Modularity and the Evolution of Software Evolvability

1
Modularity and the Evolution of Software
Evolvability

• Dissertation Talk
• Terry Van Belle
• August 11, 2004

2
Biological Modularity, example

• Halder et al (1995)
• Mis-expression of Eyeless cDNA caused extra eyes
  to form on wings, legs, and antennae of
  Drosophila
• Eyes were structurally complete
• Cornea, bristles, photoreceptors, electrically
  responsive to light
• Master control for eye formation

3
Biological Modularity

• More complex organisms have modular genotypes
  (developmental biology)
• Module is
• A complex of genes
• Single purpose
• Limited pleiotropic and epistatic influence on
  other modules
• Open question How does biological modularity
  evolve?
• Modularity improves evolvability
• Wagner/Altenberg (1995)
• Allows for independently evolving traits
• Equal fitness, different evolvabilities

4
Software Evolvability

• Software evolves?
• Software adapts to environmental changes
• Environment User Requirements
• Beyond version 1.0
• Software Evolvability
• Ability to change software in response to changes
  in requirements
• Short-term success vs. Long-term success
• Software Archaeology
• Examination of software change histories for
  evolvability clues
• Evolutionary Metrics
• Orthogonal to traditional Static vs. Dynamic
  dichotomy

5
Dissertation Talk Structure

• Software modularity allows for the evolution of
  independently changing features
• Three Approaches
• Evolution of Code Factoring (Analysis)
• The Effectiveness of Interfaces (Analysis)
• Optimizing Code Modularity (Synthesis)
• Contributions

6
Evolution of Code Factoring

• Literal evolution of evolvability to improve
  modularity
• Factoring code minimizes number of necessary
  changes
• Can Genetic Programming in a changing environment
  discover this fact?
• Supply the genomes with an Automatically Defined
  Function
• Symbolic regression on y Asin(Ax)
• A varies every five generations
• A factored representation evolved
• Unfortunately, EC with dynamic fitness function
  doesnt scale well
• y Asin(Ax) Bsin(Bx)
• Van Belle and Ackley (GECCO 2002)

7
The Effectiveness of Interfaces

• Interfaces limit the spread of changes
• Percolation network model of software change
• Interfaces improve evolvability, but
• They split work into small/frequent and
  rare/large changes (Highly Optimized Tolerance)
• Software Archaeology
• Used data from public-domain Java software
  projects
• CVS change history to find out what types of
  language elements changed

8
Optimizing Package Structure

• Can we generate a package structure better than
  the existing one?
• Elements are Java files from open-source projects
• Jikes RVM, Jakarta Tomcat, Net Beans
• Changed if added, deleted, or touched
• Hourly granularity
• Partition files into packages
• Compare results with current modularity, as
  expressed by unique directory names

9
Clustering, Change Correlations

• Correlation of changes between files
• We want to group highly correlated files together
• Use a 2x2 contingency table
• r
• Set a correlation threshold parameter

AD-BC
F2
!F2
A
B
F1
v (AB)(CD)(AC)(BD)
C
D
!F1
10
Clustering Algorithm
F2
0.5
-0.3
F1
F3
0.1
1.0
0.7
0.4
0.7
F4
0.2
0.9
-0.2
-0.1
F5
F6
0.0
11
Clustering Algorithm
F2
F1
F3
F4
F5
F6
12
Modularity Metrics

• Why do we use modules?
• Aggregation
• Segregation
• Module design lies in the tension between these
  forces
• Two metrics to capture these forces
• Breadth average number of modules touched
• Weight average total touched module size

13
Modularity Metrics, continued

• Breadth is trivially minimized by putting all
  files in one module
• Weight is trivially minimized by giving every
  file its own module
• Ideally we want to minimize both

Coarse-grained
Weight
Ideal
Fine-grained
Breadth
14
ModPartition Algorithm

• Variant of the Kernighan-Lin Algorithm
• A greedy algorithm, but able to move through
  fitness valleys
• Allows clusters to move across modules
• Adapted to generate module structure
• Use fitness instead of edge crossings
• Fitness ? breadth weight
• Pre-set maximum number of modules

15
FastModPartition Algorithm

• ModPartition is too slow for real code
• Want an adaptive number of modules
• A quicker, recursive version of ModPartition
• First, divide into modules 0 and 1
• Divide module 0 into 0 and 2
• Divide module 1 into 1 and 3, and so on
• Stop after predetermined limit, or when modules
  dont split anymore
• Two orders of magnitude faster than ModPartition

16
Modularity Scores, Jikes
17
Modularity Scores, Jakarta Tomcat
18
Modularity Scores, Net Beans
19
Jikes Evolution
Package declarations
Time (changes)
examples
jdp
on-stack replacement
Files (alphabetical by directory)
JMTk
20
Jikes Change Correlations
examples
on-stack replacement
arch
JMTk
21
Sample Module, Jikes RVM

• Module 4
• rvm/src/vm/arch/intel/runtime/VM_DynamicLinkerHelp
  er.java
• rvm/src/vm/arch/powerPC/runtime/VM_DynamicLinkerHe
  lper.java
• rvm/src/vm/compilers/optimizing/ir/util/OPT_BasicB
  lockEnumeration.java
• rvm/src/vm/compilers/optimizing/ir/util/OPT_IREnum
  eration.java
• rvm/src/vm/compilers/optimizing/ir/util/OPT_Instru
  ctionEnumeration.java
• Note the repeated names
• Intel and PowerPC architecture-specific files are
  grouped together
• Group by function, not implementation

22
Existing Structure
vm
arch
powerPC
intel
. . .
runtime
runtime
. . .
VM_DLH.java
VM_DLH.java
. . .
. . .
23
Refactored Structure
vm
runtime
. . .
VM_IntelDLH.java
VM_PowerPCDLH.java
. . .
24
Contributions

• Grounding software engineering in evolutionary
  history
• Made explicit the link between evolvability and
  code factoring, using EC
• Formed a link between HOT and Software
  engineering
• Developed automated techniques that improved
  software modularity
• Devised new metrics for measuring evolvability
• Techniques discovered a package design principle

25
Extra Material
26
Increasing Evolvability over Time
27
Sample Solution
ADF0
RPB
-

-
exp
sin
/
adf0
exp

cos
sin
sin
sin
x
adf0
0.938
0.645
0.645
0.610
28
The Benefits of Encapsulation
AreaAverager
height, width
radius
side
Circle
Square
Rectangle
29
The Benefits of Encapsulation
rarely changes
AreaAverager
Shape
area()
Circle
Square
Rectangle
30
Language Elements Jikes RVM
31
Highly Optimized Tolerance

• Doyle and Carlson 1999
• Engineering a system produces a heavy-tailed
  distribution of failures
• Conservation of Fragility
• Encapsulation Engineering the system
• Failure Change
• Programming by interfaces induces a Conservation
  of Change

32
Evolvability Metrics

• Likelihood
• Probability that an element is part of a change
• Impact
• Expected change size, given element has changed
• Work
• Likelihood Impact
• Acuteness
• Impact / Likelihood
• Acute Interfaces vs Chronic Implementations

33
Calculating Breadth
Unchanged
x
Changed
Module Changed
Time
x
x
x
x
x
x
x
x
x
x
Files
x
x
x
x
x
x
x
x
x
x
x
x
x
x
2
1
2
4
1
1
3
2
Breadth 2
34
Calculating Weight
Unchanged
x
Changed
Module Changed
Time
x
x
x
x
x
x
x
x
x
x
Files
x
x
x
x
x
x
x
x
x
x
x
x
x
x
5
4
3
10
4
1
6
6
Weight 4.875
