Technical Committee 3

1
Technical Committee 3 INFORMATION STRUCTURES,
DOCUMENTATION AND GRAPHICAL SYMBOLS
2
TC3 WorkshopStructuring principles and reference
designationsCape Town 2005-10-193(Cape
Town/MT18)5

• Eirik Selvik
• Convenor TC3/MT18

3
The revision process of IEC 61346-1

• A DC issued in April 2005
• A MCR issued in July 2005 with call for
  membership in MT 18
• A time-schedule indicating the next edition of
  IEC 61346-1 in end 2007
• MT 18 intend to have its first meeting in Dec.
  2005
• ISO/TC10 has indicated interest in cooperation

4
Questionnaire results

• The DC document (3/763/DC) raised 12 questions to
  be answered by the NCs.
• The MCR (3/773/MCR) provides a summary of the
  answers provided

5
Q1 Is this overall structure and content
satisfactory today?
CHAPTER ONE

• Generally found satisfactory.
• Support for merging part 4 into part 1
• JP propose splitting of part 2
• Principles
• Letter codes, being maintained in a database

6
Q2 Is the definition of the scope(s)
satisfactory today?

• The scope is satisfactory and need not be changed

7
Q3 Are the applied principles for structuring
adequate?

• The constituency principles are quite clear
• The concept of the object and its aspects need
  more explanations
• The description of the appliance of transitions
  and the consequences needs to be improved

8
Q4 Is the method for the construction of the
reference designations adequate?

• Generally accepted
• The transitions needs better explanations

9
Q5 Are there any vague, inappropriate or unclear
basic statements in clause 4 and 5?

• No, but improved wording

10
Q6 Are the classification principles adequate?

• Generally found satisfactory.
• The classification used in IEC 61360 is proposed
  as an alternative.

11
Q7 Do the defined classes cover the present
needs?

• The main classes do
• There are requests for the introduction of
  sub-classes of IEC/PAS 62400.

12
Q8 Are there any vague, inappropriate or unclear
basic statements in Part 2?

• A number of important clarifications are asked
  for.

13
Q9 Should the publication (part 4) be kept as a
separate part or should the content moved to Part
1?

• Majority for moving it to part 1
• Some will use it in part 3
• alternatively keeping it as a separate part.

14
Q10 Should the description of the historical
development be maintained?

• The historical description is considered to be of
  value, but possibly moved to part 1.

15
Q11 Should the life cycle story be maintained?

• Yes

16
Q12 Should the detailed discussion of the
concepts (clauses 7 to 12) be maintained?

• Yes

17
Conclusions of the MCR

• The revision work needs to emphasize
• Part 1
• The understanding of the object concept
• The impact of the use of transitions
• Unambiguous versus unique reference designations
• Unambiguous identify one object
• Unique the only identifier of an object
• How to handle part 4 in part 1
• Part 2
• Clarify the class/sub-class concept
• Clarify task/purpose/function oriented classes
• The possibility to apply a different
  classification scheme, especially that of IEC
  61360
• Eventually inclusion of IEC/PAS 62400.

18
Further issues (1)

• DE and ISO/TC10-DE introduces a new structure
  conjoint designation for distinguishing among
  different plants/factories on a common site,
  being common for the upper part of the three
  other structures
• Is this a location-oriented structure on a
  high-level ?
• The convenor has suggested in some of his earlier
  reports that the concept of the reference
  designation group should be withdrawn as it is an
  exception to the basic principles laid down in
  the publication.
• Is this proposal generally supported

19
Further issues (2)

• The following annexes are to be removed(already
  indicated in ed. 1)
• Annex E - Letter codes of IEC 750
• Annex F Differences and similarities between
  the designation system defined in this standard,
  IEC 750, ISO 3511 and ISO/DIS 1219-2
• Are the following annexes really needed?
• Annex B Examples of transitions from one aspect
  to another aspect
• Annex C Example of transition from one aspect
  to another aspect where the latter aspect has
  independent representations

20
Function-oriented decomposition
Object
Implementable ?
Product
Object
Occurrence of subobject
Description of subobject
Subobject
Subobject
Subobject
21
Decomposition and composition
AP
AF
BF
BP
object with function aspect only object with
both function and product aspectobject with
product aspect only
Function-oriented decomposition
Product-oriented composition
22
Historical background
23
Basic requirements and properties

• Annex A of IEC 61346-1 provides the basic
  requirement and the properties that the
  designation system of the publication shall
  fulfil.
• Do the NCs agree with these requirements and
  properties today, or should some be removed,
  modified or others added?

24
Basic requirement a)

• The reference designation system should be
  capable of being consistently applied in all
  phases (i.e. design, engineering, construction,
  erection, operation, maintenance, commissioning,
  decommissioning, etc.) of the life time of a
  technical product. The technical product can be a
  plant, a system, an assembly, a part, etc.
• The reference designation system shall be able to
  accommodate different types of information and
  structures important to different phases of the
  life time.
• The reference designation system should be
  flexible. It should be i) applicable in the
  different phases covering different needs. ii)
  possible to construct the reference designation
  from the available information.

25
Basic requirement b)

• The reference designation system shall provide
  the ability to identify unambiguously any single
  object within an overall system.
• The reference designation system shall allow a
  reference designation to be extended both at the
  end and at the front of the reference
  designation.

26
Basic requirements c), h) and i)

• The reference designation system should be fully
  applicable to all technical areas.
• The reference designation system should support
  the use of, and should be able to be implemented
  by, computer-aided tools for engineering,
  construction, operation, maintenance, etc.
• A reference designation shall be applicable in
  combination with terminal designations, signal
  names and document classification codes.
• The reference designation system shall contain
  rules for the creation of structures that enable
  the formulation of unambiguous reference
  designations. Rules for the interpretation shall
  also be provided.

27
Basic requirement d)

• The reference designation system shall support
  the incorporation of subsystems and products from
  multiple organizations into systems from other
  organizations without change to the original
  sub-systems and their documentation.
• The reference designation system shall not
  contain rules and restrictions that prohibit its
  use within a technical area.
• The reference designation system shall cover all
  possible use of the system that can be foreseen
  within all technical areas and not be restricted
  to a particular field.

28
Basic requirement e)

• The reference designation system shall support a
  representation of a system under different
  aspects, independently of the complexity of the
  system.
• The reference designation system shall give the
  possibility to maintain a given reference
  designation within a system when this system is
  incorporated into a bigger system.

29
Basic requirements f) and g)

• The reference designation system shall support
  the handling of computer programs and parts of
  such programs as technical products.
• The reference designation system should be easy
  to apply and the reference designations should be
  easy for the user to understand.
• The reference designation system shall be able to
  describe the fact that multiple independent
  functions are implemented within a single
  product.
• The reference designation system shall be able to
  describe different aspects (views) of the system
  in order to represent the complex relationship
  among the different objects (i.e. functions,
  components, devices, etc.) of the system.

30
Basic requirement j)

• A reference designation shall be applicable in
  combination with terminal designations, signal
  names and document classification codes.
• The reference designation system shall not
  contain rules that prohibit its use in
  combination with terminal designations, signal
  names, and document classification codes. A
  reference designation shall be clearly
  distinguishable from a terminal designation,
  signal name and document classification code

31
Thank you for your attention.Any questions?
