Grades and Standards for Nursery Stock

1
Grades and Standards for Nursery Stock

• by Edward F. Gilman, professor
• Environmental Horticulture Department
• IFAS
• University of Florida
• http//hort.ufl.edu/woody/planting

2
(No Transcript)
3
Florida grades and standards

• 1955 Passed by
• Florida legislature
• 1965 first edition printed
• Developed for more
• accurate communication
• between buyer/seller
• 1998 second edition a 10 step process for
  trees

4
Grading trees

• Tree quality at planting can have a great impact
  on longevity in the landscape
• Four grades exist for nursery plants in Florida.
  These include
• -Florida Fancy -Florida 2
• -Florida 1 -Cull

5
Florida fancy

• Single trunk
• Branch diameter smaller
• than 2/3
• No flush cuts/open injuries
• Crown full of foliage
• Root ball is appropriately sized

6
Florida 1

• Requires some pruning to develop good structure
• Has minor trunk injuries
• Double leader in top half of tree

7
Florida 2

• Trees are misshapen or require major corrective
  pruning
• Defects may take several years to correct
• Double leader on bottom half of the tree

defect
8
Cull

• Defects are not correctable
• Lack vigor
• May have poor trunk and branch structure,
  circling roots, open wounds, flush cuts, or a
  loose root ball

9
Steps for determining the grade of a tree

• Step 1- Grade trunk
• Step 2- Branch arrangement
• Step 3- Appropriate tree matrix
• Step 4- Trunk caliper
• Step 5- Crown spread
• Step 6- Structural uniformity of crown
• Step 7- Determine the lowest grade
  given in steps 1,2,5 and 6
• Step 8- Downgrading factors
• Step 9- Downgrading factors
• Step 10-Roots

10
Step 1Grade trunk
11
Florida fancy

• Single trunk
• Straight or with less than 5º bow

12
Florida 1
Codominant stems

• Trunk forks in upper half of tree
• Bow of 5º-15º

13
Florida 2

• Trunk forks in lower half of tree
• Bow greater than 15º
• Trunk has dogleg

• Three or more trunks in upper half of tree

Dogleg
14
Cull
3 trunks

• Three or more trunks in lower half of tree.

15
Steps for determining the grade of a tree

• Step 1- Grade trunk
• Step 2- Branch arrangement
• Step 3- Appropriate tree matrix
• Step 4- Trunk caliper
• Step 5- Crown spread
• Step 6- Structural uniformity of crown
• Step 7- Determine the lowest grade
  given in steps 1,2,5 and 6
• Step 8- Downgrading factors
• Step 9- Downgrading factors
• Step 10-Roots

16
Step 2 Grade branch arrangement

17
Florida fancy

• Large branches spaced at least 6 apart along the
  trunk
• No branch greater than 2/3 diameter of trunk
• No vertical branches

18
Florida 1

• All branches equally dominant
• Branches are at least 4 apart
• One branch in upper half of tree may be greater
  than 2/3
• No branch tips are taller than trunk

19
Florida 2

• Most branches vertical
• Major branches spaced 4 apart in two or more
  locations
• One branch in lower half of tree larger than 2/3

20
Cull

• Vertical branching
• Narrow branch angles
• Major branches growing from same point or
  opposite from each other
• Major branches less than 4 from the ground

21
Steps for determining the grade of a tree

• Step 1- Grade trunk
• Step 2- Branch arrangement
• Step 3- Appropriate tree matrix
• Step 4- Trunk caliper
• Step 5- Crown spread
• Step 6- Structural uniformity of crown
• Step 7- Determine the lowest grade
  given in steps 1,2,5 and 6
• Step 8- Downgrading factors
• Step 9- Downgrading factors
• Step 10-Roots

22
Step 3 Choose appropriate tree matrix from
index
23
Based on natural form of the tree

• Type 1- Spreading and rounded shapes. Ex- Live
  oak, sycamore, black olive.
• Type 2- Pyramidal shapes. Ex- Pin oak, southern
  magnolia, pine.
• Type 3- Columnar/ upright shapes. Ex- Loblolly
  bay, Italian cypress, stopper.
• Type 4- Vase shapes. Ex- Chinese elm, hawthorn,
  redbud.
• Type 5- Oval shapes. Ex- Ash, basswood, red
  maple.

24
(No Transcript)
25
Steps for determining the grade of a tree

• Step 1- Grade trunk
• Step 2- Branch arrangement
• Step 3- Appropriate tree matrix
• Step 4- Trunk caliper
• Step 5- Crown spread
• Step 6- Structural uniformity of crown
• Step 7- Determine the lowest grade
  given in steps 1,2,5 and 6
• Step 8- Downgrading factors
• Step 9- Downgrading factors
• Step 10-Roots

26
Step 4 Measure trunk caliper
27
Measure trunk caliper

• Caliper- Trunk diameter measured 6 from the
  ground for trees up to 4 caliper, and 12 from
  ground for larger trees.

28
Steps for determining the grade of a tree

• Step 1- Grade trunk
• Step 2- Branch arrangement
• Step 3- Appropriate tree matrix
• Step 4- Trunk caliper
• Step 5- Crown spread
• Step 6- Structural uniformity of crown
• Step 7- Determine the lowest grade
  given in steps 1,2,5 and 6
• Step 8- Downgrading factors
• Step 9- Downgrading factors
• Step 10-Roots

29
Step 5Grade crown spread
30
Grading for crown spread

• Measure crown spread
• Spread must be greater or equal to the minimum
  for the grade

Crown Spread Diameter The average of the widest
branch spread and that perpendicular to it.
31
Type one matrix
32
Steps for determining the grade of a tree

• Step 1- Grade trunk
• Step 2- Branch arrangement
• Step 3- Appropriate tree matrix
• Step 4- Trunk caliper
• Step 5- Crown spread
• Step 6- Structural uniformity of crown
• Step 7- Determine the lowest grade
  given in steps 1,2,5 and 6
• Step 8- Downgrading factors
• Step 9- Downgrading factors
• Step 10-Roots

33
Step 6Grade structural uniformity of crown
34
Florida fancy

• Branches evenly distributed around trunk
• No major branch located directly above another

Crown full of foliage
35
Florida 1
Small void

• Most branches evenly distributed
• One major branch located directly above another
• Not completely foliated- small voids present.

36
Florida 2

• Branches not evenly distributed
• Several branches growing on same side
• Two or more branches located directly above each
  other
• Large voids in crown

37
Cull

• Tree is one sided or flat sided
• Major branches growing from only one or two sides
• Large gaps in crown

38
Steps for determining the grade of a tree

• Step 1- Grade trunk
• Step 2- Branch arrangement
• Step 3- Appropriate tree matrix
• Step 4- Trunk caliper
• Step 5- Crown spread
• Step 6- Structural uniformity of crown
• Step 7- Determine the lowest grade given
  in steps 1,2,5 and 6
• Step 8- Downgrading factors
• Step 9- Downgrading factors
• Step 10-Roots

39
Step 7Determine the lowest grade from steps 1,
2, 5, and 6
40
Determine the lowest grade from steps 1, 2, 5,
and 6

• Step 1- Florida 1
• Step 2- Florida 1
• Step 5- Florida fancy
• Step 6- Florida 1
• Lowest grade Florida 1

41
Steps for determining the grade of a tree

• Step 1- Grade trunk
• Step 2- Branch arrangement
• Step 3- Appropriate tree matrix
• Step 4- Trunk caliper
• Step 5- Crown spread
• Step 6- Structural uniformity of crown
• Step 7- Determine the lowest grade
  given in steps 1,2,5 and 6
• Step 8- Downgrading factors-takes 1
• Step 9- Downgrading factors-takes two
• Step 10-Roots

42
Step 8Downgrading factors- Deduct one grade for
every true statement
43
Tree with caliper greater than 1 requires
staking
Stake
44
Root ball/container undersized
45
BB root ball not properly secured
Materials used to secure BB root balls
BB properly secured
46
Root-bound
Large roots growing around outer edge of root ball
47
One or two roots growing out of container or grow
bag
Root greater than 1/5 diameter of the trunk
48
Crown thin/sparsely foliated
49
Tip dieback on more than 5 of branches
50
Steps for determining the grade of a tree

• Step 1- Grade trunk
• Step 2- Branch arrangement
• Step 3- Appropriate tree matrix
• Step 4- Trunk caliper
• Step 5- Crown spread
• Step 6- Structural uniformity of crown
• Step 7- Determine the lowest grade
  given in steps 1,2,5 and 6
• Step 8- Downgrading factors-takes one
• Step 9- Downgrading factors-takes 2
• Step 10-Roots

51
Step 9Downgrading factors-Deduct one grade if
two statements are true and two grades if more
are true
52
Tree height shorter than min. or taller than max.
in appropriate matrix
53
Flush cuts
flush cut
good cut
Callus forming only around sides of flush cut.
Branch collar no longer present.
54
Branch stubs
55
Open trunk wounds/ injuries
Open wound
56
Graft unions not complete
Incomplete graft union
57
More than lower 40 of trunk free from branches
58
More than 5 of leaves are chlorotic or show
signs of pests and diseases
59
Leaves smaller than normal
60
Included bark between trunk and major branches
Included bark
61
Major branches touching
Branches touching
62
Steps for determining the grade of a tree

• Step 1- Grade trunk
• Step 2- Branch arrangement
• Step 3- Appropriate tree matrix
• Step 4- Trunk caliper
• Step 5- Crown spread
• Step 6- Structural uniformity of crown
• Step 7- Determine the lowest grade
  given in steps 1,2,5 and 6
• Step 8- Downgrading factors-takes 1
• Step 9- Downgrading factors-takes 2
• Step 10-Roots

63
Step 10Grade root structure
64
Cull tree if the following are true

• A root is greater than 1/10 trunk diameter, and

• it circles more than 1/3 the trunk, and
• it is in the top half of the root ball.

65
Circling roots inside root ball
66
