Feature Selection

1
Feature Selection

• Ioannis Tsamardinos
• Machine Learning Course, 2006
• Computer Science Dept. University of Crete
• (Some slides borrowed from Aliferis,Tsamardinos,
  2004 Medinfo Tutorial)

2
Outline

• What is Variable/Feature Selection
• Filters Wrappers
• What is Relevancy
• Connecting Wrappers, Filters, and Relevancy
• SVM-Based Variable Selection
• Markov-Blanket-Based Variable Selection

3
Back to the FundamentalsThe feature selection
problem

• Journal of Machine Learning Research special
  issue
• Variable Selection refers to the problem of
  selecting input variables that are most
  predictive of a given outcome
• Kohavi and John 1997
• variable selection is the problem of
  selecting the subset of features such that the
  accuracy of the induced classifier is maximal
• Problem according to which classifier is
  predictive power measured by?
• A specific one?
• All possible classifiers?
• What about different cost features?

4
Why Feature Selection

• To reduce cost or risk associated with observing
  the variables
• To increase predictive power
• To reduce the size of the models, so they are
  easier to understand and trust
• To understand the domain

5
Definition of Feature Selection

• Let M be a metric, scoring a model and a feature
  subset according to predictions and features used
• Let A be a learning algorithm used to build the
  model
• Feature Selection Problem Select a feature
  subset s, that maximizes the score that M gives
  to the model learned by A using features s
• Feature Selection Problem 2 Select a feature
  subset s and a learner A, that maximizes the
  score M gives to the model learned by A using
  features s

6
Examples

• M is the accuracy a preference for smaller
  models, A is a SVM
• Find the minimal feature subset that maximizes
  the accuracy of a SVM
• Other possibilities for M calibrated accuracy,
  AUC, trade-off between accuracy and cost of
  features

7
Filters and Wrappers
8
Wrappers

• An algorithm for solving the feature selection
  problem that is allowed to evaluate (has access
  to) learner A on different feature subsets
• Typical wrapper
• Search (greedily or otherwise) the feature subset
  space
• Evaluate using M each subset s during search
• Report the one that maximizes M

9
Wrappers
Say we have predictors A, B, C and classifier M.
We want to predict T given the smallest possible
subset of A,B,C, while achieving maximal
performance (accuracy)
FEATURE SET CLASSIFIER PERFORMANCE
A,B,C M 98
A,B M 98
A,C M 77
B,C M 56
A M 89
B M 90
C M 91
. M 85
10
An Example of a Greedy Wrapper

• Since the search space is exponential, we have to
  use heuristic search

Solution
A,B 98
start
A 89
A,C 77
A,B98
A,B,C98
85
B 90
B,C 56
A,C77
C 91
end
Subset returned by greedy search
B,C56
11
Wrappers

• A common example of heuristic search is hill
  climbing keep adding features one at a time
  until no further improvement can be achieved
  (forward greedy wrapping)
• Alternatively we can start with the full set of
  predictors and keep removing features one at a
  time until no further improvement can be achieved
  (backward greedy wrapping)
• A third alternative is to interleave the two
  phases (adding and removing) either in forward or
  backward wrapping (forward-backward wrapping).
• Of course other forms of search can be used most
  notably
• Exhaustive search
• Genetic Algorithms
• Branch-and-Bound (e.g., cost of features, goal
  is to reach performance th or better)

12
Example Feature Selection Methods in
Bioinformatics GA/KNN

• Wrapper approach whereby
• heuristic searchGenetic Algorithm, and
• classifierKNN

13
Filters

• An algorithm for solving the feature selection
  problem that is not allowed to evaluate (does not
  have access to) learner A
• Typical filters select the feature subset
  according to certain statistical properties

14
Filter Example Univariate Association Filtering

• Rank features according to their association with
  the target (univariately)
• Select the first k features

FEATURE ASSOCIATION WITH TARGET
No Threshold gives optimal solution
C 91
B 90
A 89
15
Example Feature Selection Methods in Biomedicine
Univariate Association Filtering

• Order all predictors according to strength of
  association with target
• Choose the first k predictors and feed them to
  the classifier
• Various measures of association may be used X2,
  G2, Pearson r, Fisher Criterion Scoring, etc.
• How to choose k?
• What if we have too many variables?

16
Example Feature Selection Methods in Biomedicine
Recursive Feature Elimination

• Filter algorithm where feature selection is done
  as follows
• build linear Support Vector Machine classifiers
  using V features
• compute weights of all features and choose the
  best V/2
• repeat until 1 feature is left
• choose the feature subset that gives the best
  performance (using cross-validation)
• give best feature set to the classifier of choice.

17
What is Relevancy
18
Relevant and Irrelevant Features

• Large effort and debate to define relevant
  (irrelevant) features (AI Journal vol. 97)
• Why?
• Intuition
• For classification (presumably) we only need
  relevant features
• We can throw away the irrelevant features
• The set of relevant features must be the solution
  to the feature selection problem!
• What is Relevant must be independent of the
  classifier A used to build the final model!
• Relevant Features teach us something about the
  domain

19
Relevancy and Filters

• Consider a definition of relevancy
• Construct an algorithm that attempts to identify
  the relevant features
• It is a filtering algorithm (independent of the
  classifier used)
• Relevancy ? a family of filtering algorithms

20
The Argument of Kohavi and John 1997

• Take a handicapped perceptron sgn(w?x) instead
  of sgn(w?x w0)
• Add an irrelevant variable to the data with value
  always 1
• For some problems, the irrelevant variables is
  necessary
• Filtering (presumably) returns only relevant
  features
• Thus, filtering is suboptimal, wrapping is not

sgn(w?x)
1
1
x0
x4
x3
x2
x1
21
KJ Definitions of Relevancy

• KJ-Strongly Relevant Variable (for target T)
• X is KJ-Strongly Relevant if it is necessary for
  optimal density estimation
• V set of all variables, SV \ X, T
• P(T X, S) ? P(T S)

22
KJ Definitions of Relevancy

• KJ-Weakly Relevant Variable (for target T)
• X is Weakly Relevant if it is not necessary for
  optimal density estimation, but still informative
  (i.e., there is some subset that makes
  conditioned on which it becomes informative)
• V set of all variables
• X not strongly relevant and
• There exists U? V \ X, T
• P(T X, U) ? P(T X)

23
KJ Definition of Irrelevancy

• A variable X is KJ-irrelevant to T if it is not
  weakly or strongly relevant to T
• Intuitively
• X provides no information for T conditioned on
  any subset of other variables

24
Connecting Wrappers, Filters, and Relevancy
25
Negative Results on Relevancy and Filters

• Kohavi and John argument filtering returns only
  relevant variables and sometimes KJ-irrelevant or
  KJ-weakly relevant variables maybe needed
• True There is no definition of relevancy
  independent of the classifier A used to build the
  final model, or independent of the metric M that
  evaluates the model of A, such that the relevant
  features are the solution to the feature
  selection problem Tsamardinos, Aliferis,
  AIStats 2003
• Have to assume a (family) of algorithm(s) and
  metric(s) to define what is relevant

26
Negative Results on Wrappers

• Wrappers are subject to the No Free Lunch theorem
  for black-box optimization if the choice of
  metric or the classifier is unconstrained
  Tsamardinos, Aliferis, AIStats 2003
• gt Averaged out on all possible problems, each
  wrapper is the same as the random search
• Requires an exponential search to provably find
  the optimal feature subset

27
Connecting with Bayesian Networks
Faithful Bayesian Network
A
KJ Strongly Relevant Features
Irrelevant Features
C
D
B
KJ-irrelevant Features (anything without a path
to T)
K
F
T
H
E
I
Markov Blanket of T
Weakly Relevant Features (anything with a path to
T)
28
Markov Blanket in Faithful Bayesian Networks
Markov Blanket of T
KJ-Strongly Relevant Features
Smallest set of variables, conditioned on which
all other variables become independent of T
Set of parents, children, and spouses of T
29
OPTIMAL Solutions to a class of Feature Selection
Problems

• MB(T) is smallest subset of variables,
  conditioned on which all other variables become
  independent of T
• The Markov Blanket of T should be all we need
• True when
• Classifier can utilize the information in those
  variables (e.g. is a universal approximator)
• The metric prefers the smallest models with
  optimal calibrated accuracy (otherwise the Markov
  Blanket may include unnecessary variables)

30
SVM Based Variable Selection
31
Linear SVMs Identify Irrelevant Features

• Theorem Both the hard and soft margin linear SVM
  will assign a weight of zero to irrelevant
  features (in the sample limit)
• Set up the sample limit SVM
• Prove there is a unique and w, b in the sample
  limit
• Prove in this w, b the weight of the irrelevant
  features is zero

32
Linear SVMs may not Identify KJ-Strongly Relevant
Variables

• Consider an exclusive OR
• The soft margin linear SVM has a zero weight
  vector
• But, both features are KJ-strongly relevant
• Similar result expected for non-linear SVMs

x2
1
1
-1
1
-1
0
1
33
Linear SVMs may Retain KJ-Weakly-Relevant Features
X2
1
1
X1
1?
0
34
Feature Selection with (Linear) SVMs

• The SVM will correct remove irrelevant features
• The SVM may incorrect also remove strongly
  relevant features
• The SVM may incorrectly retain weakly relevant
  features

35
Markov Blanket Based Feature Selection
36
Optimal Feature Selection with Markov Blankets

• MMMB and Hiton algorithms KDD 2003, AMIA 2003
• Can identify the MB(T) among thousands of
  variables
• Provably correct in the sample limit and in
  faithful distributions
• Provably the MB(T) is the solution under the
  conditions specified
• Excellent results in real datasets from
  biomedicine
• The different between the two methods is
  conditioning vs maximizing the margin

37
Causal Discovery

• Recall feature selection to understand the
  domain
• Markov Blanket of T
• Causal interpretation direct causes, direct
  effects, direct causes of direct effects
• When
• Faithfulness
• Causal Sufficiency
• Acyclicity

38
Network Alarm-1k (999 variables, consists of 37
tiles of Alarm network) Classification
Algorithm RBF SVM Training sample size
1000 Testing sample size 1000
39
Target 46
Target
Member of MB
40
Feature Selection Method HITON_MB
Classification performance 87.7 3 True
positives 2 False positives 0 False negatives
Target
False negative
True positive
False positive
41
Feature Selection Method MMMB
Classification performance 87.7 3 True
positives 2 False positives 0 False negatives
Target
False negative
True positive
False positive
42
Feature Selection Method RFE Linear
Classification performance 74.6 2 True
positives 189 False positives 1 False negative
Target
False negative
True positive
False positive
43
Feature Selection Method RFE Polynomial
Classification performance 85.6 2 True
positives 33 False positives 1 False negative
Target
False negative
True positive
False positive
44
Feature Selection Method BFW
Classification performance 82.5 3 True
positives 161 False positives 0 False negatives
Target
False negative
True positive
False positive
45
Network Gene (801 variables) Classification
Algorithm See 5.0 Decision Trees Training
sample size 1000 Testing sample size 1000
46
Target 220
Target
Member of MB
47
Feature Selection Method MMMB
Classification performance with DT 96.4 9
True positives 4 False positives 0 False negatives
Target
False negative
True positive
False positive
48
Feature Selection Method HITON_MB
Classification performance with DT 96.2 9
True positives 4 False positives 0 False negatives
Target
False negative
True positive
False positive
49
Feature Selection Method BFW
Classification performance with DT 96.3 4
True positives 20 False positives 5 False
negatives
Target
False negative
True positive
False positive
50
Is This A General Phenomenon Or A Contrived
Example?
51
Random Targets in Tiled ALARM
52
Random Targets in GENE
53
Conclusions

• A formal definition of the feature selection
  problems allows to draw connections between
  relevant/irrelevant variables, the Markov
  Blanket, and solutions to the feature selection
  problem
• Need to specify the algorithm and metric to
  design algorithms that provably solve the feature
  selection problem

54
Conclusions

• Linear SVMs (current formulations) correctly
  identify the irrelevant variables, but do not
  solve the feature selection problem (under the
  conditions specified)
• Markov Blanket based algorithms exists that are
  probably correct in the sample limit for faithful
  distributions
• Questions
• SVM formulations that provably return the
  solution
• Extend the results to the non-linear case
