Biology 2672a: Comparative Animal Physiology

1
Biology 2672a Comparative Animal Physiology

• Breathing in air

2
Gas transport in organisms - a combination of
convection and diffusion
Unidirectional flow (convection) in circulatory
system
Tidal convection ventilates lungs
Diffusion from capillaries into tissues
Diffusion into bloodstream
3
Concurrent gas exchange
Fig. 21.4a
4
Countercurrent gas exchange
Concurrent
Fig 21.4b
5
Countercurrent gas exchange
Concurrent
Fig 21.4b
6
Cross-current gas exchange
Fig. 21.5
7
Mammal lungs are inefficient
Fig. 21.19
Fig. 21.3
8
Breathing Air

• Lots of Oxygen!
• Not so easy to get rid of CO2
• Problems with water loss
• Lungs (invaginations)

9
(Most) Fishes Breathing Air
Plecostomus - Gut
Electric Eel - Mouth
Bowfin Swim bladder
Fig. 23.15
10
Tracheal system
Fig. 22.29
11
Construction of the tracheal system

• A branched series of tubes that are filled with
  air (except at the very ends)
• TracheagtTracheoles
• Terminal tracheoles
• Constructed from a single invaginated cell
• Distance between lumen cell 3 x cell
  membranes
• Fluid-filled

12
Tracheal system

• Very extensive
• no cell is more than 2-3 cell diameters from a
  tracheole
• Tissues with high metabolism (e.g. flight muscle)
  may have at least one terminal tracheole
  penetrating each cell (!)
• On-tap oxygen in every cell!

13
Gas transport in the tracheal system

• Diffusion works very well in gases
• Some convection
• Thorax abdomen pumping
• Caused by partial pressure gradients?
• Tracheal pumping? (see movie on WebCT)
• One-way flow systems
• Ram ventilation (draft ventilation)

14
Mammal lungs
Trachea
Bronchus
Alveoli
Alveolar duct
Terminal Bronchiole
Respiratory bronchiole
Fig. 21.18
15
Breathing air while flying

• Energetic costs of flying are 2.5-3 higher than
  running
• Two groups of extant flying vertebrates

16
Insects -Tracheal system reaches every cell
17
Ways to maximise O2 uptake

• Countercurrent exchange
• Reduce diffusion distance
• Increase flow rate
• Increase absorption of O2

18
Bird lungs a one-way system
Fig. 22.24
19
The bird lung - orientation
Anterior Air Sacs
Anterior 2 bronchus
Parabronchi
Posterior 2 bronchus
Posterior Air Sacs
1 bronchus
Mesobronchus
Beak
Butt
Fig. 22.22
20
Bird lung Breathe in
21
Bird lung Breathe Out
See also Fig 22.22
22
Bird Lungs Gas-blood

• Highly efficient
• gt37 of O2 extracted from the air
• Mammals 25
• Thin blood-gas barriers
• Surface area body size same as mammals
• Surface area lung volume 2 mammals

23
Bird Lungs Cross-current gas exchange
Fig. 22.23c
Fig. 22.5
24
Ways to maximise O2 uptake

• Countercurrent exchange
• Reduce diffusion distance
• Increase flow rate
• Increase absorption of O2

25
Bat lungs

• Mammalian alveolar dead space (etc)
• Equivalent O2 uptake to birds
• ?Heart size, ?Heart output
• ? Haematocrit
• Large lungs
• ?Surface area
• ?pulmonary blood volume
• ?thickness of blood-gas barrier

26
Bats vs birds

• Largest birds (18 kg) much larger than largest
  bats (1.5 kg)
• Birds function perfectly well (fly!) at high
  altitude
• Geese over Mt Everest
• Vulture in jet engine at 11.2 km
• High altitude climbers not plagued with bats

27
Reading for Thursday

• Blood
• Pp581-603
