Structural Equation Modeling SEM With Latent Variables

1
Structural Equation Modeling (SEM) With Latent
Variables

• James G. Anderson, Ph.D.
• Purdue University

2
Steps In Structural Equation Modeling

• Model specification
• Identification
• Estimation
• Testing fit
• Respecification

3
Measurement Model (1)

• Specifying the relationship between the latent
  variables and the observed variables
• Answers the questions
• To what extent are the observed variables
  actually measuring the hypothesized latent
  variables?
• Which observed variable is the best measure of a
  particular latent variable?
• To what extent are the observed variables
  actually measuring something other than the
  hypothesized latent variable?

4
Measurement Model (2)

• The relationships between the observed variables
  and the latent variables are described by factor
  loadings
• Factor loadings provide information about the
  extent to which a given observed variable is able
  to measure the latent variable. They serve as
  validity coefficients.
• Measurement error is defined as that portion of
  an observed variable that is measuring something
  other than what the latent variable is
  hypothesized to measure. It serves as a measure
  of reliability.

5
Measurement Model (3)

• Measurement error could be the result of
• An unobserved variable that is measuring some
  other latent variable
• Unreliability
• A second-order factor

6
(No Transcript)
7
(No Transcript)
8
Structural Model

• The researcher specifies the structural model to
  allow for certain relationships among the latent
  variables depicted by lines or arrows
• In the path diagram, we specified that Ability
  and Achievement were related in a specific way.
  That is, intelligence had some influence on later
  achievement. Thus, one result from the structural
  model is an indication of the extent to which
  these a priori hypothesized relationships are
  supported by our sample data.

9
Structural Model (2)

• The structural equation addresses the following
  questions
• Are Ability and Achievement related?
• Exactly how strong is the influence of Ability on
  Achievement?
• Could there be other latent variables that we
  need to consider to get a better understanding of
  the influence on Achievement?

10
Example of a Complete Structual Equation Model

• We can specify a model to further duscuss how to
  diagram a model, specify the equations related to
  the model and discuss the effects apparent in
  the model. The example we use is a model of
  educational achievement and aspirations.
• Figure 2 shows there are four latent variables
  (depicted by ellipses) two independent, home
  background (Home) and Ability and two dependent,
  aspirations (Aspire) and achievement (Achieve).

11
Example of a Complete Structual Equation Model
(2)

• Three of these latent variables are assessed by
  two indicator variables and one latent variable,
  home background, is assessed by three indicator
  variables. The indicator variables are depicted
  in rectangles.

12
(No Transcript)
13
(No Transcript)
14
Covariance

• SEM involves the decomposition of covariances
• There are different types of covariance matrices
• Among the observed variables
• Among the latent exogenous variables.
• Among the equation prediction errors
• Among the measurement errors

15
Covariance (2)

• Types of covariance
• Among the observed variables
• Among the latent exogenous variables
• Set the covariance between IQ and HOME to 0

IQ
ACH
HOME
16
Covariance (3)

• Among the equation prediction errors
• Set the error covariance between Legal and
  Profess free

Religion
Legal
Error
V1
F1
E1
E3
Profess
Error
Experience
V2
F2
E2
E4
17
Total, Direct and Indirect Effects

• There is a direct effect between two latent
  variables when a single directed line or arrow
  connects them
• There is an indirect effect between two variables
  when the second latent variable is connected to
  the first latent variable through one or more
  other latent variables
• The total effect between two latent variables is
  the sum of any direct effect and all indirect
  effects that connect them.
