Title: DICKSON DAM


1
  • Alberta Environments
  • River Forecast Centre
  • Presentation to the Alberta Broadcasters Public
    Alerting Recognition Symposium
  • Red Deer, Alberta
  • January 14, 2008
  • Scott Vatcher, P.Eng. Forecaster, Flow
    Forecasting

Red Deer River near Drumheller June 2005
2
What River Forecasting Does
  • Real-time monitoring and reporting
  • Water Management
  • Infrastructure Management
  • Water Supply Forecasting
  • Flood Forecasting

3
1. What do we monitor and report?
Real-time data
  • Stream levels and flows
  • Lake and reservoir levels
  • Precipitation
  • Snowpack
  • Temperature, wind, humidity
  • Water quality

4
Real-time Hydrometric Stations
  • Over 350 currently
  • Stream, lake, reservoir levels
  • Satellite/phone links

5
Real-time Meteorological Stations
218 Federal and Provincial
Hourly Data
  • Precipitation
  • Temperature
  • Relative humidity
  • Wind speed

6
Forestry Meteorological Stations
  • 190 stations
  • Mostly in north
  • Most report 2x-daily
  • Some report 1x-daily

7
Snow Course Sites
71 Plains
8
Snow Pillows
  • 13 Mountain Sites
  • (new site at South Esk)
  • 2 Plains Area Sites

USES
  • Snow-on-ground
  • Snow / Rain indicators
  • Melt rates

9
2. Water Management
Provide information to support in real-time
  • In-stream flow needs
  • (Fish, water intakes, ferry crossings)
  • Apportionment (sharing) agreements
  • Prairie Provinces, U.S.
  • Natural Flows
  • License requirements
  • Water Quality
  • QA/QC of real-time data

Waterton Reservoir
10
3. Infrastructure Management
  • 5.2 Billion of provincial water infrastructure
    in Alberta
  • Develop flood operating procedures and provide
    operational advice to dam operators
  • Conduct annual flood drills for provincially
    owned reservoirs
  • Provide cross-check of operations during floods
  • Coordinate with Trans Alta Utilities
  • Provide technical resources and secondary
    notification of potential dam emergencies
    coordinated with Emergency Management Alberta
  • Provide forecasts for
  • Floods
  • Water quality
  • Water supply
  • Reservoir Inflows
  • Natural flows

Oldman River Dam
11
4. Water Supply Forecasting
  • Current conditions reporting assesses snowpack,
    precipitation and soil moisture conditions and
    their impact for runoff potential

08-2001
  • Runoff forecasts and current conditions are
    updated monthly and published in the Water Supply
    Outlook for Alberta (20 forecast points)
  • Runoff forecast used by others to plan allotment
    of reservoir water supplies for irrigation,
    hydroelectric, and community municipal purposes
    and reservoir operations

09-2002
Chin Reservoir
Photos by Wally Chinn
12
5. Flood Forecasting
  • Forecast floods and flows
  • Issue Advisory and Warnings
  • High Streamflow Advisories
  • Flood Watches
  • Flood Warnings
  • Assist Alberta Environments River Engineering in
    issuing advisories and warnings for ice and ice
    jams

High River June 2005
13
Why is Forecasting Necessary?
  • Potential to reduce Flood Damage by Flood
    Avoidance
  • 66 Communities Identified having a Flood Risk
  • 36 of 66 have forecast procedures developed
  • Potential to reduce Flood Peaks using Reservoir
    Storage
  • 5 Major Government 10 Major Private Reservoirs
    located upstream of populated centres with
    potential for flood attenuation

North Saskatchewan River at Edmonton July 1986
14
Why is Forecasting Necessary?
  • Rapid Response Time of Mountain / Foothill
    Streams
  • Rapid Response FLASH FLOODS in Southern
    Alberta and Swan Hills
  • Response time much longer in Northern Alberta
  • Variety of Flood Conditions
  • Snowmelt
  • Plains - March - April
  • Only smaller streams affected (Paddle, Battle,
    Vermilion, etc)
  • Ice jams
  • Mountains - May - July
  • No flooding of major rivers by mountain
    snowmelt alone
  • Rainfall
  • Affects all rivers in Alberta
  • Flooding along major rivers is caused by heavy
    rainfall or heavy rainfall during mountain
    snowmelt

Oldman River at Lethbridge June 2005
15
Importance of Weather Forecasting
  • Lead time prior to onset of storm
  • Quick response times of many rivers
  • Identify major storm patterns
  • Storms can cover large area of the Province
  • Partnerships with Meteorological Service of
    Canada, and Alberta Sustainable Resource
    Development (Fire Weather), who provide weather
    forecasts
  • Satellite and radar imagery used to track weather
    systems

16
Provincial Responsibilities for Floods
  • Department of Environment Lead Agency
  • Flow Forecasting
  • Issuing of flood related advisories and warnings
  • Provide information/forecasts about the floods
  • Coordinate all information from government and
    non-government agencies and provide value added
    information to all stakeholders, including the
    public
  • Coordinate reservoir operations to provide early
    warning and forecasts for communities
  • Water Operations
  • Operate the 5.2 billion of infrastructure in the
    province
  • Disaster Services Act
  • Municipalities are tasked with the due care and
    safety of their citizens response on the ground
  • When overwhelmed in an emergency, provincial help
    is available through Emergency Management Alberta

17
Media
River Forecasting
18
Alerts
If a storm is forecast to cause major changes in
streamflow, we can issue up to 3 levels of alerts
Flood Watch
High Streamflow Advisory
A High Streamflow Advisory means that stream
levels are rising or expected to rise rapidly and
no major flooding is expected. Minor flooding in
low-lying areas is possible. Anyone situated
close to the streams affected (campers,
fishermen, boaters, and the general public) is
advised to be cautious of the rising levels.
A Flood Watch means that stream levels are rising
and will approach and may exceed bank full.
Flooding of areas adjacent to these streams may
occur. Anyone situated close to these streams is
advised to take appropriate precautionary
measures.
Paddle River - 2001
Paddle River - 2001
Flood Warning
A Flood Warning means that rising river levels
will result in flooding of areas adjacent to the
streams affected. Anyone situated close to the
river should take appropriate measures to avoid
flood damage.
Red Deer River at Drumheller June 2005
19
Spring Runoff Advisory
A Spring Runoff Advisory means that stream levels
are rising or expected to rise due to snowmelt
and no major flooding is expected. Minor
flooding in low-lying areas is possible. Anyone
situated close to the streams affected (property
owners and the general public) is advised to be
cautious of the rising levels.
Medicine River - 1999
20
What
When
Where
Why
Next Update
Definitions
Contacts
21
Forecasters Comments
Impact Gave Forecasters an opportunity to put
out more information restricted to one page on
fax
22
Communicating Flood Related Information
  • FAX
  • Two FAX Broadcast Systems - can notify 400
    clients in 30 minutes
  • TELEPHONE
  • Automated notification system operational since
    the 2004 season
  • INTERNET
  • http//www3.gov.ab.ca/env/water/ws/advisories/
  • Numerous data and information products
    (Forecasters Comments) available
  • IVR (Interactive Telephone Response)
  • RADIO AND TELEVISION
  • Emergency Public Warning System

North Saskatchewan River at Edmonton June 2005
23
When They Are Notified
  • Stage 1 - Anticipation Of Major Storm
  • Verify Weather Forecasts
  • Forecasting Staff - Allocate Manpower for Shift
    (7x24 two 12 hour shifts required)
  • Notify Dam Operators
  • Usually 12 - 48 Hours Prior to Start of Storm
  • Information in Forecasters Comments
  • Stage 2 - Heavy Rainfall Warning Issued or High
    Streamflow Situation
  • Assess Situation Identify Problem Areas
  • Notify Other Water Managers
  • Qualitative Forecasts
  • Update Dam Operators, Water Managers
  • Alert Local Authorities, Media (Advisory)
  • Stage 3 - Flood Emergency
  • Quantitative Forecasts (Time and Stage of peak)
  • Alert as in Stage 2

24
Questions?
Sundre June 2005
25
June 2005 Flood Events
Bearberry Creek at Sundre June 2005
26
June 2005 Flood Events
  • In June 2005, three major flood events occurred
    in a short period of time
  • The flood event covered a large geographic area
  • In many areas, these events are the worst floods
    on record

Red Deer River upstream of Red Deer June 2005
27
Chronology of Key Events Red Deer
Wednesday, June 15 130 pm Call to Dickson Dam
to inform of potential rain event over the
weekend 330 pm Dickson Dam begins to
pre-release from reservoir Thursday, June 16
910 am High Streamflow Advisory issued for
downstream of Dickson Dam, including Red Deer and
Drumheller 940 am Calls to Red Deer,
Drumheller and other local municipalities about
possibility of large flows over the weekend 100
pm Emergency Management Alberta notified of
potential heavy rain event for the Oldman, Bow
and Red Deer River basins
28
Chronology of Key Events Red Deer
  • Friday, June 17
  • 945 am Flood Watch issued for streams and rivers
    upstream of Dickson Dam, including the mainstem
    of the Red Deer also included Little Red Deer
    River
  • 1200 pm Precipitation begins in headwaters of
    Red Deer River basin
  • Saturday, June 18
  • 810 am Flood Warning issued for Red Deer River
    upstream of Dickson Dam (not including Sundre)
    and Little Red Deer River
  • 920 am Flood Warning issued for Sundre and for
    James and Raven Rivers Broadcast on Emergency
    Public Warning System
  • 1200 pm Red Deer, Drumheller and other local
    municipalities advised of major flood event to
    affect towns preliminary forecasts given
  • 1230 pm EMA advised of situation to affect Red
    Deer and Drumheller
  • 1245 pm Flood Warning issued for Red Deer River
    downstream of Dickson Dam, including Red Deer and
    Drumheller
  • 200 pm Water levels in Dickson Dam begin to
    rise
  • 230 pm RFC notified by WSC of measurement at
    Little Red Deer River near Water Valley of 568
    m³/s

29
Alberta June 2005 Floods by the numbers
  • Number of storm events 4
  • Number of flood events 3
  • Number of times High River and Okotoks flooded in
    22 days 3
  • Number of years to the day from the last flood in
    High River to the first one this year 10
  • Number of stations recording flood of record 21
  • Number of communities declaring local states of
    emergency 29
  • Highest flow recorded 3,832 m3/s
  • South Saskatchewan River at Medicine Hat
  • Number of provinces flooded as a result of second
    event 3
  • Alberta, Saskatchewan and Manitoba
  • Preliminary damage estimate 700 million

30
Alberta June 2005 Floods by the numbers
  • Number of advisories issued by River Forecasting
    44
  • Number of phone calls to/from River Forecasting
    2,566
  • Number of faxes sent by River Forecasting 26,436
  • Number of web hits to flood information 774,310
  • Previous High 179,266 - June 2002
  • Most web hits in one day 98,310 - June 7, 2005
  • Number of gauge site visits by Water Survey of
    Canada and AENV field staff 352
  • Number of gauge measurements conducted by WSC and
    AENV field staff in June 204
  • Number of days that River Forecasting was on
    7x24 22
  • Number of overtime hours worked by River
    Forecasting, Data Management and System Support
    1,553
  • Number of times Emergency Public Warning System
    used by River Forecasting 7
Write a Comment
User Comments (0)
About PowerShow.com
