Managing System Reliability and Availability

1
Chapter 12

• Managing System Reliability and Availability

2
Objectives

• Develop general problem-solving strategies
• Resolve boot problems
• Back up and restore system state data
• Restore a failed system volume
• Use Event Viewer for solving problems

3
Objectives

• Troubleshoot security using the Security
  Configuration and Analysis Snap-in
• Troubleshoot connectivity
• Remotely administer a server

4
General Problem-solving Strategies

• Understand how a server and the network interact
• Train your users to help you solve problems
• Solve problems step by step
• Track problems and solutions

5
Understanding How Servers and the Network Interact

• Create network diagrams
• Mainframes, minicomputers, and servers
• Workstations and network printers
• Network devices
• Telecommunications links
• Remote links
• Building locations
• Gather benchmarks

6
Training Users to Help

• Save work at the first sign of a problem
• Record information about a problem as the problem
  is occurring
• Report any protocol information, including error
  messages
• Quickly report the problem by telephone or voice
  mail
• Avoid sending e-mail about urgent problems

7
Solving Problems Step by Step

• Ask the right questions to get as much
  information as possible
• Record the error message when it appears or when
  the user reports it
• Start with simple solutions
• Determine if anyone else is experiencing the
  problem

8
Solving Problems Step by Step

• Regularly check the Windows Server 2003 event
  logs for signs of a problem
• Use System Monitor and Network Monitor filtering
  to help you troubleshoot problems
• Check for power interruptions

9
Tracking Problems and Solutions

• Keep a log of all network problems and their
  solutions
• Database
• Help Desk system
• Use the log for future reference, as a teaching
  tool, and as an indicator of recurring problems
• Keep a log of changes made to the system
• Serves as a reference for other administrators

10
Resolving Boot Problems

• Common causes of boot problems
• Disk failure of drive with system and boot files
• Corrupt partition table, boot file, or Master
  Boot Record
• Disk read error
• First step is to try rebooting
• Often works for temporary disk read or memory
  errors, out-of-sync registers, and disk
  controller problems

11
Troubleshooting by Using Safe Mode

• Safe mode boots the server using the most generic
  default settings with only the services needed
  for a basic configuration
• Accessed by pressing F8 when the computer boots
• Contains several advanced options for various
  problems associated with
• Modified server configuration
• New software or drivers

12
(No Transcript)
13
(No Transcript)
14
Using the Automated Recovery Set to Solve a Boot
Problem

• Restores the disk signatures, volumes and
  partitions, and system files required to start
  the computer
• Uses a previously created ASR set created with
  the Backup utility
• Windows Server 2003 is then installed and a
  system restore can be done
• The restore process uses previously created
  backup media

15
Troubleshooting by Using the Recovery Console

• Enables booting into the Windows Server 2003
  command line
• Repair a disk problem
• Copy a critical file back into the server
• Start a service
• Format a drive
• Started from the Windows Server 2003 CD-ROM or
  from an installation
• Available from the Advanced Options Menu after
  installation

16
(No Transcript)
17
(No Transcript)
18
General Tips for Fixing Boot Problems
19
(No Transcript)
20
Troubleshooting Stop Messages
21
(No Transcript)
22
Backing Up and Restoring System State Data

• System state data consists of several critical
  elements
• System and boot file, Active Directory, Sysvol
  folder, Registry, COM information, DNS zones,
  certificate information, and server cluster data
• All of the system state data must be backed up as
  a group and from the local computer
• Select the System State option in the Backup
  utility to ensure system protected files are
  backed up
• Check the Automatically backup System Protected
  files with the System State box in the Advanced
  tab

23
(No Transcript)
24
Restoring a Failed System Volume

• Replace the failed hardware
• Install Windows Server 2003 on the new drive
• Use the Backup utility to restore the system
  state data and all other data, using the most
  recent backup tapes
• Do additional restores if using differential or
  incremental backups

25
Using and Configuring Event Viewer

• Event logs contain a record of all types of
  server events
• System
• Security
• Application
• Directory Service
• DNS Service
• File Replication Service

26
(No Transcript)
27
Viewing Log Events

• Icons indicate the seriousness of an event
• Information message contains a blue i in a
  white comment circle
• Warning message contains a black ! on a yellow
  caution symbol
• Error message contains a white x inside a red
  circle
• Event Viewer can be accessed from Administrative
  Tools, Computer Management, or as an MMC snap-in
• Logs contain information about each event

28
(No Transcript)
29
Using the Event Viewer Filter Option

• All event logs have a filter option to help
  locate a problem quickly
• Events can be filtered on the following criteria
• Event type, source, and category
• Event ID
• User and computer associated with an event
• Date and time of day range

30
Maintaining Event Logs

• Size each log to prevent it from filling it too
  quickly
• Set the maximum log size
• Test the setting regularly
• Regularly clear each log before it is full
• Use the clear or overwrite option
• Automatically override the oldest events when a
  log is full
• Use the Overwrite events older than x days option
• Save logs as .evt, .txt, or .csv files

31
(No Transcript)
32
Troubleshooting Security

• Security policies may have omissions
• Security requirements may change over time
• Use the Security Configuration and Analysis tool
  to monitor and analyze security
• Creates a database to configure a server and
  perform a security check
• Can be used periodically to perform an analysis
  of a policy
• Make modifications on the basis of growth in
  server use

33
(No Transcript)
34
Troubleshooting Connectivity

• TCP/IP utilities and TCP/IP-compatible operating
  systems often have built-in IP troubleshooting
  tools
• ipconfig can find duplicate IP addresses
• Subnet mask will be 0.0.0.0
• ping can poll the presence of another TCP/IP
  computer
• netstat can verify that a workstation or server
  has established a successful TCP/IP connection
• If the network and sent data contain 0 bytes, the
  session may be hung

35
(No Transcript)
36
(No Transcript)
37
(No Transcript)
38
(No Transcript)
39
Remotely Administering a Server

• Remote access may be from another building, from
  home, or while traveling
• Enabled in the System Properties Remote tab
• Remote Desktop client
• Use a dial-up line via a RAS or VPN server
• Configure a strong password
• Remote Assistance
• Set up a Group Policy
• Access the server from a Windows XP computer

40
(No Transcript)
41
(No Transcript)
42
Summary

• Develop a problem-solving strategy before
  problems occur
• Understand your server and network
• Train users to help
• Step-by-step problem solving
• Tracking problems
• Windows Server 2003 addresses boot problems with
  several tools
• Safe mode
• ASR set
• Recovery console

43
Summary

• Regularly back up the system state data and
  system protected data in case of emergencies,
  such as a failed boot partition or volume
• Understand how to restore a failed volume,
  including system state data and system protected
  files, so you are prepared in advance
• Learn to regularly use Event Viewer as a
  monitoring and troubleshooting tool
• Configure your event logs to match the needs of
  your organization

44
Summary

• Use the Security Configuration and Analysis tool
  to troubleshoot security policy problems
• There are many tools for troubleshooting TCP/IP
  connectivity problems at the server or on a
  client
• ipconfig
• ping
• nbstat
• netstat
• You can remotely administer a server using Remote
  Desktop client or Remote Assistance
