Title: INFO 331 Computer Networking Technology II


1
INFO 331Computer Networking Technology II
  • Chapter 7
  • Multimedia Networking
  • Glenn Booker

2
Multimedia Networking
  • Recent years have seen massive growth in Internet
    audio and video apps
  • Streaming video, IP telephony, Internet radio,
    teleconferencing, interactive games, distance
    learning, etc.
  • Older Internet apps (email, WWW, FTP) were very
    elastic in bandwidth needs, but multimedia is
    much fussier delay sensitive
  • But theyre also more loss-tolerant

3
Multimedia Networking
  • Multimedia apps are in three categories
  • Streaming stored audio video (AV)
  • Streaming live AV
  • Real-time interactive AV
  • This excludes download-stuff-and-play, such as
    MP3s, iTunes, etc.
  • Download entire file before play starts
  • FTP or HTTP are fine for them

4
Streaming stored AV
  • Here, clients request on-demand compressed AV
    files that are stored on servers
  • Content may include lectures, music, TV, etc.
  • CNN video, YouTube, etc.
  • Main features of this app type are
  • Stored, prerecorded media pause, ffwd, rew
  • Streaming, hence can play part of the media while
    downloading more of it
  • Continuous play out should keep original timing

5
Streaming live AV
  • This is live broadcast of radio or TV over the
    Internet
  • Cant fast forward, since it hasnt happened yet,
    but local storage of whats been received can
    allow pausing and rewinding in some cases
  • Often accomplished using IP multicasting or IPTV,
    but more often done via separate unicast streams
  • Also has continuous play out, can tolerate some
    startup delay

6
IPTV
  • IPTV (TV over IP) is a challenge in terms of
    bandwidth
  • Traditional client/server cant work
  • Often use P2P techniques (see CoolStreaming,
    PPLive), or content distribution networks (CDNs,
    which will be discussed later)

7
Real-time interactive AV
  • This class of apps allows interaction between
    people at both ends (or many ends) of a
    connection, such as Internet telephony or
    teleconferencing
  • Apps can be integrated, e.g. Web-phone
  • Microsoft Live Messenger, Live Meeting (was
    NetMeeting), WebEx, GoToMeeting, Skype
  • Transmission delays under 150 ms are good, under
    400 ms is okay, and over 400 ms is bad

8
Multimedia Challenges
  • The Internet provides best-effort service
  • No guarantees from IP on when stuff will get
    there, consistency in delay times, if it will get
    there, or getting there in order
  • All packets are equal in the Internet!
  • Streaming stored or live AV has been pretty
    successful, real-time interactive AV less so
  • To help, use tricks to make transmission smoother

9
Multimedia Tricks
  • At app level, well look at common tricks to make
    multimedia smoother, such as
  • Use UDP to avoid TCP congestion control
  • Delay playback by 100 ms to help allow for jitter
  • Timestamp packets to know when they should be
    played
  • Stored data can be fetched in advance, to help
    cover slow periods
  • Send redundant data to help cover data losses

10
Fix the Internet!
  • Some argue the Internet should allow for
    end-to-end bandwidth guarantees, like virtual
    circuit networks can provide
  • Would require massive changes to routers to
    establish fixed paths for some service types
  • Hard guarantees mean youre certain to receive
    the QoS you paid for
  • Soft guarantees mean youre likely to receive the
    QoS you paid for

11
Fix the Internet!
  • Others insist the Internet doesnt need massive
    changes
  • Let ISPs upgrade bandwidth as customers demand it
  • Increase ISP caching for common requested stored
    AV
  • Add content distribution networks (CDNs) for paid
    stored media, conveniently near network edges

12
Fix the Internet!
  • Create multicast overlay networks servers
    which help distribute streams to large audiences
  • Third approach is to add pricing at the network
    transport layers, to pay for better service
    (Diffserv approach)

13
AV Compression
  • Compression helps speed information transmission
    rate by reducing its volume
  • Long done for static images (JPG, GIF)
  • Each pixel is 24 bits of color data (RGB),
  • A 1024x768 pixel image is 1024x768x24/8 2.36
    MB
  • Compression can reduce image size a factor of 10
    without severe quality loss
  • Key tradeoff more compression more losses
  • Huge field (e.g. ISBN 1565921615)

14
Audio Compression
  • Digital audio signals have three major
    characteristics
  • The sampling rate (samples per second)
  • The number of channels sampled (mono, stereo,
    etc.)
  • The number of bits per sample
  • These all affect the raw amount of data being
    sent, before compression is applied

15
Audio Compression
  • Raw audio signals are recorded at some sample
    rate per second, per channel
  • 8k, 16k, or 32k samples/sec (Hz) are common low
    grade rates
  • 44.1k (CD quality), 48k, 96k, and even 192kHz
    sample rates are used for professional audio
  • The number of channels used is typically one
    (mono), two (stereo), or 5 to 7 (surround)

16
Audio Compression
  • Each sample is quantized into some number of bits
    to describe its relative strength
  • 8 bits gives 256 values from silent to REALLY
    LOUD, which is typical for cheap built-in audio
  • CD quality uses 16 bits per sample
  • Pro audio typically uses 24 or 32 bits per sample
  • So one minute of absurd quality 7 channel
    surround would use 192k sample/sec x 7 channels x
    32 bits/sample / 8 bit/byte 60 sec/min 322.56
    MB/min!

17
Audio Compression
  • This approach for audio is formally called Pulse
    Code Modulation (PCM)
  • Mono speech recording at 8kHz sample rate and 8
    bits/sample equals 64 kbps of data
  • CD quality (44.1 kHz, 16 bit, stereo) 1.411
    Mbps
  • Modems cant handle 64 kbps, and most broadband
    users cant consistently get 1.4 Mbps, so
    compression is needed even for just audio

18
Audio Compression
  • Common audio compression standards include
  • GSM, G.729, and G.723.3 from ITU
  • MPEG 1 layer 3, a.k.a. MP3, which compresses to
    96, 128, or 160 kbps
  • From Drexel library, can get electronic copy of
    Compression technologies for video and audio,
    Jerry C. Whitaker, ISBN 0071391460

19
Video Compression
  • Video is a series of images presented at 24 or 30
    images per second
  • Hence the size of the images (X by 0.75X
    pixels), and the color resolution (number of bits
    per pixel) also affect the amount of raw data
  • Widescreen image sizes have a 16x9 ratio instead
    of 4x3 ratio

20
Video Compression
  • Video compression standards are mostly the MPEG
    family
  • MPEG 1 for CD quality video at 1.5 Mbps
  • MPEG 2 for DVD quality video, 3-6 Mbps
  • MPEG 4 for object oriented video
  • H.261 from ITU
  • Proprietary formats, such as QuickTime (includes
    MPEG-4 and H.264), Real networks, etc.

21
Streaming Stored AV
  • Streaming audio/video has become terribly popular
    (YouTube, AOL Video) because
  • Disk space is dirt cheap (lt 15/GB)
  • Internet infrastructure is improving
  • Theres enormous demand to entertain me NOW
  • In this multimedia mode, clients request
    compressed AV files that live on servers
  • Files are segmented, with special headers used
    for encapsulating them

22
Streaming Stored AV
  • Other examples of streaming stored AV
  • Rhapsody, a proprietary client from RealNetworks
  • MSN Video, usually played through Windows Media
    Player (WMP)
  • Muze, an audio service to retailers

23
Streaming Stored AV
  • Various protocols can be used
  • RTP Real Time Protocol is used to encapsulate
    the segments
  • RTSP Real Time Streaming Protocol is used for
    client/server interaction
  • Users typically request files via a web browser
    which has a media player plug-in, such as Flash,
    Quicktime, Shockwave, RealPlayer or Windows
    Media Player

24
Streaming Stored AV
  • The media player has several functions
  • Decompress the audio or video files
  • Buffer the incoming data to smooth out jitter
  • Repair damage from lost packets as an attempt at
    error correction
  • The media player has a GUI interface, which may
    be integrated into the rest of a web page, or
    appear as a new dedicated window

25
Accessing AV via Web Server
  • Streaming stored AV can either be on a web
    server, or on dedicated streaming servers
  • In the former case
  • A TCP connection is established
  • An HTTP message requests the desired file
  • The audio file is encapsulated in the HTTP
    response message
  • A video file may be separate from audio, so the
    media player may have to assemble them

26
Accessing AV via Web Server
  • HTTP can have parallel downloads, so both audio
    and video can be downloaded at the same time
  • Or audio and video might be in one file, making
    the process simpler
  • The file(s) are passed to the media player, which
    decompresses them and plays them
  • But this assumes the entire file is downloaded
    before playing begins grumble

27
Accessing AV via Web Server
  • To avoid this, most media players have the server
    send the AV file directly to the media player
    process
  • Done via a meta file, which tells what kind of
    file will be streamed
  • The process becomes
  • User click on link for the desired file
  • Hyperlink is to the meta file
  • HTTP response contains the meta file

28
Accessing AV via Web Server
  • Clients web browser passes meta file to the
    media player
  • The meta file tells the browser which media
    player to use!
  • Media player sets up TCP connection with the HTTP
    server, and requests the actual AV file
  • AV file is sent to the media player, which then
    streams it
  • So this could work, but its slow (TCP) and
    doesnt allow pausing or rewinding easily

29
Accessing AV via Streaming Server
  • To avoid the slowness of HTTP/TCP, AV can be sent
    via a dedicated streaming server over UDP
  • Custom protocols can be used in place of HTTP
  • Now one server has HTTP and meta files, and the
    streaming server has the AV files
  • These could be two physical servers, or one

30
Accessing AV via Streaming Server
  • Now the AV is sent over UDP, at a rate equal to
    its play rate (or drain rate)
  • Playout is delayed 2-5 seconds, to allow for
    jitter
  • Data is put in a client buffer, from which its
    played after the delay
  • Or could send AV data over TCP, to get better
    sound quality, at the risk of sound pauses
    (client buffer starvation)

31
Accessing AV via Streaming Server
32
Client Buffer
33
RTSP
  • The real time streaming protocol (RTSP) allows
    the user to control playback of audio or video
  • Defined by RFC 2326
  • It does NOT define compression schemes to be
    used, encapsulation (see RTP), transport protocol
    (TCP or UDP), or buffering approach
  • Those are all application-level concerns

34
RTSP
  • So what DOES it do?
  • Allow user to pause/resume, reposition playback,
    fast forward, or rewind
  • RTSP sends control messages out-of-band, using
    port 544, could be over TCP or UDP
  • Recall FTP also used out-of-band control messages
  • The actual media stream is a separate band
  • Like HTTP, commands are plain text, with
    code-identified responses
  • But RTSP maintains session client state
    information

35
RTSP Example
  • An HTTP GET command requests the presentation
    (meta) file from the web server
  • Then passes it to the media player to manage
    getting the media and playing it
  • In this example, the audio and video files are
    separate, but are played together (lipsynch)

36
Meta file example
  • lttitlegtTwisterlt/titlegt
  • ltsessiongt
  • ltgroup languageen lipsyncgt
  • ltswitchgt
  • lttrack typeaudio
  • e"PCMU/8000/1"
  • src
    "rtsp//audio.example.com/twister/audio.en/lofi"gt
  • lttrack typeaudio
  • e"DVI4/16000/2"
    pt"90 DVI4/8000/1"
  • src"rtsp//audio.ex
    ample.com/twister/audio.en/hifi"gt
  • lt/switchgt
  • lttrack type"video/jpeg"
  • src"rtsp//video.ex
    ample.com/twister/video"gt
  • lt/groupgt
  • lt/sessiongt

37
RTSP Example
38
RTSP
  • Many RTSP methods are pretty self-explanatory
    PLAY, PAUSE, RECORD
  • SETUP establishes the connection
  • TEARDOWN closes the connection
  • DESCRIBE identifies the media to be played
  • ANNOUNCE updates the session description
  • RTSP is used by Real Networks

39
Internet Phone
  • Real-time apps, such as Internet phone and video
    conferencing, are very sensitive to packet delay,
    jitter, and packet loss
  • See how these issues are handled for Internet
    phone
  • Data is generated at 8 kBps
  • Every 20 ms, a chunk of 160 bytes of data gets a
    header attached, and the packet is sent via UDP
  • Ideally, these packets all get to the receiver

40
Internet Phone
  • The receiver must decide
  • When to play back a given packet
  • What to do if a packet is missing
  • Recall packets can be lost if they arrive at a
    router with a full input or output queue
  • From 1-20 packet loss can be tolerated
  • Forward error correction (FEC) can help make up
    for lost packets

41
Internet Phone
  • End-to-end delay can be confusing for the
    receiver, if it simply takes too long for the
    data to get there
  • Recall the under 150 ms, 150-400 ms, and over 400
    ms ranges for good, ok, and bad delays
  • Internet phone may discard packets over 400 ms
    old
  • Jitter is typically caused by variation in
    queuing delays

42
Internet Phone
  • Some jitter problems can be removed by using
    sequence numbers, time stamps, and playout delays
    to make sure packets are in order as well as
    possible
  • Playout delay can be fixed or adaptive
  • For fixed playout delay, anything arriving after
    its planned play time is discarded
  • The amount of delay is typically 150-400 ms, less
    under good network conditions

43
Adaptive playout delay
  • Adaptive playout delay is often used because long
    delay is annoying to the users
  • Want to make the delay as small as possible
    without losing a lot of packets
  • Delay is reassessed for each talk spurt (period
    of transmission)
  • Similar to calculation of timeout interval for
    TCP, use previous history, amended by the
    most recent data

44
Adaptive playout delay
  • di (1-u)di-1 u(ri-ti)
  • Where d is the average network delay
  • u is a fixed value, e.g. 0.01
  • ri is when the ith packet was received
  • ti is the time that packet was timestamped by
    the sender
  • Similarly the average deviation is
  • vi (1-u)vi-1 uri ti di

45
Adaptive playout delay
  • Then the playout time for the first packet in a
    talk spurt is
  • pi ti di Kvi
  • Where K is typically 4, much likeTimeoutInterval
    EstimatedRTT 4DevRTT
  • This gives us an approach to calculate the
    playout delay, and keep adjusting it to
    compensate for network traffic conditions

46
Stored vs real time AV
  • Streaming stored audio video, in contrast, uses
    the same techniques to help smooth out network
    jitter
  • Sequence numbers, timestamps, playout delay
  • But stored AV can tolerate much larger delays
    before playout begins (compared to real time
    AV), which gives the app developer much more
    design flexibility

47
Recovering from packet loss
  • The method for compensating for lost packets is
    the loss recovery scheme
  • Here, lost means it never got there, or it got
    there after its planned play time
  • Retransmitting lost packets doesnt make sense
    here (why?)
  • Instead anticipate loss, using methods like
  • Forward Error Correction
  • Interleaving

48
Forward Error Correction
  • Forward Error Correction adds a little redundant
    data to packets to help allow recreating what
    missing packets had in them
  • RAT (Robust Audio Tool) is an open source
    Internet phone app that uses FEC and RTP
  • There are lots of FEC approaches well look at
    two of them

49
Forward Error Correction
  • First is to send a redundant encoded chunk of
    data after every n normal chunks
  • The redundant chunk is obtained from XOR-ing the
    normal chunks
  • If any ONE of the n chunks is missing, it can be
    reconstructed mathematically
  • But if two or more packets are lost, tough luck
  • This increases transmission rate 100/n

50
Forward Error Correction
  • The second approach is sneakier
  • Add a second, lower quality data stream in
    parallel with the primary stream (e.g. tack on a
    13 kbps stream to a 65 kbps stream)
  • When loss occurs, use the low quality stream
  • This increases playout delay little
  • Many variations on this approach are possible,
    especially to allow for higher loss rates

51
Interleaving
  • Interleaving breaks the stream of data into
    smaller chunks, and rearranges how the chunks are
    sent
  • So if each chunk of data is broken into four
    pieces, then the first unit of data sent has
    chunks number 1, 5, 9, and 13 instead of just
    1-4
  • The second chunk sent has 2, 6, 10, 14 the
    third chunk has 3, 7, 11, 15, etc.
  • That way if a chunk is lost, the loss is
    distributed across a wider range of time

52
Interleaving
  • This increases latency (have to break up
    reassemble chunks)
  • Doesnt increase bandwidth of data no extra
    data is being sent
  • So how can we fix the data if some is lost?

53
Repair of damaged audio
  • Voice is relatively easy to fix if a little data
    is missing
  • Loss rates under 15 for packets 4-40 ms long
  • One technique is simply repetition copy the
    previous packet and play it again
  • Easy to do and usually works ok
  • Or can try to interpolate between before and
    after packets
  • More tricky computationally, but sounds better

54
Content Distribution Networks
  • Content Distribution Networks (CDNs) are to
    address the need for lots of people accessing the
    same stored media often and/or at once
  • After all, a single server source would have
    terrible bandwidth and packet loss issues
  • Often a content provider (CNN, MSN, etc.) will
    pay a CDN company (Akamai) to provide videos to
    users with as little delay as possible

55
Content Distribution Networks
  • The CDN approach is simple make lots of copies
    of the media, and put them on lots of servers
    everywhere
  • CDN servers get put throughout the Internet
  • Often the CDN company will lease data center
    space to house the servers
  • Data centers might be located at second or third
    tier ISPs

56
Content Distribution Networks
  • The CDN gets source media (videos) from the
    customer, and copies them to the servers
  • When a user requests content, the nearest (or
    most available) CDN server delivers it
  • DNS redirection is used to find the correct CDN
    server
  • This results in URLs with two addresses in them
    the first is the CDN, the second is the file name
  • http//www.cdn.com/www.cnn.com/zoo/turtle.mpg

57
Content Distribution Networks
  • The best server for each ISP is determined
    using the same approaches we saw for BGP routing
    tables
  • CDNs may also be used within a large corporation
    to stream, for example, training videos locally

58
Dimensioning best-effort networks
  • Many techniques weve seen can be used to improve
    the quality of service of multimedia apps
  • We want low RTT, little jitter, few packets lost
  • Another solution is to throw enough money at the
    network to avoid all these problems
  • Given enough resources, none of these problems
    occur!

59
Dimensioning best-effort networks
  • To do so requires adequate bandwidth
    provisioning, and at a larger scale, good network
    dimensioning issues include
  • Model traffic demand between network end points
  • Clear performance requirements
  • Model performance for a given workload
  • Model to predict minimum bandwidth to meet all
    requirements

60
Real-time Interactive Protocols
  • Demand for real time interactive applications is
    huge, so there has been a lot of work on
    protocols to help make such apps easier to
    develop
  • Here well look at three common ones
  • RTP, the Real-time Transport Protocol
  • SIP
  • H.323

61
RTP
  • RTP defines a standard AV chunk-of-data structure
    for data, sequence numbers, timestamps, etc.
  • The actual data format can be a proprietary
    format, or other AV formats such as PCM, GSM,
    MP3, MPEG, H.263, etc.
  • RTP is defined by RFC 3550, and usually runs over
    UDP (no specific port number)
  • Often used for Internet telephony apps

62
RTP
63
RTP
  • An RTP packet consists of the RTP header plus the
    data
  • The RTP header is at least 12 B (3 rows x 4B ea.)
  • Apps that both use RTP have a better chance of
    cooperating (e.g. if two users have different
    apps at each end of a phone call)
  • RTP doesnt guarantee data delivery, or sequence
  • Routers cant tell RTP data from anything else

64
RTP
  • Every data source (video camera, microphone) can
    have an RTP data stream
  • Video conference could have four RTP streams to
    send video each direction, and audio each way
  • Some compression formats (MPEG-1 and -2) combine
    audio and video into one stream
  • RTP can be used with unicast or multicast
  • A group of streams from the same origin form an
    RTP session

65
RTP Header Fields
  • The RTP header is very simple
  • First line has
  • Nine bits of misc. identifiers (version, how long
    the CSRC list will be, if custom extensions are
    used, etc.)
  • Payload type (7 b)
  • Sequence number (16 b)
  • Timestamp (32 b)
  • SSRC (32 b)
  • CSRC list (0 to 15 lines of 32 b each)

66
RTP Header
  • The Payload Type is a numeric code that
    identifies what format the data has PCM, GSM,
    MPEG, etc.
  • The Sequence Number starts at a random value, and
    increments by one for each RTP data packet sent
    RFC 3550
  • The Timestamp is when the first data was sampled
    change from one to the next is inversely
    proportional to the sampling rate

67
RTP Header
  • The SSRC is the synchronization source identifier
    just a random number to identify the source
  • Only goal is that no two SSRCs are the same in a
    session
  • The CSRC list is the contributing sources for
    audio data
  • Is often used for mixing, or to identify specific
    data sources (Fred vs. Wilma)

68
RTP App Development
  • RTP can be implemented two ways
  • Use RFC 3550 and manually implement RTP headers
    within your application
  • Use existing API libraries (e.g. in C or Java) to
    implement RTP for you, and have your app call
    them
  • Hmm, I wonder which is easier?
  • RTP can be coded as an app-layer protocol, or
    used in conjunction with UDP via the API

69
RTP Control Protocol (RTCP)
  • RTCP is also defined by RFC 3550
  • It defines control packets that are sent by data
    senders and receivers in an RTP session via IP
    multicast
  • Main purpose is to provide feedback on the
    quality of the data distribution
  • It identifies the RTP source by a canonical name
    or CNAME
  • Control rate of data transmission, identify
    users

70
RTCP
  • RTCP uses the next port number above that used by
    RTP
  • RTCP packets are sent periodically by all session
    systems
  • They have no data attached just headers
  • Sender Report (SR) has SSRC of the session,
    timestamp of most recent RTP packet, of packets
    and bytes sent in the stream

71
RTCP
  • Sender reports can synch streams in a session
  • The Reception Report (RR) has reception
    statistics
  • SSRC of the RTP stream of interest
  • Fraction of packets lost
  • Last sequence number received
  • Interarrival jitter
  • There are source description packets, giving
    user name, email, app, SSRC

72
RTCP
  • RFC 3550 has massive detail on the statistics
    which can be collected (bandwidth, packet size,
    jitter, transmission interval, packets lost,
    etc.) but leaves analysis and interpretation of
    the data to the app developer
  • Sender and receiver reports can be stacked into a
    combined report

73
RTCP Scaling
  • The amount of RTP traffic doesnt change with a
    large number of receivers, but the amount of RTCP
    traffic does grow
  • RTCP tries to limit itself to 5 of session
    bandwidth(!)
  • This results in different RTCP transmission
    periods (T) for senders versus receivers
  • Two senders and 100 receivers will get
    T(receiver) 16.67T(sender)

74
SIP
  • The Session Initiation Protocol (SIP) is defined
    by RFC 3261
  • SIP can be over UDP or TCP, and uses port 5060
  • It is designed to handle Internet telephone
    across LANs (not local phone exchanges)
  • It allows calls to be placed over IP
  • Allows caller to determine IP of callee (varies)
  • Can add media streams during call

75
SIP Session Example
  • Caller sends an INVITE message
  • Tells caller and callee IP addresses, media
    format and encoding, type of encapsulation (RTP)
    and receiving port number
  • Callee sends response msg
  • Confirms IP address, encoding, encapsulation, and
    port number
  • Caller sends ACK to callee, and the call can take
    place

76
SIP Session Example
77
SIP
  • So what?
  • The two parties can be using completely different
    encoding and encapsulation methods, yet carry on
    the call
  • Also note that the control messages stay over
    port 5060, yet the media are over two other,
    negotiated ports so SIP uses out-of-band
    control messages
  • SIP requires ACK of all messages, so either UDP
    or TCP can be used

78
SIP Addressing
  • SIP addresses can look like email addresses, or
    cite IP addresses, or be a phone number, or even
    a full personal name
  • bob_at_mydomainnotyours.com
  • bob_at_213.33.129.97
  • 12125551212_at_phone2net.com

79
SIP Messages
  • The SIP protocol is huge 269 pages so only a
    brief overview is in order
  • The INVITE message typically is addressed to an
    email-like address, e.g. bob_at_domain.com
  • Each device the message passes through adds a
    Via header with that devices IP
  • A SIP proxy finds the IP of the device the
    callee is currently using

80
SIP Messages
  • Every SIP user is associated with a SIP
    registrar
  • When a SIP device is launched, it registers with
    the registrar to give its current IP address
  • So the SIP proxy asks the callees registrar for
    their IP address
  • The proxy might be redirected to another
    registrar if the callee is not nearby

81
SIP applications
  • SIP has been described for voice over IP, but can
    also be used for any media video, even text
    messaging
  • SIP software is widely available for many common
    functions, on various platforms (PC/Mac/Linux)

82
H.323
  • H.323 (catchy name, huh?) is an alternative to
    SIP
  • Computers can use SIP or H.323 to connect to
    plain telephones, as well as do IP-only calling
  • H.323 supports audio and optionally, video
  • Audio must support at least G.711 speech
    compression at 56 or 64 kbps

83
H.323
  • Video, if used, must support at least QCIF H.261,
    which is a massive 176x144 pixels
  • H.323 is a suite of protocols
  • Includes a separate control protocol (H.245),
    signaling channel (Q.931), and uses RAS for
    registering with the gatekeeper
  • The gatekeeper is between the IP and plain
    telephone networks
  • Whereas, SIP only manages connections

84
H.323 vs SIP
  • H.323 is from the ITU (mainly telephone basis),
    whereas SIP is from IETF (the RFC folks)
  • SIP can work with RTP, G.711, and H.261, but
    doesnt require any of them
  • SIP is simple compared to H.323

85
Beyond Best Effort
  • So lots of techniques have been used to get the
    most out of the Internets best effort approach
  • The current quality of service (QoS) has no
    guarantees
  • How can we improve on that?
  • Change the architecture of the Internet!
  • Look at a simple network to examine the
    problems

86
A Sample Network
87
A Sample Network
  • In this example, the local networks are assumed
    much faster than the 1.5 Mbps connection between
    them
  • Two apps are competing for that 1.5 Mbps of
    bandwidth, e.g. leaving the first router (R1)
  • Scenario 1 If hosts H1 is sending FTP to H3,
    and then H2 tries to send audio traffic to H4,
    the router R1 will already be full, making for
    lost audio packets

88
A Sample Network
  • But IF we could mark audio packets versus FTP
    packets, we could give priority to audio packets,
    since they are delay sensitive
  • Principle 1 packet marking lets a router
    distinguish between different classes of traffic
  • Scenario 2 what if the FTP traffic was on a
    high priority (paid) connection, but the audio
    traffic was normal free Internet
  • Principle 1a packet classification lets a router
    distinguish between different classes of traffic

89
A Sample Network
  • The distinction is important
  • Marking packets for type of payload is one way to
    classify them, but hardly the only one
  • The packets could be prioritized by the
    originating IP address (which could imply whether
    premium service was used)
  • Scenario 3 Bad application
  • What if the audio app should get priority, but
    it abuses that and hogs the whole link?

90
A Sample Network
  • Instead of allowing 1.0 Mbps for audio, the app
    tries to take the whole 1.5 Mbps, thereby
    shutting off the FTP service
  • Just like circuit switching, we want to isolate
    each traffic flow, so a misbehaving app doesnt
    ruin the link for everyone
  • Principle 2 Some degree of isolation is
    desirable to protect traffic flows from each
    other
  • This might imply the need for traffic cops, to
    ensure app compliance

91
A Sample Network
  • So two approaches could address these concerns
    and improve the QoS
  • Mark packets, and police app behavior to share
    bandwidth fairly
  • Or, logically isolate traffic flows, and
    designate some specific bandwidth for each
  • But if the flows are isolated, need to make sure
    full bandwidth is used if a traffic flow
    isnt active

92
A Sample Network
  • Principle 3 When traffic flows are isolated,
    need to use resources (bandwidth, router buffers)
    as efficiently as possible
  • Scenario 4 Two 1.0 Mbps audio apps over a 1.5
    Mbps link
  • Both audio apps cant get the full bandwidth
    needed each would lose 25 of their packets
  • To maintain any decent QoS level, the network
    should allow or block the flow
  • Telephones have done this for years!

93
A Sample Network
  • So to guarantee a minimum level of QoS we need a
    call admission process
  • Principle 4 a call admission process is needed
    to admit or block calls from the network, based
    on the calls QoS requirements
  • Now that we have the principles of guaranteeing
    QoS, look at how these are implemented in
    the Internet

94
Scheduling and Policing
  • Recall at the link level, packets from various
    flows are multiplexed and queued on the output
    buffers to go onto a link
  • The link-scheduling discipline is the process for
    queuing packets, which is vital for making QoS
    guarantees
  • Look at FIFO, priority, round robin, and WFQ
    approaches for link-scheduling

95
FIFO Scheduling
  • FIFO (first-in first-out), also called first-come
    first-served (FCFS) is the McDonalds approach to
    scheduling
  • Packets are queued in the order in which they
    arrived at the device
  • If the output buffer gets full, the
    packet-discarding policy is used to decide which
    packets are dropped

96
Priority Queuing
  • Here, packets are grouped by their priority a
    separate queue for each level of priority
  • How they are grouped could be by type of service,
    source IP, or other methods
  • The highest priority queue is emptied before the
    next priority queue is transmitted
  • If the high priority queue is empty, a lower
    priority packet will still be sent immediately
  • Within each queue, FIFO applies

97
Round Robin Queuing
  • In round robin, packets are sorted into classes
    which have no relative priority
  • One packet from class 1 is sent, then one from
    class 2, etc.
  • Then go back to class 1 and keep repeating the
    cycle
  • A work-conserving round robin tries to keep the
    link busy, so will check the next class if
    one is empty

98
Weighted Fair Queuing (WFQ)
  • WFQ is a variation on round robin queuing
  • Here each class is assigned a weight, which
    determines how much transmission time they get
  • In short, some classes are more equal than others
  • The weights for all classes total 100
  • Incoming packets are classified into the correct
    class, which has its own queue
  • WFQ is very widely used

99
Policing
  • We may need to control the rate data are allowed
    to enter the network a traffic cop
  • Could control three aspects
  • Long term average data rate
  • Peak or max rate
  • Burst size max number of packets in a short
    time interval

100
The Leaky Bucket Analogy
  • Bucket holds b tokens (packets)
  • New tokens are created at rate r tokens per sec
  • If bucket is full, new tokens are discarded

101
The Leaky Bucket Analogy
  • The token generation rate, r, limits the long
    term average rate
  • In any time t, the max number of tokens which
    could be added to the network is rt b, so
    that limits the peak rate
  • The size of the bucket limits the max burst size
  • No more than b tokens can be removed in a short
    time

102
WFQ Leaky buckets
  • If we combine the WFQ scheduling with the leaky
    bucket policing options, what happens to the
    delay for any class of packets?
  • If the class bucket is full, and b1 packets
    arrive, the rate the bucket is emptied is at
    least Rwi/sum(w) where R is the link rate, wi is
    the weight of this class, and sum(w) is the sum
    of all active classes weights

103
WFQ Leaky buckets
  • So the time for the bi packets to be handled is
    time quantity/rate
  • di bi/Rwi/sum(w)
  • Hence there is a provable maximum delay
  • As long as the rate this class can handle packets
    is less than Rwi/sum(w), the above di equation
    is the max delay in a WFQ queue

104
Integrated vs Differentiated Services
  • Now weve covered the types of mechanisms needed
    to provide QoS guarantees in the Internet
  • Cool. So, how is this being implemented?
  • Two major architectures are trying to provide an
    answer Intserv and Diffserv
  • Integrated Services Intserv
  • Differentiated Services Diffserv

105
Intserv
  • Intserv provides a way for QoS to be specified
    for a given session
  • Kind of like setting up a virtual circuit
  • Intserv depends on two key features
  • Must know what resources are already occupied by
    routers along a desired path
  • Must do call setup to prepare for a session

106
Intserv
  • Call setup includes
  • A session must define the QoS needs
  • An Rspec defines the type of QoS service desired
  • A Tspec defines the traffic the session will be
    sending
  • See RFC 2210 and 2215 for Rspec and Tspec
  • Then a signaling protocol, RSVP, is used to set
    up along the paths routers
  • Each router (element) decides whether to allow
    the session

107
Intserv
  • Intserv provides two different types of QoS
  • Guaranteed QoS the bounds on queuing delays for
    each router are assured
  • See RFC 2212 for gory details how this is done
  • Controlled-load Network Service the session
    will receive a close approximation to the QoS
    an unloaded element would provide
  • Oddly, this QoS is not quantified
  • RFC 2211, since you were wondering

108
Diffserv
  • Diffserv (RFC 2475) was in response to problems
    with Intserv
  • Scalability problems with per-flow (session)
    reservations
  • Gets very time consuming for large networks
  • Flexibility in service classes Intserv only
    provides specific service classes
  • Want ability to grade or rank service classes
    (low/med/high, silver/gold/platinum, etc.)

109
Diffserv
  • Diffserv assumes the whole network will be aware
    of Diffserv protocols, and that most traffic
    flows are under Diffserv
  • You will be assimilated!
  • Two main functions under Diffserv
  • At the edges of the network, hosts or first hop
    routers mark the DS field in the packet header
  • Within the core of the network, traffic is
    handled based on its class per-hop behavior

110
Diffserv
  • Analogy
  • The marking process is like getting your hand
    stamped at a night club, or having a VIP or
    backstage pass, or getting comped for spending
    too much money at a casino
  • Packets are classified based on source or
    destination IP or port, or (transport) protocol
  • There could be different marking algorithms for
    various classes of flows

111
Diffserv
  • Classes of flows could follow a traffic profile
  • May limit their peak transmission rate, or
    burstiness
  • A metering function could be used to control flow
    rate into the network, or shape flow rates
  • The differentiated services (DS) field (RFC 3260)
    replaces the type of service and traffic class
    fields from IPv4 and IPv6
  • The packets are marked using the DS field

112
Diffserv
  • Within the network, each class per-hop behavior
    (PHB) is critical to controlling its handling
  • PHB influences the forwarding behavior
    (performance) at a Diffserv node
  • No method for implementing behavior is given
  • Only key is that they are externally measurable
  • Two PHBs have been defined expedited forwarding
    (EF), and assured forwarding (AF)

113
Diffserv
  • Expedited forwarding (EF, RFC 3246) requires the
    departure rate of a class must equal or exceed a
    certain rate
  • Implies isolation from other traffic classes,
    since the absolute rate is guaranteed
  • Assured forwarding (AF, RFC 2597) divides traffic
    into four classes
  • Each is guaranteed bandwidth and buffer space
  • Per class there are three levels of drop
    preference

114
Intserv, Diffserv, and Reality
  • So while techniques exist to provide QoS
    guarantees, they arent widely used
  • Why? The Internet is highly distributed, and not
    everyone will agree 1) to implement QoS methods,
    2) on the type of QoS needed, and 3) on how to
    pay for it
  • And if traffic levels are low, best effort will
    provide the same service as Intserv/Diffserv!

115
RSVP Protocol
  • In order to reserve resources in the Internet, a
    signaling protocol is needed
  • The Resource reSerVation Protocol (RSVP, RFC
    2205) does so
  • Here we focus on bandwidth reservation, but RSVP
    can be used for other applications
  • To work, hosts and routers need to implement the
    RSVP protocol

116
RSVP Protocol
  • RSVP provides reservations for bandwidth in
    multicast trees (unicast is easy then)
  • The receiver of the data controls getting the
    reservations (not the sender)
  • In a session, each sender can control many flows
    (audio and video, e.g.)
  • Each flow has the same multicast address
  • To distinguish flows, use the flow identifier
    (IPv6)

117
RSVP Protocol
  • RSVP does not specify how the bandwidth is
    obtained see earlier scheduling methods
    (priority scheduling, WFQ, etc.)
  • RSVP depends on other routing protocols to
    determine the path needed, and hence the specific
    links in the path
  • If the path changes during the session, RSVP
    re-reserves the path

118
RSVP Protocol
  • In multicast, receivers could have many different
    speeds dial up, cable, DSL, etc.
  • Sender doesnt need to know the rate of all
    receivers, only the rate of the fastest one
  • Encode the media in layers at different data
    rates (e.g. 20 kbps 100 kbps)
  • A slow base layer (dial up), and add other layers
    to enhance the image/signal for faster receivers
  • Each receiver picks up the layers they can use

119
RSVP Protocol
  • The source of a multicast advertises content
    using RSVP path messages through a multicast
    tree
  • Tells the bandwidth required, timeout interval,
    and upstream path to the sender
  • Receivers send RSVP reservation messages
  • Tells what rate they want the data
  • Message is passed upstream to the source, where
    each router allocates the bandwidth

120
RSVP Protocol
  • Routers can merge requests for the same multicast
    event saves having many reservations for the
    same signal!
  • Hence routers only need to reserve the maximum
    downstream receiver rate
  • Routers only send one reservation message
    upstream

121
RSVP Protocol
  • In a conference call situation, all participants
    are typically senders and receivers of video, so
    the bandwidths are added
  • For audio only, its rarer for many to speak at
    once, to typically if one user is transmitting at
    rate b bps, reserving 2b bps is typically
    adequate bandwidth

122
RSVP Protocol
  • When a router gets a reservation request, it must
    do an admission test
  • If there isnt enough bandwidth to handle the
    reservation, the router rejects the reservation
    and returns an error message to the receiver
  • RSVP is very receiver-oriented, since they
    request reservations

123
Soft Hard State Reservations
  • In general, a signaling protocol can have soft or
    hard state reservations
  • Soft state reservations will time out unless
    renewed periodically
  • You have to say Im alive! or Ill assume
    youre dead
  • A system could crash and reboot, and it wouldnt
    lose its reservation, if it responded fast enough
  • RSVP, PIM, SIP, and IGMP use soft state

124
Soft Hard State Reservations
  • Hard state signaling means the reservation stays
    forever, until explicitly removed by an
    uninstall, delete, tear-down, or other message
  • Requires a means to look for orphaned states
    (its installer is dead or gone)
  • Typically used for reliable systems (not best
    effort) so few Internet protocols use it
  • RSVP has optional removal of reservations

125
Summary
  • Multimedia is huge in the Internet, and getting
    bigger!
  • May replace circuit switched telephones
  • Here we reviewed the types of multimedia apps,
    looked at methods for best-effort networking,
    added methods for QoS guarantees, and outlined
    architectures for providing QoS
Write a Comment
User Comments (0)
About PowerShow.com
