Title: Organized testable Design for Testability


1
Design For Testability
Towards Industry 4.0 IoT
2
Change from NPI
Past
Yesterday
Today
Vayo customer solved this issue. Ex.
Intel/Venture/SurfaceArt/Bosch
They may still happen at your side.
Above issues puzzles most of us.
Intelligent Vayo NPI software makes manufacturing
more agile and smart!
3
Are you always willing to stay with those issues?
Quality defects, reliability issue, process
headache, business risk
1
Design
4
Equipment programming
  • No thermal consideratiaon, small annual ring
    small, silkscreen error, Silkscreen incomplete,
  • gt30 PCB design comes with problem.
  • Wrong polarity, location offset, inline
    fine-tune,
  • Lower test coverage, lower utilization,

2
Manufacturing
NPI cycle
5
  • Short, open, tombstone, cold sold, Void,
  • gt60 defects could be found prior to build
  • Frequent prototyping, high cost
  • Long cycle, impact time to market,

3
6
Post sales
Process design
  • sold joint crack, sold joint peeloff,
  • Repair rate for consumer product 537 in
    initials 3 years
  • Difficult to transfer knowledge
  • No effective tool to continually improve process
    capability

IPC research 80 defects could be found and
resolve during NPI stage.
4
Core product Intelligent NPI software for PCBA
  • Reduce design mfg cycle 30-70
  • Reduce quality defects 30
  • Increase reliability 30
  • Increase design and mfg efficiency 40
  • Reduce design and mfg cost 20

Intelligent DFx analysis
PCB layout Eng., process Eng. NPI Eng.
NPINew Product Introduction
5
Company introduction
  • Founded on Jan of 2005, headquarter in
    China/Shanghai
  • Dedicates to intelligent NPI software to
    accelerate design to manufacturing
  • Fully in-house development, owns copyrights and
    patents
  • Product installed gt20 countries and regions
    worldwide
  • Strategy partnership with equipment and EDA
    provider Keysight/ViTrox/TRI/Fuji/Panasonic/Altiu
    m

gt10 years dedication on NPI technology brings up
the world-class product.
6
Contact Us Address Calle Independencia 1018
 L201 Edificio 2, Col. Parques del Bosque,
Tlaquepaque Jalisco Mexico, CP 45609 Website
www.vayoinfo.com Email sales_at_vayoinfo.com
