FPGA Based Fuzzy Logic Controller for SemiActive Suspensions

1
FPGA Based Fuzzy Logic Controller for Semi-Active
Suspensions

• Aws Abu-Khudhair

2
Outline

• Types of Suspension Systems
• Project Objective

3
DSP and Reconfigurable Computing Systems

• Aws Abu-Khudhair

4
Outline

• What is DSP?...
• Implementation of Various Algorithms
• Advantages of FPGA in DSP
• Tools available/Mapping DSP onto FPGA

5
Resources

• 1 A Primer on FPGA-Based DSP Applications, by
  Acromag Inc.
• 2 Designing Digital Signal Processing with
  FPGAs, by Allen Kinast
• 3 FPGA Implementations of Fast Fourier
  Transforms for Real-Time Signal and Image
  Processing, by I.S. Uzun, A. Amira and A.
  Bouridane
• 4 Choosing the Right Architecture for
  Real-Time Signal Processing Designs, by Leon
  Adams.
• 5 Digital Signal Processors Applications and
  Architectures, by Kurt Keutzer

6
What is DSP?

• Concerned with the manipulation of signals for
• Filtering
• Transformation
• Decoding/Encoding etc.
• Widely implemented in PDSP

7
DSP Applications

• Wireless Communication
• Audio Applications
• Image Processing/Medical Imaging
• Networking
• Weather forecasting

8
Various Algorithms

• Finite Impulse Response (FIR) filters
• Fast Fourier Transforms (FFT)
• Infinite Impulse Response (IIR) filters
• Forward Error Correction (FEC)
• Modulation/Demodulation

9
DSP Implementation Comparison
Most suitable technology??
10
PDSP vs. FPGA

• PDSP
• Specialized microprocessor based on the Von
  Neumann arch.
• Programmed in C/assembly for performance
• Suited for complex math-intensive tasks, with
  conditional processing.
• Limited in performance by the clock rate and
  number of operations it can perform per clock
  cycle.
• e.g. TMS320C6201 has 2 multipliers 200MHz clock
  ? 400M multipliers/second

11
PDSP vs. FPGA cont.

• FPGA
• Uncommitted gates
• Programmed by HDL.
• Performance limited by the number of gates and
  clock rate.
• Suited for a wide range of applications

12
Advantages/Disadvantages of FPGA

• Advantages
• Parallel Processing (Performance)
• Flexible Architecture
• Price
• Power Demand compared to DSP
• Disadvantages
• Higher development cost and increased time to
  market than DSP
• Implementation of conditional processing

13
Important Building Blocks

• Add
• Subtract
• Multiply
• Multiply and Add
• Multiply and Accumulate (MAC) Unit

14
256 Tap FIR Filter
Conventional DSP Serial processing
256 Loops needed to process samples 1 FIR tap per
DSP instruction cycle
15
256 Tap FIR Filter cont.
FPGA Parallel processing
All 256 MAC operations in 1 clock cycle
16
FPGA Design Flexibility
Multiply and Add
FPGA Design Optimization
Parallel
Semi-Parallel
Serial
D Q

Q (A x B) (C x D) (E x F) (G x H)
Cost
Speed
17
Performance of PDSP VS. FPGA
18
Advanced FPGA Architectures with DSP Resources
19
DSP Design tools

• C, C
• MATLAB / Simulink
• HDL (VHDL / Verilog)
• Xilinx EDK/ISE

20
MATLAB / Simulink
21
Simulink
22
Simulink ISE
23
Design flow with FPGA
24
DSP Design Evolution from HW DSP to FPGA DSP
solutions

• Signal capture and sync.
• Data exchange methodology
• off-the shelf hardware
• Logic Processing
• Price/Feature
• Data/Sample rates
• Debugging
• Use of IP cores
• I/O interface
• Development cycles
• Deployment cost

25
Conclusion

• The primary reason solutions were so expensive
  to design, slow to develop and prove, and
  difficult to re-deploy was that the solutions
  were fixed in hardware 1

26
Questions?

• Thank you
