Title: Local Nondestructive Evaluation and Materials Characterization


1
Local Nondestructive Evaluation and Materials
Characterization
  • Glenn A. Washer, Ph.D., P.E.
  • University of Missouri Columbia
  • washerg_at_missouri.edu

2
Agenda
  • Introduction in NDE
  • NDE timelines
  • NDE for defect detection
  • Materials Characterization
  • Conclude

3
Nondestructive Evaluation
  • Technologies to determine the condition of a
    material without altering that condition

4
What are NDE Methods?
  • NDE methods use waves to transmit data on
    material condition
  • Acoustic and electromagnetic waves carry the
    legacy of their environment
  • NDE methods measure common wave properties to
    infer the condition of the material frequency,
    amplitude, time of flight
  • Example visual inspection
  • Reflection of light

5
Why NDE?
  • Safety detect deterioration at sub-critical
    levels
  • Fatigue cracks in steel bridges
  • Maintenance detect deterioration during
    embryonic stages to
  • Identify repair needs
  • Reduce the cost of repairs
  • Management
  • Provide quantitative knowledge
  • on inventory condition
  • Focus funding on most
  • critical needs
  • Quality Control
  • Materials characterization

6
Classifying NDE Technologies
  • Local defect detection
  • Single point binary detection (threshold)
    analysis
  • UT, ET, MT, etc
  • Full-Field defect detection and imaging
  • Spatial representation of common wave properties
    (ex. Amp. )
  • Binary detection (threshold) quantitative
    spatial measurements analysis
  • Infrared thermography, imaging (dt),
    interferometric optical methods
  • Global Techniques
  • Health Monitoring
  • Stress, strain, dynamic characteristics
  • Corrosion, distributed local NDE technologies
    within a system
  • Materials Characterization
  • Quality control
  • Gross Materials Degradation
  • UT pulse velocity in concrete

7
Timelines and NDE
  • Most traditional NDE technologies are historical
  • Record events that have previously occurred
  • Defects are detected once they have grown to
    detectable levels
  • Inspection intervals can be optimized for these
    techniques such that known defect growth rates
    combined with known POD rates form a reliable and
    safe system
  • There are a few exceptions
  • Acoustic Emission systems
  • Real time is a benefit and a deficiency
  • Cannot measure damage that already exists, and
    generally is not intended to detect
    manifestations of that damage

8
Timelines and NDE
  • Pre-construction
  • Material characterization, defect detection
  • Weld flaws, voids in pre-cast concrete
  • Characterizing earth properties
  • Construction
  • Quality control, installation stresses
  • Ex. Anchor bolt stresses, erection stresses
  • Post-construction
  • GPR for pavement thickness, rebar depth etc.
  • Service Life
  • Detect deterioration and defect growth
  • Deconstruction
  • Quantify material conditions/properties following
    service life
  • Corrosion rates, chloride intrusion etc.

9
Example
  • Acoustic detection of subsurface features

10
September 2000
  • Imaging of acoustic backscatter (density changes)
  • Fixed point in time
  • Detection and analysis single fetus

11
November, 2000
12
Jack and Beau
13
Pin Inspection
Ref FHWA NDE Center
14
Bridge Pin EvaluationC-Scan Image
15
Phased Array Ultrasonics
16
Pin Radiography
17
Computed Tomography
099
18
Acoustic Wave Spectrum
A/E
Audible
Impact - echo
Ultrasonic
Structural vibrations
1
101
102
103
104
105
106
107
KHz
Hz
MHz
19
MHz
KHz
GHz
MHz
THz
PHz
radar
IR
20
Materials Characterization
  • Waves carry the legacy of the environment in
    which they propagate
  • Electromagnetic waves and acoustic waves
  • Many physical properties are linear over certain
    ranges, for example steel modulus of elasticity
  • Scale
  • Magnitude
  • NDE technologies can measure physical properties
    when other variables can be controlled
  • Quality control, production control, and
    global/localized materials degradation

21
Equation of Motion for a Anisotropic Linear -
Elastic Solid
Orthortropic Case
  • vij wave velocity
  • density
  • m,l Lamé Constants
  • u Poissone ratio
  • u Displacement

22
RPC Structure
3D reconstruction (steel fibers)
23
UT vs. Static ModulusBy Curing Method
Correlation coef. 0.94
9000
8500
Steam cured
Delayed Steam
8000
Tempered Steam
Air Cured
STATIC MOD. (ksi)
7500
7000
11
6500
6000
6000
6500
7000
7500
8000
8500
9000
UT Modulus (ksi)
Ref. Washer, Fuchs, Graybeal Rezai, QNDE 2003
24
Acoustoelastic Equation of Motion
25
Concept
Transmitter
P/S Beam
Receiver pair
Strand
26
Strands
Ref. Washer, Green Pond, RNDE 2001
27
Future Opportunities
Managing the aging infrastructure into the future
will require the development of increasing
sophisticated condition assessment tools
  • NDE Technologies
  • Detect defects and material degradation
  • Physical properties of engineering materials
  • Variability and scale of civil structures
    presents a significant challenge
  • Local NDE techniques can be distributed as part
    of health monitoring systems
  • Development of systematic approaches and sensor
    technologies is required

28
Acknowledgements
  • FHWA NDE Center

29
Thank you Questions?
