Title: EECE 631 Microcomputer System Design Lecture 21: Timing


1
EECE 631Microcomputer System DesignLecture 21
Timing
  • Spring 2008
  • Chris Lewis
  • clewis_at_ksu.edu

2
Next Parameter Twr
3
Twr mins0
Address must Be valid at end Of WE pulse
4
Add to CPU timing diagram
5
Inequality
  • SMC_17_min gt Twr
  • 8gt0 OK

6
Next Parameter Twhz
7
Twhz mins0, max20,25
  • How long can memory
  • Stay on the data buss
  • After a read, going into A write?
  • 3 different terms
  • Each guarantee
  • Memorys withdraw
  • After WE (Twhz)
  • After CS (Thz)
  • After OE (Tohz)


8
Fundamental Understanding
  • If any one of these conditions satisfies the
    CPUs requirements then Memory will be off in
    time
  • Even though we have 3 different inequality
    constraints, not all have to be satisfied.

9
Twhz on CPU timing diagram?
SMC 19-23 provide Min times relative to rise of
write pulse In which cpu provided data will be
valid
10
Twhz and Tohz provide maximum time after some
signal In which memory will relinquish the buss
NRD
SMC22 Min.5Tcpmck -5.2
CPU provided data
SMC20 minnTcpmck -.5
memory provided data
Twhz min0,max(20,25)
Tohz min 0,max(20,30)
11
Which parameter Guarantees that memory will be
off the buss first, Twhz or Tohz?
NRD
CPU provided data
Smc20 minnTcpmck -.5
memory provided data
Twhz min0,max(20,25)
Tohz min 0,max(20,30)
12
Parameters are given relative to input signals
  • Tohz max(20,30) is given relative to the rising
    edge of the previous read pulse
  • Twhz max(20,25) is given relative to the falling
    edge of the current write pulse
  • When, relative to the clock do these two pulses
    occur?

13
When does Memory give up Control?
SMC 38 provide Min times before CS becomes
active that the read pulse rising edge occurs
14
ADD SMC38 to picture to give time reference for
Tohz
SMC38
NRD
CPU provided data
Smc20 minnTcpmck -.5
memory provided data
Twhz min0,max(20,25)
Tohz min 0,max(20,30)
15
When does NWR rise?
SMC 18 provide Min times before CS becomes
active that the read pulse rising edge occurs
16
ADD SMC18 to picture
SMC18
SMC38
NRD
CPU provided data
SMC20
memory provided data
Twhz min0,max(20,25)
Tohz min 0,max(20,30)
17
When does NWR fall?
SMC 18 SMC27 provide Min time Falling edge of
NWR occurs relative To rising edge of chip select
18
ADD SMC27 to picture SMC18 and SMC27 give time
reference to NWR leading edge
SMC18
SMC27
SMC38
NRD
CPU provided data
SMC20
memory provided data
Twhz min0,max(20,25)
Tohz min 0,max(20,30)
19
ADD SMC7 to picture This relates both edges to a
single event, NCS falling
SMC7
SMC18
SMC27
SMC38
NRD
CPU provided data
SMC20
memory provided data
Twhz min0,max(20,25)
Tohz min 0,max(20,30)
20
The inequalities
  • Relative to the start of the write cycle,
    (falling edge of Chip Select), the cpu takes
    control of the data buss at this time
  • SMC7 - SMC18 - SMC20
  • Relative to the start of write cycle, (falling
    edge of Chip Select), the memory guarantees HighZ
    at these times
  • SMC38Tohz
  • SMC7 -SMC18-SMC27Twhz
  • Two inequalities
  • SMC38Tohz lt SMC7 - SMC18 - SMC20
  • SMC7 - SMC18 - SMC27 Twhz lt SMC7 - SMC18 -
    SMC20
  • -SMC27 Twhz lt - SMC20

21
Guaranteed to have contention
  • Relative to the start of the write cycle,
    (falling edge of Chip Select), the cpu takes
    control of the data buss at this time
  • SMC7 - SMC18 - SMC20 (n1)Tcpmck-5.5-nTcpmck-.5
    Tcpmck-5ns
  • This is the latest time the cpu will take over
    not earliest time
  • Data is guaranteed to be valid at this time
  • Relative to the start of write cycle, (falling
    edge of Chip Select), the memory guarantees HighZ
    at these times
  • SMC38Tohz This is a good guarantee (23,33)ns
  • SMC7 -SMC18-SMC27Twhz
  • This is a good guarantee if SMC7 is taken without
    rise and falls
  • (n1)Tcpmck-5.5-(n)Tcpmck-2.5(20 or25)
  • Tcpmck 22ns for 70ns memory
  • Tcpmck 17ns for 55ns memroy
  • Two inequalities
  • (23,33) lt Tcpmck-5ns
  • Tcpmck 22ns lt. Tcpmck-5ns

22
Need to add data float wait states
  • How many need to be added?
  • Consider the effect on the following
  • Array0 10 // first write
  • Array1 20 // second write
  • V 0x8E // read followed by write
