Title: Chapter 1 Background


1
Chapter 1 Background
2
Outline
  • Instruction Set Principles
  • The Simplified Instructional Computer (SIC)
  • Traditional (CISC) Machines
  • RISC Machines

3
Instruction Set Principles
4
Brief Introduction to ISA
  • Instruction Set Architecture a set of
    instructions
  • Each instruction is directly executed by the
    CPUs hardware
  • How is it represented?
  • By a binary format since the hardware understands
    only bits
  • Concatenate together binary encoding for
    instructions, registers, constants, memories
  • Options - fixed or variable length formats
  • Fixed - each instruction encoded in same size
    field (typically 1 word)
  • Variable half-word, whole-word, multiple word
    instructions are possible

5
Example of Program Execution
  • Command
  • 1 Load AC from Memory
  • 2 Store AC to memory
  • 5 Add to AC from memory
  • Add the contents of memory 940 to the content of
    memory 941 and stores the result at 941

Fetch
Execution
6
Instruction Set Principles -- Classifying
Instruction Set Architecture
7
Instruction Set Design
The instruction set influences everything
8
Instruction Characteristics
  • Usually a simple operation
  • Which operation is identified by the op-code
    field
  • But operations require operands - 0, 1, or 2
  • To identify where they are, they must be
    addressed
  • Address is to some piece of storage
  • Typical storages are main memory, registers, or a
    stack
  • 2 options explicit or implicit addressing
  • Implicit - the op-code implies the address of the
    operands
  • ADD on a stack machine - pops the top 2 elements
    of the stack, then pushes the result
  • Explicit - the address is specified in some field
    of the instruction
  • Note the potential for 3 addresses - 2 operands
    the destination

9
Classifying Instruction Set Architectures
10
Operand Locations for Four ISA Classes
11
CAB
  • Stack
  • Push A
  • Push B
  • Add
  • Pop the top-2 values of the stack (A, B) and push
    the result value into the stack
  • Pop C
  • Accumulator (AC)
  • Load A
  • Add B
  • Add AC (A) with B and store the result into AC
  • Store C
  • Register (register-memory)
  • Load R1, A
  • Add R3, R1, B
  • Store R3, C
  • Register (load-store)
  • Load R1, A
  • Load R2, B
  • Add R3, R1, R2
  • Store R3, C

12
Pros and Cons of Stack, Accumulator, Register
Machine
13
Modern Choice Load-store Register (GPR)
Architecture
  • Reasons for choosing GPR (general-purpose
    registers) architecture
  • Registers (stacks and accumulators) are faster
    than memory
  • Registers are easier and more effective for a
    compiler to use
  • (AB) (CD) (EF)
  • May be evaluated in any order
  • But on a stack machine ? must left to right
  • Registers can be used to hold variables
  • Reduce memory traffic
  • Speed up programs
  • Improve code density (fewer bits are used to name
    a register)

14
Characteristics Divide GPR Architectures
  • of operands
  • Three-operand 1 result and 2 source operands
  • Two-operand 1 both source/result and 1 source
  • How many operands are memory addresses
  • 0 3 (two sources 1 result)

Load-store
Register-memory
Memory-memory
15
Pros and Cons of Three Most Common GPR Computers
16
Instruction Set Principles -- Memory Addressing
17
Typical Address Modes (I)
18
Typical Address Modes (II)
19
Operand Type Size
  • Specified by instruction (opcode) or by hardware
    tag
  • Tagged machines are extinct
  • Typical types assume word 32 bits
  • Character - byte - ASCII or EBCDIC (IBM) - 4 per
    word
  • Short integer - 2- bytes, 2s complement
  • Integer - one word - 2s complement
  • Float - one word - usually IEEE 754 these days
  • Double precision float - 2 words - IEEE 754
  • BCD or packed decimal - 4- bit values packed 8
    per word
  • Instructions will be needed for common
    conversions -- software can do the rare ones

20
What Operations are Needed
  • Arithmetic Logical
  • Integer arithmetic ADD, SUB, MULT, DIV, SHIFT
  • Logical operation AND, OR, XOR, NOT
  • Data Transfer - copy, load, store
  • Control - branch, jump, call, return, trap
  • System - OS and memory management
  • Well ignore these for now - but remember they
    are needed
  • Floating Point
  • Same as arithmetic but usually take bigger
    operands
  • Decimal - if you go for it what else do you need?
  • legacy from COBOL and the commercial application
    domain
  • String - move, compare, search
  • Graphics pixel and vertex, compression/decompres
    sion operations

21
Top 10 Instructions for 80x86
  • load 22
  • conditional branch 20
  • compare 16
  • store 12
  • add 8
  • and 6
  • sub 5
  • move register-register 4
  • call 1
  • return 1
  • The most widely executed instructions are the
    simple operations of an instruction set
  • The top-10 instructions for 80x86 account for 96
    of instructions executed
  • Make them fast, as they are the common case

22
Control Instructions are a Big Deal
  • Jumps - unconditional transfer
  • Conditional Branches
  • How is condition code set? by flag or part of
    the instruction
  • How is target specified? How far away is it?
  • Calls
  • How is target specified? How far away is it?
  • Where is return address kept?
  • How are the arguments passed? Callee vs. Caller
    save!
  • Returns
  • Where is the return address? How far away is it?
  • How are the results passed?

23
Branch Address Specification
  • Known at compile time for unconditional and
    conditional branches - hence specified in the
    instruction
  • As a register containing the target address
  • As a PC-relative offset
  • Consider word length addresses, registers, and
    instructions
  • Full address desired? Then pick the register
    option.
  • BUT - setup and effective address will take
    longer.
  • If you can deal with smaller offset then PC
    relative works
  • PC relative is also position independent - so
    simple linker duty

24
Returns and Indirect Jumps
  • Branch target is not known at compile time
  • Need a way to specify the target dynamically
  • Use a register

25
Condition Testing Options
26
Instruction Set Principles -- Encoding an
Instruction Set
27
Encoding the ISA
  • Encode instructions into a binary representation
    for execution by CPU
  • Can pick anything but
  • Affects the size of code - so it should be tight
  • Affects the CPU design - in particular the
    instruction decode
  • So it may have a big influence on the CPI or
    cycle-time
  • Must balance several competing forces
  • Desire for lots of addressing modes and registers
  • Desire to make average program size compact
  • Desire to have instructions encoded into lengths
    that will be easy to handle in a pipelined
    implementation (multiple of bytes)

28
3 Popular Encoding Choices
  • Variable (compact code but difficult to encode)
  • Primary opcode is fixed in size, but opcode
    modifiers may exist
  • Opcode specifies number of arguments - each used
    as address fields
  • Best when there are many addressing modes and
    operations
  • Use as few bits as possible, but individual
    instructions can vary widely in length
  • e. g. VAX - integer ADD versions vary between 3
    and 19 bytes
  • Fixed (easy to encode, but lengthy code)
  • Every instruction looks the same - some field may
    be interpreted differently
  • Combine the operation and the addressing mode
    into the opcode
  • e. g. all modern RISC machines
  • Hybrid
  • Set of fixed formats
  • e. g. IBM 360 and Intel 80x86

Trade-off between size of programVS. ease of
decoding
29
3 Popular Encoding Choices (Cont.)
30
An Example of Variable Encoding -- VAX
  • addl3 r1, 737(r2), (r3) 32-bit integer add
    instruction with 3 operands ? need 6 bytes to
    represent it
  • Opcode for addl3 1 byte
  • A VAX address specifier is 1 byte (4-bits
    addressing mode, 4-bits register)
  • r1 1 byte (register addressing mode r1)
  • 737(r2)
  • 1 byte for address specifier (displacement
    addressing r2)
  • 2 bytes for displacement 737
  • (r3) 1 byte for address specifier (register
    indirect r3)
  • Length of VAX instructions 153 bytes

31
Short Summary Encoding the Instruction Set
  • Choice between variable and fixed instruction
    encoding
  • Code size than performance ? variable encoding
  • Performance than code size ? fixed encoding

32
The Simplified Instructional Computer (SIC)
33
Overview
  • Designed to illustrate the most commonly
    encountered hardware features and concepts, while
    avoiding most of the idiosyncrasies that are
    often found in real machines
  • Standard model and an XE (extra equipment)
    version
  • Upward compatible

34
SIC Machine Architecture
  • Memory
  • Byte addressable
  • 8-bit bytes
  • 3-byte words
  • Addressed by the lowest numbered byte
  • A total of 32,768 (215) bytes
  • Registers
  • Five special-purpose registers
  • Each 24 bits in length
  • Data formats
  • Integers 24-bit binary numbers
  • 2s complement
  • Characters 8-bit ASCII
  • No floating-point hardware
  • Instruction formats

8 1 15
opcode
x
address
x indexed-addressing mode
35
SIC Registers
36
SIC Machine Instructions (Example)
  • (Binary) 00000000 0 000000000011111
  • Load the content of the word at memory address 31
    into A
  • (H) 00001F

Appendix A
37
SIC Machine Architecture (Cont.)
  • Addressing modes
  • Two addressing modes indicated by the x bit
  • Target address
  • (X) the contents of register X
  • Example 00801F
  • Load the content of the word at memory address
    (X)31 into A

38
SIC Machine Architecture (Cont.)
See Appendix A for a complete list of SIC
instructions
  • Instruction set
  • Load and store registers (LDA, LDX, STA, STX)
  • Integer arithmetic operations (ADD, SUB, MUL,
    DIV)
  • All arithmetic operations involve register A and
    a word in memory, with the result being left in
    the register
  • COMP compare the value in register A with a word
    in memory
  • Set a condition code (CC) to indicate the result
    (lt, , gt)
  • Conditional jump instructions (JLT, JEQ, JGT)
    test the setting of CC and jump accordingly
  • Subroutine linkage
  • JSUB jump to the subroutine, placing the return
    address in register L
  • RSUB return by jumping to the address contained
    in register L

39
SIC Machine Architecture (Cont.)
  • Input and output
  • Perform I/O by transferring 1 byte at a time to
    or from the rightmost 8 bits of register A
  • Each device is assigned a unique 8-bit code
  • Three I/O instructions, each specifies the device
    code as an operand
  • Test Device (TD) tests whether the addressed
    device is ready to send or receive a byte of data
  • The conditional code is set to indicate the
    result of this test (lt ready not ready)
  • Read Data (RD)
  • Write Data (WD)

40
SIC/XE Machine Architecture
  • Memory
  • Memory structure same as SIC
  • Maximum 1 megabyte (220 bytes)
  • Registers
  • Additional registers

41
SIC/XE Machine Architecture (Cont.)
  • Data formats
  • Additional 48-bit floating-point data type
  • Fraction 01 (high-order bit must be 1)
  • Exponent unsigned binary number between 0 and
    2047

1 11 36
f 2(e-1024)
exponent
s
fraction
42
SIC/XE Machine Architecture (Cont.) Instruction
Formats
Format 1 (1 byte)
Format 4 (3 bytes)
8
op
Format 2 (2 bytes)
1
8
4
4
op
r1
r2
Format 3 (3 bytes)
Relative Addressing
0
Instructions of formats 1 and 2 do not refer to
memory
43
SIC/XE Machine Architecture (Cont.)
  • Addressing modes
  • Relative addressing mode for Format-3
    instructions
  • Direct addressing
  • b p 0 for Format 3 ? disp is the target
    address
  • b p 0 (normally) for Format 4 ? address is
    the target address
  • Indexed addressing
  • x 1 ? (X) is added in the target address
    calculation

44
SIC/XE Machine Architecture (Cont.)
  • Addressing modes (Cont.)
  • i1 and n0 ? the target address itself is used
    as the operand value (immediate addressing)
  • i0 and n1 ? the word at the location given by
    the target address is fetched the value
    contained in this word is then taken as the
    address of the operand value (indirect
    addressing)
  • i n 0 or 1 ? the target address is taken as
    the location of the operand (simple addressing)
  • SIC/XE ? in1
  • SIC?in0
  • Indexing cannot be used with immediate or
    indirect addressing

45
Examples of SIC/XE Instructions and Addressing
Modes
46
SIC/XE Machine Architecture (Cont.)
  • Instruction set
  • Provides all the instructions available on the
    standard version
  • Instructions to load and store the new registers
    (LDB, STB)
  • Instructions to perform FP arithmetic operations
    (ADDF, SUBF)
  • RMO (register move)
  • Register-to-register arithmetic operations (ADDR,
    SUBR)
  • Supervisor call instruction (SVC) for generating
    interrupts
  • Input and output
  • I/O channels to be used to perform I/O while CPU
    is executing other instructions
  • SIO, TIO, HIO Start, test, halt the operation of
    I/O channels

47
Data Movement for SIC
48
Data Movement for SIC/XE
49
Arithmetic for SIC
50
Arithmetic for SIC/XE
51
Looping and Indexing for SIC
52
Looping and Indexing for SIC/XE
53
Looping and Indexing for SIC
54
Looping and Indexing for SIC/XE
55
Input and Output for SIC
56
Subroutine Call and Record Input for SIC
JSUB READ CALL READ SUBROUTINE

57
Subroutine Call and Record Input for SIC/XE
58
Traditional (CISC) Machines
  • Complex Instruction Set Computers (CISC)
  • Generally have a relative large and complicated
    instruction set, several different instruction
    formats and lengths, and many different
    addressing modes
  • Complex to implement such a machine
  • Examples
  • VAX
  • Pentium Pro

59
RISC Machines
  • Reduced Instruction Set Computers
  • Standard, fixed instruction length (usually one
    machine word), and single-cycle execution of most
    instructions
  • Memory access is usually done by load and store
    only
  • All instructions except for load and store are
    register-to-register
  • Typically a relative large number of GPR
  • The number of machine instructions, instruction
    formats, and addressing modes is relative small
  • Simplify the design of processors
  • Faster and less expensive processor development,
    greater reliability, and faster instruction
    execution times
  • ExamplesSun UltraSPARC, PowerPC, Cray T3E
Write a Comment
User Comments (0)
About PowerShow.com
