Point-to-Point Protocols and Links

1
Chapter 2

• Point-to-Point Protocols and Links

2
Section 2.1

• Introduction

3
2.1 Introduction

• Physical communication links
• Data link control
• i.e. point-to-point protocols
• Physical links requires background in
• Linear system theory
• Random process
• Modern communication theory
• Recall
• Chapter 1 section 1.3.1 page 34

4
Introduction
5
Introduction

• Our major problem in DLC correct bit error
• Error detection correction
• ARQ ( Automatic Repeat request)
• Header packet trailer gt frame

6
Section 2.2

• Physical layer
• Channels modems

7
2.2 Physical layerchannels modems

• Skip,will be discussed if necessary

8
Section 2.3

• Error Detection

9
2.3 Error Detection

• DLC layer is to provide error-free packets to
  next layer up

10
2.3.1 Single Parity checks

• Parity checks bit is the sum, modulo 2 , of the
  bits in the original bit string
• Total number of 1s in an encoded string is
  always even
• Detect single bit error only.And , odd number of
  bit errors

11
2.3.2 Horizontal Vertical Parity Checks
12
Horizontal Vertical Parity Checks

• Common use for ASCII encoded characters
• Cannot detect four errors confined to 2 rows and
  2 columns

13
2.3.3 Parity Check Codes
14
Parity Check Codes

• Effectiveness of a code for error detection
• Minimum distance of the code
• Single parity check is 2
• Horizontal Vertical is 4
• Burst-detecting capability
• Single parity is 1
• Horizontal Vertical is 1length of row
• Probability that a completely random string will
  be accepted as error-free

15
(No Transcript)
16
Parity Check Codes

• E.g.
• Minimum distance
• Single parity check is 2
• Horizontal Vertical is 4
• Burst-detecting
• Single parity check is 1
• Horizontal Vertical is 1 length of row

17
Parity Check Codes
18
Figure 2.15
19
2.3.4 Cyclic Redundancy Checks(CRC)
20
Cyclic Redundancy Checks(CRC)
21
Cyclic Redundancy Checks(CRC)
L3 S(D)D21
22
Cyclic Redundancy Checks(CRC)
23
Cyclic Redundancy Checks(CRC)
24
Cyclic Redundancy Checks(CRC)
25
Cyclic Redundancy Checks(CRC)
26
Cyclic Redundancy Checks(CRC)
27
Cyclic Redundancy Checks(CRC)
28
Cyclic Redundancy Checks(CRC)
29
Cyclic Redundancy Checks(CRC)
30
Section 2.4

• ARQ Retransmission Strategies

31
2.4 ARQRetransmission Strategies

• 2 aspects of retx algorithms or protocols
• Succeed in releasing each packet,one oad only
  once without errors
• Efficiency releasing unnecessary waiting
  unnecessary retx

32
ARQRetransmission Strategies

• We assume , all frames containing transmission
  errors are detected
• Delay is arbitrary
• Frame may be lost never arrive
• Frames arrive in the same order as transmitted

33
ARQRetransmission Strategies
34
2.4.1 Stop-and-wait ARQ

• Each packet has been received correctly before
  initiating tx of next packet
• If
• Error free
• Acknowledge , Ack
• Error frame
• Negative acknowledgement , NAK
• Ack NAK is protect with a CRC
• Ack lost or NAK
• Resend the old packet

35
Stop-and-wait ARQ
36
Stop-and-wait ARQ
37
Stop-and-wait ARQ

• Avoid this problem,returns the number of next
  packet awaited
• Piggyback

38
Stop-and-wait ARQ
39
Fig 2.21
40
Stop-and-wait ARQ

• The algorithm for A to B
• At node A
• SN?0
• Assign SN to the new packet
• Tx SN-th frame
• If receive from B with B RNgtSN,SN?RN,go to Step2
• If no received frame from B,timeout , go to Step
  3

41
Stop-and-wait ARQ

• Continued
• At node B
• RN?0,repeat step2 3 forever
• If error-free frame received with SNRN,RN
• Within bounded delay after receiving error-free
  frame send a frame to A containing RN

42
Stop-and-wait ARQ

• Correctness of stop-and-wait
• An algorithm is safe if it never produces an
  incorrect result
• An algorithm is live if it can continue forever
  to produce results
• Safety
• Initially, node B awaiting packet 0 , and only
  packet 0 is released.Subsequently,node B has
  released all packets in order,up to , but not
  including ,packet RN

43
Stop-and-wait ARQ
44
Stop-and-wait ARQ
45
Stop-and-wait ARQ
46
Stop-and-wait ARQ
47
Stop-and-wait ARQ

• One trouble with Stop-and-wait
• SN become arbitrarily large with increasing time
• Given our assumption that frames travel in order
  on the link,SN modulus 2 is sufficient!

48
Stop-and-wait ARQ
49
2.4.2 Go Back n ARQ

• Several successive packets can be sent without
  waiting for the next packet to be requested
• Accept packets only in the correct order , and
  send RN back
• RN is to acknowledge all packets prior to RN and
  to request packet RN

50
Go Back n ARQ
51
Go Back n ARQ
52
Go Back n ARQ
53
Go Back n ARQ
54
Go Back n ARQ
55
Go Back n ARQ

• Go back n algorithm
• At node A
• SNmin ?0,SNmax?0 (SNmin to SNmax-1)
• Do steps 3,4,5 repeatedly in any order
• If SNmaxltSNminn and a packet is available,assign
  SNmax to it increment SNmax
• If an error-free frame is received from B
  containing RNgtSNmin,increase SNmin to RN
• If SNminltSNmax,and no frame is currently in
  transmission,choose some number SN,SNmin
  ltSNltSNmaxtransmit SN-th frame. At most a
  bounded delay is allowed between successive
  transmission of packet SNmin over intervals when
  SNmin does not change

56
Go Back n ARQ

• Go back n algorithm
• At node B
• RN?0,repeat steps 23 forever
• When an error-free frame is received from A
  containing SNRN,increment RN
• At arbitrary times,but within bounded delay after
  receiving any error-free data frame from
  A,transmit a frame to A containing RN

57
Go Back n ARQ

• Safety
• Same as stop-and-wait
• Liveness
• t1ltt3 ,t2ltt3

58
Go Back n ARQ
59
Go Back n ARQ
60
Go Back n ARQ

• t2 could be ltt1(why? P.77)
• It t1ltt2 ,then RN(t)i for t1 ? t ? t2?
• packet i after t1 will be accepted and since
  t2ltt3 , node A will retx packet i until this
  happened
• ?t1 to t2 is finite
• No matter t1ltt2 or t1gtt2
• Node B transmit frames carrying RN ? i1 from
  time t2 until t3 since ggt0, t2 to t3 is
  finite?live!

61
Go Back n ARQ with modulo mgtn
62
Go Back n ARQ with modulo mgtn
63
Go Back n ARQ with modulo mgtn
64
2.4.3 Selective Repeat ARQ

• Even if unnecessary retx are avoided,go back n
  protocol must re-tx at least one round-trip-delay
  when a single error occurs in an awaited packet
• Idea of selective repeat ARQ is to accept out
  -of-order packet,and to request retx from A only
  for those packets that are not correctly received

65
Selective Repeat ARQ

• RN lowest number packet not yet correctly
  received
• N window size
• Let p is probability of frame error,the expected
  number ? of packets delivered to B per frame
• ? ? 1-p ? throughput of ideal
  selective repeat

66
Ideal go back n ARQ

• r ( 1-p ) p( 1 ? ? )
• r ????Frames???next awaited frame
• ( 1-p ) ?????
• p ??

67
Selective Repeat ARQ modulo m?2n

• B accept RNRNn-1
• Feedback also contains which packets beyond RN
  have been correctly received
• Accepted out -of-order packets are saved until
  earlier packets are accepted released

68
Selective Repeat ARQ modulo m?2n

• t1 frame was first generated at node A at time
  t1
• t2 frame is received at node B
• RN(t2)-n?SN?RN(t2)n-1
• If mod m ,and if packets are accepted in the
  range RN(t2)RN(t2)n-1
• ?it is necessary for B to distinguish values of
  SN in the entire range?m?2n

69
2.4.4 ARPANET ARQ

• Using 8 stop-and-wait strategies in parallel
• Each incoming packet is assigned to one of eight
  virtual channels if one of eight is idle
• If all channels are busy,wait

70
ARPANET ARQ
71
ARPANET ARQ

• More overhead is required
• Sequence number modulo 2
• Each frame carries information for all 8 virtual
  channels
• ?ack information is repeated so often
• (Typically,only one retx is required in forward
  direction)
• Undesirable packets released at receiver in a
  different order

72
Section 2.5

• Framing

73
2.5 Framing

• Decide where successive frames start and stop
• Character-based framing use special control
  characters for idle fill and to indicate frame
  beginning and ending
• Bit-oriented framing with flagsuse special bit
  string(flag)
• Length countsin a field of the header

74
2.5.1 Character-Based Framing

• SYN(synchronous idle) provides idle fill b/w
  frames
• STX(start of txt)
• ETX(end of text)

75
Character-Based Framing
76
Character-Based Framing

• If the packet to be transmitted in an arbitrary
  binary string,?packet might contain ETX character
  ,for example ?trouble!
• ?transparent modeDLE character is inserted
  before STX (Data Link Escape)
• DLE in dataDLE DLE ?DLE
• E.g. (x)DLE ETX ? end of frame
• (x)DLE DLE ETX ? DLE ETX ? Data

77
Character-Based Framing
78
Character-Based Framing

• Disadvantages
• Excessive use of framing overhead
• Each frame must consist of an integer number of
  characters
• What happens if error?
• Error in DLE ETX ending a frame won't detect
  end of frame
• Error in data causes DLE ETX interpret as end of
  frame
• Probability 2-L CRC undetected

79
2.5.2 Bit-Oriented Framing Flags

• Another approach use a flag at the end of frame
• Bit stuffing is used to avoid confusing b/w data
  ad flag
• Difference b/w bit-oriented character-based
  framingbit-oriented can have any length of bits
• For example 0160 as a flag to indicate frame
  ending
• Rule insert (stuff) a 0 into data string of the
  frame proper after each successive 5 1s

80
Bit-Oriented Framing Flags
81
Bit-Oriented Framing Flags

• After stuffing never contains more than 5
  consecutive 1s.If a string of 5 1s is followed
  by a 1 ?frame end
• 016 frame end
• 016 0 normal frame termination
• 016 1 abnormal termination ? abort

82
Bit-Oriented Framing Flags

• ??(fig 2.36)
• The first stuffed bit not necessary(????,??just
  start)
• Second stuffed bit necessary
• Third stuffed bit could be eliminated
• Fourth stuffed bit required(????0??stuffed)
• ?by modifying stuffing rule, but the reduction
  of overhead is negligible

83
Bit-Oriented Framing Flags

• Consider the overhead
• Assume a frame(before bit stuffing) consists of i
  id random binary variables with equal probability
  0 or 1
• Assume for increased generality that the flag
  uses 01j for some j
• 01j0 normal termination
• 01j1 abnormal

84
Bit-Oriented Framing Flags

• An insertion will occur at the i-th bit of the
  original frame (for i ? j)
• if the string from i-j1 to I is 01j-1
• ?probability 2-j
• An insertion will also occur (for i ? 2j-1)
• if string from i-2j2 to i is 012j-2(01j-11j-1)
• ?probability 2-2j1 (ignore this term,??)

85
Bit-Oriented Framing Flags

• Bit j-1 occur an insertion if the first j-1 bits
  are all 1s
• ? probability 2-j1
• Recall
• Expected value of a sum of r.vs
• Expected number f insertions in a frame
• ?for k(original frame length) ? j-1
• Expected number of insertions
• 2-j1 (k-j1)2-j (k-j3)2-j

86
Bit-Oriented Framing Flags

• Eoverhead (Ek-j3)2-jj1(2.33)
• j1 means termination string
• Since Ekgtgtj
• ?Eoverhead ? Ek2-jj1(2.34)

87
Bit-Oriented Framing Flags

• Minimize(2.34) for a given Ek?find optimal j
• So, optimal j must
• Ek2-jj1 lt Ek2-j-1j2
• Ek2-j-1 lt1
• smallest j j ?log2Ek? (2.36)
• Eoverhead ? log2Ek 2 (2.37)
• For example
• if Ek 1000 bits , optimal j 9
• Eoverhead ? 12 bits
• for j 6 , Eoverhead ? 23 bits

88
2.5.3 Length Fields

• Basic problem in framing
• Determine where each idle fill string
  ends(trivial, when pattern is broken) where each
  frame endsharder
• Include a length field in the frame header(e.g.
  DECNET) length field(overhead) must have at least
  ? log2Kmax? 1 bits where Kmax is maximum frame
  size
• Compared to 2.37?similar overhead
• Question
• Any other method requires smaller overhead

89
Bit-Oriented Framing Flags

• Information theory
• By source coding theorem
• Given any probability assignment P(K) on frame
  lengths.Minimum expected number of bits that can
  encode such a length is at least entropy of that
  distribution
• (2.38)
• at least this many bits of framing overhead to
  specify length

90
(No Transcript)
91
(No Transcript)
92
Bit-Oriented Framing Flags

• If uniform P(K) 1/Kmax for 1 ? K ? Kmax
• H log2Kmax
• If geometric distance on lengths
• H log2EKlog2e for large EK(2.37)-1/2
• Note geometric have largest entropy.
  i.e.requires more bits than any other distance

93
Bit-Oriented Framing Flags

• If one does this for a geometric distance
  ?unary-binary encoding
• In particular , for a given j , K i2jr0?rlt2j
• Encoding for K i?0s followed by a 1 (unary
  encoding of i) followed by ordinary binary
  encoding of r (j bits)
• For example if j2 , k7 ? i1,r3
• so, K 01 11

94
Bit-Oriented Framing Flags

• End of encoding occurring j bits after the
  first 1 .
• In general
• K ?(maps) bit string of length ?K/2j? 1j
• Eoverhead ? EK2-j1j (2.40)
• ?(2.34)??
• Again , minimize by choosing j ? log2EK?

95
2.5.4 Framing with Errors

• Error in the flag ? will not detect frame-end
  until next flag is detected CRC check with 2
  frames (undetected probability 2-L)
• Error within the frame to change a bit string
  into the flag 0160
• 0100110111001(sent)
• 0100111111001(received)
• Probability ? 1/32 Kp , where p is bit error
  probability using CRC, undetected probability
  2-L

96
Framing with Errors

• If length field has error ? causes receiver to
  look for CRC in wrong place ? 2-L

97
Framing with Errors

• There are several partial solutions to the above
  problems , but none are without disadvantages
• Using a fixed-length header for each frame , and
  put length of frame in header , and header has
  its own CRC
• If error in length field , still got CRC. But
  have to resynchronize after such an error. ??will
  not know when next frame starts. 2 CRCs must be
  used ? inefficient some what!

98
Framing with Errors

• Put length field of one frame into trailer of the
  preceding frame
• Avoid inefficiency , but still requires a special
  synchronizing sequence after each detected error
• Require a special header whenever length of next
  frame is unknown
• Use a longer CRC
• Reduce probability of falsely accepting a frame

99
Framing with Errors

• Regard framing as being at a higher layer than
  ARQ
• Packets would be separated by flags
• Resulting sequence of packets flags would be
  divided into fixed-length frames. ( If a packet
  ended in middle of a frame ? idle fill)
• Because of fixed-length , CRC would always be
  found
• Disadvantage delay
• A packet could not be accepted until entire frame
  containing end of packet was accepted

100
2.5.5 Maximum Frame(packet) Size

• Variable packet lengths
• Most existing packet networks
• Use very short frames with a fixed length
• ISDN,ATM53bytes

101
Maximum Frame(packet) Size

• Variable frame length
• Fixed number V of overhead bits
• Let Kmax maximum length of a packet
• Assume each message is broken up into as many
  maximum-length packets as possible with last
  packet containing what is left over
• message of length M ? ?M/Kmax? packets
• Total bits transmitted M ?M/Kmax? V

102
Maximum Frame(packet) Size

• Kmax????
• As Kmax ?, ?
• fraction overhead?
• Processing on a frame basis
• Kmax ? , processing ?

103
Maximum Frame(packet) Size

• Kmax????
• Pipeline
• Assume a packet must be completely received over
  one link before starting transmission over the
  next
• If message is broken into several packets ,
  earlier packets may proceed along the path on
  first link ? reducing overall message delay

104
Maximum Frame(packet) Size
105
Maximum Frame(packet) Size(pipeline contd)

• Let's consider combined effects of overheads
  pipelining
• Assume message transmitted over j equal-capacity
  links and that network is lightly loaded(no
  waiting packets) and ignore propagation delay
• Total time T required to transmit message to
  destination
• T time for first packet to travel over the
  first j-1 links time for entire message to
  travel over the final link

106
Maximum Frame(packet) Size (pipeline contd)

• Assume M?Kmax
• Let C be capacity of each link
• TC number of bit transmission times (Kmax
  V)(j-1) M ?M/Kmax? V
• Approximate E?M/Kmax? EM/Kmax1/2
• ETC ? (KmaxV)(j-1)EMEMV/Kmax V/2

107
Maximum Frame(packet) Size (pipeline contd)

• to minimize ETC
• so, Kmax ?
• An overhead V ? , Kmax ?
• As path length j ? , Kmax ?
• In practice , see if delay is important

108
Maximum Frame(packet) Size (pipeline contd)

• Delay for stream-type traffic(such as voice)
• delay from when a given bit enters the network
  until that bit leaves
• Consider the light leading case
• Assume arrival rate R
• Packet length K
• The first bit in a packet is held up for K/R
  waiting time for packet to be assembled
• Along the path , link capacities C1,C2(gtR)
• A given packet is delayed by (KV)/Ci on i-th
  link

109
Maximum Frame(packet) Size (pipeline contd)

• Total delay
• (KV)/Ci ? K/Ri for each link i
• T? as K? until (KV)/Ci K/R for some link
  yields minimum delay (i.e. small K)
• Under heavy-loading
• Use long packets by some users increases delay
  for all users

110
Maximum Frame(packet) Size

• Retransmission
• increase waiting time
• small maximum packet size
• Large frame have higher probability of error than
  small frames
• In WAN , frame size ?order of 1 a few K bits
• In LAN , much longer frame size , ??single multi
  access link

111
Maximum Frame(packet) Size

• Fixed frame length
• Determine end of frame ?same
• Optimal packet length ? smaller

112
Homework One

• 2.15
• 2.16
• 2.17
• 2.30
• 2.33
• 2.39
• ???

113
Section 2.8

• Point-to-Point Protocols
• at Network Layer

114

• Major issues
• Routing
• Flow control
• Here, smaller issue
• Transfer of packets between a pair of nodes
• Distinguish packets of one session from another
• Distinguish packets within same session.

115
2.8.1 Session ID addressing

• Brute-force approach source destination ID
  allows different packets of same paths ? But
  considerable overhead
• If uses virtual circuit(VC) ?far less overhead
• Each link shared by a set of virtual channels
• When set up, a path is established,use one unused
  virtual channel to that session.

116
Virtual Channel
117
Session ID addressing

• Headervirtual channel
• ?because limited capacity of link.
• so upper bound on of sessions
• ?use a fixed of bits(overhead)

118
Session ID in TRMNET 1970
119
Session ID addressing

• Note data from multiple sessions are included in
  a single frame
• Go back n ARQ with modulo m8
• Virtual channel identify session
• ?statistical multiplexing link is multiplexed
  between virtual channels
• Sessions are served in round-robin
• Each frame takes some chars from each session

120
Session ID in codex networks

• Again, multiple sessions transmitting chars
  within the same frame
• But, a more efficient encoding is used to
  represent VC
• Four bit nibbles

121
Figure 2.49
122
Figure 2.49

• Map char into one nibble(highly probable)
• Map char into two nibble(less likely)
• Map char into three nibble(least likely)
• Packet header1 nibble for start record
• 1 or more nibble for
  session
• -under heavy loadingheader 1byte

123
2.8.2 packet numbering, Window Flow Control,Error
Recovery

• Reorder or re-tx packets?need packet numbering
  can be done in Network or Transport Layer
• This is necessary, because
• at DLC Layer
• 1. CRC could fail
• 2. If link fail, DLC dont know how many packets
  was sent
• 3. If node fail, packets stored at the node are
  lost

124
Error Recovery(at Network or Transport Layer)

• Similar to ARQ at DLC Layer
• Each packet within a session is numbered modulo
  m2k
• Different between end-to-end and DLC
• 1. End-to-end involves 2 sites and subnet in
  between
• DLC2 nodes with a link in between
• 2. Sequence numbering for end-to-end error
  recovery involves only packets of a given
  sessions.
• DLCall packets using the link
• 3. frame stay in order on a link, packets might
  arrive out of order in a network.

125
Error Recovery

• NoteVC would guarantee in order for same
  session,
• but,link fails?a new path is set up.
• Last packet on old path might arrive out of
  order,relative to first packet on new path.
• Packet retx, and arbitrary delay?earlier copy can
  remain in network until packet numbering wraps
  around?trouble.

126
Error Recovery

• 1. insist use virtual circuits
• 2. Modulus large enough
• 3. Packets are destroyed after lifetime.

127
Flow Control

• Use of either go back n or selective repeat
  ARQ,also provide flow controlwindow sizen
• Some limitation
• 1. If ACK not arrive because of error, packet
  should be re-tx.
• If ACK is delayed due to congestion, packet
  should not be re-tx.
• ?difficult to set time-out

128
Flow Control

• Partial solution(at destination)
• 1. Slow down the source, but not delay ACK.
• 2. permittells source how many packets is
  prepared to receive.
• RNprovide ACK

129
DiscussionError recovery at transport vs network
layer

• From practical standpoint, belongs to transport
  layer.
• Large of networks do not provide reliable
  service
• E.g. internet protocol
• Disadvantage for error recovery at transport
• ACK are slow due to congestion
• ACK was throw away
• ?no way to distinguish

130
DiscussionError recovery at transport vs network
layer

• When congestion ,
• Packet retx?greater congestion
• More dropped packets?unstable

131
2.8.3 X.25(self-reading)
132
2.8.4 The Internet Protocol(IP)

• 2 transport layer protocols were developed along
  with IP
• TCP(transmission control protocol)reliable VC
  service
• UPP(user datagram protocol)simply where to sent
  datagram to destination

133
2.8.4 The Internet Protocol(IP)

• Primary functions of IP
• 1.route datagram through internet
• 2.provide addressing to identify source
  destination
• 3.fragment datagram into smaller pieces
• Addresses in IP32 bits
• 1.class A(0)7 bit network ID, 24 bit host ID
• 2.class B(10)14 bit network ID,16 bit host ID
• 3.class C(11)22 bit network ID,8 bit host ID

134
2.9 Transport Layer

• Functions
• 1. Breaking message into packets
• 2. error recovery
• 3. flow control
• 4. Multiplexing / Demultiplexing sessions
  together

135
2.9.2

• In ICP, entire address of a source(or
  destination)is called a socket.
• (Network ID, host ID?in IP header, user/process
  ID within that node?port?in transport header)
• All session between same pair of hosts are
  multiplexed together at transport layer into a
  common lower-layer session

136
2.9.3 Error recovery in TCP

• Enlarge modulus to allow out-of-order packet
  arrivals.
• Some complications
• 1. retx timeouts (retx due to congestion,)
• (if done at network layer, better estimate delay)

137
2.9.3 Error recovery in TCP

• 2. Setting up tearing down connection
• Packet from an old connection entering a new
  connection
• Packet still exist at some nodes after loss of
  connection

138
2.9.4 Flow control in TCP/IP

• Source monitor round-trip delay
• Provide measure of congestion
• Unfair
• good citizen session cut back under congestion,
• bad citizen do not cut back
• ?network resources should be shared fairly, need
  to have individual control over session.
• But, network layer does not know session.

139
2.10.1 ATM(Asynchronous Transfer Mode)

• Cell 53 bytes 485(header)
• Because packetization delay of voice
• E.g. 64 kbps voice(by 8 bit sample each 125
  ?sec), time to collect 48 bytes6 ms.
• ATM uses VC
• Address
• (user-network interface) 24 bits?16 million
  sessions
• (Internal subnet )28 bits ?268 million.

140
2.10.1 ATM(Asynchronous Transfer Mode)

• Address field is divided into 2 subfield
• VCI(Virtual channel identifier)
• VPI(Virtual path identifier)
• ?sessions sharing same path are assigned same VPI
  to be switched together

141
2.10.1 ATM(Asynchronous Transfer Mode)

• Use CRC to correct errors(not just detect)
• Bit error rate(fiber)lt10-9
• Single error correction might remove most
  errors(note CRC checks only header)
• Why?(voice,videos, tx)
• Neither ARQ nor framing is required
• Bit error rate is quite low
• Voice, video.

142
2.10.2 Adaptation layer

• Breaking incoming source data into ATM
  cells.(network layer)
• Used only on entry exit from the
  network(transport layer)
• Not yet well-defined
• Different types of input
• Class 1CBR64 kbps voice
• Class 2VBRpacketized voice or video
• Class 3connection-oriented data
• Class 4connectionless datadatagram

143
2.10.2 Adaptation layer

• Class 3(connection-oriented) traffic
• Split into 2 sublayer
• Convergence segmentation/reassembly
• ?flow control error recovery

144
2.10.2 Adaptation layer

• ?Class 4(connectionless) traffic
• Routed still by VC??Trouble
• Passes through adaptation layer, use a datagram
  switch
• Use permanent VC to carry all datagram between 2
  switches

145
2.10.3 Congestion

• Congestion is still a problem for broadband
  networks
• Due to large data rate for video
  applications,etc.
• 3 mechanisms
• 1. At connection setup time, negotiate QoS,
  burstiness.
• 2. Monitor each connection
• 3. Use priority bit in ATM header

146
2.10.3 Congestion

• For connectionless, no negotiation,
• Carefully controlled to avoid excessive delays
  for connection-oriented sessions.
• Usually, a higher-layer network handles this.
• For negotiation ?QoS guarantee

147
2.10.3 Congestion

• ?For monitor regular ?e.g. leaky bucket
• (noteFor light loaded,allow excessive traffic )
• Discarded later when congestion
• For priorityby user to indicate low priority
  traffic
• E.g. video/voice compression.

148
Session ID addressing
