Computer Graphics Animation Techniques

1
Computer GraphicsAnimation Techniques
Ronen Barzel

• Geometric programming
• Parametric models
• class 2
  22 january 2003

2
Outline for today

• Course business
• Geometric Programming
• Parametric models (graphics programming)

3
Textbooks

• Computer Animation Algorithms and Techniques.
  Rick Parent 2001
• Computer Graphics Principles and Practice.
  Foley, van Dam, Feiner, Hughes 1995

4
Review Grading

• I need some way to know how youre doing
• You might want feedback
• Email me your TD.
• Feel free to expand it, have fun.

5
Go over TD1

• (see my version)

6
Todays animation

• Knick knack

7
Outline for today

• Course business
• Geometric Programming
• Parametric models (graphics programming)

8
Linear geometry

• Basic for all computer graphics
• Linear Geometry
• Coordinate-free geometry
• Affine Space
• Linear Algebra
• Homogeneous coordinates

9
Geometric objects

• Coordinate-free geometry
• Affine Space
• A vector space with points
• Interesting Objects
• Points
• Vectors
• Transformations
• Frames
• Spaces, normals, rotations,

10
Points and vectors

• You know linear algebra, vector spaces
• Why am I talking about this?
• Emphasize differences
• between a point and a vector
• between point or vector and its representation as
  coordinates

11
Points and vectors

• in R3, can represent point as 3 numbers
• in R3, can represent vector as 3 numbers
• 3-Tuple array of 3 numbers
• Easy to think theyre the same thing
• but theyre not!
• different operations, different behaviors
• many program libraries make this mistake
• easy to have bugs in programs

12
In 1D, consider time

• point in time a course meets at 8h
• duration of time a course lasts 8 hours
• operations
• course at 8h course at 10h ? class at 18h !!
• 8 hour course 10 hour course 18 hours course
• course ends at 10h starts at 8h 2 hour course
• course starts at 8h lasts 2 hours ends at 10h
• 2 courses at 8h ? one course at 16h !!
• 2 courses last 8 hours 16 hours of courses
• starts at 8h, ends at 10h. half done at
  .58h.510h 9h

13
Programming with time

• is this the start of the meeting or the duration?
• float time // time of meeting
• fewer bugs
• class TimePoint TimeDuration
  subtract(TimePoint) TimePoint
  add(TimeDuration) etc.
• class TimeDuration TimeDuration
  add(TimeDuration) TimeDuration scale(float
  s) etc.
• In C, define , -, operators

14
Coordinate Systems for time

• 8 oclock ambiguous use 8h00 vs 20h00
• time zones same point, many representations
• 10 (Paris) 9 (London)
• to remove ambiguity, often use GMT
• if always staying local, not imporant
• if scheduling globally, must be careful.
• convert from one time zone to another.
• Also, hours only good within one day
• need to specify date time
• UNIX time seconds since 01/01/1970, 00h00 GMT
• Notice time durations are unaffected!

15
Programming with time

• what time zone is this?
• TimePoint tp1 NewTimePoint(15)
• float h tp2.hour
• fewer bugs
• class TimePoint TimePoint(TimeZone tz, float
  hour) float getHour(TimeZone tz) etc.
• class TimeZone
• Privately, the class might store GMT or Unix time.

16
Geometry, analogously

• point describes a location in space
• can subtract points to get a vector
• can take weighted average of points to get a
  point
• vector describes a displacement in space
• has a magnitude
• can add, subtract, scale vectors
• can add vector to a point to get a point

17
Multiple spaces

• Can also have multiple spaces
• operations only on objects in same space
• can have transformation from one space to another
• e.g. point in city vs point on map of the city
• (less often a source of bugs)

18
Reference frames for geometry

• A reference frame origin basis vectors
• Given origin point O, vectors v0, v1, v2
• any point P expressible as P Oav0bv1cv2
• Use many frames at once when doing CG.
• Use mostly orthonormal (Cartesian) frames
• Right-handed vs. left-handed

19
Coordinates of a Frame

• Frame f origin O, vectors v0, v1, v2
• In world coordinates, might have
• O (10,10,3) v0 (0,-1,0), v1
  (0.7,0,0.7), v2 (-0.7,0,0.7)
• But in frame f, always have
• O (0,0,0) v0 (1,0,0), v1 (0,1,0), v2
  (0,0,1)

20
Programming geometry

• class GeomPoint GeomPoint(GeomFrame f,
  float coords) void getCoords(GeomFrame f,
  float coords) GeomVector subtract(GeomPoint)
  GeomPoint add(GeomVector) etc
• class GeomVector GeomVector(GeomFrame f,
  float coords) void getCoords(GeomFrame f,
  float coords) GeomVector add(GeomVector)
  GeomVector scale(float) etc
• class GeomFrame GeomFrame(GeomPoint origin,
  GeomVector basis) etc
• Bootstrap start with standard frame for the
  space

21
Computing using components

• Privately, class keeps array of coordinates.
• Operations work in any coordinate frame
• v0 pa0 pb0 v1 pa1 pb1
  v2 pa2 pb2
• if all coordinates are from the same frame!
• Internally, might convert all objects to standard
  frame.

22
Affine Transformations

• Several types
• From one space to another different objects
• From a space to itself different object
• Change frame same object, different
  representation
• Linear F(aPbQ) aF(P)bF(Q)
• parallel lines stay parallel lines
• angles not necessarily preserved

23
Affine Transformations

• To define a transform M(A)gtB,
• sufficient to specify a FrameA gt FrameB,
• I.e., OriginA gt OriginB and BasisA gt BasisB
• Programming an affine Transform
• class AffineTransform AffineTransform(GeomFrame
  A, GeomFrame B) GeomPoint apply(GeomPoint)
  GeomVector apply(GeomVector) AffineTransform
  compose(AffineTransform)

24
Affine Transformations

• Rotations, Translations, Scaling
• Build transformations by composition
• not commutative G(F(P)) ? F(G(P))
• Rotate then translate ? translate then rotate
• vectors unaffected by translation parts
• analogous to duration not affected by time zone

25
Computing using components

• Given frames for the domain and range!
• Point P with coordinates (P0,P1,P2)
• F(P)0 m00 P0 m01 P1 m02 P2 b0F(P)1 m10
  P0 m11 P1 m12 P2 b1F(P)2 m20 P0 m21 P1
  m22 P2 b2
• Vector V with coordinates (V0,V1,V2)
• F(V)0 m00 V0 m01 V1 m02 V2 F(V)1 m10 V0
  m11 V1 m12 V2 F(V)2 m20 V0 m21 V1 m22
  V2

26
Matrix operations Linear algebra

• When working with coordinates
• Affine transform general form is
• F(P) M P B F(V) M V
• B contains translation
• M contains rotation, scale, shear

27
Some Coordinate Equivalences

• Given a frame with origin O
• point P ? vector v P O
• coordinates P (a,b,c)
• coordinates v (a,b,c)
• given a standard frame s
• frame f ? transformation F(s) gt f
• coordinates of origin B, basis columns of M
• transforming point vs changing from one
  representation to another same matrix

28
Inconveniences

• Different rules for points and vectors
• Inconvenient to compose transformations
• F(P) M P B
• G(P) N P C
• G(F(P)) (NM) P (NBC)
• Inconvenient to compute inverse, etc.
• Introduce Homogeneous Coordinates

29
Homogeneous coordinates

• Basic a trick to unify/simplify computations.
• Deeper projective geometry
• Interesting mathematical properties
• Good to know, but less immediately practical

30
Homogeneous coordinates

• add an extra component to a point or a vector
• point (a,b,c,1)
• vector (a,b,c,0)
• combine M and B into single matrix
• (in this figure M?r, B?t. sorry! )
• Transformation is always matrix operation
• F(P) M P
• F(V) M V

31
Homogeneous coordinates

• Legal operations always end in 0 or 1
• Last row of matrix always (0,0,0,1)
• Compose transformations by multiplying matrices

32
Final note transforming normals

• A normal vector perpendicular to surface
• Not really a vector
• represents relationship to other vectors
• (a co-vector, a linear functional)
• Transform using transpose of inverse of M

33
Programming in practice

• Everyone uses homogeneous matrices.
• built into low-level software, hardware
• In practice, nobody explicitly uses 1 and 0.
• no need for storage computation
• keep track of points vs vectors explicitly

34
Programming in practice

• Standard libraries linear algebra, homogeneous
  coordinates not geometric.
• e.g. Javas Point2D and AffineTransform
• No Vector2D, you must use Point2D
• Remember to use a.transform(p)or
  a.deltaTransform(v)
• No support for transforming a normal
• Keep track of coordinate frames yourself.

35
Geometric programming

• A few academic libraries
• http//www.cgl.uwaterloo.ca/njlitke/geometry/
• Why not in wider use?
• Not many people familiar with it
• Existing libraries very minimal
• Not integrated with platform
• Depending on how implemented and how general, can
  be less efficient
• Even without geometric libraries, its very
  useful to think about it this way.

36
Note assuming Euclidean space

• Affine Space with a metric
• Vectors are freesame everywhere
• Other spaces (curved, finite, etc.) are messier
• a vector is defined only for a given point

37
Aside perspective projection

• homogeneous coordinates for 3D gt 2D
• introduce perspective divide
• (a,b,c,1) gt (x,y,z,w) gt (x/w, y/w, z/w, 1)
• frustum changes to cube

38
Outline for today

• Administrative stuff
• Geometric programming
• Parametric models (graphics programming)

39
Parametric models

• also, procedural modeling
• modeling by executing a program
• at the core of all CG
• parameters for location
• parameters for pose
• compute shape of parts
• compute relationship between parts

40
Example model Snowman

• Basic model Three circles on top of each other.
• Parameters
• squash stretch for each
• position of torso on base
• position of head on torso
• tilt each part
• This will be TD2

41
Programming Graphics

• You provide a draw()routine.
• Library maintains current state
• Fill color, line style, shading, lighting,
• current transformation
• g.setTransform(xf) // replaces the transform
• g.transform(xf) // composes transform
• g.rotate(angle) // composes rotation
• g.translate(tx,ty) // composes translation
• g.scale(sx,sy) // composes scale
• etc

42
Current transformation

• Typically, have a graphics stack
• g.push() // saves current state
• g.pop() // restores to saved
• Typically, split into two parts
• Local to World Modeling transformation
• World to Screen Viewing transformation
• Java Graphics2D doesnt do either
• (TD2 includes a wrapper that does)

43
Typical use in a program

• drawHighLevelObject(parameters)
• g.push()g.rotate()g.translate()g.scale()g.
  drawSimpleShape()g.pop()
• drawModel() g.push()drawHighLevelObject()g.tr
  anslate()drawHighLevelObject()etcg.pop()

44
Thinking top-down vs bottom-up

• Sample sequence
• 1. Rotate(45)2. translate(0,5)3. scale(2,1)4.
  drawSquare()
• Top-down transform a coordinate frame
• rotate it 45 degrees about its origin, then
  translate it along its Y, then stretch it in X,
  then draw the primitive.
• Bottom-up transform the object
• create a square, then scale it in X then
  translate it along the Y axis, then rotate 45
  degrees about the origin.
• Both ways useful

45
Building your own transform

• Often, want not just to draw, but also to operate
  or compute.
• Instead of
• g.rotate()g.translate()g.scale()
• can do
• xf new AffineTransform()xf.rotate()xf.transl
  ate()xf.scale()g.transform(xf)
• Now xf is available for xf.transform(pt), etc.

46
end of class 2
