ECE 4110: Sequential Logic Design

1
ECE 4110 Sequential Logic Design
2
ECE 4110 Sequential Logic Design

• Lecture 1
• Agenda
• Course Logistics
• Course Content
• Digital Review
• Announcements
• Welcome
• Homework 1 assigned

3
Course Overview

• Instructor Omar Elkeelany
• Office 331 Brown Hall Phone
  (931)-372-3677 Email oelkeelany_at_tntehc.edu
  Web http//iweb.tntehc.edu/oelkeelany
• Time / Location Lecture MWF 1010am
  1105am BN 321

4
Course Overview

• Textbook Digital Design Principles and
  Practices", 4th Addition John F. Wakerly,
  Prentice Hall, 2006
• Website http//iweb.tntech.edu/oelkeelany/4110F10

• all handouts, homework assignments are ONLINE
• it is your responsibility to download assignments

5
Course Overview

• Office Hours 331 Brown Hall MWF, 800am
  900am
• Also available by email appointment
• Pre-requisites ECE2110 / ECE3160
• Grading Homework/VHDL and Quizzes 20
• Combo System project 20
• Exam 1 20 Exam 2
  20
• Final Exam 20
• - Homework Assignments are due at the
  beginning of class.
• - No Late homework will be accepted.
• - No make up exams will be given, unless
  pre-execuesd before the test.
• Plan on being available on the exam dates.
  - Term paper assignment will be given for 5110
  graduate level.

6
Course Overview

• Where does this course fit into the Electrical
  Engineering curriculum?

7
Course Overview

• Where does this course fit into the Computer
  Engineering curriculum?

8
Course Content

• What is this course?- In ECE2110 you learned
  - basic combinational logic design - basic
  sequential logic design- In ECE3160 you
  learned - how to implement logic circuits
  using off-the-shelf parts- ECE4110 is a
  follow-on course that looks at - Large scale
  digital designs - Performance of digital
  circuitry - Programmable Logic

9
Course Content

• What does "Large" mean?
• - Large means that you can't do it by hand. We
  need a way to design and simulate Millions of
  gates- K-maps for a Pentium would take too much
  paper

10
Course Content

• We will learn VHDL in order to describe large
  digital designs - VHDL is a text based
  Hardware Description Language - We can
  simulate our digital designs created in VHDL

11
Course Content

• We can also prototype our designs using an FPGA
  - FPGA Field Programmable Gate Array - An
  FPGA is a programmable logic device - In this
  course,
• we will implement our designs and test them in
  FPGA hardware

12
Course Content

• What topics will be covered? 1) VHDL
  (Exam 1 Topics)
• 2) Medium Scale Combinational Logic Devices
• 3) More Complex Finite State Machines (Exam
  2 Topics) 4) Computer Systems 5) FPGA Timing
  and Implementation
• For the 5110 level, a special assignment is to
  Write an original research paper on a topic
  related to those in this course, such as
• Modern programmable logic devices, survey,
  features, comparisons, usage, etc..
• Hardware description languages survey,
  comparisons, usage, IP, etc.
• Sequential Logic Design methods

13
Digital Review

• Combinational Logic
• Combinational Logic Gates
• - Output depends on the logic value of the
  inputs
• - no storage

14
Digital Review

• NOT out in in f(in) in in
• OR out ab f(a,b) ab
• AND out ab f(a,b) ab

15
Digital Review

• XOR out a?b f(a,b) a?b
• NOR out ab f(a,b) ab
• NAND out ab f(a,b) ab

16
Digital Review

• XNOR out a?b f(a,b) a?b
• Also remember about XOR Gates
• f(a,b) a?b (ab ba)
• Also remember the priority of logic operations
  (without parenthesis) is
• NOT, AND, OR

17
Digital Review

• DeMorgans Theorems
• Inverting the output of any gate results in the
  same function as the opposite gate (AND/OR) with
  inverted inputs

18
Digital Review

• DeMorgans Theorems
• Graphically breaking the bar changes the logic
  function (AND-OR) under the break

out ab
1) Break bar
out ab
2) Change to under break
out ab
19
Digital Review

• Boolean Expressions Using SOP
• Logic functions can be described using a Sum of
  Products techniques
• Sum of Products (SOP) is the summation of all
  minterms resulting in the truth table
• A minterm is the expression for an input
  configuration which yields a TRUE output
• A minterm expression is the ANDing of the input
  "1" signal configuration

Truth Table a b out 0 0 0 0 1 1 minterm m1
ab 1 0 1 minterm m2 ab 1 1 0
SOP Expression f(a,b) ab ab Note
un-minimized Boolean expression
20
Digital Review

• Boolean Expressions Using POS
• Logic functions can be described using a Product
  of Sums techniques
• Product of Sums (POS) is the multiplication of
  all maxterms resulting in the truth table
• A maxterm is the expression for an input
  configuration which yields a FALSE output
• A maxterm expression is the ORing of the input
  "0" signal configuration

Truth Table a b out 0 0 0 maxterm m0 ab
(input configuration of 0's) 0 1 1 1 0 1 1 1 0
maxterm m3 a'b' (input configuration of 0's)
POS Expression f(a,b) (ab) (a'b')
21
Digital Review

• Boolean Expressions Using SOP POS
• SOP and POS functions are equivalent

SOP Expression f(a,b) ab ab
is equal to POS Expression f(a,b) (ab)
(a'b')
22
Digital Review

• Karnaugh Maps
• K-maps provide a graphical method to find SOP/POS
  expressions
• K-maps also provide a graphical method to perform
  logic minimization
• K-map SOP Process 1) Circle minterms to
  create SOP
• 2) Circle in Horizontal Vertical manner
• 3) Circle in groups with powers of 2
  (1,2,4,8,)

Truth Table a b out 0 0 0 0 1 1 1 0 1 1 1 1
No dependency on b, minterm a
No dependency on a, minterm b
SOP expression f(a,b) a b
23
Digital Review

• Karnaugh Maps
• K-maps provide a graphical method to find SOP/POS
  expressions
• K-maps also provide a graphical method to perform
  logic minimization
• K-map POS Process 1) Circle maxterms to
  create SOP
• 2) Circle in Horizontal Vertical manner
• 3) Circle in groups with powers of 2
  (1,2,4,8,)

Truth Table a b out 0 0 0 0 1 1 1 0 1 1 1 1
Dependency on a' and b', maxterm ab
POS expression f(a,b) a b
24
Digital Review

• Sequential Logic
• - Concept of Storage Element
• - With Storage, logic functions can depend on
  current past values of inputs
• - Sequential State Machines can be created
• D-Flip-Flop
• - on timing event (i.e., edge of clock input), D
  input goes to Q output

CLK
D
Q
tc2q
25
Digital Review

• State Machines
• - Moore Outputs depend on present state
• - Mealy Outputs depend on present state and
  current inputs

26
Digital Review

• State Machine Example Design a 2-bit Gray Code
  Counter

1) Number of States? 4 2) Number of bits to
encode states? 2n4, n2 3) Moore or Mealy?
Moore For this counter, we can make the outputs
be the state codes
27
Digital Review

• State Machine Example Design a 2-bit Gray Code
  Counter

STATE Current Next Acur Bcur Anxt Bnxt 0
0 0 1 0 1 1 1 1 1 1 0 1
0 0 0
Anxt Logic
Bnxt Logic
Bcur 0 1
Bcur 0 1
Acur 0 1
Acur 0 1
0
1
1
1
0
1
0
0
Anxt Bcur
Bnxt Acur
A
counter output
B
A
B
CLK
