ASC Machine Tools, Inc'

1
ASC Machine Tools, Inc.
2
Select Series IPrecut Rollforming LineNote
Some Machine Guards have been removed for photo
clarity.
3
Select Series 10,000 lb. Single Arm Uncoiler
Shown with optional 10,000 lb. Coil Car
4
Select Series Option 10,000lb. Coil Car
5

• Hydraulic Power Unit
• Variable Volume
• Pressure Compensated

6
Select Series Precut System
Hydraulic Up-Cut Shear
Inboard Entry Guide Rail with Line Encoder.
Entry Guide Rail
7
Select Series Precut System
8
Infeed Guide Table
9
Easy Guide Adjustment
10
Positioning Rollers
11
Select Series Pre-Cut Cutoff Shear
12
Hydraulic Up-Cut Shear Design
13
Precut Sheet Conveyor(Belt over Roller)
14
Powered Rollformer Infeed System
15
Steel Weldment Rollformer Base
16
Precision Mounted Roll Stands
All stand passes are numbered.
All inboard drive side stands are pinned into
location.
17
Heavy Duty Casted No. 4 Stands
18
Precision Tooling
19
Standard Profile Tooling Available
Tooling from pre-heat treated material with a
hard chrome finish.
48 Mill Tool Space
20
Easy Identification of Tooling
All tooling is located with spacers to the
inboard machined shoulder of shafts. No Clamp
Collars.
All tools are numbered for easy identification
21
Stand Adjustment
Precision Micrometer for Fine Adjustments
22
Shaft locknut ensures shaft to bearing surface
location.
23
Precision Machined Rollformer Base
24
Sprocket to Sprocket Drive
25
Chain Driven Shafts
26
Center Mounted Rollformer Drive
27
Optional Magnetic Stacker
28
Optional Side Discharge Conveyor From Magnetic
Stacker
29
Optional CNC500 Controller with upload/download
server software.
