Platform LSF

1
Platform LSF
2
Cluster Contents

• Cluster-level Architecture
• Fault Tolerance
• How LSF deals with Resources
• How users interface with LSF
• Security Architecture
• Parallel Jobs
• Extensibility

3
Cluster-level Architecture
4
Cluster-level Architecture

• Four daemons run on each server host
• lim - Collects host load and configuration
  information and forwards it to the master LIM
  running on the master host.
• pim - Collects information about job processes
  running on the host such as CPU and memory used
  by the job, and reports the information to
  sbatchd.
• res - Accepts remote execution requests to
  provide, transparent and secure remote execution
  of jobs and tasks.
• sbatchd - Receives the request to run the job
  from mbatchd and manages local execution of the
  job.
• Two additional daemons run on the master host
• mbatchd - Receives job submission, and
  information query requests. Manages jobs held in
  queues. Dispatches jobs to hosts as determined by
  mbschd.
• mbschd Makes scheduling decisions based on job
  requirements and policies. Works with and is
  started by mbatchd.

5
Fault Tolerance

• System Level
• The master host is the first host listed in the
  lsf.cluster.cluster_name file or is defined along
  with other candidate master hosts by
  LSF_MASTER_LIST in lsf.conf.
• Every event in the system is logged to the
  lsb.events file, including all job submissions
  and job and host state changes.
• If the master LIM becomes unavailable, a LIM on
  another host automatically takes over. The
  sbatchd on the new master starts the mbatchd.
• The new mbatchd reads the lsb.events file to
  recover the state of the system.
• When the new mbatchd starts up it polls the
  sbatchds on each host and finds the current
  status of its jobs.
• If an sbatchd fails but the host is still
  running, jobs running on the host are not lost.
  When sbatchd is restarted it regains control of
  all jobs running on the host.

6
Fault Tolerance

• Job Level Rerun and Requeue
• Automatic job requeue occurs when a job finishes
  and has specified a certain exit code
  (indicating some type of failure).
• Automatic job rerun occurs when the execution
  host becomes unavailable, or the system fails
  while a job is running.
• Job rerun can be configured on the queue or job
  level (RERUNNABLE yes)
• Job requeue can be configured at the queue level
  (REQUEUE_EXIT_VALUES 99)

7
Resources

• The LSF system uses built-in and configured
  resources to track resource availability and
  usage. Jobs are scheduled according to the
  resources available on individual hosts.
• Dynamic Resources
• Load Indicies Periodically collected by the
  lim status, r15s, r1m, r15m, ut, pg, io, ls, it,
  tmp, swp, mem
• Dynamic External Load Indicies Collected by the
  elim daemon. Typically used to track floating
  licenses or available scratch space
• Static Resources
• Static Indicies Collected by the lim at
  startup ncpus, ndisks, maxmem, maxswp, maxtmp
• Static External Resources Defined in the
  lsf.shared file and attached to hosts in the
  lsf.cluster.cluster file. Typically used to
  represent node locked licenses or parallel file
  systems.

8
Resources

• LSF monitors the resource consumption of jobs
  submitted to the LSF system.
• The pim daemons samples the following
  information at regular intervals (defined by
  SBD_SLEEP_TIME in the lsb.params file)
• Total CPU time consumed by all processes in the
  job
• Total resident memory usage in KB of all
  currently running processes in a job
• Total virtual memory usage in KB of all currently
  running processes in a job
• Currently active process group ID in a job
• Currently active processes in a job
• The information is used to enforce resource
  limits and load thresholds as well as fairshare
  scheduling.
• Workload and Infrastructure information can be
  archived for analysis by using Platform
  Analytics. By default job related information is
  summarized and retained in the lsb.acct file.

9
User Interface

• Command Line
• Jobs can be submitted on the command line, or
  more commonly by using scripts
• Web Interface
• LSF provides a web GUI that operates via web
  services to submit, monitor, and operate on user
  jobs
• API
• C Applications coded in C can use this API. The
  application must be running on an LSF server or
  client.
• Java Java applications can use this API. The
  application must be running on an LSF server or
  client.
• Web Services Any web services aware application
  can use the LSF web services API to submit jobs
  to LSF. The application can run on any host.

10
User Interface
Monitor/control/configure/submit
11
User Interface

• Access to Enterprise Grid anytime, anywhere
• Job Submission, Monitoring Administration
• Cluster Management
• SOAP/XML API

12
Security Architecture

• LSF supports the following three authentication
  mechanisms
• External authentication (eauth) This is the
  default authentication method and is used by the
  vast majority of our customers. Eauth uses a
  configurable internal encryption key to encrypt
  authentication data.
• Privileged ports (setuid) -- If you do not use
  external authentication, privileged ports
  (setuid) authentication is used. This is the
  mechanism most UNIX remote utilities use. The LSF
  commands must be installed as setuid programs and
  owned by root.
• Identification daemon (identd) -- LSF also
  supports authentication using the RFC 931 or RFC
  1413 identification protocols. Under these
  protocols, user commands do not need to be
  installed as setuid programs owned by root. You
  must install the identd daemon available in the
  public domain.

13
Security Architecture

• External Authentication (eauth)
• LSF ships with an eauth binary which is
  installed in LSF_SERVERDIR
• Customers are free to write their own eauth
  programs to enforce site specific security
  requirements. Example eauth source code is
  provided in the LSF distribution.
• The LSF Kerberos integration package comes with
  an eauth (source code) that implements Kerberos
  authentication. Because Kerberos authentication
  is widely used within the DOD, the discussion
  that follows will focus on this method.
• The eauth mechanism can pass data (such as
  authentication credentials) from users to
  execution hosts. The environment variable
  LSF_EAUTH_AUX_DATA specifies the full path to a
  file where data, such as a credential, is stored.
  The mechanisms of eauth -c and eauth -s allow the
  LSF daemons to pass this data using a secure
  exchange.
• eauth operates in two modes client and server
  mode. When called as eauth c, eauth acquires
  credentials. When called as eauth s it
  validates them.

14
Security Architecture

• Kerberos Example
• The purpose of the Kerberos (krb5) integration
  with LSF is to provide the following
  functionality
• Perform krb5 authentication of end users to LSF
  when submitting jobs
• Authenticate the LSF daemon communications
• Provide the functionality to forward krb5
  credentials to the execution environment
• The integration makes use of LSFs eauth
  mechanism which allows all krb5 specific calls to
  be encapsulated within a small set of programs
• eauth The main driver for user and daemon
  communication and initial credential creation
• daemons.wrap Wraps the LSF daemons and is
  responsible for setting up the credential cache
  on the execution host
• eexec Creates the initial credential cache with
  a job specific name
• krenewPendJob Renews credentials for pending
  jobs
• krenew Renews credentials for running jobs

15
Extensibility

• LSF can be extended in many different ways to
  achieve almost any objective
• Dynamic external resources can be added via the
  elim facility
• LSF can run a pre and/or post execution script
  to setup or clean up after a job
• A job starter script can be configured to run
  just before a job (defined on the queue level).
  This script runs in the same shell as the user
  job
• Job submission parameters can be validated by an
  esub script. Esub can also pass information to
  eexec which can modify the environment of the job
• A script can be configured to run in the case
  of
• Job termination
• Termination/suspension/resuming action
• Checkpointing/restarting
• Custom authentication requirements can be
  satisfied by the creation of an external
  authentication program.
• Sites can even create their own scheduling
  algorithms and plug them into the LSF scheduler
