Functions and Architecture of Workflow System

1
Functions and Architecture of Workflow System
2
Role of Workflow Management Systems

• Information systems must meet a number of
  requirements
• IS must set up in such a way that the structure
  of the business processes is clearly reflected.
• There should be an integrated approach, which
  also encompasses non-computerized tasks.
• IS must be set up in such a way that the
  structure of the business processes can easily be
  modified.
• The performance of a business process can be
  tracked properly, so that any problems can be
  discovered at an early stage.
• Good workload management is crucial to achieving
  effective and efficient business processes.

3
Role of Workflow Management Systems

• How information systems are traditionally
  structured?
• Process management has not been separated from
  the application software in information systems.
• The process management has been hidden inside the
  information system.
• Little attention been paid to process structure
  within the framework of traditional systems, it
  has often been difficult to actually recognize
  the business process.
• The process contained in the system has sometimes
  been incorrect or incomplete.

4
Role of Workflow Management Systems
5
Role of Workflow Management Systems

• Advantages--
• This makes it possible to reuse the same
  functionality in more than one task.
• This makes it possible to rearrange the business
  process at a later stage.
• In this way, it is even possible to integrate new
  applications with legacy systems.
• The process execution is more manageable, with
  progress and bottlenecks being more easy to check.

6
A REFERENCE MODEL

• WFMC,1996
• Workflow Enactment Service
• Process Definition Tools
• Workflow Client Applications
• Invoked Applications
• Administration and Monitoring Tools

7
A REFERENCE MODEL
8
Workflow Enactment Service

• The heart of a workflow system.
• The Enactment Service may consist of several
  workflow engines.
• Workflow engine
• creating new cases and removing completed ones.
• routing cases, using the interpretation of the
  appropriate process definition.
• submitting work items to the correct resources
  (employees), based upon resource
• classification.
• managing and handling triggers.
• starting up application software during the
  performance of an activity.
• recording historical data.
• providing a summary of the workflow.
• monitoring the consistency of the workflow.

9
Process Definition Tools

• The process definition tool
• The resource classification tool
• The analysis tool

10
Process Definition Tools

• Ability to establish process definitions (name,
  description, date, version, components, and so
  on).
• Ability to model sequential, parallel, selective
  and iterative routing by means of such graphic
  components as the AND-split, AND-join, OR-split
  and OR-join.
• Version-management support (after all, there may
  be several versions of the same process) .
• Definition of case attributes used in the process
  .
• Task specification.
• Checking of the (syntactical) correctness of a
  process definition and the tracing of any
  omissions or inconsistencies.

11
Process Definition Tools

• The following is established for each task
• name and description of the task
• task information - any instructions and
  supporting information for the employee
  performing the task
• the requirements with respect to the resource
  carrying out the task (for example, a
  specification of its role and organizational
  unit, or information about the separation of
  functions)
• the task's routing characteristics (AND-split,
  AND-join, OR-split, OR-join)
• the specification of any triggers required
• instructions for the workflow engine (for
  example priorities, case management and resource
  management)

12
Process Definition Tools

• The resource classification tool
• A list of the resource classes, often subdivided
  into roles (based upon qualifications, functions
  and skills) and organizational units (based upon
  arrangement into teams, branches and/or
  departments).
• Any specific characteristics of a resource class.
• Relationship between the various resource classes
  (for example, a hierarchy of roles or
  organizational units).

13
Process Definition Tools

• The analysis tool
• Before a workflow which has been defined can go
  'into production', it is first useful to analyze
  it.

14
Workflow Client Applications

• The standard worklist handler
• Work items may be preformed by an employee
• Provide relevant properties of a work item
• Sort or select work item by properties
• Report the completion of an activity
• The integrated worklist handler
• This specific worklist (customized worklist
  handler) handler would contain supporting
  facilities alongside the standard functionality
  described above
• Ex processing similar cases in batch processing
  a series of successive tasks for a case

15
Worklist Handler
16
Invoked Applications

• Interactive application (ex. word, excel)
• Fully-automatic application (ex. calculation)

17
Administration and Monitoring Tools

• The operational management tool
• Not case-related (resource-related or
  system-related)
• addition or removal of staff
• input/revision of an employee's details (name,
  address, telephone number, role, organizational
  unit, authorization and availability).
• Case-related
• inspection of the logistical state of a case
• manipulation of the logistical state of a case
  due to problems and exceptional circumstances.

18
Administration and Monitoring Tools

• The recording and reporting tool
• These are historical data which may be useful for
  management. For example, the following
  interesting performance indicators may be
  distilled from the data
• average completion time for a case
• average waiting time and processing time
  (possibly subdivided per task)
• percentage of cases completed within a fixed
  standard period
• average level of resource capacity utilization.

19
Components of a Workflow System
20
Users of a Workflow Management System
21
Roles of people involved

• Workflow management system
• The Workflow Designer
• The Administrator
• The Process Analyst
• The Employee
• Applications
• database designers/programmers
• application designers/programmers

22
Data in a workflow system
23
Interfacing problems

• WFMC recognizes five interfaces
• Improve the exchange of data.
• Create links between servers in a simple way.
• Applications are entirely independent of the
  workflow management system.
• Every interface will be achieved using
  Application Programming Interface (API).

24
Interfacing problems (cont.)

• Interface 1
• Connect/disconnect
• Process definitions and resource classifications
• Opening, creating and saving a process
  definition

• Interface 5
• Management
• Addition of an employee
• Permission of authorization
• Execution of a process definition
• Track
• Waiting times
• Completion times
• Processing times
• Routing
• Staff utilization

Interface 4 Other Workflow Enactment Services

• Interface 2
• Connect/disconnect production of case
• Work item state summaries
• Generation of new cases
• Beginning, interruption and completion of
  activities

• Interface 3
• Application is opened from the system through
  interface 3. (also can opened from the worklist
  handler)

25
Interfacing problems (cont.)
An application can be started by an engine and/or
from a worklist handler.
An application is called to perform a task.
If the workflow engine does not become accessible
following the execution of the Application due to
a system error, the engine and the application
will be 'out of synch.
Once the system has been corrected, the engine
will have no choice but to roll back the task.
26
Interfacing problems (cont.)

• Atomicity
• Completed in full (Commit).
• Restarts from the very beginning (Rollback).
• Consistency
• The result of an activity leads to a consistent
  state.
• Isolation
• Tasks performed at the same time must not
  influence one another.
• Durability
• Task is successfully completed.
• The result must be saved.
• Completed with a commit.

27
Interfacing problems (cont.)

• In the financial world, we frequently have to
  pass the ACID test.
• Linking two or more workflow systems, most of
  the workflow management systems is not always
  entirely clear what the state of a case is.

28
Required Technical Infrastructure

• Most workflow system operate within a
  client/server environment.
• Client
• Worklist handler
• User Interface
• Application
• Server
• Workflow engine
• Application
• DBMS
• Application data

29
Required Technical Infrastructure
30
Current Generation of Workflow Product

• Product in 2000?200 suppliers
• The number of workflow systems actually in
  production is relatively limited.
• Why?
• The technology is quite new.
• Resulting in limited functionality and
  unsatisfactory reliability.

31
Current Generation of Workflow Product

• Staffware
• Graphical Workflow Definer (GWD)
• Graphical Form Designer (GFD)
• Work Queue Manager (WQM)
• Staffware Server (SS)
• Staffware Administration Managers (SAM)
• Audit Trail (AT)

32
Current Generation of Workflow Product

• GWD
• The tasks are called steps.
• Automatic steps
• Normal steps
• Event steps
• Semantics
• Step
• OR-join/AND-split
• Wait
• AND-join/AND-split

33
Current Generation of Workflow Product

• Condition
• OR-split? two choice
• Compare with Petri net
• Concepts such as AND/OR-split/join play an
  important role in both types of models.
• One of the core differences is the fact that the
  notion of states.

34
COSA

• COSAR
• is produced by Software-Ley GmbH.
• It is a workflow management system based upon
  Petri nets.
• COSA can be described as a traditional workflow
  management system that closely follows the WFMC
  reference model.

35
ActionWorkflow

• ActionWorkflowR is produced by Action
  Technologies Inc., and focuses upon supporting
  processes in which communication between people
  and/or parties plays a major role.
• Unlike COSA and Staffware, which concentrate upon
  the process, ActionWorkflow centers on
  coordination.
• ActionWorkflow uses so-called Business Process
  Maps (BPM).
• Each workflow corresponds with a transaction that
  passes through the following stages
• (1) preparation
• (2) negotiation
• (3) performance
• (4) completion

36
ActionWorkflow(cont.)

• ActionWorkflow is only available for a limited
  range of platforms.
• COSA is traditional and thorough, enabling the
  support of most routine production processes
  within administrative organizations.
• ActionWorkflow differs in many respects from
  standard workflow management system, and appears
  to be best suited to supporting processes in
  which coordination is crucial.

37
Analysis tools
38
Analysis tools

• Woflan (WOrkFlow Analyzer) is a tool that
  analyzes workflow process definitions specified
  in terms of Petri nets.
• Todays workflow management systems do not verify
  the correctness of workflow process definitions.
• Therefore errors made at design time such as
  deadlocks and livelocks may remain undetected.
• To avoid these costly problems, it is important
  to verify the correctness of a workflow process
  definition before it becomes operational.

39
Analysis tools (cont.)

• Woflan takes a workflow process definition
  imported from some workflow product, translates
  it into a Petri net, and tells whether or not the
  net is a sound workflow net.
• Using some standard Petri-net analysis techniques
  as well as those tailored to workflow nets, the
  tool provides diagnostic information about the
  net in case it is not a sound workflow net.

40
Selecting a workflow management system

• The selection process begins with the listing of
  the requirements which the system must meet.
  Based upon these, a shortlist is then compiled.
• One way to quickly gain a good impression of a
  workflow management system is to work through a
  sample process chosen in advance.
• The sample process is representative of the
  relevant business processes.
• Once the workflow management systems on the
  shortlist have been put on trial in this way, it
  usually becomes clear which package is the best
  choice.

41
Exercises

• 5.2(a,b)
• Present the future prospects for WFMS in terms of
  7 areas of functionality
