Regression Analysis

1
Regression Analysis
2
Introduction to Regression Analysis (RA)

• Regression Analysis is used to estimate a
  function f( ) that describes the relationship
  between a continuous dependent variable and one
  or more independent variables.
• Y f(X1, X2, X3,, Xn) e
• Note
• f( ) describes systematic variation in the
  relationship.
• e represents the unsystematic variation (or
  random error) in the relationship.

3

• In other words, the observations that we have
  interest can be separated into two parts
• Y f(X1, X2, X3,, Xn) e
• Observations Model Error
• Observations Signal Noise
• Ideally, the noise shall be very small,
  comparing to the model.

4
Signal to Noise
What we observe can be divided into
signal
noise
5
Model specification
If the true function is
yi B0 B1Xi B2Zi
And we fit
yi b0 b1Xi b2Zi ei
Our model is exactly specified and we obtain an
unbiased and efficient estimate.
6
Model specification
And finally, if the true function is
yi B0 B1Xi B2Zi B3XiZi B4Zi
2
And we fit
yi b0 b1Xi b2Zi ei
Our model is underspecified, we excluded some
necessary terms, and we obtain a biased estimate.
7
Model specification
On the other hand, if the true function is
yi B0 B1Xi B2Zi
And we fit
yi b0 b1Xi b2Zi b3XiZi ei
Our model is overspecified, we included some
unnecessary terms, and we obtain an inefficient
estimate.
8
Model specification

• if specify the model exactly, there is no bias
• if you overspecify the model (add more terms than
  needed), result is unbiased, but inefficient
• if you underspecify the model (omit one or more
  necessary terms (the result is biased)
• Overall Strategy
• best option is to exactly specify the true
  function
• we would prefer to err by overspecifying our
  model because that only leads to inefficiency
• Therefore, start with a likely overspecified
  model and reduce it

9
An Example

• Consider the relationship between advertising
  (X1) and sales (Y) for a company.
• There probably is a relationship...
• ...as advertising increases, sales should
  increase.
• But how would we measure and quantify this
  relationship?

10
A Scatter Plot of the Data
11
The Nature of a Statistical Relationship
12
A Simple Linear Regression Model

• The scatter plot shows a linear relation between
  advertising and sales.

13
Determining the Best Fit

• Numerical values must be assigned to b0 and b1

• If ESS0 our estimated function fits the data
  perfectly.
• We could solve this problem using Solver...

14
Estimation Linear Regressin
Formula for a straight line
outcome
program
D
y
b1 slope

y b0 b1x e
x
D
y
D
y
x
D
want to solve for
b0 intercept
x
15
The Estimated Regression Function

• The estimated regression function is

16
Evaluating the Fit
600.0
500.0
400.0
300.0
2
R
0.9691
Sales (in 000s)
200.0
100.0
0.0
20
30
40
50
60
70
80
90
100
Advertising (in 000s)
17
The R2 Statistic

• The R2 statistic indicates how well an estimated
  regression function fits the data.
• 0lt R2 lt1
• It measures the proportion of the total variation
  in Y around its mean that is accounted for by the
  estimated regression equation.
• To understand this better, consider the following
  graph...

18
Error Decomposition
Yi (actual value)
Y

Yi -

Y b0 b1X
X
19
Partition of the Total Sum of Squares
or, TSS ESS RSS
20
(No Transcript)
21
Degree of Linear Correlation

• R2 1 perfect linear correlation R2 0 no
  correlation
• High R2 good fit only if linear model is
  appropriate always check with a scatterplot
• Correlation does not prove causation x and y may
  both be correlated to a third (possibly
  unidentified) variable
• A more popular (but less meaningful) measure is
  the correlation coefficient

R2 RSQ(y-range,x-range r
CORREL(y-range,x-range)
22
R2 0.67
R2 0.67
R2 0.67
R2 0.67
23
Testing for Significance F Test

• Hypotheses
• H0 ?1 0
• Ha ?1 0
• Test Statistic
• Rejection Rule
• Reject H0 if F gt F?
• where F? is based on an F distribution with 1
  d.f. in
• the numerator and n - 2 d.f. in the denominator.

24
Some Cautions about theInterpretation of
Significance Tests

• Rejecting H0 b1 0 and concluding that the
  relationship between x and y is significant does
  not enable us to conclude that a cause-and-effect
  relationship is present between x and y.
• Just because we are able to reject H0 b1 0 and
  demonstrate statistical significance does not
  enable us to conclude that there is a linear
  relationship between x and y.

25
An Example of Inappropriate Interpretation

• A study shows that, in elementary schools, the
  ability of spelling is stronger for the students
  with larger feet.
• ? Could we conclude that the size of foot can
  influence the ability of spelling?
• ? Or there exists another factor that can
  influence the foot size and the spelling ability?


26
Making Predictions

• Estimated Sales 36.342 5.550 65
• 397.092

• So when 65,000 is spent on advertising, we
  expect the average sales level to be 397,092.

27
The Standard Error

• For our example, Se 20.421
• This is helpful in making predictions...

28
An Approximate Prediction Interval

• An approximate 95 prediction interval for a new
  value of Y when X1X1h is given by

where

• Example If 65,000 is spent on advertising
• 95 lower prediction interval 397.092 -
  220.421 356.250
• 95 upper prediction interval 397.092
  220.421 437.934
• If we spend 65,000 on advertising we are
  approximately 95 confident actual sales will be
  between 356,250 and 437,934.

29
An Exact Prediction Interval

• A (1-a) prediction interval for a new value of Y
  when X1X1h is given by

where
30
Example

• If 65,000 is spent on advertising
• 95 lower prediction interval 397.092 -
  2.30621.489 347.556
• 95 upper prediction interval 397.092
  2.30621.489 446.666
• If we spend 65,000 on advertising we are 95
  confident actual sales will be between 347,556
  and 446,666.
• This interval is only about 20,000 wider than
  the approximate one calculated earlier but was
  much more difficult to create.
• The greater accuracy is not always worth the
  trouble.

31
Comparison of Prediction Interval Techniques
Sales
575
Prediction intervals created using standard error
Se
525
475
425
375
325
Regression Line
275
Prediction intervals created using standard
prediction error Sp
225
175
125
25
35
45
55
65
75
85
95
Advertising Expenditures
32
Confidence Intervals for the Mean

• A (1-a) confidence interval for the true mean
  value of Y when X1X1h is given by

where
33
A Note About Extrapolation

• Predictions made using an estimated regression
  function may have little or no validity for
  values of the independent variables that are
  substantially different from those represented in
  the sample.

34
What Does Regression Mean?
35
What Does Regression Mean?

• Draw best-fit line free hand
• Find mothers height 60, find average
  daughters height
• Repeat for mothers height 62, 64 70 draw
  best-fit line for these points
• Draw line daughters height mothers height
• For a given mothers height, daughters height
  tends to be between mothers height and mean
  height regression toward the mean

36
What Does Regression Mean?
37
Residual Analysis

• Residual for Observation i
• yi yi
• Standardized Residual for Observation i
• where

38
?
?
?
39
Residual Analysis

• Detecting Outliers
• An outlier is an observation that is unusual in
  comparison with the other data.
• Minitab classifies an observation as an outlier
  if its standardized residual value is lt -2 or gt
  2.
• This standardized residual rule sometimes fails
  to identify an unusually large observation as
  being an outlier.
• This rules shortcoming can be circumvented by
  using studentized deleted residuals.
• The i th studentized deleted residual will be
  larger than the i th standardized residual.

40
Multiple Regression Analysis

• Most regression problems involve more than one
  independent variable.

• The optimal values for the bi can again be found
  by minimizing the ESS.
• The resulting function fits a hyperplane to our
  sample data.

41
Example Regression Surface for Two Independent
Variables
Y























X2
X1
42
Multiple Regression ExampleReal Estate Appraisal

• A real estate appraiser wants to develop a model
  to help predict the fair market values of
  residential properties.
• Three independent variables will be used to
  estimate the selling price of a house
• total square footage
• number of bedrooms
• size of the garage

43
Selecting the Model

• We want to identify the simplest model that
  adequately accounts for the systematic variation
  in the Y variable.
• Arbitrarily using all the independent variables
  may result in overfitting.
• A sample reflects characteristics
• representative of the population
• specific to the sample
• We want to avoid fitting sample specific
  characteristics -- or overfitting the data.

44
Models with One Independent Variable

• With simplicity in mind, suppose we fit three
  simple linear regression functions

• The model using X1 accounts for 87 of the
  variation in Y, leaving 13 unaccounted for.

45
Important Software Note

• When using more than one independent variable,
  all variables for the X-range must be in one
  contiguous block of cells (that is, in adjacent
  columns).

46
Models with Two Independent Variables

• Now suppose we fit the following models with two
  independent variables

• The model using X1 and X2 accounts for 93.9 of
  the variation in Y, leaving 6.1 unaccounted for.

47
The Adjusted R2 Statistic

• As additional independent variables are added to
  a model
• The R2 statistic can only increase.
• The Adjusted-R2 statistic can increase or
  decrease.

• The R2 statistic can be artificially inflated by
  adding any independent variable to the model.
• We can compare adjusted-R2 values as a heuristic
  to tell if adding an additional independent
  variable really helps.

48
A Comment On Multicollinearity

• It should not be surprising that adding X3 ( of
  bedrooms) to the model with X1 (total square
  footage) did not significantly improve the model.
• Both variables represent the same (or very
  similar) things -- the size of the house.
• These variables are highly correlated (or
  collinear).
• Multicollinearity should be avoided.

49
Testing for Significance Multicollinearity

• The term multicollinearity refers to the
  correlation among the independent variables.
• When the independent variables are highly
  correlated (say, r gt .7), it is not possible
  to determine the separate effect of any
  particular independent variable on the dependent
  variable.
• If the estimated regression equation is to be
  used only for predictive purposes,
  multicollinearity is usually not a serious
  problem.
• Every attempt should be made to avoid including
  independent variables that are highly correlated.

50
Model with Three Independent Variables

• Now suppose we fit the following model with three
  independent variables

• The model using X1 and X2 appears to be best
• Highest adjusted-R2
• Lowest Se (most precise prediction intervals)

51
Making Predictions

• Lets estimate the avg selling price of a house
  with 2,100 square feet and a 2-car garage

• The estimated average selling price is 134,444

52
Binary Independent Variables

• Other types of non-quantitative factors could
  independent variables could be included in the
  analysis using binary variables.

53
Polynomial Regression

• Sometimes the relationship between a dependent
  and independent variable is not linear.

• This graph suggests a quadratic relationship
  between square footage (X) and selling price (Y).

54
The Regression Model

• An appropriate regression function in this case
  might be,

or equivalently,
where,
55
Implementing the Model
56
Graph of Estimated Quadratic Regression Function
57
Fitting a Third Order Polynomial Model

• We could also fit a third order polynomial model,

or equivalently,
where,
58
Graph of Estimated Third Order Polynomial
Regression Function
59
Overfitting

• When fitting polynomial models, care must be
  taken to avoid overfitting.
• The adjusted-R2 statistic can be used for this
  purpose here also.

60
Example Programmer Salary Survey

• A software firm collected data for a sample of
  20 computer programmers. A suggestion was made
  that regression analysis could be used to
  determine if salary was related to the years of
  experience and the score on the firms programmer
  aptitude test. The years of experience, score on
  the aptitude test, and corresponding annual
  salary (1000s) for a sample of 20 programmers is
  shown on the next slide.

61
Example Programmer Salary Survey

• Exper. Score Salary Exper.
  Score Salary
• 4 78 24 9 88 38
• 7 100 43 2 73 26.6
• 1 86 23.7 10 75 36.2
• 5 82 34.3 5 81 31.6
• 8 86 35.8 6 74 29
• 10 84 38 8 87 34
• 0 75 22.2 4 79 30.1
• 1 80 23.1 6 94 33.9
• 6 83 30 3 70 28.2
• 6 91 33 3 89 30

62
Example Programmer Salary Survey

• Multiple Regression Model
• Suppose we believe that salary (y) is related to
  the years of experience (x1) and the score on the
  programmer aptitude test (x2) by the following
  regression model
• y ?0 ?1 x1 ?2 x2 ??
• where
• y annual salary (000)
• x1 years of experience
• x2 score on programmer aptitude test

63
Example Programmer Salary Survey

• Multiple Regression Equation
• Using the assumption E (?) 0, we obtain
• E(y ) ?0 ?1 x1 ?2 x2
• Estimated Regression Equation
• b0, b1, b2 are the least squares estimates of
  ?0, ?1, ?2. ?
• Thus
• y b0 b1x1 b2x2.

64
Example Programmer Salary Survey

• Solving for the Estimates of ?0, ?1, ?2

Least Squares Output
Input Data
Computer Package for Solving Multiple Regression P
roblems
b0 b1 b2 R2 etc.
x1 x2 y 4 78 24 7 100 43 .
. . . . . 3 89 30
65
Example Programmer Salary Survey

• Data Analysis Output
• The regression is
• Salary 3.17 1.40 Exper 0.251 Score
• Predictor Coef Stdev
  t-ratio p
• Constant 3.174 6.156 .52 .613
• Exper 1.4039 .1986 7.07 .000
• Score .25089 .07735 3.24 .005
• s 2.419 R-sq 83.4
  R-sq(adj) 81.5

66
Example Programmer Salary Survey

• Computer Output (continued)
• Analysis of Variance
• SOURCE DF SS MS
  F P
• Regression 2 500.33 250.16 42.76 0.000
• Error 17 99.46 5.85
• Total 19 599.79
