Title: Nuclear Reactions and Nuclear Astrophysics


1
Nuclear Reactions and Nuclear Astrophysics
  • Focus on Physics

2
Speakers
  • Phillipe Collon Possibilities for AMS
    experiments at ATLAS
  • Livius Trache Single-nucleon transfer between
    p-shell nuclei around 10 MeV/u
  • William Peters (d,pg) as a surrogate for (n,g)
  • Lee Sobotka Decay spectroscopy next up 14C
  • Catherine Deibel Studying the (a,p) process at
    ATLAS
  • Xiaodong Tang The 12C12C fusion reaction

3
Themes
  • Nucleon transfer reactions for structure,
    astrophysics, and applications
  • Other reactions for structure
  • (In)elastic scattering for optical-model
    potentials, structure
  • Other means AMS, production/counting for
    astrophysics

4
Transfer reactions for structure and astrophysics
  • Heavy-ion single-particle transfer for nuclear
    astrophysics
  • ANC studies linked to determination of (p,g)
    reaction rates
  • Need for accurate optical-model potentials
  • Need high-quality beams, intensity for production
    of high-quality secondary beams (energy
    resolution, low emittance)

5
Details and problems
angular resolution (limited!) Beam res. 0.8 2
deg!
Energy resolution (bad!) Beam res. 1-2 2-4 MeV
Ang distr ? ANC ? astrophys S-factor ? react rate
6
TAMU exps _at_ 12 MeV/u
12N on melamine
Optical Model Potentials for Nucleus-Nucleus
collisions for RNBs 10 MeV/u
  • Essential to make credible DWBA calc needed in
    transfer r.
  • Have established semi-microscopic double folding
    using JLM effective interaction
  • Established from exps with stable loosely bound
    p-shell nuclei 6,7Li, 10B, 13C, 14N _at_ 10 MeV/u
  • Parameters renormalization coeff.
  • Predicts well elastic scatt for RNBs
  • 7Be, 8B, 11C, 12N, 13N, 17F
  • 7-10 uncertainty in DWBA calc
  • L. Trache ea, PRC 61 (2000)
  • F Carstoiu ea PRC 70 (2004)

A. Banu ea, PRC 79, 025805 (2009)
  • OMP need extension to sd-shell
  • Work on stable projectiles at TAMU
  • RNB of good quality ATLAS ?!
  • Energy and angular resolution
  • Trojan-horse with RNB ?!

7
Transfer reactions as surrogates Inverse (d,pg)
as a tool to probe (n,g), (n,2n)
  • Applications
  • Astrophysics
  • Nuclear reactors and device modeling
  • Stockpile stewardship and waste storage
  • Needs
  • Reasonable intensity for RNBs at least 105 to
    106 pps
  • Coulomb-barrier energy beams
  • Gammasphere for g efficiency
  • Particle detector with reasonable spatial
    resolution
  • See also instrumentation Steve Pains talk

8
75As d,p?
  • 73As/74As 1/2 s74(n,2n) ?n (D.Vieira)
  • Isotope ratios measured after event
  • (n,2n) reactions most important
  • (n,?) reactions can effect results

August 8, 2009
ANL
8
9
Decay from excited 76As
August 8, 2009
ANL
9
10
My two cents
  • Nucleon transfer for Classical nuclear physics
    with RNB
  • Spectroscopic factors to test wave functions from
    (d,p), (d,3He), (d,t), (a,t) ...
  • In light nuclei tests of ab-initio calculations
  • Single-particle states around, say, 132Sn...
  • Needs More intense RNB further than 1 nucleon
    from stability at Coulomb-barrier energies
  • Intense primary beams
  • High energies (20 MeV/u) for very negative
    Q-value reactions
  • Robust production targets
  • New separator
  • RF sweeper at HELIOS
  • CARIBU!

11
(a,p) reactions and HELIOS
  • Information about ap process and X-ray bursts
  • Requires intense secondary in-flight beams,
    Coulomb-barrier- energies
  • Tool HELIOS instrumented with cryogenic 4He
    target, A30 recoil detector

12
ap-process in X-Ray Bursts
  • The early rp-process a series of (p,g), (a,g) and
    (a,p) reactions
  • Stalls where (p,g) and (g,p) reactions come into
    equilibrium and must wait for b decay
  • (a,p) reactions can break out if they are faster
    than the b decay
  • May be responsible for double-peaked luminosity
    profiles
  • Sensitivity studies have shown many of these
    reactions have significant effects on final
    abundances and energy output

13
ap-process studies with HELIOS
  • Original design
  • Solid targets
  • Detection of backward light recoils
  • Detection of heavy recoils at 0
  • Additions
  • Gas target allows 3,4He targets
  • Full Si array allows almost 4p acceptance
  • PPAC and IC allows for more robust particle
    identification of heavier recoils, beam, and beam
    contaminants

Si Array
Beam
Gas target
PPAC and IC
14
Other reactions for structure Breakup and
resonant particle spectroscopy
  • Study multi-particle correlations following
    inelastic excitation
  • Physics of exotic cluster states at high
    excitation energy
  • Needs high energy, intense (at least few X 105)
    pps

15
Decay Continuum spectroscopy Using MARS-HiRA
  • 6Be 10C

PL B 677, 30 (2009) PRC in press (2009)
PRC 78 031602 (2008) 75 051304 (2007) in
press (2009)
  1. Decay paths, branching ratios determined for all
    known levels.
  2. A branch of the 6.57 MeV state has the best
    diproton correlation observed to date!
  3. Did NOT confirm previous identified state at
    4.2 MeV thought to be the 0 (Curtis et al.,
    PRC77, 021301 (2008).
  4. Found new state at 8.4 MeV

Perhaps we should do 10C p (inelastic) to
really find this 0. (But will it be excited?
Just above threshold.)
16
After that perhaps 14C
9Be(7Li,10Bea) Soic, PRC 68, 014321 (03)
? 2a6He
Gd.st
1st excited state
2
But most channels not Observed, i.e. 12C
2n 12C 2n 8Be 6He 8Be 6He i.e. aa6He
(and intermediates) Calls for a 3 cp neutron
correlation Experiment. HiRA WU neutron
detectors
2nd grp
2,1-,0,2-
17
(In)elastic scattering
  • Necessary, especially for RNBS, to determine
    optical potentials
  • Needed to interpret ANC measurements
  • And Spectroscopic factor measurements
  • 15-20 MeV/u measurements of (p,p) on RNBs as a
    benchmark for higher energy studies, probe
    asymmetry dependence in dispersive optical
    potential
  • Use (p,p) as a spectroscopic tool search for
    the excited 0 cluster state in 10C? Moments and
    transition matrix elements?
  • Needs high-energy beams, HELIOS is the tool

18
Other means
  • AMS as a tool for astrophysics

19
Present status of AMS experiments at ATLAS
  • A number of AMS experiments have been performed
    at ATLAS
  • Environmental science (39Ar, 81Kr, )
  • Stellar nucleosynthesis (59Ni, 62Ni(n,g)63Ni,
    146Sm, 182Hf,)
  • WIMP dark matter detector development (39Ar)
  • AMS relies on a number of factors
  • Good isobaric separation (high energies help!)
  • Stability of the entire system
  • High overall transmission

20
Other means
  • AMS as a tool for astrophysics
  • Production studies for p-process nuclei
  • Use intense ATLAS beam to do, e.g., 144Sm(a,g),
    142Nd(a,g), 154Gd(a,g) followed by AMS counting
    needs very intense, high-energy beams

21
Discussions my interpretation so blame me
  • (d,n) reactions as a spectroscopic tool neutron
    detection capabilities?
  • Resolution and sensitivity are key for uncovering
    the physics. (No kidding, really?)
  • High beam energies are most welcome
  • High intensities useful for extending the reach
    of the secondary in-flight program
  • Where can we get a tritium target??!!...
