Prelude to Multiprocessing

1
Prelude to Multiprocessing

• Detecting cpu and system-board capabilities with
  CPUID and the MP Configuration Table

2
CPUID

• Recent Intel processors provide a cpuid
  instruction (opcode 0x0F, 0xA2) to assist
  software in detecting a CPUs capabilities
• If its implemented, this instruction can be
  executed in any of the processor modes, and at
  any of its four privilege levels
• But this cpuid instruction might not be
  implemented (e.g., 8086, 80286, 80386)

3
Intel x86 EFLAGS register
31
16
21
0
0
0
0
0
0
0
0
0
0
I D
V I P
V I F
A C
V M
R F
15
0
0
N T
IOPL
O F
D F
I F
T F
S F
Z F
0
A F
0
P F
1
C F
Software can toggle the ID-bit (bit 21) in the
32-bit EFLAGS register if the processor is
capable of executing the cpuid instruction
4
But what if theres no EFLAGS?

• The early Intel processors (8086, 80286) did not
  implement any 32-bit registers
• The FLAGS register was only 16-bits wide
• So there was no ID-bit that software could try to
  toggle (to see if cpuid existed)
• How can software be sure that the 32-bit EFLAGS
  register exists within the CPU?

5
Detecting 32-bit processors

• Theres a subtle difference in the way the
  logical shift/rotate instructions work when
  register CL contains the shift-factor
• On the 32-bit processors (e.g., 80386) the value
  in CL is truncated to 5-bits, but not so on the
  16-bit CPUs (8086, 80286)
• Software can exploit this distinction, in order
  to tell if EFLAGS is implemented

6
Detecting EFLAGS

• Heres a test for the presence of EFLAGS
• mov -1, ax a nonzero value
• mov 32, cl shift-factor of 32
• shl cl, ax do logical shift
• or ax, ax test result in AX
• jnz is32bit EFLAGS present
• jmp is16bit EFLAGS absent

7
Testing for ID-bit toggle

• Heres a test for the presence of the CPUID
  instruction
• pushfl copy EFLAGS contents
• pop eax to accumulator register
• mov eax, edx save a duplicate image
• btc 21, eax toggle the ID-bit (bit 21)
• push eax copy revised contents
• popfl back into EFLAGS
• pushfl copy EFLAGS contents
• pop eax back into accumulator
• xor edx, eax do XOR with prior value
• bt 21, eax did ID-bit get toggled?
• jc y_cpuid yes, can execute cpuid
• jmp n_cpuid else cpuid unimplemented

8
How does CPUID work?

• Step 1 load value 0 into register EAX
• Step 2 execute cpuid instruction
• Step 3 Verify GenuineIntel character- string
  in registers (EBX,EDX,ECX)
• Step 4 Find maximum CPUID input-value in the
  EAX register

9
Version and Features

• load 1 into EAX and execute CPUID
• Processor model and stepping information is
  returned in register EAX

1. 20 19 16 13 12 11
   8 7 4 3 0

Extended Family ID
Extended Model ID
Type
Family ID
Model
Stepping ID
10
Some Feature Flags in EDX
28
H T T
9
3
1
2
0
13
P G E
A P I C
P S E
D E
V M E
F P U
HTT HyperThreading Technology (1 yes, 0
no) PGE Page Global Entries (1yes, 0no) APIC
Advanced Programmable Interrupt Controller
on-chip (1 yes,0 no) PSE Page-Size
Extensions (1 yes, 0 no) DE Debugging
Extensions (1yes, 0no) VME Virtual-8086 Mode
Enhancements (1 yes, 0 no) FPU
Floating-Point Unit on-chil (1yes, 0no)
11
Some Feature Flags in ECX
5
V M X
VMX Virtual Machine Extensions (1 yes, 0 no)
12
Multiprocessor Specification

• Its an industry standard, allowing OS software
  to use multiple processors in a uniform way
• OS software searches in three regions of the
  physical address-space below 1-megabyte for a
  paragraph-aligned data-structure of length
  16-bytes called the MP Floating Pointer
  Structure
• Search in lowest KB of Extended Bios Data Area
• Search in topmost KB of conventional 640K RAM
• Search in the 128KB ROM-BIOS (0xE0000-0xFFFFF)

13
MP Floating Pointer Structure

• This structure may contain an ID-number for one a
  small number of standard SMP system
  architectures, or may contain the memory address
  for a more extensive MP Configuration Table
  having entries that specify a customized system
  architecture
• The machines in our classroom employ the latter
  of these two options

14
An example record

• The MP Configuration Table will contain a record
  for each logical processor

reserved (0)
reserved (0)
Feature Flags
CPU signature (stepping, model, family)
CPU Flags BP (bit 1), EN (bit 0)
Local-APIC version
Local-APIC ID
Entry Type 0
BP Bootstrap Processor (1yes, 0no), EN
Enabled (1yes, 0no)
15
Our mpinfo.cpp utility

• We created a Linux utility that will display the
  system-information contained in the MP
  Configuration Table (in hex format)
• You can refer to the MP Specification 1.4
  document (online) to interpret this display
• This utility needs a device-driver dram.c to be
  pre-installed (in order that it be able to
  directly access the systems memory)

16
A processors Local-APIC

• The purpose of each processors APIC is to allow
  the CPUs in a multiprocessor system to send
  messages to one another and to manage the
  delivery of the interrupt-requests from the
  various peripheral devices to one (or more) of
  the CPUs in a dynamically programmable way
• Each processors Local-APIC has a variety of
  registers, all memory mapped to
  paragraph-aligned addresses within the 4KB page
  at physical-address 0xFEE00000

17
Local-APICs register-space
APIC
0xFEE00000
4GB physical address-space
RAM
0x00000000
18
Analogies with the PIC

• Among the registers in a Local-APIC are these
  (which had analogues in the older 8259 PICs
  design
• IRR Interrupt Request Register (256-bits)
• ISR In-Service Register (256-bits)
• TMR Trigger-Mode Register (256-bits)
• For each of these, its 256-bits are divided among
  eight 32-bit register addresses

19
New way to do EOI

• Instead of using a special End-Of-Interrupt
  command-byte, the Local-APIC contains a dedicated
  write-only register (named the EOI Register)
  which an Interrupt Handler writes to when it is
  ready to signal an EOI

issuing EOI to the Local-APIC mov 0xFEE00000,
ebx address of the cpus Local-APIC movl 0,
fs0xB0(ebx) write any value into EOI
register Here we assume segment-register FS
holds the selector for a segment-descriptor for
a writable 4GB-size expand-up data-segment
whose base-address equals 0
20
Each CPU has its own timer!

• Four of the Local-APIC registers are used to
  implement a programmable timer
• It can privately deliver a periodic interrupt (or
  one-shot interrupt) just to its own CPU
• 0xFEE00320 Timer Vector register
• 0xFEE00380 Initial Count register
• 0xFEE00390 Current Count register
• 0xFEE003E0 Divider Configuration register

21
Timers Local Vector Table
0xFEE00320
7 0
12
16
17
Interrupt ID-number
M O D E
M A S K
B U S Y
MODE 0one-shot 1periodic
MASK 0unmasked 1masked
BUSY 0not busy 1busy
22
Timers Divide-Configuration
0xFEE003E0
3 2 1 0
reserved (0)
0
Divider-Value field (bits 3, 1, and 0) 000
divide by 2 001 divide by 4 010 divide by
8 011 divide by 16 100 divide by 32 101
divide by 64 110 divide by 128 111 divide
by 1
23
Initial and Current Counts
0xFEE00380
Initial Count Register (read/write)
0xFEE00390
Current Count Register (read-only)
When the timer is programmed for periodic mode,
the Current Count is automatically reloaded from
the Initial Count register, then counts down
with each CPU bus-cycle, generating an interrupt
when it reaches zero
24
Using the timers interrupts

• Setup your desired Initial Count value
• Select your desired Divide Configuration
• Setup the APIC-timers LVT register with your
  desired interrupt-ID number and counting mode
  (periodic or one-shot), and clear the LVT
  registers Mask bit to initiate the automatic
  countdown operation

25
In-class exercise 1

• Run the cpuid.cpp Linux application (on our
  course website) to see if the CPUs in our
  classroom implement HyperThreading (i.e.,
  multiple logical processors in a cpu)
• Then run the mpinfo.cpp application, to see if
  the MP Base Configuration Table has entries for
  more than one processor
• If both results hold true, then we can write our
  own multiprocessing software in H235!

26
In-class exercise 2

• Run the apictick.s demo (on our CS 630 website)
  to observe the APICs periodic
  interrupt-handler drawing Ts onscreen
• It executes for ten-milliseconds (the 8254 is
  used here to create that timed delay)
• Try reprogramming the APICs Divider
  Configuration register, to cut the interrupt
  frequency in half (or perhaps to double it)
