Practical Implementation of High Dynamic Range Rendering

1
Practical Implementation of High Dynamic Range
Rendering

• Masaki Kawase
• BUNKASHA GAMES
• BUNKASHA PUBLISHING CO.,LTD
• http//www.bunkasha-games.com
• http//www.daionet.gr.jp/masa/

2
Agenda

• What can be done with HDR?
• HDR rendering topics
• Implementation on DX8 hardware
• Implementation on DX9 hardware
• Glare generation
• Exposure control
• HDR in games
• References

3
What can be done with HDR?

• Dazzling light
• Dazzling reflection
• Fresnel reflection
• bright reflection in the normal direction
• Exposure control effects
• Realistic depth-of-field effects
• Realistic motion blur

Agenda
4
Dazzling Light
5
Dazzling Reflection
6
HDR Fresnel
Bright reflection off low-reflectance surfaces
7
Exposure Control
8
HDR Depth-of-Field
Future perspective
9
HDR Motion Blur
Future perspective
10
HDR Rendering Topics

• Dynamic range
• HDR buffers
• Glare generation
• Exposure control
• Tone mapping

Agenda
11
Dynamic Range

• The ratio of the greatest value to the smallest
  value that can be represented
• Displayable image
• 28 Low dynamic range (LDR)
• Frame buffer of absolute luminance
• Render the scene in absolute luminance space
• gt232 represents all luminances directly
• Frame buffer of relative luminance
• Apply exposure scaling during rendering
• gt21516 dark regions are not important

12
HDR Buffers

• Frame buffers
• For glare generation
• Environment maps
• To prevent luminances from being clamped when the
  surface reflectance is very low
• To achieve dazzling reflection
• Self-emission textures
• For post-rendering glare generation
• Decal textures dont need HDR

13
HDR Frame Buffers

• For glare generation
• When rendering with relative luminances
• Ideally, more than 21516
• In games
• 21213 (4,00010,000) is acceptable

14
HDR Environment Maps

• Very important for representing
• Realistic specular reflection
• Dazzling specular reflection
• Specular reflectance of nonmetals
• Reflectance in the normal direction is
  typicallyless than 4
• Bright light remains bright after such low
  reflection
• To maintain dazzles after reflection of 1-4
• Dynamic range of more than 10,000 or 20,000 is
  necessary

15
Implementation on DX8 Hardware

• We have no choices
• Pixel Shader 1.x
• Integer operations only
• HDR buffer formats
• Low-precision buffers only
• Use the alpha channel as luminance information
• Fake it to achieve believable appearance
• Accurate calculation is not feasible

Agenda
16
Fake HDR Pixel Shader
ps_1_1 tex t0 tex t1 tex t2 mad r0.rgb, v0,
t2, v1 // Scale the primary diffuse color by
// shadow/light map, and
add the result of //
other per-vertex lighting mul t0.a, v1.a, t0.a
// Scale the specular reflectance
// by gloss map mul r0.rgb, t0,
r0 // Modulate diffuse color with decal
texture mul r0.a, t0.a, t1.a // r0.a
specular reflectance
envmap luminance mul t1.rgb, t1, c0
// Modulate envmap with specular color mul
r1.a, r0.a, t1.a // Envmap brightness
parameter // r1.a
specular reflectance
envmap luminance gloss map lrp r0.rgb,
t0.a, t1, r0 // Reflect the envmap by specular
reflectance mul r1.a, r1.a, c0.a // Envmap
brightness parameter
// r1.a specular reflectance
envmap luminance gloss map
Clamp(gloss
2, 0, 1) lrp r0.rgb, r1.a, t1, r0 // Output
color // Interpolate
the envmap color and the
// result of LDR computation, based on
// the envmap brightness
parameter (r1.a) lrp r0.a, r1.a, t1.a, r0.a //
Output luminance information

• Glossy reflection material

// v0.rgb Diffuse color of primary light //
v1.rgb Color for other lights/ambient //
pre-scaled by (exposure 0.5) // // v1.a
Specular reflectance (Fresnel) // // t0.rgb
Decal texture (for diffuse) // t0.a Gloss map
(for specular) // t1.rgb Envmap color // t1.a
Envmap luminance // t2.rgb Shadow/light
map // // c0.rgb Specular color // c0.a
Clamp(gloss 2, 0, 1)
17
Fake HDR Pixel Shader

• Self-emission material

ps_1_1 tex t0 tex t1 tex t2 mad r0.rgb, v0,
t2, v1 // Scale the primary diffuse color by
// shadow/light map, and
add the result of //
other per-vertex lighting mul t0.a, t0.a, c1.a
// Scale the self-emission luminance mul
r0.rgb, t0, r0 // Modulate diffuse color
with decal texture mul r1.rgb, t0, c1 //
decal texture self-emission color lrp r0.rgb,
t0.a, r1, r0 // Output color
// Add self-emission color to diffuse
color // Make it close
to the self-emission color
// where the luminance information is
high mov r0.a, t0.a // Output
luminance information
// v0.rgb Diffuse color for primary light //
v1.rgb Color for other lights/ambient //
pre-scaled by (exposure 0.5) // // t0.rgb
Decal texture (for diffuse) // t0.a
Self-emission luminance // t2.rgb Shadow/light
map // // c1.rgb Self-emission color //
(to be modulated by t0.rgb) // c1.a Emission
intensity (scale for t0.a) // pre-scaled
by (exposure 0.5)
18
Generating Displayable Image

• Extract high-luminance regions
• Threshold 0.4-0.5
• Generate glare
• Reference
• Kawase, Masaki, Frame Buffer Postprocessing
  Effects in DOUBLE-S.T.E.A.L (Wreckless)
• Generate a displayable image
• Calculate the luminance from the frame buffer
• Add the result of glare generation to the
  luminance

19
Bright-Pass Pixel Shader

• // Bright-Pass Pixel Shader
• // Out.rgb FrameBuffer.rgb ( (1 - Threshold)
  / 16 FrameBuffer.a )
• // t0.rgb Frame-buffer color
• // t0.a Frame-buffer extra luminance
  information
• //
• // c0.a Luminance bias
• // (1 - Threshold) / 16
• // 0.5/16 0.6/16
• ps_1_1
• tex t0 // Frame buffer
• add r0.a, t0.a, c0.a // r0.a (1 - Threshold)
  / 16 Buffer.a
• mul r0.rgb, t0, r0.a // r0.rgb Buffer.rgb (
  (1 - Threshold) / 16 Buffer.a )

20
Glare Generation

• Reference
• Kawase, Masaki, Frame Buffer Postprocessing
  Effects in DOUBLE-S.T.E.A.L (Wreckless)

21
Luminance Calculationand Glare Composition

• // Tone Mapping / Glare Composition Pixel Shader
• // Out.rgb (FrameBuffer.rgb FrameBuffer.rgb
  FrameBuffer.a2 16) 2 Glare.rgb Glare.rgb
• // t0.rgb frame buffer color
• // t0.a frame buffer extra luminance
  information
• // t1.rgb result of glare generation
• ps_1_1
• tex t0 // frame buffer
• tex t1 // glare
• mul_x4 r0.a, t0.a, t0.a // r0.a
  FrameBuffer.a2 4
• mul_x4 r1.rgb, t0, r0.a // r1.rgb
  FrameBuffer.rgb FrameBuffer.a2 16
• add_x2 r0.rgb, t0, r1 // (FrameBuffer.rgb
  FrameBuffer.rgb FrameBuffer.a2 16) 2
• mad r0.rgb, t1, t1, r0 // add the glare

22
Notes on DX8 Implementation

• Accurate calculation is not feasible
• How to make it believable by faking
• Based on appearance rather than theory

23
Implementation on DX9 Hardware

• There are currently many limitations
• Choose implementations accordingly
• Pixel Shader
• Pixel Shader 2.0 or later
• Pixel Shader 1.x
• Buffer formats for HDR
• High-precision integer/float buffers
• Low-precision integer buffers

Agenda
24
Issues with High-Precision Buffers

• Memory usage
• A16B16G16R16 / A16B16G16R16F
• 64bpp (bits per pixel)
• Twice as much as A8R8G8B8
• A32B32G32R32 / A32B32G32R32F
• 128bpp
• Four times as much as A8R8G8B8
• At least twice as much memory as the conventional
  full-color buffer is needed

25
Issues with High-Precision Buffers

• Limitations
• Alpha blending cannot be used
• Texture filtering cannot be used with
  floating-point formats
• Affects the quality of environment maps and
  self-emission textures
• Some systems dont support them

26
Practicability ofHigh-Precision Buffers

• Current hardware has many problems
• In order to use high-precision buffers
• A16B16G16R16 / A16B16G16R16F
• The hardware must support them
• Plenty of memory is needed
• You dont use alpha blending
• The situation is not good

27
Use Low-Precision Buffers

• Make use of low-precision buffers
• A8R8G8B8 / A2R10G10B10 etc.
• Low memory consumption
• Alpha blending can be used
• Operations may be incorrect, but it doesnt
  matter very much

28
Compression with Tone Mapping

• Render directly to displayable format
• Nonlinear color compression
• Effectively wide dynamic range
• Reference
• Reinhard, Erik, Mike Stark, Peter Shirley, and
  Jim Ferwerda, Photographic Tone Reproduction for
  Digital Images
• The alpha channel is not used
• Can be used for any other purpose

29
Low-Precision Buffer Formats

• A8R8G8B8 (8 bits per color channel)
• The alpha channel can be used for any other
  purpose
• Works on any system
• RGB precision may be insufficient
• A2B10G10R10A2R10G10B10 (10 bits per color
  channel)
• The color channels have nearly ideal precision
• Few alpha bits
• Not suited for storing other information
• Many systems do not support it

30
Environment Map Formats

• Ideally
• Dynamic range of more than 10,000 or 20,000
• Texture filtering available

31
Environment Map Formats

• Relatively low resolution
• Alpha channel/blending is not very important
• Use the 16-bit integer format if enough memory
  storage is available
• Treat it as having an interval of 0, 256 or 0,
  512
• Fast encoding/decoding
• Texture filtering can be used
• In the future
• Do it all with A16B16G16R16F

32
Low-Precision Environment Maps

• Use them when
• High-precision buffers are not supported, or
• Memory storage is limited
• If the fill-rate of your system is relatively low
• Use the same format as used in DX8 fake HDR
• If the fill-rate is high enough
• Nonlinear color compression
• Similar to tone mapping
• Store exponents into the alpha channel
• More accurate operations are possible
• Using it just as a scale factor is not enough
• Even the DX8 fake HDR has a much bigger impact

33
Color Compression

• Similar to tone mapping
• Encode when rendering to an environment map
• Offset luminance curve controlling factor
  (2-4)
• A bigger offset means
• High-luminance regions have higher resolutions
• Low-luminance regions have Lower resolutions
• Decode when rendering to a frame buffer
• From the environment map fetched
• d a small value to avoid divide-by-zero

34
Color Compression

• Use carefully
• Mach banding may become noticeable on reflections
  of large area light sources
• e.g. Light sky

35
E8R8G8B8

• Store a common exponent for RGB into the alpha
  channel
• Use a base of 1.04 to 1.08
•
  offset 64-128
• Base1.04 means dynamic range of 23,000
  (1.04256)
• A bigger base value means
• Higher dynamic range
• Lower resolution (Mach banding becomes
  noticeable)
• Encode when rendering to an environment map
• Decode when rendering to a frame buffer
• From the environment map fetched

36
E8R8G8B8 Encoding (HLSL)

• // an b
• define LOG(a, b) ( log((b)) / log((a)) )
• define EXP_BASE (1.06)
• define EXP_OFFSET (128.0)
• // Pixel Shader (6 instruction slots)
• // rgb already exposure-scaled
• float4 EncodeHDR_RGB_RGBE8(in float3 rgb)
• // Compute a common exponent
• float fLen dot(rgb.rgb, 1.0)
• float fExp LOG(EXP_BASE, fLen)
• float4 ret
• ret.a (fExp EXP_OFFSET) / 256
• ret.rgb rgb / fLen
• return ret

// More accurate encoding define EXP_BASE
(1.04) define EXP_OFFSET (64.0) // Pixel
Shader (13 instruction slots) float4
EncodeHDR_RGB_RGBE8(in float3 rgb) float4 ret
// Compute a common exponent // based on the
brightest color channel float fLen max(rgb.r,
rgb.g) fLen max(fLen, rgb.b) float fExp
floor( LOG(EXP_BASE, fLen) ) float4 ret
ret.a clamp( (fExp EXP_OFFSET) / 256, 0.0,
1.0 ) ret.rgb rgb / pow(EXP_BASE, ret.a
256 - EXP_OFFSET) return ret
37
E8R8G8B8 Decoding

• // Pixel Shader (5 instruction slots)
• float3 DecodeHDR_RGBE8_RGB(in float4 rgbe)
• float fExp rgbe.a 256 - EXP_OFFSET
• float fScale pow(EXP_BASE, fExp)
• return (rgbe.rgb fScaler)

// If R16F texture format is available, // you
can use texture to convert alpha to scale
factor float3 DecodeHDR_RGBE8_RGB(in float4
rgbe) // samp1D_Exp 1D float texture of
256x1 // pow(EXP_BASE, uCoord 256 -
EXP_OFFSET) float fScale tex1D(samp1D_Exp,
rgbe.a).r return (rgbe.rgb fScale)

• Encoding/decoding should be done using
  partial-precision instructions
• Rounding errors inherent in the texture format
  are much bigger

38
Self-Emission Textures

• Textures for emissive objects
• Use the alpha channel as a common scale factor
  for RGB
• scale 16-128
• Bright enough to cause glare
• Encode offline
• Decoding is fast

39
Rendering with Tone Mapping

• Glossy reflection material

float4 PS_GlossReflect(PS_INPUT_GlossReflect vIn)
COLOR0 float4 vDecalMap tex2D(samp2D_Decal,
vIn.tcDecal) float3 vLightMap
tex2D(samp2D_LightMap, vIn.tcLightMap) float3
vDiffuse vIn.cPrimaryDiffuse vLightMap
vIn.cOtherDiffuse vDiffuse vDecalMap //
HDR-decoding of environment map float3 vSpecular
DecodeHDR_RGBE8_RGB(
texCUBE(sampCUBE_EnvMap, vIn.tcReflect) )
float3 vRoughSpecular texCUBE(sampCUBE_DullEn
vMap, vIn.tcReflect) float fReflectance
tex2D( samp2D_Fresnel, vIn.tcFresnel ).a
fReflectance vDecalMap.a vSpecular
lerp(vSpecular, vRoughSpecular, fShininess)
float3 vLum lerp(vDiffuse, vSpecular,
fReflectance) // HDR tone-mapping
encoding float4 vOut vOut.rgb vLum / (vLum
1.0) vOut.a 0.0 return vOut
struct PS_INPUT_GlossReflect float2 tcDecal
TEXCOORD0 float3 tcReflect
TEXCOORD1 float2 tcLightMap
TEXCOORD2 float2 tcFresnel
TEXCOORD3 // Exposure-scaled lighting
results // Use TEXCOORD to avoid clamping
float3 cPrimaryDiffuse TEXCOORD6 float3
cOtherDiffuse TEXCOORD7
40
Rendering with Tone Mapping

• Self-emission material

float4 PS_SelfIllum(PS_INPUT_SelfIllum vIn)
COLOR0 float4 vDecalMap tex2D(samp2D_Decal,
vIn.tcDecal) float3 vLightMap
tex2D(samp2D_LightMap, vIn.tcLightMap) float3
vDiffuse vIn.cPrimaryDiffuse vLightMap
vIn.cOtherDiffuse vDiffuse vDecalMap //
HDR-decoding of self-emission texture //
fEmissiveScale self-emission luminance
exposure float3 vEmissive vDecalMap.rgb
vDecalMap.a fEmissiveScale
// Add the self-emission float3 vLum
vDiffuse vEmissive // HDR tone-mapping
encoding float4 vOut vOut.rgb vLum / (vLum
1.0) vOut.a 0.0 return vOut
struct PS_INPUT_SelfIllum float2 tcDecal
TEXCOORD0 float2 tcLightMap
TEXCOORD2 // Exposure-scaled lighting
results // Use TEXCOORD to avoid clamping
float3 cPrimaryDiffuse TEXCOORD6 float3
cOtherDiffuse TEXCOORD7
41
Generating Displayable Image

• Extract high-luminance regions
• Threshold 0.5-0.8
• Divide by (1 - Threshold) to normalize
• Generate glare
• Use an integer buffer to apply texture filtering
• Hopefully, a float buffer with filtering
• Generate a displayable image
• Add the glare to the frame buffer

42
Glare Composition

• struct PS_INPUT_Display
• float2 tcFrameBuffer TEXCOORD0
• float2 tcGlare TEXCOORD1
• float4 PS_Display(PS_INPUT_Display vIn) COLOR0
• float3 vFrameBuffer tex2D(samp2D_FrameBuffer,
  vIn.tcFrameBuffer)
• float3 vGlare tex2D(samp2D_Glare, vIn.tcGlare)

• // Add the glare
• float4 vOut
• vOut.rgb vFrameBuffer vGlare vGlare
• vOut.a 0.0
• return vOut

43
Notes on DX9 Implementation

• High-precision buffers
• Consumes a lot of memory
• No blending capability
• Will be recommended in the near future
• Low-precision buffers
• Pixel shaders are expensive
• Consider fake techniques like DX8
• High performance
• Low memory consumption
• Very effective

44
Glare Generation

• Notes on glare generation
• Bloom effects by compositing multiple Gaussian
  filters
• Image processing and sprites

Agenda
45
Notes on Glare Generation

• Requires a lot of rendering passes
• Beware of precision of integer buffers
• Clamping
• Rounding errors
• 16-bit integer may be insufficient
• Always maintain an appropriate range

46
Multiple Gaussian Filters

• Bloom generation
• A single Gaussian filter does not give very good
  results
• Small effective radius
• Not sharp enough around the light position
• Composite multiple Gaussian filters
• Use Gaussian filters of different radii
• Larger but sharper glare becomes possible

Agenda
47
Multiple Gaussian Filters
48
Multiple Gaussian Filters
Original image
49
Multiple Gaussian Filters

• A filter of large radius is very expensive
• Make use of downscaled buffers
• A large radius means a strong low-pass filter
• Apply a blur filter to a low-res version of the
  image and magnify it by bilinear filtering ? The
  error is unnoticeable
• Change the image resolution rather than the
  filter radius
• 1/4 x 1/4 (1/16 the cost)
• 1/8 x 1/8 (1/64 the cost)
• 1/16 x 1/16 (1/256 the cost)
• 1/32 x 1/32 (1/1024 the cost)
• Even a large filter of several hundred pixels
  square can be applied very quickly

50
Applying Gaussian Filters to Downscaled Buffers
1/4 x 1/4 (256x192 pixels)
1/8 x 1/8 (128x96 pixels)
1/16 x 1/16 (64x48 pixels)
1/32 x 1/32 (32x48 pixels)
1/64 x 1/64 (16x12 pixels)
51
Bilinear Filtering and Composition

• Magnify them using bilinear filtering and
  composite the results
• The error is almost unrecognizable

52
Good Enough!
53
Separable Filter

• A 2D Gaussian filter can be separated into a
  convolution of two 1D filters in x and y
  directions
• Can be efficiently implemented as two passes
• Reference
• Mitchell, Jason L., Real-Time 3D Scene
  Post-Processing
• Use high-precision formats for low-res buffers
• Dont take too many samples
• Very expensive, especially for high-res images
• Use a 1-pass cone filter for high-res images

54
Cone Filter
Texture sampling points
55
Other Types of Glare

• Afterimage
• Stars (light streaks)
• Ghosts
• Reference
• Kawase, Masaki, Frame Buffer Postprocessing
  Effects in DOUBLE-S.T.E.A.L (Wreckless)

56
Image Processing and Sprites

• Image Processing
• Extract high-luminance regions from the HDR frame
  buffer
• Image-based post-processing
• Sprites (traditional technique)
• Check the visibility of light sources
• Based on the geometry information
• Use hardware visibility test capability if
  available
• Determine the visibility based on the number of
  pixels rendered
• For each visible light source, draw flare sprites

Agenda
57
Image Processing
58
Sprites
59
Advantages

• Image processing
• Can be applied to reflected lights and area
  lights
• Cost is independent of the number of light
  sources
• The shape of glare can easily be changed by using
  different filter kernels
• Sprites
• High-quality rendering
• Unlimited dynamic range
• Low cost for a small number of light sources

60
Disadvantages

• Image processing
• High fixed cost for pixel filling
• Aliasing artifacts
• Especially for small light sources
• Limited dynamic range
• Hard to handle too bright and too sharp lights
• Sprites
• Cost is proportional to the number of light
  sources
• Difficult to use for arbitrarily shaped lights
• Difficult to apply to indirect lights
• Cannot represent dazzling reflection

61
Choose by the Type of Light

• Image processing
• Area light
• Arbitrarily shaped light sources
• Light sources that have large projected area
• Reflected light
• A lot of light sources
• Sprites
• Very bright and sharp light sources
• Light sources that have small projected area
• A small number of light sources

62
Choose by the Type of Light

• Image processing is suited for
• Illuminations / neon signs
• Windows of buildings at night
• A group of many small light sources
• Light reflected off a surface
• Sprites are suited for
• Sun
• Street lamps
• Car headlights
• In the future, image processing can do it all?
• Sprites are still useful at present

63
Exposure Control

• The scenery outside the window appears very
  bright from indoors
• The inside of the room appears very dark from
  outdoors
• Dark adaptation and light adaptation
• Blinded for a while just after coming into a room
• Dazzled for a while just after going out of a room

Agenda
64
Process of Exposure Control

• Get the average luminance of the scene
• Calculate a proper exposure level
• Tweak the exposure level

65
Getting Average Luminance

• Down-sample the frame buffer
• Reduce to 16x16 or smaller
• Convert the HDR buffer into luminances
• If using alpha as extra luminance information
• If using tone mapping to compress RGB color

66
Getting Average Luminance

• Calculate the average luminance over the entire
  screen
• d a small value to avoid the singularity
• Reference
• DirectX 9.0 SDK Summer 2003 Update, HDRLighting
  Sample
• Reinhard, Erik, Mike Stark, Peter Shirley, and
  Jim Ferwerda. Photographic Tone Reproduction for
  Digital Images
• Trial and error
• Give higher weights to the central region

67
Calculating Proper Exposure

• Exp the proper exposure level of the scene
• Scale an arbitrary scale factor

68
Tweaking Exposure

• Change it gradually to emulate adaptation
• Ratio adaptation speed (0.02-0.1)

69
Tweaking Exposure

• Trial and error
• Give different speed to dark and light adaptation
• Compute the adaptation based on the proper
  exposure of, say, 0.5 sec before
• Tweak the adaptation sensitivity
• Base the logarithm of a base exposure level
• Sensitivity adaptation rate (0-1)

70
HDR in Games

• Should be appealing rather than accurate
• Accuracy is not important for players
• Accuracy does not necessarily mean attractiveness
• Even an inaccurate scene can be appealing
• Cost and performance
• The key is to understand the effects of HDR
• Devise a fake technique that is fast enough and
  produces believable results
• Accurate HDR rendering is still hard in games
• Use HDR only for effects that give a large impact
• Use sprites if you want to generate glare only
  for the sun, which is much faster and gives high
  quality results

Agenda
71
HDR in Games

• Integer formats have very limited dynamic range
• Render in relative luminance space
• Apply exposure scaling during rendering
• High precision is not needed for the dark regions
  after exposure scaling
• As those regions remain dark in the final image
• Carefully choose the range to maximize effective
  precision

72
HDR in Games

• Future perspective
• All operations can be done in float
• Environment maps / frame buffers / glare
  generation
• Rendering in absolute luminance space
• Image-based generation of all the glare
• Effective use of HDR
• Depth-of-field with the shape of aperture stop
• Motion blur with high luminances not clamped

73
References

• Reinhard, Erik, Mike Stark, Peter Shirley, and
  Jim Ferwerda, Photographic Tone Reproduction for
  Digital Images
• Mitchell, Jason L., Real-Time 3D Scene
  Post-Processing
• DirectX 9.0 SDK Summer 2003 Update, HDRLighting
  Sample
• Debevec, Paul E., Paul Debevec Home Page
• Kawase, Masaki, Frame Buffer Postprocessing
  Effects in DOUBLE-S.T.E.A.L (Wreckless)

Top
