Title: Lecture 19: Threads


1
Lecture 19Threads
  • Prof. Kenneth M. Mackenzie
  • Computer Systems and Networks
  • CS2200, Spring 2003

Includes slides from Bill Leahy
2
Review Mutex
  • Mutex -- mutual exclusion problem
  • only one process/thread in a critical section
    at a time
  • motivated by multiprocessor applies to
    uniprocessor too
  • Five low-level solutions
  • enable/disable interrupts (works
    in-kernel only)
  • lock-free data structures (restrictive!)
  • software solutions
  • e.g. Petersons algorithm (O(n) time, space)
  • special atomic operations in HW lt--- std.
    solution
  • test set, swap
  • speculate retry! possible
    future soln?

3
Today Threads
  • 1. What are threads why do you want em
  • 2. Styles of thread programming
  • intro to POSIX threads (pthreads) API
  • 3. Synchronization (again)
  • from point of view of programmer, not of hardware
  • primitives that block instead of spin-wait
  • 4. Implementation

4
Terminology
  • Process full-blown virtual machine
  • register set stack
  • protected area of memory
  • Thread multiplexed CPU only
  • registers set stack
  • A process may contain multiple threads. If so,
    all threads see the same address space.

5
Recall
  • Process
  • Program Counter
  • Registers
  • Stack
  • Code (Text)
  • Data
  • Page Table
  • etc.
  • Processes must be protected from one another.

Memory
6
Recall
  • Context Switching
  • Requires considerable work
  • What about a single users application?
  • Is there a way to make it more efficient
  • In effect, allow the user to have multiple
    processes executing in the same space?
  • Yes, solution Threads or Multithreading

7
What is Multithreading?
  • Technique allowing program to do multiple tasks
  • Example Java GUI's
  • Is it a new technique?
  • no has existed since the 70s (concurrent
    Pascal, Ada tasks, etc.)

8
SMP?
  • What is an SMP?
  • Multiple CPUs in a single box sharing all the
    resources such as memory and I/O
  • Is a dual-processor SMP more cost effective than
    two uniprocessor boxes?
  • Yes, (roughly 20 more for a dual processor SMP
    compared to a uniprocessor).
  • Modest speedup for a program on a dual-processor
    SMP over a uniprocessor will make it worthwhile.
  • Example DELL WORKSTATION 650
  • 2.4GHz Intel Xeon (Pentium 4)
  • 1GB SDRAM memory, 80GB disk, 20/48X CD, 19
    monitor, Quadro4 900XGL Graphics card, RedHat
    Linux, 3yrs service
  • 2,584 for 2nd processor, add 434

9
What is a Thread?
  • Basic unit of CPU utilization
  • Consists of
  • Program Counter
  • Register Set
  • Stack Space
  • Shares with peer threads
  • Code
  • Data
  • OS Resources
  • Open files
  • Signals

10
Process Vs. Thread
P1
P2
user
PCB
PCB
kernel
Kernel code and data
  • Two single-threaded applications on one machine

11
Process Vs. Thread
P1
P2
user
PCB
PCB
kernel
Kernel code and data
  • P1 is multithreaded P2 is single-threaded
  • Computational state (PC, regs, ) for each thread
  • How different from process state?

12
Threads
  • Can be context switched more easily than
    processes
  • Just registers and PC
  • Not memory management
  • Can run on different processors concurrently in
    an SMP
  • Share CPU in a uniprocessor
  • May (Will) require concurrency control
    programming like mutex locks.

13
Why use threads?
  • Multiprocessor
  • convenient way to use the multiple processors
  • all memory is shared
  • Uniprocessor?

14
Threads in a Uniprocessor?
Process
active
  • Allows concurrency between I/O and user
    processing even in a uniprocessor box

15
Example
  • Omni 3000 Reading System
  • scanner
  • OCR software
  • speech-to-text software
  • on-screen viewer with bouncing ball
    highlighting
  • Reading process
  • 1. scan
  • 2. OCR
  • 3. speak and display simultaneously

20 seconds 30 seconds 10s to 100s of seconds
16
Example
speech
scan
OCR
GUI
pipeline speak/display page N OCR on page
N1 Scan page N2
17
Example
  • Natural implementation with four threads
  • Easy to write each thread does one thing
  • Alternatives? Could interleave the four
    operations
  • except thats really hard to do right
  • OCR was an opaque component

18
Thread Programming
  • Three common models
  • one per processor model
  • workpile or pool of threads model
  • pipeline model

19
One per Processor
main
thread
workers one per physical processor
synchronization
Common strategy in multiprocessing
20
Workpile model
  • Central pile of work to do
  • queue or other data structure
  • N threads (gt of processors)
  • read unit of work from pile
  • do work, possibly generating more work
  • add new work to pile

21
Pipeline Model
  • As in reading system application
  • Good for tolerating I/O delays
  • Also used in heterogenous system
  • e.g. system with specialized processors

22
  • Workpile model

Mailbox
  • Pipelined model

Mailbox
23
Programming Support for Threads
  • Creation
  • pthread_create(top-level procedure, args)
  • Termination
  • return to top-level procedure
  • explicit kill
  • Rendezvous
  • creator can wait for children
  • pthread_join(child_tid)
  • Synchronization
  • mutex
  • condition variables

24
Programming with Threads
  • Synchronization
  • For coordination of the threads
  • Communication
  • For inter-thread sharing of data
  • Threads can be in different processors
  • How to achieve sharing in SMP?
  • Software accomplished by keeping all threads in
    the same address space by the OS
  • Hardware accomplished by hardware shared memory
    and coherent caches

25
Synchronization
26
Synchronization Primitives
  • mutual exclusion
  • enforce locks among threads
  • pthread_mutex_lock
  • pthread_mutex_unlock
  • Two issues
  • 1. mutex isnt very general
  • 2. what do you do when you dont get the mutex?
  • Plan
  • 1. a more general construct semaphore w/examples
  • 2. spinning vs. blocking
  • 3. very general construct condition variables

27
Semaphore
  • semaphore is a positive integer
  • sem_wait()
  • wait if integer is zero
  • decrement integer
  • sem_signal()
  • increment integer

28
Case 1/3
  • Thread/processor

29
Case 2/3
  • mutex semaphore works as a mutex
  • mutex is a degenerate binary semaphore

30
Case 3/3
  • Counting, e.g. slots in a bounded buffer

31
How to wait?
  • 1. spin!
  • easy to implement
  • - locks out the thread youre waiting for?

32
How to wait?
  • 1. spin!
  • 2. switch-spin
  • easy to implement
  • doesnt scale
  • ideal for two threads, though

33
How to wait?
  • 1. spin!
  • 2. switch-spin
  • 3. sleep-spin
  • easy to implement
  • - wasteful

34
How to wait?
  • 1. spin!
  • 2. switch-spin
  • 3. sleep-spin
  • 4. block
  • - hard to implement
  • - expensive
  • absolutely the right thing if youre waiting a
    long time

35
How to wait?
  • 1. spin!
  • 2. switch-spin
  • 3. sleep-spin
  • 4. block
  • 5. hybrid strategy
  • e.g. spin 10uS then block
  • competative no worse than 2x cost of blocking

36
Example
Initially mutex is unlocked resource_state is
FREE
  • lock(mutex)
  • while (resource_state BUSY)
  • //spin
  • resource_state BUSY
  • unlock(mutex)
  • use resource
  • lock(mutex)
  • resource_state FREE
  • unlock(mutex)

37
Example
  • lock(mutex)
  • while (resource_state BUSY)
  • //spin
  • resource_state BUSY
  • unlock(mutex)
  • use resource
  • lock(mutex)
  • resource_state FREE
  • unlock(mutex)

Thread 1
38
Example
  • lock(mutex)
  • while (resource_state BUSY)
  • //spin
  • resource_state BUSY
  • unlock(mutex)
  • use resource
  • lock(mutex)
  • resource_state FREE
  • unlock(mutex)

Thread 2
Thread 1
39
Example
  • lock(mutex)
  • while (resource_state BUSY)
  • //spin
  • resource_state BUSY
  • unlock(mutex)
  • use resource
  • lock(mutex)
  • resource_state FREE
  • unlock(mutex)

Thread 2
Thread 1
40
Example with cond-var
  • lock(mutex)
  • while(resource_state BUSY)
  • wait(cond_var) / implicitly give up mutex /
  • / implicitly re-acquire mutex
    /
  • resource_state BUSY
  • unlock(mutex)
  • / use resource /
  • lock(mutex)
  • resource_state FREE
  • unlock(mutex)
  • signal(cond_var)

41
Example with cond-var
  • lock(mutex)
  • while(resource_state BUSY)
  • wait(cond_var) / implicitly give up mutex /
  • / implicitly re-acquire mutex
    /
  • resource_state BUSY
  • unlock(mutex)
  • / use resource /
  • lock(mutex)
  • resource_state FREE
  • unlock(mutex)
  • signal(cond_var)

T1
42
Example with cond-var
  • lock(mutex)
  • while(resource_state BUSY)
  • wait(cond_var) / implicitly give up mutex /
  • / implicitly re-acquire mutex
    /
  • resource_state BUSY
  • unlock(mutex)
  • / use resource /
  • lock(mutex)
  • resource_state FREE
  • unlock(mutex)
  • signal(cond_var)

T2
T1
43
pthreads
  • Mutex
  • Must create mutex variables
  • pthread_mutex_t padlock
  • Must initialize mutex variable
  • pthread_mutex_init(padlock, NULL)
  • Condition Variable (used for signaling
  • Must create condition variables
  • pthread_cond_t non_full
  • Must initialize condition variables
  • pthread_cond_init(non_full, NULL)

44
Classic CS ProblemProducer Consumer
  • Producer
  • If (! full)
  • Add item to buffer
  • empty FALSE
  • if(buffer_is_full)
  • full TRUE
  • Consumer
  • If (! empty)
  • Remove item from buffer
  • full FALSE
  • if(buffer_is_empty)
  • empty TRUE

buffer
...
45
Example Producer Threads Program
  • while(forever)
  • // produce item
  • pthread_mutex_lock(padlock)
  • while (full)
  • pthread_cond_wait(non_full, padlock)
  • // add item to buffer
  • if (buffercount BUFFERSIZE)
  • full TRUE
  • empty FALSE
  • pthread_mutex_unlock(padlock)
  • pthread_cond_signal(non_empty)

46
Example Consumer Threads Program
  • while(forever)
  • pthread_mutex_lock(padlock)
  • while (empty)
  • pthread_cond_wait (non_empty, padlock)
  • // remove item from buffer
  • full false
  • if (buffercount 0)
  • empty true
  • pthread_mutex_unlock(padlock)
  • pthread_cond_signal(non_full)
  • // consume_item

47
// Producer while(forever) // produce
item pthread_mutex_lock(padlock) while (full)
pthread_cond_wait(non_full, padlock) // add
item to buffer if (buffercount BUFFERSIZE)
full TRUE empty FALSE pthread_mutex_unl
ock(padlock) pthread_cond_signal(non_empty) /
/ Consumer while(forever) pthread_mutex_lock(pa
dlock) while (empty) pthread_cond_wait
(non_empty, padlock) // remove item from
buffer full false if (buffercount 0)
empty true pthread_mutex_unlock(padlock)
pthread_cond_signal(non_full) //
consume_item
48
Thread Implementation
49
Threads Implementation
  • User level threads
  • OS independent
  • Scheduler is part of the runtime system
  • Thread switch is cheap (save PC, SP, regs)
  • Scheduling customizable, i.e., more application
    control
  • Blocking call by thread blocks process

50
  • Solution to blocking problem in user level
    threads
  • Non-blocking version of all system calls
  • Switching among user level threads
  • Yield voluntarily
  • How to make preemptive?
  • Timer interrupt from kernel to switch

51
  • Kernel Level
  • Expensive thread switch
  • Makes sense for blocking calls by threads
  • Kernel becomes complicated process vs. threads
    scheduling
  • Thread packages become non-portable
  • Problems common to user and kernel level threads
  • Libraries
  • Solution is to have thread-safe wrappers to such
    library calls

52
Solaris Threads
  • Three kinds
  • user, lwp, kernel
  • User Any number can be created and attached to
    lwps
  • One to one mapping between lwp and kernel threads
  • Kernel threads known to the OS scheduler
  • If a kernel thread blocks, associated lwp, and
    user level threads block as well

53
Solaris Terminology
54
More Conventional Terminology
Processes
P1
P2
P3
Thread
kernel thread (user-level view)
(Inside the kernel)
55
Kernel Threads vs. User Threads
  • Advantages of kernel threads
  • Can be scheduled on multiple CPUs
  • Can be preempted by CPU
  • Kernel scheduler knows their relative priorities
  • Advantages of user threads
  • (Unknown to kernel)
  • Extremely lightweight No system call to needed
    to change threads.

56
Things to know?
  • 1. The reason threads are around?
  • 2. Benefits of increased concurrency?
  • 3. Why do we need software controlled "locks"
    (mutexes) of shared data?
  • 4. How can we avoid potential deadlocks/race
    conditions.
  • 5. What is meant by producer/consumer thread
    synchronization/communication using pthreads?
  • 6. Why use a "while" loop around a
    pthread_cond_wait() call?

57
Things to know?
  • 7. Why should we minimize lock scope (minimize
    the extent of code within a lock/unlock block)?
  • 8. Do you have any control over thread
    scheduling?
Write a Comment
User Comments (0)
About PowerShow.com
