Signal Conditioning

1
CHAPTER 6

• Signal Conditioning

Norazila Jaalam Fkee
2
CHAPTER OUTLINE

• Introduction to signal conditioning
• Bridge circuits
• Amplifiers
• Protection
• Filters

3
AMPLIFIER

• Introduction
• Operational Amplifier in Instrumentation.
• Inverting Amplifier
• Non-inverting Amplifier
• Unity Follower
• Summing Amplifier

4
AMPLIFIER intro..

• the basis of signal conditioning
• is an electronic circuit which makes a signal
  bigger
• is often needed in systems using analogue signals

5
AMPLIFIER intro..

• Has two inputs inverting i/p (-) and
  non-inverting i/p ()
• The output depends on the connections made to
  this i/p
• Operational amplifier (Op-amp) is a semiconductor
  device that consist dozen of transistors and
  resistors sealed in a package
• Simple amplifier for analog circuit can be
  developed by using this op-amp.

Normally VCC is set to 15V
6
Properties for Ideal Op Amp
AMPLIFIER intro..
(Infinite gain)
(Infinite input resistance)
(Zero output resistance)
For idealized model
7
AMPLIFIER intro..
Properties for practical Op Amp

• Very high voltage gain
• Very high input impedance
• Very low output impedance
• Wide bandwidth

8
Inverting Amplifier

• Figure shows the connections made to amplifier
  when used as an inverting amplifier
• The input is taken to the inverting i/p through
  R1 with non-inverting i/p being connected to
  ground
• A feedback path is provided from the output via
  the resistor Rf to the inverting i/p

I1 If
The negative feedback stabilizes the voltage
gain indicates inversion
9
EXERCISE 1 Find Vout for both circuits shown
below
10
Non-Inverting Amplifier

• Figure below shows the connection to the op-amp
  when used as non-inverting amplifier with
  feedback
• The output can be considered to be taken from
  across a potential divider circuit consist of R1
  in series with Rf

11
EXERCISE 2

Determine the gain of the amplifier in figure
below. Given Rf 100 k? and R1 4.7k?.
12
UNITY FOLLOWER (or voltage follower)

• special case of non-inverting amplifier where
  all output voltage is fed back straight away to
  inverting (-) input
• has very high input impedance and very low
  output impedance
• ideal buffer amplifier for interfacing high
  impedance source and low impedance loads

13
Summing Amplifier (with unity gain)

• Figure below shows the circuit of summing
  amplifier
• It is an inverting type of op-amp
• has two or more inputs (any number of input can
  be used)

For n input,
14
EXERCISE 3Determine the output voltage of
figure below. Given R1 10k?, R2 15k?, R3
20k?, Rf 10k? and VIN1 3V, VIN2 1V, VIN3
8V.
15
Gain of cascade circuit
16
EXERCISE 4 Determine the total gain produced by
the network below. Then, determine the output
voltage, Vout
AV1
AV2
17
EXAMPLE 5 Determine the total gain produced by
the network below. Then, determine the output
voltage, Vout
AV2
AV1
18
PROTECTION
A unit after a sensor (eg. microprocessor) has a
possibility to damage as a result of high current
or high voltage
How to protect?
High Current
High Voltage

• a series resistor to limit the current to an
  acceptable level
• a fuse to break if the current exceed a safe
  level

• use a Zener diode circuit

19
PROTECTION

• Zener diodes behave like ordinary diodes up to
  some breakdown voltage when they become
  conducting.
• Thus to allow a maximum voltage of 5 V, a Zener
  diode with a voltage rating of 5.1 V might be
  chosen.
• When the voltage rises to 5.1 V the Zener diode
  breakdown and its resistance drops to a very low
  value.
• Since the zener diode is a diode with low
  resistance for current in one direction and high
  resistance in opposite direction, therefore it
  also provides protection against wrong polarity

20
FILTERS

• A filter is a device that shapes or modifies the
  frequency content (spectrum) of a signal or
  waveform.
• often used in electronic systems to emphasize
  signals in certain frequency range and reject
  signals in other frequency range/decrease the
  amplitude .
• 4 types of filter Low pass filter (LPF), high
  pass filter (HPF), Band pass filter (BPF) and
  band stop filter (BSF)

21
Effect of filtering on a noisy signal
Signal with noise
FILTER
Signal Noise
Signal
Signal with noise removed
22
TYPE OF FILTERS
Band pass filter
Low pass filter
High pass filter
fc cut-off frequency
23
Low pass filter
0.707Am

• Passes frequency from dc to fc and significantly
  attenuates all other frequencies.
• fc (critical frequency or cut off frequency) is
  the end of the pass band and normally specified
  at the point where the response drops -3 dB of
  attenuation
• The output at the critical frequency is 70.7 of
  the input -3dB
• Approximate low frequency with ? ? 0 and high
  frequency with ?? ?
• at low frequency, gain 1,
• at high frequency, gain 0

20 log (0.707) -3dB
24
Low pass filter
Noise is a high-frequency waveform
Low-pass filter will only allow low-frequency
signal to pass through the network
25
Low pass filter design
Vi(t)
Vo(t)
26
Low pass filter
Cut off frequency is where the gain 1/?2 ( ?3
dB)
At cut-off frequency ZR Zc. Therefore
27
High pass filter
Am
0.707Am

• A high pass filter is device that significantly
  attenuates the low-frequency content of a signal
  while passing the high-frequency content with
  minimal attenuation.
• A filter designed to pass all frequency above a
  given cut-off frequency
• High-pass filters invert the frequency
  characteristics of low-pass filters
• Approximate low frequency with ?? 0 and high
  frequency with ? ? ?
• at low frequency, gain 0
• at high frequency, gain 1

28
High pass filter
Vo(t)
Vi(t)
29
High pass filter

• Cut off frequency is where the gain 1/?2 ( ?3
  dB)

At cut-off frequency ZR Zc. Therefore
30
Effect on filtering the high frequency signal
Noise is a high frequency signal
Only noise is allowed to pass through the high
pass signal
31
Filters

HPF
LPF







32
Band pass filter

• Designed to pass all frequency that fall between
  fc1 (HPF) and fc2 (LPF)
• High pass filter followed by Low pass filter
• Gain

33
Band pass filter
34
(No Transcript)
35
Band Pass Filters
Cut off frequency fc1 10 Hz fc2 100 Hz
100 Hz
10 Hz
36
After passing the High Pass filter
37
After passing the Low Pass filter
38
THANK YOU
