Data Link Protocols

1
Data Link Protocols

• By Erik Reeber

2
Goals

• Use SPIN to model-check successively more complex
  protocols
• Using the protocols in Tannenbaums 3rd Edition
  of Computer Networks
• Compare this approach to using other verification
  tools

3
Background

• Processes communicate using layers
• Each layer provides services to higher-level
  layers and ultimately to the user

4
Data Link Layer

• Sits between the physical and network layers
• For our purposes provides non-lossy, error-free,
  and ordered communication for the network layer
• The physical layer will provide error-free
  communication, but packets may get lost.

5
Specification

• Safety ! Bad_network_packet
• Liveness (network_message_sent -gt ltgt
  network_message_received)
• A packet is bad if it is not the packet expected

6
Problems with the Spec

• Ideally, requires an infinite queue to check
• Ideally, any packet can be sent. This can be
  implemented in SPIN with

packet new_packet do (i lt PKT_SIZE) -gt
if true-gt new_packet.pi true-gt
skip fi else -gt break od
7
Simplifications

• Use a finite queue, that loops around
• Use a packet size of 1, and pick between 0 and 1.

0,4,8 12,
1
2
3
packet new_packet if true-gt
new_packet.p00 true-gt new_packet.p01 fi
8
Why OK?

• Finite-queue of k elements not always ok
  (consider k2, and drop 2). We must prove
• ((network_sent network_received) lt k).
• Packet size 1 ok, since the physical layer can
  only lose packets. Any packet loss or reordering
  can be detected with just 1 bit.

9
Protocol 1

• Assumes no packets are lost by the physical layer
• Assumes receiver infinitely fast

sender() packet buffer frame s do
true -gt A_from_network?to_sender(buffer)
s.info.pbuffer.p
A_to_physical!to_physical(s)
receiver() packet pack frame r,s do
true -gt B_wait_for_event?to_receiver()
B_from_physical_layer?to_receiver(r)
pack.info.p r.info.p
B_to_network!to_network(pack)
10
Notes on Protocol 1

• I use separate processes for the network,
  physical, and data-link processes (6 processes
  already!)
• Wire is multiple channel, all other communication
  is done with 0 width (synchronous) channels.
• Need to add a constraint to both properties
  (num_packets_in_DLR lt 2)
• With the constraint, both properties went through
  SPIN ?

11
Protocol 2

• No longer assume infinite speed receiver
• Instead, receiver sends ack back to sender

B
A
frame
ack
12
Notes on Protocol 2

• Up to 8 processes!
• Model-checker getting slow (liveness proof went
  252,700 states deep)
• Never more than one message being dealt with at a
  time
• Both checks went through ?

13
Protocol 2_5

• Tannenbaum mentions a simple extension to
  protocol 2 to make it handle dropped messages.
  Just set a timer on the sender, if the timer
  buzzes resend.
• Why doesnt that work?
• Safety proofs goes through if add the condition
  that the ack is never dropped ?

14
Protocol 3

• Truly handle lost messages
• Add a one bit sequence number to the message and
  the ack. Also timeout as in 2_5.
• But how does one implement a timer in SPIN

15
Timer Implementations

• Use the timeout keyword
• Had problems with the timeout keyword sticking
• Use the scheduler

timer() do timeout -gt A_wait_for_event!to
_sender(time_out) od
timer() do true -gt A_wait_for_event!to_s
ender(time_out) od
16
More timer implementations

• Use non-determinism

timer() do true -gt do
true -gt skip true
-gt break od
A_wait_for_event!to_sender(time_out) od
17
Notes on protocol 3

• Proved liveness with the schedulers timer and
  safety under the timeout keyword.
• Looking for the right timer implementation
• Made a pretty and an ugly version of protocol 3.
  The ugly version gets rid of the physical senders

18
Protocol 4

• Bidirectional
• 1-bit windowing protocol (only 1 bit ack)
• More efficient symmetric
• Original implementation has 12 processes my ugly
  version weans this down to 6 and still does not
  make it through.

19
Notes on Protocol 4

• I tried using various forms of compression, but
  never got a full search ?
• On the other hand, between my 5 implementations
  of protocol 4, SPIN caught a lot of errors.

20
3 More Protocols?

• There are three more data link protocols in
  Tannenbaums book. First n-bit windowing, then
  1-bit sliding window, and finally the n-bit
  sliding window protocol
• Since Protocol 4 did not go through,

21
Spin v. ACL2

• ACL2 proof would work at a lower level
• ACL2 can handle more states
• - if the user can do the proof
• SPIN has a better simulator its tough to
  simulate this type of ACL2 code.

(defun next_system_state (i system_state)
(cond (( i 0) (execute_A system_state))
(t (execute_B system_state)))) ... (thm (and
(not (get-val bad_network_packet
(init_state))) (implies (not
(get-val bad_network_packet s))
(not (get-val bad_network_packet
(next_system_state i s))))
22
Conclusions

• Model-checking complex protocols is hard
• SPIN is very good at helping users find bugs.
  The interactive simulator is useful.
• Try combining SPIN with theorem proving

23
Future Work

• Simplify the spec Is there something simpler
  that will still distinguish ordering?
• Simplify the model 6 processes are not really
  necessary.
• Implement a better timer
• Prove the network protocols in ACL2 or PVS for
  comparison
