Open Distributed Systems - Lecture 5

1
Open Distributed Systems - Lecture 5

• Mark Baker
• School of Computer Science
• University of Portsmouth
• Tel [phone]
• Email Mark.Baker_at_computer.org
• URL http/www.dcs.port.ac.uk/mab/

2
Contents - Concurrency

• Semaphores and Shared Memory.
• Process Co-operation.
• Mutual Exclusion
• The Ornamental Gardens Problem.
• Critical Sections.
• Producer - Consumer Problem.
• Dining Philosophers.
• Locking/optimistic concurrency/Timestamps.

3
Semaphores and Shared Memory

• Semaphores are not used to exchange data between
  processes instead they are used to synchronize
  two or more processes.
• They prevent two processes from simultaneously
  accessing a shared resource.
• Consider a semaphore as an integer value variable
  that is a resource counter.

4
Semaphores and Shared Memory

• The value of the semaphore is a number to
  indicate whether the resources are available or
  not.
• A semaphore has only two values 0 and 1.
• Since the use of semaphores is to provide shared
  resources synchronisation, the semaphore value
  must be stored in the kernel as shown in the next
  slide.

5
Semaphores and Shared Memory
6
Process Co-operation

• In single CPU systems, critical regions, mutual
  exclusions, and other synchronisation problems
  are generally solved using methods such as
  semaphores and monitors.
• These methods are not well suited to use in
  distributed systems because they generally rely
  on the existence of shared memory.

7
Process Co-operation

• Two processes that are interacting using
  semaphores must both be able to share the
  semaphore by having it stored in the kernel, and
  then execute a system call to access it.
• If, however, the processes are running on
  different machines, this method no longer works,
  and other techniques are needed.
• In distributed systems it not even easy to
  determine whether one event occurred before
  another...

8
Mutual Exclusion

• Systems involving multiple processes are often
  most easily programmed using critical regions.
• When a process has to read or update certain
  shared data structures, it first enters a
  critical region to achieve mutual exclusion and
  ensure that no other process will use the shared
  data structures at the same time.
• In single-processor systems, critical regions are
  protected using semaphores, monitors and similar
  constructs.
• We will look at a few examples of how critical
  regions and mutual exclusion can be implemented
  in distributed systems.

9
Mutual Exclusion

• Now consider the problem of threads working
  (processing and updating) some data that is
  shared.
• In particular, think about the problem of
  interference and its solution using mutually
  exclusive access.

10
The Ornamental Gardens Problem

• A large Ornamental Garden is open to members of
  the public who can enter through either one of
  two turnstiles.
• The management want to determine how many people
  there are in the garden at any one time.
• They require a computer system to provide this
  information.

11
The Ornamental Gardens problem

• We will represent each turnstile by a thread and
  provide an object to store the count.
• Each turnstile displays the number of people it
  has let into the park
• The concurrent program consists of two concurrent
  threads and a shared counter object.

12
Ornamental garden Program
The Turnstile thread simulates the periodic
arrival of a visitor to the garden every second
by sleeping for a second and then invoking the
increment() method of the counter object.
13
Ornamental Garden - pseudo code

• main()
• int counter
• Thread turnstile() // Thread Def.
• for(int i 0 i lt 20 i)
• counter counter 1
• turnstile turnstileE, turnstileW // Thread
  Dec.
• turnstileW.start()
• turnstileE.start()

14
Ornamental Garden - Count Object

• class Counter
• int value_ 0
• public void increment()
• int temp value_ //read
• Simulate.interrupt()
• temp //add1
• value_ temp //write
• The simulated interrupt simply calls yield()
  randomly to force a thread switch - this is to
  make sure the demonstration works on all JVM.

15
The Ornamental Gardens problem

• In this example program, each turnstile is
  represented by a thread that updates a shared
  counter object.
• This version does not work correctly as can be
  observed, increments to the counter are lost so
  that the total number of people in the garden is
  not the sum of the people who entered through the
  turnstiles.

16
Ornamental garden program - display
After the East and West turnstile threads have
each incremented its counter 21 times, the garden
people counter is not the sum of the counts
displayed. Counter increments have been lost.
Why?
17
Interference

• The problem in the Ornamental Gardens program is
  that we have permitted the increment action by
  the West Turnstile to overlap with the increment
  action of East.
• GARDEN EAST WEST
• where
• EAST (increment ? EAST)
• WEST (increment ? WEST)
• and
• increment (read?add1?write)

18
concurrent method activation
Java method activations are not atomic - thread
objects east and west may be executing the code
for the increment method at the same time.
west
east
shared code
increment read value write value 1
program counter
program counter
19
Ornamental garden Model
Process VAR models read and write access to the
shared counter value. Increment is modelled
inside TURNSTILE since Java method activations
are not atomic i.e. thread objects east and west
may interleave their read and write actions.
20
Interference

• Consequently the following is a legal execution
  trace
• Wread ? Eread ? Wadd1 ? Wwrite ? Eadd1 ? Ewrite
• It can easily be seen that this results in losing
  an increment on counter.
• For correctness, we require that the increment
  actions do not overlap.
• forall e (Winc ? Einc) or (Einc ? Winc)

21
Interference and Mutual Exclusion
Destructive update, caused by the arbitrary
interleaving of read and write actions, is termed
interference.
Interference bugs are extremely difficult to
locate. The general solution is to give methods
mutually exclusive access to shared objects.
Mutual exclusion can be modeled as atomic actions.
22
Critical Sections

• We can avoid the problem of interference by
  making actions indivisible or atomic.
• The piece of code that must appear (from the
  point of view of some other process) as an atomic
  action and is called a Critical Section (CS).
• If processes P and Q both contain critical
  sections whose overlapped executions could
  interfere with one another, then we need to
  ensure these sections are executed under mutual
  exclusion.

23
Critical Sections

• forall e (CSiP ? CSjQ) or (CSjQ ? CSiP)
• For all pairs of processes P and Q and
  repetitions of their critical sections i and j.
• We say that two operations are serialised when
  they may be executed in either order but without
  overlap.

24
Critical Sections in Java
class Counter int value_0 public
synchronized void increment() int
temp value_ //read Simulate.interrupt()
temp //add1 value_temp //write

• A method can be made a critical section in Java
  by prefixing its definition with the keyword
  synchronized.
• The corrected code for the Counter class becomes

25
Java Synchronized Statement

• Java associates a lock with every object.
• Consequently in the previous example the Java
  compiler inserts code to acquire the lock before
  executing the body of the synchronized method and
  code to release the lock before the method
  returns.
• Access to an object may also be made mutually
  exclusive by using the synchronized statement.

26
Java Synchronized Statement

• For example, an alternative (but less elegant)
  way to correct the example would be to modify the
  Turnstile.run() method

public void run() while(true)
synchronized(people_) people_.increment()

27
Mutual Exclusion - Summary

• Concepts
• Interference.
• Critical section.
• Mutual Exclusion.
• Practice
• Synchronized methods.
• Synchronized statement.

28
Monitors

• A monitor is a language construct which provides
  automatic mutual exclusion to the variables it
  encapsulates.
• Variables may only be accessed via monitor access
  procedures which are critical sections.
• Consequently, only a single thread may be
  executing inside a monitor at any one time.

29
Monitors in Java

• Any object may be a monitor in Java by making all
  its methods synchronized and its data attributes
  private or protected.
• Consequently, the data encapsulated by the object
  can only be accessed via its methods.
• Because this access is synchronized, mutual
  exclusion is enforced.

30
Example Monitor in Java
class Counter private long value_ 0
public synchronized void inc() value_
public synchronized void dec() --value_
public synchronized long value()
return(value_)
31
Condition Synchronization

• In addition to mutual exclusion, monitors need to
  handle the more general problem of inter-thread
  synchronization.
• Hoare in his classic paper on monitors proposed
  condition variables which are simply FIFO queues
  of suspended threads.
• Hoare C.A.R.(1974), Monitors an Operating
  System Structuring Concept, Communications of the
  ACM, 17(10), 549-57.

32
Condition Synchronization

• wait(c) - Suspend execution of calling thread -
  place thread on condition queue(c).
• signal(c) - Resume execution of thread at the
  head of c.
• They are called condition variables (queues)
  since they are used to signal that some condition
  within the monitor holds, i.e. value_ 0 or
  buffer_empty.

33
Synchronization Mutual Exclusion

• Although only one thread may be executing inside
  a monitor at a time, a wait operation - which
  suspends a thread inside the monitor - will allow
  another thread to enter the monitor.
• Waiting threads effectively exit the monitor.
• If this was not the case and a suspended thread
  retained the monitor lock then no other thread
  could enter the monitor - the waiting thread
  could never be resumed.

34
Synchronization Mutual Exclusion
35
Condition Synchronization in Java

• Java provides only one condition queue per
  monitor .
• The following methods are provided by class
  Object (the base class).
• public final void notify() - Wakes up a single
  thread that is waiting on this object's monitor
  queue.
• public final void notifyAll() - Wakes up all
  threads that are waiting on this object's monitor
  queue.

36
Condition synchronization in Java

• public final void wait() throws
  InterruptedException - Waits to be notified by
  another thread, when notified, the thread must
  wait to reacquire the monitor before resuming
  execution.
• These operations fail if called by a thread which
  does not currently own the monitor, i.e. has
  acquired the monitor lock by executing a
  synchronized method or statement.

37
Semaphores

• Semaphores are the synchronization datatype
  defined by Dijkstra - Dijkstra E.W. (1968)
  Co-operating Sequential Processes. In Programming
  Languages, Academic Press.
• It is based on an integer variable to count the
  wakeups saved for future use.
• A semaphore could have a value 0, indicating no
  wakeups were saved, or some positive value if one
  or more wakeups are pending.

38
Semaphores

• Dijkstra proposed having two operations, DOWN and
  UP - generalisations of SLEEP and WAKEUP.
• WAIT if the value of the semaphore is gt 0 then
  decrement it and allow the process to continue,
  else suspend the process (noting that it is
  blocked on this semaphore)
• SIGNAL if there are no processes waiting on the
  semaphore then increment it else free one
  process, which continues at the instruction after
  its WAIT instruction.
• Semaphore S
• S.down() // - when Sgt0 decrement S
• S.up() // - increment S

39
Signalling using Semaphores

• The demonstration program has two threads Thread
  A signals the semaphore using up() and Thread B
  waits for the semaphore using down().

class Signaller implements Runnable
Semaphore sema_ Signaller(Semaphore s)
sema_ s public void run()
while(true) for(int i0ilt60 i)
DisplayThread.rotate()
sema_.up()
class Waiter implements Runnable Semaphore
sema_ Waiter(Semaphore s) sema_ s public
void run() while(true)
sema_.down() for(int i0ilt10 i)
DisplayThread.rotate()
40
Producer - Consumer Problem

• As an example of how these primitives can be
  used, consider the Producer-Consumer Problem
  (bounded-box problem).
• Two processes share a common, fixed-sized buffer.
• One of them, the producer puts information into
  the buffer, and the other, the consumer, takes it
  out.
• Trouble arises when the producer wants to put a
  new item in the buffer, but it is already full.

41
Producer - Consumer Problem

• The solution is to put the producer to sleep, to
  be awaken when the consumer has removed one of
  more items.
• Similarly, if the consumer want to remove an item
  from the buffer and see that the buffer is empty,
  it goes to sleep until the producer puts
  something in the buffer and wakes it up.

42
Producer - Consumer Problem
43
Correctness of Concurrent Programs

• A concurrent program must satisfy two classes of
  property safety and liveness.
• Safety Properties Assert that nothing bad will
  ever happen during an execution (that is, that
  the program will never enter a bad state).
• Liveness properties Assert that something good
  will eventually happen during execution.

44
Correctness of Concurrent Programs

• Liveness is concerned with making progress in a
  program - situations which prevent progress are
  livelock and starvation.
• Deadlock can be considered to impact both safety
  and liveness.
• Liveness properties are in general more difficult
  to prove than safety properties since they are
  dependent on the scheduling properties being used
  and require reasoning about infinite sequences of
  actions.

45
Readers - Writers

• Through synchronize , Java provides exclusive
  locking.
• However, in many programs it will be correct for
  a number of threads which do not modify a shared
  resource to access that resource concurrently
  (Readers).
• Threads which update the state of the resource
  (Writers) will still require exclusive access.

46
Dining Philosophers

• Dining Philosophers Problem Five philosophers
  sit around a circular table.
• Each philosopher spends his life alternatively
  thinking and eating.
• In the centre of the table is a large plate of
  noodles.
• A philosopher needs two chopsticks to eat a
  helping of noodles.

47
Dining Philosophers

• Unfortunately, as philosophy is not as well paid
  as computing, the philosophers can only afford
  five chopsticks.
• One chopstick is placed between each pair of
  philosophers and they agree that each will only
  use the chopstick to his immediate right and left.

48
Dining Philosophers
49
Dining Philosophers
50
Dining Philosophers - Specification

• DINERS PHIL0 ... PHIL5 CHOP0 ...
  CHOP5
• PHILi (i.think
• ?i.get.i ? i.get.(i1)
• ?i.eat
• ?i.put.I ? i.put.(i1)
• ?PHILi)
• CHOPi (( i.get.i?i.put.i (i?1).get.i
  ?(i?1).put.I ) ? CHOPi )
• where
• i1 (i5-1)5
• i?1 (i1)5

51
Philosopher implementation

• Each philosopher is a process with its own thread
  of control.
• CHOP is implemented by the monitor class
  Chopstick - the choice in CHOP is provided by the
  get()operation which allocates the chopstick to
  the first philosopher to request it and blocks a
  neighbours request until the fork is released by
  put().

52
Philosopher implementation

• The notion of first is realised by the
  synchronization lock which ensures that only one
  thread can be executing in get() at any one time.

• What happens when eating and thinking time is
  reduced in the demonstration program?

53
Deadlock

• The Dining Philosophers program deadlocks when
  every philosopher has obtained his/her right
  chopstick.
• No philosopher can obtain his/her left chopstick
  and so no progress can be made - the system is
  deadlocked.
• A thread/process is said to be in a deadlock
  state if it is waiting for a condition that will
  never become true (e.g. left chopstick becoming
  free).

54
Deadlock

• Note that the potential for deadlock exists
  independently of the thinking and eating times.
• However, the probability of deadlock occurring
  increases as these times are reduced.

55
Deadlock necessary and sufficient conditions

• Serially reusable resources the processes
  involved share resources which they use under
  mutual exclusion.
• Incremental acquisition processes hold on to
  resources already allocated to them while waiting
  to acquire additional resources.
• No pre-emption once acquired by a process,
  resources cannot be pre-empted (forcibly
  withdrawn) but are only released voluntarily.
• Wait-for cycle a circular chain (or cycle) of
  processes exists such that each process holds a
  resource which its successor in the cycle is
  waiting to acquire.

56
Wait-for cycle
Has A awaits B
A
Has E awaits A
Has B awaits C
E
B
C
D
Has C awaits D
Has D awaits E
57
Deadlock

• Deadlock can be avoided in the Dining
  Philosophers system by making one of the
  philosophers pick up his/her chopsticks in the
  reverse order (i.e. left before right).
• Can you suggest alternatives strategies for
  avoiding deadlock in the dining philosophers
  program ?

PHIL0 (0.think --gt 0.get.4 --gt 0.get.0 --gt
0.eat --gt 0.put.4 --gt 0.put.0 --gt PHIL0)
58
Distributed Concurrency Control

• We already covered simple case of single-system
  mutual exclusion.
• Now consider concurrency control in a distributed
  system...
• Techniques Used
• Locking.
• Optimistic Concurrency Control.
• Timestamps.

59
Locking

• The oldest and most widely used concurrency
  control algorithm is locking.
• In its simplest form, when a process needs to
  read or write data as part of a transaction, it
  first locks the data.
• Locking can be done using a single centralised
  lock manager, or with a local lock manager on
  each machine.

60
Locking

• In both cases the lock manager maintains a list
  of locked files and rejects all attempts to lock
  files that are already locked by another process.

• Since well-behaved processes do not attempt to
  access data before it has been locked, setting a
  lock on the data keeps everyone else away from it
  and ensure that it will not change during the
  lifetime of the transaction.

61
Locking

• Locks are normally acquired and released by the
  transaction system and do not require the
  intervention of the programmer.
• This system is very restrictive and can be
  improved greatly by distinguishing between
• read and write locks.
• Read locks make sure the data does not change,
  but does not exclude other processes reading the
  data.
• Write locks locks are exclusive !

62
Locking

• One issue with locking is the granularity of the
  lock - is it an entire file, record, memory page,
  object, data item
• Obviously the finer the granularity, the more
  precise the lock and the greater the potential
  for parallelism.
• On the other hand, fine granularity requires more
  locks, is more expensive to support and is more
  likely to lead to deadlocks.

63
Dead Locks

• Locking techniques can lead to dead locks.
• For example, if two processes acquire locks and
  then need to acquire each others lock before they
  can release their own, a state of dead lock will
  occur.
• Dead lock can be overcome by some type of queuing
  scheme of by having timeouts and aborts on locks.

64
Conditions for Dead Locks

• A resource request can be refused
• The systems concurrency control policy is such
  that objects can be acquired for exclusive use or
  some specific use.
• It is possible for a process to be refused access
  to an object on the grounds that some other
  process acquired it for exclusive use.
• An example is that a process may request
  exclusive access to an object in order to write
  to it but is refused because the object is
  currently locked for shared access.

65
Conditions for Dead Locks

• Hold while waiting
• A process is allowed to hold objects while
  requesting further objects. The assumption is
  that the process will wait for the resource until
  it become available.
• No preempton
• Objects cannot be recovered from processes. A
  process may acquire an object use it and release
  it.
• Circular wait
• A cycle of processes exists such that each
  process holds an object that is being requested
  by the next process in the cycle and that request
  has been refused.

66
Optimistic Concurrency Control

• The idea behind this technique is simple - just
  go ahead and do whatever you want to without
  paying attention to what anybody else is doing.
  If there is a problem worry about it later
• In practice conflicts are rare, so most of the
  time it works OK.

67
Optimistic Concurrency Control

• This technique manages conflicts by keeping track
  of which files have been read and written.
• At the point of committing, it checks all other
  transactions to see if its files have been
  changed since the transaction started.
• If it has, the transaction is aborted, if it has
  not the transaction is committed.

68
Optimistic Concurrency Control

• The advantages of this technique are
• deadlock free.
• maximizes parallelism as there no locks.
• The disadvantages are
• The technique sometimes fails, in which case the
  transaction need to be re-run.
• Under conditions of heavy load, the probability
  of failure may go up substantially, making this
  technique a poor choice.

69
Timestamps

• A completely different approach to concurrency
  control is to assign each transaction a timestamp
  at the moment that it begins.
• Every file in the system has a read and write
  timestamp.
• It will normally be the case that when a process
  tries to access a file, the files read and write
  timestamp will be lower (older) then the
  transactions timestamp.

70
Timestamps

• This ordering means that the transactions are
  being processed in the proper order, so
  everything is OK.
• When the ordering is incorrect, this means that a
  transaction that started later has managed to
  access update and commit.
• This situation means that the current transaction
  is late (working on an older copy of the data)
  and must be aborted.

71
Summary

• We have been looking at synchronisation in
  distributed systems.
• We have looked some of the methods of providing
  exclusive access to data.
• Hopefully now have some idea of the problems
  associated with distributed processes
  concurrently trying to access some shared
  resource.
