Chapter 6 Relaxation 1 CDS in unit disk graph

1
Chapter 6 Relaxation(1) CDS in unit disk graph

• Ding-Zhu Du

2
Sensor Networks
A sensor network is an ad hoc wireless network
which consists of a huge amount of static or
mobile sensors. The sensors collaborate to sense,
collect, and process the raw information of the
phenomenon in the sensing area (in-network), and
transmit the processed information to the
observers.
3
Sensor Networks (Cont.)

• Sensor Node
• Sensing Computation Communication
• Small size
• Limited power

4
Applications
Example 1
Military applications
5
Environmental Monitoring
Example 2
6
Example 3
7
Example 4
8
Applications of CDS Virtual backbone
CDS is used as a virtual backbone in wireless
networks.
9
Applications of CDS Broadcast

• Only nodes in CDS relay messages
• Reduce communication cost
• Reduce redundant traffic

10
Applications of CDS Unicast

• Only nodes in CDS maintain routing tables
• Routing information localized
• Save storage space

C
D
B
A ? B
A
11
Unit Disk Graph
12
Unit Ball Graph
13
Connected Dominating Set
Dominating set
Connected dominating set
14
CDS in unit disk graphs
15
CDS in unit ball graphs
16
Two Stage Algorithm
Stage 1. Compute a dominating set D. Stage 2.
Connect D into a connected
dominating set.
Dominating set
Connected dominating set
17
Stage 1
18
MCDS (opt)
MIS
19
Disk Packing
20
How many independent points can be contained by
a disk with radius 1?
5!
21
How many independent points can be contained
by two disks with radius 1 and center distance
lt 1?
(Wu et al, 2006)
8!
22
How many independent points can be packed Into
four disks that one contains centers of other
three?
lt 15!
(Yao et al, 2008)
23
In unit disk graph
(Wan et al, 2002)
(Wu et al. 2006)
(Funke et al. 2006)
(Yao et al. 2008)
24
Sphere Packing
25
1. How many independent points can be packed
by a ball with radius 1?
1
gt1
26
2. How many (untouched) unit balls can be packed
into a ball with radius 1.5?
0.5
1.5
27
3. Gregory-Newton Problem (1694)
How many unit balls (not touch each other) can
kiss a unit ball?
28
Relationship between problems 1, 2 and 3?
1.5
1
.5
29
For balls not touched each other,
12!! (Hoppe, 1874)
icosahedron
Allow balls to touch,
12!!
30
How many independent points can be contained In
a ball subtracting another ball?

11!
31
How many independent points can be contained
by two balls with radius 1 and center distance lt
1?
22!
1
gt1
32
How many unit balls can kiss two intersecting
unit balls?
20?!
33
In unit ball graph
(Butenko, et al, 2007)
11
12
11
(Zhang, et al, 2008)
34
Stage 2
Connect all nodes in an MIS with a spanning tree
for unit disk graphs
(Wan-Yao)
for unit ball graphs
(Butenko, 2007)
35
Stage 2 Connect all nodes in an MIS D.
Consider a greedy method.
36
Connect all nodes in an MIS with greedy algorithm
37
Theorem
38
Proof
39
(No Transcript)
40
(No Transcript)
41
(No Transcript)
42
Operations Research
Dominating
Packing
Wireless Networking
mathematics
Computer Science
43
Thanks, End
