Title: Chapter 14 Water: A Limited Resource


1
Chapter 14Water A Limited Resource
2
Overview of Chapter 14
  • Importance of Water
  • Hydrologic Cycle
  • Water Use and Resource Problems
  • Too Much Water
  • Too Little Water
  • Water Problems in US and Canada
  • Global Water Problems
  • Sharing Water Resources
  • Water Management
  • Providing Sustainable Water Supply
  • Water Conservation

3
Importance of Water
  • Moderates the climate, and allows organisms to
    survive
  • 97 of the Earths water is salty and not
    available for use by terrestrial organisms
  • humans use 54 of the Earths accessible,
    renewable fresh water
  • Cooking
  • Washing
  • Use large amounts for
  • Agriculture
  • Manufacturing
  • Mining
  • Energy production
  • Waste disposal
  • Use of freshwater is increasing

4
Properties of Water
  • Composed of 2 Hydrogen and 1 oxygen
  • Exists as solid, liquid or gas
  • Polar
  • One end has () charge, one end has (-) charge
  • Forms Hydrogen bond between other water molecules
  • H-bonds define waters physical properties
  • High melting/freezing point and high boiling
    point
  • High heat capacity
  • Universal solvent
  • Expands when heated, contracts when cold

5
(No Transcript)
6
Properties of Water
  • Water is never completely pure in nature
  • Content of seawater (left)
  • Many substances water dissolves cause water
    pollution

7
Hydrologic Cycle
Describes how water continuously circulates
through the environment
8
Distribution of Water
  • Only 2.5 of water on earth is freshwater
  • 2 is in the form of ice!
  • Only 0.5 of water on earth is available
    freshwater

9
Freshwater Terminology
  • Surface water
  • Precipitation that remains on the surface and
    does not seep into soil
  • Runoff
  • Movement of surface water to lakes, rivers, etc.
  • Watershed (drainage basin)
  • Land area that delivers water into a stream or
    river system
  • Groundwater
  • Freshwater under the earths surface stored in
    aquifers
  • Aquifer
  • Underground caverns and porous layers of sand,
    gravel and rock in which groundwater is stored
  • Unconfined aquifer (UA) has porous rock layers
    above it
  • Upper limit of UA is water table
  • Confined aquifer/Artesian Well
  • Groundwater storage area between impermeable
    layers of rock

10
Freshwater Aquifer
11
Water Use and Resource Problems
  • The greatest user of water worldwide is
    agriculture (71 for irrigation, 20 for
    industry, 9 for domestic and municipal use)
  • Problems Fall into Three Categories
  • Too much water
  • Too little water
  • Poor quality/contamination (discussed in Chapter
    22)

12
Too Much Water
  • Flooding
  • Both natural and human-induced
  • Modern floods are highly destructive because
    humans
  • Remove water-absorbing plant cover from soil
  • Construct buildings on floodplains
  • Floodplain
  • Area bordering a river channel that has the
    potential to flood

13
Pre-Urban vs. Urban Floodplains
Transpiration the loss of water vapor from the
aerial surfaces of plants
14
Floodplain
  • Government restrictions on building
  • Levees can fail
  • Rather than rebuild levees adjacent to rivers,
    experts suggest allowing some flooding of
    floodplains during floods
  • (next slide)

15
Left Traditional levees adjacent to river
Right Suggested levee style, set back from river
16
Case-In-Point Floods of 1993
  • Mississippi River flooded
  • Covered 23 million acres
  • 50 killed
  • 12 billion in damages
  • 70,000 homes lost
  • 8.7 million acres of farmland
  • Draining wetlands, building on flood plains, and
    levees made problem worse

17
Too Little Water
  • Typically found in arid land
  • Problems
  • Drought
  • Overdrawing water
  • for irrigation
  • purposes
  • Aquifer depletion
  • Subsidence
  • Sinkholes

18
Too Little Water
  • Problems (continued)
  • Saltwater Intrusion
  • Seawater moves into a freshwater aquifer

19
Water Problems In US and Canada
  • US has a plentiful supply of freshwater
  • Many areas have a severe shortages
  • Geographical variations
  • Seasonal variations

20
Water Problems in US and Canada
  • Water shortages in West and Southwest
  • Water is diverted and transported via aqueducts

21
Water Problems in US and Canada- Surface Water
  • Mono Lake (Eastern CA)
  • Rivers and streams that once fed this lake are
    diverted to Los Angeles (275mi away)
  • Becoming highly saline
  • Court ordered water diversion reduction
  • Colorado River Basin
  • provides water for 27 million people irrigates
    3.5 million acres of crops
  • 1922 Colorado River Compact stipulates an annual
    allotment of 7.5 million acre-feet of water to
    the lower Colorado average annual flow was
    overestimated
  • Mexico receives a share of the Colorado
    stipulated by a 1944 treaty
  • The Colorado River water is often completely
    consumed before it can reach the Pacific Ocean
    in places, it is saltier than the ocean

22
Colorado River bed in Mexico
23
Water Problems in US and Canada-Groundwater
  • Aquifer Depletion
  • 50 of the U.S. population uses groundwater for
    drinking
  • 40 of water used for irrigation in the U.S.
    comes from groundwater
  • Saltwater intrusion often results from removal of
    too much groundwater

24
Global Water Problems
  • Amount of freshwater on planet CAN meet human
    needs
  • BUT, it is unevenly distributed and some places
    lack stable runoff
  • Problems
  • Climate Change
  • Drinking Water
  • Population Growth
  • Sharing Water Resources Among Countries

25
Global Water Problems
  • Water and Climate Change
  • Climate change affects the type and distribution
    of precipitation
  • Potential issues
  • Reduced snowfall will impact water resources
    downstream
  • Sea level rise will cause saltwater intrusion
    into drinking water supplies

26
Global Water Problems
  • Drinking Water Problems
  • Many developing countries have insufficient water
    to meet drinking and household needs
  • 1.1 billion people lack access to safe drinking
    water
  • 2.6 billion people are without access to a
    satisfactory means of domestic wastewater and
    fecal waste disposal
  • Population Growth
  • Increase in population means an increase in
    freshwater requirements
  • Limits drinking water available
  • Limits water available for agriculture (food)

27
Global Water Problems
  • Sharing Water Resources Among Countries
  • Rhine River Basin (right)
  • Countries upstream discharged pollutants into
    river
  • Countries downstream had to pay to clean the
    water before they could drink it
  • International Commission for Protection of the
    Rhine (ICPR) help clean up Rhine in 1986
  • Spurred by massive chemical spill
  • Successful return of Atlantic Salmon

28
Aral Seastraddles Kazahkhstan and Uzbekistan
  • Water diversion for irrigation has caused sea to
    become too saline
  • Lots of health problems
  • All 24 species of fish are gone
  • Currently the area is recovering thanks to
    funding from the World Bank

1967
1997
29
Global Water Problems
  • Potentially Volatile International Water
    Situations
  • Jordan River
  • Supplies water to Israel, Jordan, West Bank, and
    Gaza Strip
  • Nile River
  • 10 nations use water but the majority is used by
    Egypt

30
Water Management
  • Main Goal Provide sustainable supply of
    high-quality water
  • Requires humans to use resource carefully
  • Dams and Reservoirs
  • Water Diversion Projects
  • Desalinization

31
Dams and Reservoirs
  • Benefits
  • Ensure year-round supply of water with regulated
    flow
  • Generate electricity
  • Provide recreational activities
  • Disadvantages
  • Alter the ecosystem
  • Reduce sediment load

32
Dams and Reservoirs
  • Glen Canyon Dam
  • Built in 1963
  • Regulated flow has changed ecosystem in Colorado
    River and Grand Canyon
  • To rectify situation
  • Canyon has been flooded several times
  • Small floods compared to natural floods
  • Still helps rebuild habitat

33
Dams and Reservoirs
  • Salmon Population in Columbia River is very low
    due to dams that impede migration
  • Hatchery efforts not working
  • Fish ladders help, but are not effective enough
  • Most controversial plan involves removal of
    several dams on the Snake River

34
Water Diversion Projects
  • Requires diverting water to areas that are
    deficient by pumping through a system of
    aqueducts
  • Much of CAs receives its water supply from
    diverted water from Northern CA
  • Controversial and expensive

35
Desalinization
  • Removal of salt from ocean or brackish water
  • Two methods
  • Distillation- salt water is evaporated, and water
    vapor is condensed into freshwater (salt left
    behind)
  • Reverse Osmosis- involves forcing salt water
    through a membrane permeable to water, but not
    salt
  • Very expensive

36
Water Conservation
  • Reducing Agricultural Water Waste
  • Agriculture is very inefficient with water
  • Microirrigation- irrigation that conserves water
    by piping it to
  • crops through sealed
  • systems
  • Also called drip or
  • trickle irrigation

37
Water Conservation
  • Reducing Industrial Water Waste
  • Stricter laws provide incentive to conserve water
  • Recycling water within the plant
  • Water scarcity (in addition to stricter pollution
    control requirements) will encourage further
    industrial recycling
  • Potential to conserve water is huge!

38
Water Conservation
  • Reducing Municipal Water Waste
  • Gray Water
  • Used water (e.g. from sinks)
  • Can be used to flush toilets, wash car or water
    lawn
  • Water saving household fixtures
  • Government incentives
  • Charge more for water during dry periods

39
Conserving at Home
  • Install water-saving shower heads and faucets
  • Install low-flush toilets
  • Fix leaky fixtures
  • Purchase high efficiency appliances
  • Modify personal habits
  • Use the dishwasher instead of washing by hand
