Chapter 17 The Beginning of Time

1
Chapter 17The Beginning of Time
2
What were conditions like in the early universe?
3
The universe must have been much hotter and
denser early in time.
Estimating the Age of the Universe
4
The early universe must have been extremely hot
and dense.
5
Photons converted into particleantiparticle
pairs and vice versa. E mc2 The early
universe was full of particles and radiation
because of its high temperature.
6
What is the history of the universe according to
the Big Bang theory?
7
Defining Eras of the Universe

• The earliest eras are defined by the kinds of
  forces present in the universe.
• Later eras are defined by the kinds of particles
  present in the universe.

8
Four known forces in universe Strong Force
Electromagnetism Weak Force Gravity
9
Thought Question

• Which of the four forces keeps you from sinking
  to the center of Earth?
• A. Gravity
• B. Electromagnetism
• C. Strong Force
• D. Weak Force

10
Thought Question

• Which of the four forces keeps you from sinking
  to the center of Earth?
• A. Gravity
• B. Electromagnetism
• C. Strong Force
• D. Weak Force

11
Do forces unify at high temperatures?
Four known forces in universe Strong Force
Electromagnetism Weak Force Gravity
12
Do forces unify at high temperatures?
Four known forces in universe Strong Force
Electromagnetism Weak Force Gravity
Yes! (Electroweak)
13
Do forces unify at high temperatures?
Four known forces in universe Strong Force
Electromagnetism Weak Force Gravity
Yes! (Electroweak)
Maybe (GUT)
14
Do forces unify at high temperatures?
Four known forces in universe Strong Force
Electromagnetism Weak Force Gravity
Yes! (Electroweak)
Maybe (GUT)
Who knows? (String Theory)
15
Planck Era Time lt 10-43 sec Temp gt 1032 K No
theory of quantum gravity All forces may have
been unified
16
GUT Era Time 10-43 10-38 sec Temp 1032
1029 K GUT era began when gravity became
distinct from other forces. GUT era ended when
strong force became distinct from electroweak
force.
17
Electroweak Era Time 10-10 10-10 sec Temp
1029 1015 K Gravity became distinct from other
forces. Strong, weak, and electromagnetic forces
may have been unified into GUT force.
18
Particle Era Time 10-10 0.001 sec Temp 1015
1012 K Amounts of matter and antimatter are
nearly equal. (Roughly one extra proton for
every 109 protonantiproton pairs!)
19
Era of Nucleosynthesis Time 0.001 sec5
min Temp 1012109 K Began when matter
annihilates remaining antimatter at 0.001
sec. Nuclei began to fuse.
20
Era of Nuclei Time 5 min380,000 yrs Temp
1093,000 K Helium nuclei formed at age 3
minutes. The universe became too cool to blast
helium apart.
21
Era of Atoms Time 380,000 years1 billion
years Temp 3,00020 K Atoms formed at age
380,000 years. Background radiation is released.
22
Era of Galaxies Time 1 billion
yearspresent Temp 203 K The first stars and
galaxies formed by 1 billion years after the
Big Bang.
23
Why is the darkness of the night sky evidence for
the Big Bang?
24

• Olbers Paradox
• infinite
• unchanging
• everywhere the same

If the universe were
then stars would cover the night sky.
25

• Olbers Paradox
• infinite
• unchanging
• everywhere the same

If the universe were
then stars would cover the night sky.
26
The night sky is dark because the universe
changes with time. As we look out in space, we
can look back to a time when there were no stars.
27
The night sky is dark because the universe
changes with time. As we look out in space, we
can look back to a time when there were no stars.
28
Primary Evidence in Support of the Big Bang Theory

• We have detected the leftover radiation from the
  Big Bang.
• The Big Bang theory correctly predicts the
  abundance of helium and other light elements.

29
How do we observe the radiation left over from
the Big Bang?
30
The cosmic microwave background the radiation
left over from the Big Bang was detected by
Penzias and Wilson in 1965.
31
Background radiation from the Big Bang has been
freely streaming across the universe since atoms
formed at temperature 3,000 K visible/IR.
Creation of the Cosmic Microwave Background
32
Background has perfect thermal radiation spectrum
at temperature 2.73 K
Expansion of the universe has redshifted thermal
radiation from that time to 1,000 times longer
wavelength microwaves.
33
Full sky in all wavelengths
34
WMAP gives us detailed baby pictures of structure
in the universe.
35
How do the abundances of elements support the Big
Bang theory?
36
Protons and neutrons combined to make
long-lasting helium nuclei when the universe was
3 minutes old.
37
Big Bang theory prediction 75 H, 25 He (by
mass) Matches observations of nearly primordial
gases
38
Abundances of other light elements agree with Big
Bang model having 4.4 normal mattermore
evidence for WIMPS!
39
Thought Question

• Which of these abundance patterns is an
  unrealistic chemical composition for a star?
• A. 70 H, 28 He, 2 other
• B. 95 H, 5 He, less than 0.02 other
• C. 75 H, 25 He, less than 0.02 other
• D. 72 H, 27 He, 1 other

40
Thought Question

• Which of these abundance patterns is an
  unrealistic chemical composition for a star?
• A. 70 H, 28 He, 2 other
• B. 95 H, 5 He, less than 0.02 other
• C. 75 H, 25 He, less than 0.02 other
• D. 72 H, 27 He, 1 other

41
What aspects of the universe were originally
unexplained by the Big Bang theory?
42
Mysteries Needing Explanation

• Where does structure come from?
• Why is the overall distribution of matter so
  uniform?
• Why is the density of the universe so close to
  the critical density?

43
Mysteries Needing Explanation

• Where does structure come from?
• Why is the overall distribution of matter so
  uniform?
• Why is the density of the universe so close to
  the critical density?
• An early episode of rapid inflation can solve all
  three mysteries!

44
How does inflation explain these features of the
universe?
45
Inflation can make structure by stretching tiny
quantum ripples to enormous sizes. These
ripples in density then become the seeds for all
structure in the universe.
46
How can microwave temperature be nearly identical
on opposite sides of the sky?
47
Regions now on opposite sides of the sky were
close together before inflation pushed them far
apart.
Inflation of the Early Universe
48
The overall geometry of the universe is closely
related to total density of matter and energy.
Density Critical
Density gt Critical
Density lt Critical
49
The inflation of the universe flattens the
overall geometry like the inflation of a balloon,
causing overall density of matter plus energy to
be very close to critical density.
50
How can we test the idea of inflation?
51
Patterns of structure observed by WMAP show us
the seeds of the universe.
52
Observed patterns of structure in universe agree
(so far) with the seeds that inflation would
produce
53
Observed patterns of structure in the universe
agree (so far) with the seeds that inflation
would produce.
54
Seeds Inferred from CMB

• Overall geometry is flat
• Total mass energy has critical density
• Ordinary matter 4.4 of total
• Total matter is 26 of total
• Dark matter is 22 of total
• Dark energy is 74 of total
• Age of 13.7 billion years

55
Seeds Inferred from CMB

• Overall geometry is flat
• Total mass energy has critical density
• Ordinary matter 4.4 of total
• Total matter is 26 of total
• Dark matter is 22 of total
• Dark energy is 74 of total
• Age of 13.7 billion years

In excellent agreement with observations of
present-day universe and models involving
inflation and WIMPs!
