VELO Overview

1
VELO Overview

• T. Bowcock
• University of Liverpool

2
Post-TDR

• Hardware
• Software
• Critical Issues
• Summary

3
Hardware

• Sensors
• Hybrids
• Thermo-Mechanical Module
• Testbeam
• Production Facilities

4
Hardware Sensors (1)

• Two types of sensors produced
• Hamamatsu (nn)- 1998
• Micron (pn) 2000
• In fabrication (mask design at Lpool)
• Micron (nn) 2001

5
Hardware Sensors (2)

• Laboratory
• High precision tests with 1060nm lasers for both
  sets of detectors (LHCb note)
• Testbeam at CERN
• Under preparation for 2001

6
(No Transcript)
7
(No Transcript)
8
(No Transcript)
9
(No Transcript)
10
Hardware Sensors (3)

• Additional test equipment
• Cosmic ray facility now commissioned
• Shorter wavelength laser (900nm)
• Ordered
• Automated Scanning x-y stage

11
Hardware Sensors (4)

• Simulation complete
• First principle analysis of leakage currents and
  charge collection as a function voltage
• Agreement with data
• Note low voltage phenomena lt20V Q/I amplifiers.

12
Hardware Sensors (5)

• Identify manufactures for Production
• Hamamatsu (withdrawn nn option)
• Micron (nn, pn)
• CSEM, Eurysis, SEIKO, SINTEF, ST
• Technical discussions ? Price Enquiry

13
Hardware Hybrids(1)

• Hybrid DesignProduction to IDE
• Delivered
• Bonded and mounted with chips
• Fan-ins produced
• Under test
• 4 chips r/o (26/6)

14
Hardware Hybrids(2)

• Kapton version to be ordered early 7/01
• SCT-VELO design (Liverpool)
• improved cable connections
• Viable pre-production prototype
• Beetle design

15
Hardware Module(1)

• Thermal models for TDR
• Cooling system
• Safety issues addressed

16
(No Transcript)
17
(No Transcript)
18
Calibration Model
Delta(T) (from nominal)
Power
19
glue
Chip
kapton
sensor
ceramic
TPG
glue
Chip
kapton
CF(UD)
sensor
CF weave
TPG
20
(No Transcript)
21
Hardware Module (2)

• Prototype and testing of adjustment
• Re-engineering
• Carbon fibre base
• O CTE materials including adjustment screws

22
(slew)
(pitch)
(roll)
23
(No Transcript)
24
(No Transcript)
25
(No Transcript)
26
Hardware Module (3)

• Curvature of the sensors measured
• We may need to survey (cold?) the modules

27
Hardware Module (4)
Measurement points
28
(No Transcript)
29
(No Transcript)
30
Hardware Testbeam

• Module for October 2001
• See also software

31
Hardware Production Facilities

• Clean rooms
• Bonding equipment
• Jigs and Assembly
• Vacuum compatible glue dispensing

32
Production Facilities
RD
LHCb
33
(No Transcript)
34
Software

• TDR analysis and optimisation
• Monte Carlo simulations of VELO
• VELO core software (meeting 5/6 July)
• Alignment
• Testbeam

35
Software Optimisation

• We generated and analysed over 10m bb events
  generated and analysed for different
  configurations Physics Section
• Optimisation paper (for TDR) huge effort
  impossible without substantial effort

36
Software Silicon

• Other (non GEANT software) for optimisation of
  operating conditions

37
(No Transcript)
38
(No Transcript)
39
(No Transcript)
40
(No Transcript)
41
(No Transcript)
42
Software Alignment(1)

• Alignment Underway
• From HERA code used by H1
• Fast determination of global parameters
• Reduced to linear problem

43
Software Alignment(2)

• Curvature of detectors

44
Residuals
45
Software Other

• LHCb production
• LHCb Grid
• Testbeam as testbed

46
Critical Issues

• Electronics
• Electronics
• Electronics
• Manufacturers for Silicon
• Grid

47
Summary

• Sensors
• Hybrid
• Module
• Software
