CALIBRATING EQUIPMENT MECO

1
Measure, Conserve and Preserve is the new mantra
adopted for the future. MECO is concerned and
committed to the wise and efficient use of the
world's resources especially Power and
Electricity.
http//www.mecoinst.com/
2
CALIBRATING EQUIPMENT
Features/parameters
Display 5½ Digit Display
System (1 Phase) DC AC
Voltage (IV) AC/DC V (0 - 200mV to 1000V) AC/DC V (0 - 250mV to 1000V)
CURRENT (A) AC/DC A (0 - 100µA to 20A) AC/DC A (0 - 100µA to 50A) AC A (0 - 10mA to 100A)
PHASE ANGLE 0 to 359.99
POWER (1 PHASE) Range 0 to 100kW
POWER FACTOR Range -1 to 1
http//www.mecoinst.com/
3
UNIVERSAL cALIBRATOR
APPLICATIONS
Calibration of AC Volt, Amp, Frequency Meters
Calibration of DC Volt, Amp Meters
Calibration of Resistance Meters, Clamp Meters, Multimeters
STANDARD ACCESSORIES
1 x Key Adjuster
1 x Power Cord
1 x Pair of Output Leads
2 x Fuse (2A)
1 x Data Cable for PC Connectivity
1 x Operation Manual
GENERAL SPECIFICATIONS
Ripple lt 0.1
Stability DC lt 0.01 FS / 2 min, AC lt 0.03 FS / 2 min
Power Supply 230 VAC, 50 (60) Hz
Power Consumption lt 180 VA
Operating Temperature 5ºC to 35ºC
http//www.mecoinst.com/
4
AC MULTIFUNCTIONAL CALIBRATOR
Features/parameters
APPLICATIONS
Calibration of Power Meters, AC Volt, Amp, Watt, Var, Frequency, Powerfactor, Phase Angle and Energy Meters.
Calibration of Voltage, Current, Active Reactive Power, Frequency,
Powerfactor, Phase angle and Energy Transducers.
STANDARD ACCESSORIES
1 x Key Adjuster
1 x Power Cord
1 x Pair of Output Leads
2 x Fuse (2A)
1 x Data Cable for PC Connectivity
1 x Operation Manual
GENERAL SPECIFICATIONS
Power Range 0 to 100kW
l Power Basic Error (0.07 RD 0.03 FS)
l Stability V, I lt 0.01 FS / 2 min, P lt 0.02 FS / 2 min
l Distortion lt 0.5
l Power Factor Range -1 to 1
l Power Factor Basic Error 0.001 (PF 0 to 0.8) 0.0005 (PF -0.8 to -1, 0.8 to 1)
http//www.mecoinst.com/
5
MECO INSTRUMENTS PVT. LTD. Plot No. EL-1, MIDC
Electronic Zone, TTC Industrial Area,
Mahape, Navi Mumbai 400710. (INDIA)
Contact US Tel [phone]-16 (Sales),2767
3300 Fax [phone]
27673330
Email us - info_at_mecoinst.com
http//www.mecoinst.com/
