333 pounds pressure2.31
feet 1 pound pressure
Tank
100 feet high
100 x .4333 43.33 pounds per square inch (PSI)
44
Lesson Two DSS Operators
Answers
X
Size tank to avoid excessive cycling of pump

• Figure 10 Gallons per 1 GPM of pump capacity
• Examples
• If well pumps 20 GPM, then tank 200 gallons
• (10 x 20 200)
• If well pumps 30 GPM, then tank 300 gallons(10
  x 30 300)

45
Lesson Two DSS Operators
Answers
X

• A cross connection is any actual or potential
  connection between a public water supply and a
  source of contamination or pollution
• Examples
• Factories
• Hospitals
• Cooling water tanks

46
Lesson Two DSS Operators
Answers
X
An action level is is a level, when the water is
sampled,that ninety percent (90) of samples
must be below Action level for lead (Pb) is
0.015 mg/L Action level for copper (Cu) is 1.3
mg/L
47
Lesson Two DSS Operators
Answers
X
Lead and copper monitoring Sampling

• Water must have been in contact with plumbing for
  atleast 6 hours (first draw)

48
Lesson Two DSS Operators
Answers
X
If any routine sample is unsatisfactory
(positive), repeat samples must be taken within
24 hours of notification
49
Lesson Two DSS Operators
Answers
X
50
Lesson Two DSS Operators
Answers
X

• Inorganic chemicals (IOCs) naturally occurring
  contaminants
• Volatile organic compounds (VOCs) industrial
  solvents
• Synthetic organic compounds (SOCs) pesticides and
  herbicides

51
Lesson Two DSS Operators
Answers
X

• DWB may grant a public water system a chemical
  monitoring waiver if the system meets established
  criteria for source type, nondetection,
  vulnerability, population, and use of
  contaminants in the area
• Use waiver for VOCs and SOCs
• Use waiver for Asbestos
• Statewide waiver for PCBs and Dioxin
• Susceptibility waiver for Glyphosate and Cyanide

52
Thank you for your participation

• Are there any other questions or comments?
• Please turn in your
• Self-graded examinations
• Training course evaluation forms
• Continuing education credit reports

53
Indiana Water Operator Training
Indiana Department of Environmental Management
Indiana Rural Water Association
American Water Works Association
54
Contact Information
Instructor For additional information
concerning this water operatortraining course,
please contact Indiana Rural Water
Association Odetta Cadwell, Executive
Director 317-402-7349
