Feature Selection Focused within Error Clusters

• Sui-Yu Wang and Henry Baird
• Presented by Sui-Yu Wang

2
Feature Selection

• Given a set of n features, find a subset of k lt n
  features that still performs well
• Best k features chosen separately are usually not
  the best k when chosen together (Elashoff et. al,
  1967)
• To select the optimal subset, one has to
  exhaustively search through all k-elements
  subsets (Cover and Campenhout, 1977)
• Given limited number of training samples and
  features, finding the minimum subset of features
  without misclassifying any training sample is NP
  complete (Van Horn and Martinez, 1994)

3
Feature Selection

• Methods can be divided into three categories
  wrappers, filters, and embedded methods. (Guyon
  and Elisseeff, 2003)
• Filters rank features according to various
  metrics
• Wrappers evaluate subset of features according
  to given classifier
• Embedded methods similar to wrapper, but uses
  non-exhaustive search methods

4
A Motivating Example

• Task Classify each pixel into handwriting or
  blank
• We have to search in a diameter of 25 pixels to
  get any useful features D 450 pixel values
• So possible features can be extremely numerous
  any combination of 450 pixel values

4
5
Popular Method PCA

• Principal Components Analysis
• PCA finds a small number of linear combinations
  of original features
• PCA finds the dimension that represents the data
  best in a least square sense, but does not
  guarantee good separation of data (Pearson, 1901)
• Most algorithms employee PCA first then operate
  respective feature selection algorithm on the
  reduced set
• Could throw away potentially interesting
  information

6
Our Research Strategy

• We want to find methods for guiding the search
  for a few strongly discriminating features.
• We adopt a greedy heuristic constructing one
  feature at a time.
• We focus our search on cases where the current
  features fail.

7
Formalities

• We assume a two class problem
• The original sample space is , D is huge
• We are given d ltlt D hand-crafted features, all
  samples are projected into this feature space
  by feature extractor . We may lose
  information during the process
• If there is any discriminating information in the
  sample space but not in the feature space
  , it is must be in the null space

8
Finding the Null Space

• If is linear, the null space can be computed
  by linear algebra methods
• Given , a singular value
  decomposition, or SVD, can be used to find the
  set of vectors spanning the null space of
• can be factorized as
  where and
  are orthogonal matrices
• And

9
Finding the Next Feature

• Samples that fall at the same point in
  are not discriminated by the current feature set
• Samples that lie in tight clusters in are
  only weakly discriminated by the current feature
  set
• A tight cluster of errors of both classes
  indicates cases where the current feature set
  fails completely
• Therefore, we use these tight clusters to guide
  the forward search for new features
• Once we have projected samples from the tight
  error cluster into the null space, we find a
  hyperplane that best separates the data,
  and calculate a given sample xs distance to this
  hyperplane, , as the new feature

10
Operate on Points in the Null Space

• There are many ways to projects points in the
  sample space into the null space of ,
• The orthogonal projection onto a particular
  subspace is unique
• Let where
  is an orthonormal basis for the subspace
  . Then

11
(No Transcript)
12
Outline of the Algorithm

• Repeat
• Draw enough samples to train a classifier
• Draw enough samples to build a test set
• Find clusters of errors in
• Repeat
• Choose a tight cluster with both types of
  errors
• Draw enough samples to populate this cluster
  (if necessary)
• Project the cluster into the null space
• Find a separating hyperplane in the null space
  with
• normal vector that best separates the
  samples in this cluster
• Construct a new feature and examine its
  performance
• Until the feature lowers the error rate
  sufficiently
• Until the error rate is satisfactory to the user

13
Experiments

• Experiments were conducted on a document image
  content extraction problem
• Each image pixel is treated as a sample
• The task is to classify each sample into
  handwriting or machine print
• Possible features are extracted from a 25?25
  pixel square, D625

14
Experimental Results
PH
MP
BL
HW
15
Experiments

• We divide the data into three sets training set,
  discovery set, and test set.
• The training set consists of 4,469,740 MP samples
  and 943,178 HW samples
• The feature discovery set consists of 4,980,418
  MP and 1,496,949 HW samples
• The test set consists of 816,673 MP samples and
  649,113 HW samples

16
Experimental Results
17
Which Cluster is Best?

• Experiments suggest that tight balanced clusters
  are best

Cluster 1 2 3 4 5
error rate 14.4 15.5 15.6 13.5 14.8
Balance 90 60 51 52 65
Tightness 83 90 83 70 80
18
Future Work

• Apply the method to other problems
• Continue the experiment to see how low the error
  can drop
• Analyze cluster statistics to establish rules for
  selecting better cluster candidate
• Try other hyperplane-finding methods
• Establish theoretical framework as to when this
  approach is guaranteed to work and when it fails
