Chapter 8 Skeletal Muscle: Structure and Function

1
Chapter 8Skeletal Muscle Structure and Function

• EXERCISE PHYSIOLOGY
• Theory and Application to Fitness and
  Performance, 6th edition
• Scott K. Powers Edward T. Howley

2
Skeletal Muscle

• Human body contains over 400 skeletal muscles
• 40-50 of total body weight
• Functions of skeletal muscle
• Force production for locomotion and breathing
• Force production for postural support
• Heat production during cold stress

3
Connective Tissue Covering Skeletal Muscle

• Epimysium
• Surrounds entire muscle
• Perimysium
• Surrounds bundles of muscle fibers
• Fascicles
• Endomysium
• Surrounds individual muscle fibers

4
Connective Tissue Surrounding Skeletal Muscle
Figure 8.1
5
Microstructure of Skeletal Muscle

• Sarcolemma
• Muscle cell membrane
• Myofibrils
• Threadlike strands within muscle fibers
• Actin (thin filament)
• Myosin (thick filament)
• Sarcomere
• Includes Z-line, M-line, H-zone, A-band, I-band
• Sarcoplasmic reticulum
• Storage sites for calcium
• Transverse tubules

6
Microstructure of Skeletal Muscle
Figure 8.2
7
The Sarcoplasmic Reticulum and Transverse Tubules
Figure 8.3
8
The Neuromuscular Junction

• Junction between motor neuron and muscle fiber
• Motor end plate
• Pocket formed around motor neuron by sarcolemma
• Neuromuscular cleft
• Short gap between neuron and muscle fiber
• Acetylcholine is released from the motor neuron
• Causes an end-plate potential (EPP)
• Depolarization of muscle fiber

9
The Neuromuscular Junction
Figure 8.4
10
Muscular Contraction

• The sliding filament model
• Muscle shortening occurs due to the movement of
  the actin filament over the myosin filament
• Formation of cross-bridges between actin and
  myosin filaments
• Power stroke
• Reduction in the distance between Z-lines of the
  sarcomere

11
The Sliding Filament Theory
Figure 8.5
12
The Relationships Among Troponin, Tropomyosin,
Myosin, and Calcium
Figure 8.6
13
Energy for Muscle Contraction

• ATP is required for muscle contraction
• Myosin ATPase breaks down ATP as fiber contracts
• Sources of ATP
• Phosphocreatine (PC)
• Glycolysis
• Oxidative phosphorylation

14
Sources of ATP for Muscle Contraction
Figure 8.7
15
Excitation-Contraction Coupling

• Depolarization of motor end plate (excitation) is
  coupled to muscular contraction
• Action potential travels down T-tubules and
  causes release of Ca2 from SR
• Ca2 binds to troponin and causes position change
  in tropomyosin
• Exposing active sites on actin
• Strong binding state formed between actin and
  myosin
• Contraction occurs

16
Muscle Excitation, Contraction, and Relaxation
Figure 8.9
17
Steps Leading to Muscular Contraction
Figure 8.10
18
Muscle Fatigue

• Decrease in muscle force production
• Reduced ability to perform work
• Contributing factors
• High-intensity exercise (60 sec)
• Accumulation of lactate, H, ADP, Pi, and free
  radicals
• Long-duration exercise (24 hours)
• Muscle factors
• Accumulation of free radicals
• Electrolyte imbalance
• Glycogen depletion
• Central Fatigue
• Reduced motor drive to muscle from CNS

19
Muscle Fatigue
Figure 8.8
20
Characteristics of Muscle Fiber Types

• Biochemical properties
• Oxidative capacity
• Number of capillaries, mitochondria, and amount
  of myoglobin
• Type of myosin ATPase
• Speed of ATP degradation
• Contractile properties
• Maximal force production
• Force per unit of cross-sectional area
• Speed of contraction (Vmax)
• Myosin ATPase activity
• Muscle fiber efficiency

21
Characteristics of Individual Fiber Types

• Type IIx fibers
• Fast-twitch fibers
• Fast-glycolytic fibers
• Type IIa fibers
• Intermediate fibers
• Fast-oxidative glycolytic fibers
• Type I fibers
• Slow-twitch fibers
• Slow-oxidative fibers

22
Characteristics of Muscle Fiber Types
Table 8.1
23
Comparison of Maximal Shortening Velocities
Between Fiber Types
Figure 8.12
24
Histochemical Staining of Fiber Type
Figure 8.11
25
Fiber Types and Performance

• Nonathletes
• Have about 50 slow and 50 fast fibers
• Power athletes
• Sprinters
• Higher percentage of fast fibers
• Endurance athletes
• Distance runners
• Higher percentage of slow fibers

26
Exercise-Induced Changes in Skeletal Muscles

• Strength training
• Increase in muscle fiber size (hypertrophy)
• Increase in muscle fiber number (hyperplasia)
• Endurance training
• Increase in oxidative capacity
• Alteration in fiber type with training
• Fast-to-slow shift
• Type IIx ? IIa
• Type IIa ? I with further training
• Seen with endurance and resistance training

27
Effects of Endurance Training on Fiber Type
Figure 8.13
28
Muscle Atrophy Due to Inactivity

• Loss of muscle mass and strength
• Due to prolonged bed rest, limb immobilization,
  reduced loading during space flight
• Initial atrophy (2 days)
• Due to decreased protein synthesis
• Further atrophy
• Due to reduced protein synthesis
• Atrophy is not permanent
• Can be reversed by resistance training
• During spaceflight, atrophy can be prevented by
  resistance exercise

29
Age-Related Changes in Skeletal Muscle

• Aging is associated with a loss of muscle mass
• 10 muscle mass lost between age 2550 y
• Additional 40 lost between age 5080 y
• Also a loss of fast fibers and gain in slow
  fibers
• Also due to reduced physical activity
• Regular exercise training can improve strength
  and endurance
• Cannot completely eliminate the age-related loss
  in muscle mass

30
Types of Muscle Contraction

• Isometric
• Muscle exerts force without changing length
• Pulling against immovable object
• Postural muscles
• Isotonic (dynamic)
• Concentric
• Muscle shortens during force production
• Eccentric
• Muscle produces force but length increases

31
Muscle Actions
Type of exercise Muscle Muscle Action
Length Change ________________________
_________________________ Dynamic Concentric De
creases Eccentric Increases Static Isome
tric No Change
Table 8.3
32
Isometric and Isotonic Contractions
Figure 8.14
33
Speed of Muscle Contraction and Relaxation

• Muscle twitch
• Contraction as the result of a single stimulus
• Latent period
• Lasting 5 ms
• Contraction
• Tension is developed
• 40 ms
• Relaxation
• 50 ms
• Speed of shortening is greater in fast fibers
• SR releases Ca2 at a faster rate
• Higher ATPase activity

34
Muscle Twitch
Figure 8.15
35
Force Regulation in Muscle

• Force generation depends on
• Types and number of motor units recruited
• More motor units greater force
• Fast motor units greater force
• Initial muscle length
• Ideal length for force generation
• Increased cross-bridge formation
• Nature of the neural stimulation of motor units
• Frequency of stimulation
• Simple twitch
• Summation
• Tetanus

36
Relationship Between Stimulus Strength and Force
of Contraction
Figure 8.16
37
Length-Tension Relationships in Skeletal Muscle
Figure 8.17
38
Simple Twitch, Summation, and Tetanus
Figure 8.18
39
Force-Velocity Relationship

• At any absolute force the speed of movement is
  greater in muscle with higher percent of
  fast-twitch fibers
• The maximum velocity of shortening is greatest at
  the lowest force
• True for both slow and fast-twitch fibers

40
Muscle Force-Velocity Relationships
Figure 8.19
41
Force-Power Relationship

• At any given velocity of movement the power
  generated is greater in a muscle with a higher
  percent of fast-twitch fibers
• The peak power increases with velocity up to
  movement speed of 200-300 degreessecond-1
• Power decreases beyond this velocity because
  force decreases with increasing movement speed

42
Muscle Force-Power Relationships
Figure 8.20
43
Receptors in Muscle

• Provide sensory feedback to nervous system
• Tension development by muscle
• Account of muscle length
• Muscle spindle
• Golgi tendon organ

44
Muscle Spindle

• Responds to changes in muscle length
• Consists of
• Intrafusal fibers
• Run parallel to normal muscle fibers (extrafusal
  fibers)
• Gamma motor neuron
• Stimulate intrafusal fibers to contract with
  extrafusal fibers (by alpha motor neuron)
• Stretch reflex
• Stretch on muscle causes reflex contraction
• Knee-jerk reflex

45
Muscle Spindles
Figure 8.21
46
Golgi Tendon Organ (GTO)

• Monitor tension developed in muscle
• Prevents muscle damage during excessive force
  generation
• Stimulation results in reflex relaxation of
  muscle
• Inhibitory neurons send IPSPs to muscle fibers

47
Golgi Tendon Organ
Figure 8.22
