Hard Drive Installation and Support

1
Chapter 7

• Hard Drive Installation and Support

2
You Will Learn

• How to install a hard drive
• How to manage a hard drive to optimize its
  performance
• How to apply hard drive troubleshooting skills

3
Installing a Hard Drive

• Physical installation set jumpers and install
  cable and drive
• Change CMOS setup
• Partition using FDISK
• Format and install software on the drive

4
Precautions for Working with Hard Drives

• Handle the drive carefully
• Do not touch exposed circuitry or chips
• Drain static electricity from your body and from
  the package containing the drive
• If you must set it down, place the drive
  component-side up on top of the static-protective
  package on a flat surface
• Do not place the drive on the computer case cover
  or on a metal table

5
Physical Installation of IDE Hard Drives

• IDE
• Drive
• 40-pin data cable
• Possibly a kit to make drive fit in larger bay

6
Installing an IDE Hard Drive

• IDE hard drives support up to four IDE devices on
  the same system
• Four possible setups for each device
• Primary IDE channel, master device
• Primary IDE channel, slave device
• Secondary IDE channel, master device
• Secondary IDE channel, slave device
• Place fastest devices on primary channel and
  slower devices on secondary channel

7
Jumper Settings
8
Typical Jumper Arrangement
9
Jumper Settings on an IDE Hard Drive
10
Using an IDE Connection on the System Board
11
Entering Hard Drive Info in CMOS
continued
12
Entering Hard Drive Info in CMOS
continued
13
Entering Hard Drive Info in CMOS
continued
14
Informing Setup of the New Hard Drive

• Setup for hard drives less than 528 MB
• Older BIOS setup assumes use of CHS mode
• New BIOS select CHS mode or normal mode
• Setup for large-capacity hard drives
• Two ways BIOS relates to large capacity drives
• LBA
• Large mode

continued
15
Informing Setup of the New Hard Drive

• When BIOS does not support large-capacity hard
  drives
• Let the BIOS see the drive as a smaller drive
• Upgrade the BIOS (best solution)
• Upgrade the entire system board
• Use software that interfaces between the older
  BIOS and the large-capacity drive (e.g., Disk
  Manager by OnTrack, SpeedStor by Storage
  Dimensions, EZ-Drive by StorageSoft)

16
A Note on Moving a Hard Drive or Changing BIOS

• Backup up the data on the hard drive before you
  move it to avoid potential problems with
• Lost data
• Inability to access the drives data
• Different translation methods for LBA mode
• Dont change options in setup unless you are sure
  of what you are doing

17
Partitioning the Hard Drive with FDISK

• Partition table
• Written at the very beginning of a hard drive
• Describes number and location of all partitions
• Identifies the boot partition
• A drive must have one primary partition and can
  have one extended partition
• The drive boots from the primary partition
• The extended partition can be subdivided into
  several logical drive partitions

18
Partitioning the Hard Drive
19
Partitioning the Hard Drive
20
Partitioning the Hard Drive
21
OS or High-level Format

• Individually formats each volume or logical drive
  within a partition
• Performed by means of the DOS or Windows 9x
  Format program
• For DOS
• Use FORMAT C/S command
• For Windows 9x
• The Windows 9x CD-ROM contains the real-mode
  drivers necessary to access the CD-ROM without
  having Windows installed

22
Installing Software

• Install Windows 9x
• Load the applications software
• Make a complete backup of the entire drive
• Create a rescue disk to recover from a corrupted
  partition table

23
Optimizing a Hard Drive

• Fragmentation
• Cross-linked and lost clusters

24
Fragmentation

• Distribution of data files in noncontiguous
  clusters increases data access time
• Routine maintenance defragment the hard drive
• DOS
• DOS 6 DEFRAG or a utility software package
• Windows 98
• Defragmenter utility

25
Windows 98 Defragmenter Utility
26
Disk Defragmenter Results
27
Cross-linked and Lost Clusters

• Cross-linked
• More than one file points to them
• Lost
• No file in the FAT points to them
• To repair use ScanDisk utility in either DOS or
  Windows 9x

28
Cross-linked and Lost Clusters
29
SCANDISK Command for DOS
30
ScanDisk
31
ScanDisk
32
Using DOS under Windows 9x to Manage a Hard Drive

• CAUTION Using some DOS commands on a hard drive
  that uses Windows 9x as the OS may cause damage
  to a hard drives file structure

33
DOS Commands to Avoid with Windows 9x

• Dont use disk utility software that does not
  know about VFAT, long filenames or FAT32
• Dont use FDISK, FORMAT C, SYS C, or CHKDSK
  while in a DOS session
• Dont optimize or defragment the hard drive using
  software that does not know about long filenames

continued
34
DOS Commands to Avoid with Windows 9x

• Dont run hard drive cache programs unless
  written especially for Windows 95 or Windows 98
• Dont use older DOS backup programs (BACKUP,
  MSBACKUP)

35
When Things Go Wrong

• Information to have ready before calling
  technical support
• Drive model and description
• Manufacturer and model of computer
• Exact wording of error message
• Description of the problem
• Hardware and software configuration of the system

36
Troubleshooting Hard Drives and Data Recovery

• An ounce of prevention
• Make backups and keep them current
• Defragment files and scan the hard drive
  occasionally
• Dont smoke around the hard drive
• Dont leave PC turned off for weeks/months
• High humidity can be dangerous for hard drives
• Be gentle with a hard drive

37
Problems with Hard Drives

• Hardware problems
• Problems with hard drive controller, power
  supply, data cable, BIOS or setup
• Damage to drive mechanism or physical damage to
  disk surface where the partition table, boot
  record, directories, FAT and/or data are stored

continued
38
Problems with Hard Drives

• Software problems
• Corrupted OS files
• Corrupted partition table, boot record, or root
  directory, making all data on the hard drive
  inaccessible
• Corruption of the area of the FAT that points to
  the data, the datas directory table, or the
  sector markings where data is located
• Data or access to it destroyed by a virus

39
Resolving Hard Drive Problems

• Hard drive problems usually show up at POST
• For a hard drive to be accessible by DOS or
  Windows 9x, these must be intact for boot to
  occur
• Partition table
• Boot record
• FAT
• Root directory
• Specific DOS files
• Specific Windows files

40
Resolving Hard Drive Problems

• For the OS to access data, these must be intact
• Directory in which files are located
• In the FAT, the sector information where the
  files are located
• Beginning of the file (header information) and
  the end of the file (end-of-file marker)
• Data itself

41
Corrupted System Files

• DOS error message
• Non-system disk or disk error
• Windows 9x error message
• Invalid system disk
• Boot from a floppy disk, access drive C, begin
  looking for the problem

42
Corrupted Sector and Track Markings

• DOS error message
• Bad Sector or Sector Not Found
• Low-level format will refresh these sector bits
• Nondestructive format
• Destructive format

43
Virus Problems

• Use a virus scan program

44
Hard Drive Troubleshooting Guidelines

• Was the computer recently moved?
• Was any new hardware recently installed?
• Was any new software recently installed?
• Was any software recently reconfigured or
  upgraded?
• Does the computer have a history of similar
  problems?

45
Causes and Solutions for Common Hard Drive
Problems

• Hard drive does not boot
• Disk retrieves and saves data slowly
• Computer will not recognize a newly installed
  hard drive

46
Chapter Summary

• Installing a new hard drive
• What to do when a hard drive fails, shows signs
  of impending disaster, or when data is lost
• Importance of keeping good backups of software
  and data stored on the hard drive as well as
  backups of partition table, boot record, root
  directory, and FAT

47
