Statistical physics and finance

1
Statistical physics and finance

• I. Kondor
• Collegium Budapest and Eötvös University
• Seminar talk at Morgan-Stanley Fixed Income
• Budapest, March 1, 2007

2
Coworkers

• Sz. Pafka (ELTE CIB Bank Paycom, Santa Monica)
• G. Nagy (Debrecen University CIB Bank)
• R. Karádi (Budapest University of Technology
  ProcterGamble)
• N. Gulyás (ELTE Budapest Bank Lombard Leasing
  ELTE Collegium Budapest)
• I. Varga-Haszonits István (ELTE Morgan-Stanley)
• G. Papp (ELTE)
• A. Ciliberti (Roma and ScienceFinance, Paris)
• M. Mézard (Orsay)

3
Contents

• Links between economics and physics
• What can physics offer to finance that
  mathematics might not?
• Three examples random matrices, phase
  transitions and replicas

4
Early links

• The physics-complex of classical economics
• Maxwell
• Bachelier

5
Physicists in finance

• From the early nineties on financial institutions
  hire more and more physicists.
• Some 30-35 of the invited speakers of risk
  managements conferences are ex-physicists.
• Today finance is one of the standard fields of
  employment for physics graduates and PhDs (EU
  document on the harmonization of the Bologna-type
  higher education curricula Tuning Educational
  Structures in Europe http//tuning.unideusto.org/
  tuningeu/ ).

6
Econophysics is there such a thing?

• The term was introduced by H. E. Stanley, it is
  not universally beloved, but wide-spread.
• Do these two disciplines have anything to do with
  each other?
• A trivial answer we are dealing with stochastic
  processes in finance, and statistical physics is
  their main field of application.
• But the theory of stochastic processes in its
  pure form belongs to probability theory.

7
So the question is Why do banks hire not only
probabilists, applied mathematicians, computer
scientists, statisticians, etc., but also
physicists?

• What is the special knowledge or skill, if any,
  that physicists can bring into finance? What can
  physics offer to finance? (Stanley at the Nikkei
  conference)
• A common, albeit vague, answer modeling skills,
  creative use of mathematics, knowledge of a
  wide spectrum of approximation and numerical
  methods, etc. may contribute to the market value
  of physicists.

8
A bit deeper

• Physics has got the farthest in the understanding
  of strongly interacting systems and collective
  phenomena.
• Textbook-economics is, at best, on the conceptual
  level of mean-field theory even today
  (representative agent).
• The building up of structures and new qualities
  from simple interactions, emergence, collective
  coordinates, averaging over microscopic degrees
  of freedom, etc. these conceptual tools are not
  known in finance or economics at large (cf. Basel
  II).

9
Therefore I think that

• some knowledge of quantum mechanics, many body
  problem, field theory, renormalisation, phase
  transitions, nonlinear and complex systems, etc.,
  although neither necessary nor sufficient, may be
  useful (as a conceptual introduction or just as a
  source of metaphores) in the understanding of
  social phenomena, including the market.

10
In this talk I will illustrate the use of
conceptual tools imported from physics on the
following three examples

• Random matrices
• Phase transitions and critical phenomena
• Replica method

11
The concrete field of application will be the
problem of portfolio selection

• The basic question How to distribute our wealth
  over the set of possible investment instruments
  so that to earn the highest return at the lowest
  risk?
• Here I will focus my attention on the minimal
  risk portfolio, irrespective of the return.

12
The original formulation of the problem

• The returns , i1,2,,N, are random
  variables drawn from a known (say, multivariate
  normal) distribution, with covariance matrix
  ( is the correlation
  matrix, the standard deviation of ).
• Find the weights , , for
  which the variance
• of the portfolio
  is minimal.

13
Unconstrained short selling

• We have not stipulated that the weights be
  positive, they can be of either sign, with an
  arbitrarily large absolute value. This is
  obviously unrealistic, for, among other things,
  liquidity reasons. Nevertheless, it is useful to
  consider the problem first in this idealised form
  (just as the finance text-books do), because then
  the optimal weights can be calculated
  analytically
• If we ban short selling, the task becomes one in
  quadratic programming.

14
Infinite volume limit

• Allowing unlimited short selling makes the domain
  of the optimization task infinite. This is not an
  innocent idealisation, because, as we will see,
  the solution vector can show huge fluctuations,
  and the restriction on the domain could bound
  these fluctuations .
• Similarly to the theory of phase transitions,
  however, it is expedient to understand the
  essence of the phenomenon in the limit of
  infinite volume, and take into account the
  finite-volume effects only later.

15
Variants of the problem

• When we use the standard deviation as a risk
  measure, we are assuming that the underlying
  process is normal, or has some similarly
  concentrated distribution. Typically, financial
  processes are not like this.
• Alternative risk measures mean absolute
  deviation (MAD), average loss above a high
  threshold (ES), maximal loss (ML), or, indeed,
  any homogeneous convex functional defined over
  the distribution of the losses.

16
Empirical covariance matrices

• The covariance matrix has to be determined from
  measurements on the market. From the returns
  observed at time t we have the estimator
• The number of covariance matrix elements of a
  portfolio composed of N instruments is O(N²). In
  the time series of length T of N instruments we
  have NT data. In order to have a precise
  estimate, we should have N ltltT . Large portfolios
  can contain hundreds of instruments, while it is
  hardly meaningful to use data older than, say, 4
  years, that is T1000. Therefore the inequality
  N/T ltlt 1 almost never holds in reality. Thus our
  estimates will contain a lot of noise, and the
  estimation error will depend on the scaling
  variable N/T .

17
Information deficit

• Thus the Markowitz problem suffers from the
  curse of dimensions, or from information
  deficit
• The estimates will contain error and the
  resulting portfolios will be suboptimal
• How serious is this effect?
• How sensitive are the various risk measures to
  this kind of error?
• How can we reduce the error?

18
Fighting the curse of dimensions

• Economists have been struggling with this problem
  for ages. Since the root of the problem is lack
  of sufficient information, the remedy is to
  inject external info into the estimate. This
  means imposing some structure on s. This
  introduces bias, but beneficial effect of noise
  reduction may compensate for this.
• Examples
• single-index models (ßs) All these help
  to
• multi-index models various degrees.
• grouping by sectors Most studies are
  based
• principal component analysis on
  empirical data
• Bayesian shrinkage estimators, etc.
• Random matrix theory

19
Random matrices
20
Origins of random matrix theory (RMT)

• Wigner, Dyson 1950s
• Originally meant to describe (to a zeroth
  approximation) the spectral properties of heavy
  atomic nuclei
• - on the grounds that something that is
  sufficiently complex is almost random
• - fits into the picture of a complex system, as
  one with a large number of degrees of freedom,
  without symmetries, hence irreducible, quasi
  random.
• - markets, by the way, are considered stochastic
  for similar reasons

21
RMT

• Later found applications in a wide range of
  problems, from quantum gravity through quantum
  chaos, mesoscopics, random systems, etc., etc.
• Has developed into a rich field with a huge set
  of results for the spectral properties of various
  classes of random matrices
• They can be thought of as a set of central limit
  theorems for matrices

22
Wigner semi-circle law

• Mij symmetrical NxN matrix with i.i.d. elements
  (the distribution has zero mean and finite second
  moment)
• ?k eigenvalues of
• The density of eigenvalues ?k (normed by N) goes
  to the Wigner semi-circle for N?8 with prob. 1
• ,
• , otherwise

23
Remarks on the semi-circle law

• Can be proved by the method of moments (as done
  originally by Wigner) or by the resolvent method
  (Marchenko and Pastur and countless others)
• Holds also for slightly dependent or
  non-homogeneous entries
• The convergence is fast (believed to be of 1/N,
  but proved only at a lower rate), especially what
  concerns the support

24
Wishart matrices

• Generate very long time series for N iid random
  variables, with an arbitrary distribution of
  finite variance, and cut out samples of length T
  from these, as if making empirical observations.
• The true covariance matrix of these variables
  is the unit matrix, but if we try to reconstruct
  this from the simulated samples we will not
  recover the unit matrix for any finite T.
  Instead, we will have an empirical covariance
  matrix.

25
Correlation matrix of iid normal random variables

• The spectrum consists of a single,
  N-fold degenerate
• eigenvalue ? 1
• The noise lifts the degeneracy and makes
  a band out of the single eigenvalue.

1
0
C
26
The corresponding empirical covariance matrix
is the Wishart matrix

• If N and T ?8 such, that their ratio r N/T
  is fixed, lt 1, then the spectrum of this
  empirical covariance matrix will be the Wishart
  or Marchenko-Pastur spectrum (eigenvalue
  distribution)
•

  where

27
Remarks

• The theorem also holds when the (average) sample
  covariance matrix is of finite rank
• The assumption that the entries are identically
  distributed is not necessary
• If T lt N the distribution is the same with an
  extra point of mass 1 T/N at the origin
• If T N the Marchenko-Pastur law is the squared
  Wigner semi-circle
• The proof extends to slightly dependent and
  inhomogeneous entries
• The convergence is fast, believed to be of 1/N ,
  but proved only at a lower rate

28
N1000 T/N2
29

• If the matrix elements are not centered but have,
  say, a common mean, one large eigenvalue breaks
  away, the rest stay in the random band
• Eigenvector components just as in the Wigner
  case, the eigenvectors in the bulk are random,
  the one outside is delocalized (has nonzero
  entries everywhere)
• There is a lot of fluctuation, level crossing,
  random rotation of eigenvectors taking place in
  the random band
• The eigenvector belonging to the large eigenvalue
  (when there is one) is much more stable. The
  larger the eigenvalue, the more so.

30
An intriguing observation

• L.Laloux, P. Cizeau, J.-P. Bouchaud, M. Potters,
  PRL 83 1467 (1999) and Risk 12 No.3, 69 (1999)
• and
• V. Plerou, P. Gopikrishnan, B. Rosenow, L.A.N.
  Amaral, H.E. Stanley, PRL 83 1471 (1999)
• noted that there is such a huge amount of noise
  in empirical covariance matrices that it may be
  enough to make them useless.
• A paradox Covariance matrices are in widespread
  use and banks still survive ?!

31
Laloux et al. 1999
The spectrum of the covariance matrix obtained
from the time series of SP 500 with N406,
T1308, i.e. N/T 0.31, compared with that of a
completely random matrix (solid curve). Only
about 6 of the eigenvalues lie beyond the random
band.
32
Remarks on the paradox

• The number of junk eigenvalues may not
  necessarily be a proper measure of the effect of
  noise The small eigenvalues and their
  eigenvectors fluctuate a lot, indeed, but perhaps
  they have a relatively minor effect on the
  optimal portfolio, whereas the large eigenvalues
  and their eigenvectors are fairly stable.
• The investigated portfolio was too large compared
  with the length of the time series (although it
  is hard to find a better ratio in practice).
• Working with real, empirical data, it is hard to
  distinguish the effect of insufficient
  information from other parasitic effects, like
  nonstationarity (which is why we prefer to work
  with simulated data for the purposes of
  theoretical studies).

33
A filtering procedure suggested by RMT

• The appearence of random matrices in the context
  of portfolio selection triggered a lot of
  activity, mainly among physicists. Laloux et al.
  and Plerou et al. proposed a filtering method
  based on random matrix theory (RMT) subsequently.
  This has been further developed and refined by
  many workers.
• The proposed filtering consists basically in
  discarding as pure noise that part of the
  spectrum that falls below the upper edge of the
  random spectrum. Information is carried only by
  the eigenvalues and their eigenvectors above this
  edge. Optimization should be carried out by
  projecting onto the subspace of large
  eigenvalues, and replacing the small ones by a
  constant chosen so as to preserve the trace. This
  would then drastically reduce the effective
  dimensionality of the problem.

34

• Interpretation of the large eigenvalues The
  largest one is the market, the other big
  eigenvalues correspond to the main industrial
  sectors.
• The method can be regarded as a systematic
  version of principal component analysis, with an
  objective criterion on the number of principal
  components.
• In order to better understand this novel
  filtering method, I introduce a simple market
  model

35
Simple modell market sectors

single
- fold degenerate
1
- fold degenerate
36

• The empirical covariance martix corresponding to
  this model consists of the Marchenko Pastur
  spectrum, a large (Frobenius-Perron) eigenvalue
  (the whole market), and a number of medium-sized
  eigenvalues.
• If we resolve the equivalence of the sectors,
  with the appropriate tuning of the parameters we
  can mimic the spectrum observed on real markets
  (Noh model)

37

• We have made extensive studies on the RMT-based
  filtering, and found that it performs
  consistently well compared with other, more
  conventional methods.
• An additional advantage is that the method can be
  tuned according to the assumed structure of the
  market.
• There are attempts to extract information from
  below the random band edge.

38
Divergent sampling error an algorithmic phase
transition
39
A measure of the effect of noise

• Assume we know the true covariance matrix and
• the noisy one . Then a natural, though not
  unique,
• measure of the impact of noise is
• where w are the optimal weights corresponding
• to and , respectively.

40
The model-simulation approach

• For the purposes of our numerical calculations
  we chose various model covariance matrices
  and generated long simulated time series with
  them. Then we cut out segments of length T from
  these time series, as if observing them on the
  market, and tried to reconstruct the covariance
  matrices from them. We optimized a portfolio both
  with the true and with the observed
  covariance matrix and determined the measure .

41
Fluctuations over the samples

• The relative error refers to a given
  sample, so it is a random variable that
  fluctuates from sample to sample.
• Likewise, there are strong fluctuations in the
  weights of the optimal portfolio

42
The distribution of qo over the samples
43
The average of qo as function of N/T
44
The divergent error signals an algorithmic phase
transition (I.K., Sz. Pafka, G. Nagy)

• The rank of the covariance matrix is minN,T
• In the limit N/T 1 the lower band edge of
  eigenvalues goes to zero, around the lower edge
  there are many small eigenvalues many soft
  modes.
• N/T 1 is the critical point of the problem
• Upon approaching the critical point we find
  scaling laws, e.g.
• the expectation value of the portfolio error is
  ,
• while the standard deviation diverges as
• For TltN zero modes appear and the optimization
  becomes meaningless

45
Fluctuations of the weights the distribution of
the weights of a portfolio consisting of N100
iid normal variables, in a given sample, for T500
46
Sample to sample fluctuation of the weight of a
given instrument, non-overlapping windows, N100,
T500
47
Fluctuation of the weight of a given instrument,
step by step moving average, N100, T500
48
After RMT filtering the error drops to an
acceptable level and we can even penetrate the
region TltN
49
Finite volume

• A ban on short selling, or any other constraint
  that renders the domain of optimization finite,
  or filtering will all supress the infinite
  fluctuations. However, the weights will keep
  wildly fluctuating as we approach N/T1 and an
  increasing part of them will stick to the walls
  of the allowed region. These zero weights will
  belong to different instruments in different
  samples. If we are not sufficiently far away from
  the critical point, the solution of the Markowitz
  problem cannot serve as the basis of rational
  decision making.

50
Universality

• We have studied a number of different market
  models, different risk measures and different
  underlying processes (including fat tailed ones,
  and, with István Varga-Haszonits, also
  autoregressive, GARCH-like processes). The value
  of the critical point and the coefficients can
  change, but we have not yet found convincing
  evidence for any change in the critical exponents
  we have not yet discovered the boundaries of
  the universality class.

51
How come these phenomena have not been noticed
earlier?

• Somehow the scaling has escaped attention
• Typically, econometricians study the limit
  Nfixed, T?8 , rather than N/Tfixed, N,T ?8 .
• The instability of the weights is an everyday
  experience, but the idea that their fluctuations
  can actually diverge has not arisen. If one
  insists on using empirical data, one cannot study
  the fluctuations over the samples, because there
  are not enough of them.
• Random matrices, critical phenomena, zero modes,
  etc. are mostly unknown in finance.
• The different aspects of the problem have not
  been integrated into a coherent picture that can
  only be achieved on the basis of the phase
  transition concept.

52
Replicas
53
Optimization and statistical mechanics

• Any convex optimization problem can be
  transformed into a problem in statistical
  mechanics, by promoting the objective function
  into a Hamiltonian, and introducing a fictitious
  temperature. At the end we can recover the
  original problem in the limit of zero
  temperature.
• Averaging over the time series segments (samples)
  is similar to what is called quenched averaging
  in the statistical physics of random systems one
  has to average the logarithm of the partition
  function (i.e. the cumulant generating function).
• Averaging can then be performed by the replica
  trick a heuristic, but very powerful method
  that is on its way to be firmly established by
  mathematicians (Guerra and Talagrand).

54
The first application of replicas in a finance
context the ES phase boundary (A. Ciliberti,
I.K., M. Mézard)

• ES is the average loss above a high threshold ß
  (a conditional expectation value). Very popular
  among academics and slowly spreading in practice.
  In addition, as shown by Uryasev and Rockafellar,
  the optimization of ES can be reduced to linear
  programming, for which very fast algorithms
  exist.
• Portfolios optimized under ES are much more noisy
  than those optimized under either the variance or
  absolute deviation. The critical point of ES is
  always below N/T 1/2 and it depends on the
  threshold, so it defines a phase boundary on the
  N/T- ß plane.
• The measure ES can become unbounded from below
  with a certain probability for any finite N and T
  , and then the optimization is not feasible!
• The transition for finite N,T is smooth, for N,T
  ?8 it becomes a sharp phase boundary that
  separates the region where the optimization is
  feasible from that where it is not.

55
Formulation of the problem

• The time series of returns
• The objective function
• The variables
• The linear programming problem
• Normalization

56
Associated statistical mechanics problem

• Partition function
• Free energy
• The optimal value of the objective function

57
The partition function

• Lagrange multipliers

58
Replicas

• Trivial identity
• We consider n identical replicas
• The probability distribution of the n-fold
  replicated system
• At an appropriate moment we have to analytically
  continue to real ns

59
Averaging over the random samples

• where

60
Replica-symmetric Ansatz

• By symmetry considerations
• Saddle point condition
• where

61
Condition for the existence of a solution to the
linear programming problem

• The meaning of the parameter
• Equation of the phase boundary

62
(No Transcript)
63
The limit

• The problem goes over into the minimax problem of
  maximal loss
• In this limit the phase boundary can be
  determined by a direct geometric argument (I.K.,
  Sz. Pafka, G. Nagy)

64
The probability of the solvability of the minimax
problem

• For TgtN the probability of a solution (for any
  elliptical underlying process)
• (The problem is isomophic to some operations
  research or random geometrical tasks Todd, M.J.
  (1991), Probabilistic models for linear
  programming, Math. Oper. Res. 16, 671-693. )
• For large N and T , p goes over into the error
  function.
• For N,T? 8, the transition becomes sharp at
  N/T1/2.

65
(No Transcript)
66
(No Transcript)
67
Conclusions

• P.W. Anderson The fact is that the techniques
  which were developed for this apparently very
  specialized problem of a rather restricted class
  of special phase transitions and their behavior
  in a restricted region are turning out to be
  something which is likely to spread over not just
  the whole of physics but the whole of science.

68
In a similar spirit...

• I think the phenomenon treated here, that is the
  sampling error catastrophe due to lack of
  sufficient information appears in a much wider
  set of problems than just the problem of
  investment decisions. (E.g. multivariate
  regression, all sorts of linearly programmable
  technology and economy related optimization
  problems, microarrays, etc.)
• Whenever a phenomenon is influenced by a large
  number of factors, but we have a limited amount
  of information about this dependence, we have to
  expect that the estimation error will diverge and
  fluctuations over the samples will be huge.
