MIS 300

1
MIS 300

• 100 Top Hits for Slides for the Course
• With emphasis on the 2nd half

2
Contents

• General Model of Problem Solving
• MIS DSS GSS ESS
• Specialized Systems
• Management Support Systems
• Technological Leadership
• System Development
• Risk Management and Security
• Computer Crime and Ethics

3
Focus of the Course

• First six weeks Information technology and how
  it works, definitions, IT as a business enabler
  and platform
• Last six weeks What information technology can
  do for users user roles producing and managing
  information technology effects of IT

4
Decision Making as a Component of Problem Solving
SEE THINK SAY DO LEARN
Figure 6.1 How Decision Making Relates to
Problem Solving
5
Decision Making as a Component of Problem Solving
(continued)

• Problem solving a process that goes beyond
  decision making to include the implementation
  stage
• Implementation stage a solution is put into
  effect
• Monitoring stage decision makers evaluate the
  implementation

6
Programmed Versus Nonprogrammed Decisions

• Programmed decisions
• Decisions made using a rule, procedure, or
  quantitative method
• Easy to computerize using traditional information
  systems

7
Programmed Versus Nonprogrammed Decisions
(continued)

• Nonprogrammed decisions
• Decision that deals with unusual or exceptional
  situations
• Not easily quantifiable

8
Optimization, Satisficing, and Heuristic
Approaches

• Optimization model a process that finds the best
  solution, usually the one that will best help the
  organization meet its goals
• Satisficing model a process that finds a
  goodbut not necessarily the bestproblem
  solution
• Heuristics commonly accepted guidelines or
  procedures that usually find a good solution

9
An Overview of Management Information Systems
Management Information Systems in Perspective

• A management information system (MIS) provides
  managers with information that supports effective
  decision making and provides feedback on daily
  operations
• The use of MISs spans all levels of management

10
Management Information Systems in Perspective
(continued)
Figure 6.3 Sources of Managerial Information
11
Outputs of a Management Information System

• Scheduled report produced periodically, or on a
  schedule
• Key-indicator report summary of the previous
  days critical activities
• Demand report developed to give certain
  information at someones request
• Exception report automatically produced when a
  situation is unusual or requires management
  action
• Drill-down report provides increasingly detailed
  data about a situation

12
Functional Aspects of the MIS

• Most organizations are structured along
  functional lines or areas
• The MIS can be divided along functional lines to
  produce reports tailored to individual functions
• This tends to lead to fragmentation, the sort of
  effect that ERP is designed to counter!

13
An Overview of Decision Support Systems

• A DSS is an organized collection of people,
  procedures, software, databases, and devices used
  to support problem-specific decision making and
  problem solving
• The focus of a DSS is on decision-making
  effectiveness when faced with unstructured or
  semistructured business problems

14
Capabilities of a Decision Support System

• Support all problem-solving phases
• Support different decision frequencies
• Support different problem structures
• Support various decision-making levels

15
Capabilities of a Decision Support System
(continued)
What else goes along with level? Why?
Figure 6.10 Decision-Making Level
16
Components of a DSS

• Model base provides decision makers access to a
  variety of models and assists them in decision
  making
• Database
• External database access
• Access to the Internet and corporate intranet,
  networks, and other computer systems
• Dialogue manager allows decision makers to
  easily access and manipulate the DSS and to use
  common business terms and phrases

17
Components of a DSS (continued)
Figure 6.11 Conceptual Model of a DSS
18
Group Support Systems

• Group support system (GSS)
• Consists of most elements in a DSS, plus software
  to provide effective support in group decision
  making
• Also called group decision support system or
  computerized collaborative work system

19
Group Support Systems (continued)
Figure 6.12 Configuration of a GSS (Cf. Figure
6.11)
20
Characteristics of a GSS That Enhance Decision
Making

• Special design
• Ease of use
• Flexibility
• Decision-making support
• Anonymous input
• Reduction of negative group behavior
• Parallel communication
• Automated record keeping

21
Executive Support Systems

• Executive support system (ESS) specialized DSS
  that includes all hardware, software, data,
  procedures, and people used to assist
  senior-level executives within the organization

22
Executive Support Systems in Perspective

• Tailored to individual executives
• Easy to use
• Drill-down capable
• Support the need for external data
• Can help when uncertainty is high
• Future-oriented
• Linked to value-added processes

23
Capabilities of Executive Support Systems

• Support for defining an overall vision
• Support for strategic planning
• Support for strategic organizing and staffing
• Support for strategic control
• Support for crisis management

24
An Overview of Artificial Intelligence

• Artificial intelligence (AI) the ability of
  computers to mimic or duplicate the functions of
  the human brain
• Artificial intelligence systems the people,
  procedures, hardware, software, data, and
  knowledge needed to develop computer systems and
  machines that demonstrate the characteristics of
  intelligence

25
The Nature of Intelligence

• Learn from experiences and apply knowledge
  acquired from experience
• Handle complex situations
• Solve problems when important information is
  missing
• Determine what is important
• React quickly and correctly to a new situation
• By definition, a computer is unintelligent
• The hallmark of intelligence is generating
  information out of experience.

26
The Nature of Intelligence (continued)

• Understand visual images
• Process and manipulate symbols
• Be creative and imaginative
• Use heuristics

27
The Difference Between Natural and Artificial
Intelligence
Table 7.1 A Comparison of Natural and Artificial
Intelligence
28
Expert Systems

• Hardware and software that stores knowledge and
  makes inferences, similar to a human expert
• Used in many business applications

29
Robotics

• Mechanical or computer devices that perform tasks
  that either require a high degree of precision or
  are tedious or hazardous for humans
• Contemporary robotics combines high-precision
  machine capabilities with sophisticated
  controlling software
• Many applications of robotics exist today
• Research into robots is continuing

30
Vision Systems

• The hardware and software that permit computers
  to capture, store, and manipulate visual images
  and pictures
• Used by the U.S. Justice Department to perform
  fingerprint analysis
• Used for identifying people based on facial
  features

31
Natural Language Processing

• Processing that allows the computer to understand
  and react to statements and commands made in a
  natural language, such as English
• Three levels of voice recognition
• Command recognition of dozens to hundreds of
  words
• Discrete recognition of dictated speech with
  pauses between words
• Continuous recognition of natural speech

32
An Overview of Expert Systems Characteristics
and Limitations of an Expert System

• Can explain its reasoning or suggested decisions
• Can display intelligent behavior
• Can draw conclusions from complex relationships
• Can provide portable knowledge
• Can deal with uncertainty

33
Characteristics and Limitations of an Expert
System (continued)

• Not widely used or tested
• Difficult to use
• Limited to relatively narrow problems
• Cannot readily deal with mixed knowledge
• Possibility of error
• Cannot refine its own knowledge
• Difficult to maintain
• May have high development costs
• Raises legal and ethical concerns

34
When to Use Expert Systems

• Provide a high potential payoff or significantly
  reduce downside risk
• Capture and preserve irreplaceable human
  expertise
• Solve a problem that is not easily solved using
  traditional programming techniques
• Develop a system more consistent than human
  experts

35
When to Use Expert Systems (continued)

• Provide expertise needed at a number of locations
  at the same time or in a hostile environment that
  is dangerous to human health
• Provide expertise that is expensive or rare
• Develop a solution faster than human experts can
• Provide expertise needed for training and
  development to share the wisdom and experience of
  human experts with a large number of people

Do you see a potential problem here?
36
Components of Expert Systems
Figure 7.2 Components of an Expert System
37
The Explanation Facility

• Allows a user or decision maker to understand how
  the expert system arrived at certain conclusions
  or results
• For example it allows a doctor to find out the
  logic or rationale of the diagnosis made by a
  medical expert system

38
The Knowledge Acquisition Facility

• Provides convenient and efficient means of
  capturing and storing all the components of the
  knowledge base
• Acts as an interface between experts and the
  knowledge base

39
Participants in Developing and Using Expert
Systems

• Domain expert individual or group that has the
  expertise or knowledge one is trying to capture
  in the expert system
• Knowledge engineer an individual who has
  training or experience in the design,
  development, implementation, and maintenance of
  an expert system
• Knowledge user individual or group that uses and
  benefits from the expert system

40
Applications of Expert Systems and Artificial
Intelligence

• Credit granting and loan analysis
• Catching cheats and terrorists
• Information management and retrieval
• AI and expert systems embedded in products
• Plant layout and manufacturing
• Hospitals and medical facilities
• Help desks and assistance
• Employee performance evaluations

41
What Is SUPPORTED?
Tools for bringing things to conclusion

• Managers are employed to create conclusions, to
  make things happen
• Thus, any support they receive can be only of two
  types
• To make it easier to make things happen or
• To make others think things have happened (i.e.,
  to increase the perception of things happening)

Tools for helping others see that things have
happened
42
What Is a Conclusion?

• A Decision
• Agreement or consensus
• Realization of a model or plan
• Addition to knowledge
• Increase in confidence
• Any (presumed positive) change in resources (such
  as cash, staff, customers, etc.)

43
What is the Support in Management Support Systems
?
Gather Access, Analyze
Display, Communicate Remember
better Knowledge Array,
Compare Debate Archive Data

Compute WHAT A MANAGEMENT SUPPORT SYSTEM CAN DO
FOR MANAGERS TO INCREASE CONFIDENCE AND
EFFECTIVENESS OF PROBLEM-SOLVING
44
What Kinds of Tools Are There

• Display and Data Formatting (Presentation)
• Data Search and Processing (MIS)
• Suggested Action (Consulting)
• Evaluation of Action (DSS)
• Logical Conclusion (Expert System)
• Action (Operational System)

45
How These Tools Differ

• Each one incorporates more knowledge than those
  above.
• The value of the knowledge is higher and the
  knowledge is more specific.
• Each removes some of the burden from the problem
  solver in generating and evaluating solutions

46
Structure of a Management Support System
This takes place continually, refining
the Quality and relevance of the stored data
DIALOG MANAGER
47
Structure of a Management Support System
System Management
Model Management
Model
Usage
DIALOG MANAGER
48
General Model of a Management Support System
AdvisingSystemInterface
Advice
LEARNING
Feedback
49
Who Is a Technology Leader?
Those who specify and build the systems

• Technology developers
• Technology commercializers
• Technology stewards

Those who figure out how to make a profit
Those who get the systems built and employed
USE
Project
50
Who Is a Technology Leader?

• Technology stewards
• User management
• Project managers clients
• Process managers
• Product owners

51
Technology Leadership

• Three components
• Assessment
• Forecasting
• Management
• Transfer
• A technological leader fosters technological
  innovation, and understands the technology life
  cycle.
• Such a leader initiates and steers
  commercialization of technological advances,
  links business and technology strategies, manages
  technology RD and understands technological
  revolutions.

52
Technology Management Components

• Technology Assessment
• Evaluating technologies as they are created
• To make wise investments, understand the true
  costs, improve existing technologies, and develop
  ways of employing technologies
• Technology Forecasting
• Predicting what technologies are going to be
  available
• To strategize technology use, second-guess the
  competition, stay on top of the technology wave

53
Technology Management Components

• Technology Management
• Developing and using appropriate technologies
• To lead the technology, employ it in the best
  way, and to profit from technology use.
• Technology Transfer
• Helping others learn the benefits and uses of
  appropriate technologies
• Making technologies available to others

54
Technology Transfer
Rest of Organization
Technology Innovation Source
55
Technology Management Process(Pre-implementation)
56
Technology Management Process (Post-implementatio
n)
57
Technology Life Cycle
58
Commercialization and Marketing of Technology
Are all internally developed systems loss
leaders?
Break-even
Time
59
An Overview of Systems Development Participants
in Systems Development

• Development team
• Responsible for determining the objectives of the
  information system and delivering a system that
  meets these objectives
• Usually consists of stakeholders, users,
  managers, systems development specialists, and
  various support personnel

60
Systems Development Methods

• The systems development process is also called a
  systems development life cycle (SDLC)
• Traditional systems development life cycle
• Prototyping
• Rapid application development (RAD)
• End-user development

61
The Traditional Systems Development Life Cycle
Figure 8.4 The Traditional Systems Development
Life Cycle
62
The Traditional Systems Development Life Cycle
(continued)

• Systems investigation problems and opportunities
  are identified and considered in light of the
  goals of the business
• Systems analysis study of existing systems and
  work processes to identify strengths, weaknesses,
  and opportunities for improvement
• Systems design defines how the information
  system will do what it must do to obtain the
  problems solution

63
The Traditional Systems Development Life Cycle
(continued)

• Systems implementation the creation or acquiring
  of various system components detailed in the
  systems design, assembling them, and placing the
  new or modified system into operation
• Systems maintenance and review ensures that the
  system operates, and modifies the system so that
  it continues to meet changing business needs

64
The Major Phases of System Development
Review Evaluation Mainenance
Analysis
Implemen- tation
Design
65
Prototyping
Expert Imple-menta-tion
Figure 8.5 Prototyping Is an Iterative Approach
to Systems Development
66
The End-User Systems Development Life Cycle

• Any systems development project in which the
  primary effort is undertaken by a combination of
  business managers and users
• End-user-developed systems can be structured as
  complementary to, rather than in conflict with,
  existing and emerging information systems

67
Outsourcing and On Demand Computing

• An outside consulting firm or computer company
  that specializes in systems development can be
  hired to take over some or all of the development
  and operations activities
• Outsourcing can involve a large number of
  countries and companies in bringing new products
  and services to market

68
Systems Investigation

• What primary problems might a new or enhanced
  system solve?
• What opportunities might a new or enhanced system
  provide?
• What new hardware, software, databases,
  telecommunications, personnel, or procedures will
  improve an existing system or are required in a
  new system?
• What are the potential costs (variable and
  fixed)?
• What are the associated risks?

69
Feasibility Analysis
Is there a workable technology?

• Technical feasibility
• Economic feasibility
• Schedule feasibility
• Legal feasibility
• Operational feasibility

Can we afford the potential implementations?
Can we do it in time?
These two types of feasibility are often joined
with othersinto a set of criteria termed
organizational will. Do we have the courage
and culture to carry out the implementation?
70
The Systems Investigation Report

• Summarizes the results of systems investigation
  and the process of feasibility analysis
• Recommends a course of action continue on into
  systems analysis, modify the project in some
  manner, or drop it

71
Systems Analysis

• Answers the question What must the information
  system do to solve the problem?
• Primary outcome a prioritized list of system
  requirements

72
Data Analysis

• A set of diagramming techniques
• Data modeling
• Entity-relationship (ER) diagrams
• Relatively easy to understand a narrative of
  what entities (actors, objects) produce or use
  what information
• Activity modeling
• Data-flow diagrams (DFDs)
• Conceptual, intuitive, should be shared with
  potential users for verification

73
The Systems Analysis Report

• The systems analysis report should cover
• The strengths and weaknesses of the existing
  system from a stakeholders perspective
• The user/stakeholder requirements for the new
  system (also called the functional requirements)
• The organizational requirements for the new
  system
• A description of what the new information system
  should do to solve the problem

?
74
Systems Design

• Answers the question How will the information
  system do what it must do to solve a problem?
• Has two dimensions logical and physical
• Logical design description of the functional
  requirements of a system a model of the user
• Physical design specification of the
  characteristics of the system components
  necessary to put the logical design into action
  a model of the system

75
Systems Implementation User Roles
Heavy user involvement
Figure 8.18 Typical Steps in Systems
Implementation
76
Personnel Hiring and Training

• IS manager
• Systems analysts
• Computer programmers
• Data-entry operators
• Hiring users describe the job match the skills
• Users may take up to three months to learn the
  new jobs.

77
Data Preparation

• Also called data conversion
• Ensuring all files and databases are ready to be
  used with new computer software and systems
• With mission-critical data, generally a really
  expensive proposition

78
Testing

• Unit testing testing of individual programs
• System testing testing the entire system of
  programs
• Volume testing testing the application with a
  large amount of data
• Integration testing testing all related systems
  together
• Acceptance testing conducting any tests required
  by the user

79
Installation

• The process of physically placing the computer
  equipment on the site and making it operational
• Normally the manufacturer is responsible for
  installing computer equipment
• Someone from the organization (usually the IS
  manager) should oversee the process

80
Start-Up

• The process of making the final tested
  information system fully operational
• Direct conversion (also called plunge or direct
  cutover Black Monday effect)
• Phase-in approach (function by function perhaps
  department by department)
• Pilot start-up (a test area, function or
  department)
• Parallel start-up (where mission critical
  information is required or involved, where
  absolutely reliable service is needed)

81
User Acceptance

• User-acceptance document formal agreement signed
  by the user that states that a phase of the
  installation or the complete system is approved

82
Systems Operation and Maintenance

• Systems operation use of a new or modified
  system
• Systems maintenance checking, changing, and
  enhancing the system to make it more useful in
  achieving user and organizational goals

83
Systems Review

• Process of analyzing systems to make sure that
  they are operating as intended
• Often compares the performance and benefits of
  the system as it was designed with the actual
  performance and benefits of the system in
  operation
• Event-driven review review triggered by a
  problem or opportunity, such as an error, a
  corporate merger, or a new market for products
• Time-driven review review performed after a
  specified amount of time

84
General Risk Model
85
Risk Management Components

• Assessment/Awareness
• Avoidance
• Deterence/Deflection
• Defence
• Audit/Detection
• Recovery
• Retaliation
• Reassessment/Learning

1 2-10 4-100 8-1000 16-10000 32-100000 64-1
000000 Priceless!
Costs rise rapidly as risk manage-ment tactics
evolve in time by powers of 2 to 10
86
Cost/Benefit Tradeoff
Because loss is highest for late actions, there
is a rapid increase in value of expense
At some point tactics are complex themselves and
expose actor to further risk
87
Computer Waste and Mistakes

• Computer waste
• The inappropriate use of computer technology and
  resources
• Computer-related mistakes
• Errors, failures, and other computer problems
  that make computer output incorrect or not useful

88
Computer Waste

• Discarding of technology
• Unused systems
• Personal use of corporate time and technology
• Spam
• Poorly designed systems
• Unintelligent system use

89
Computer-Related Mistakes

• Mistakes can be caused by unclear expectations
  and a lack of feedback
• A systems analyst might specify a system that is
  not what is needed or wanted
• A programmer might develop a program that
  contains errors
• Users might accept a system that is not what is
  needed or what is wanted
• A data-entry clerk might enter the wrong data

90
Computer Crime

• Often defies detection
• The amount stolen or diverted can be substantial
• The crime is clean and nonviolent (so far!)
• The number of IT-related security incidents is
  increasing dramatically
• Computer crime is now global

91
The Computer as a Tool to Commit Crime

• Criminals need two capabilities to commit most
  computer crimes
• Knowing how to gain access to the computer system
• Knowing how to manipulate the system to produce
  the desired result
• Social engineering
• Dumpster diving

92
Identity Theft

• An imposter obtains key pieces of personal
  identification information, such as Social
  Security or drivers license numbers, in order to
  impersonate someone else
• The information is then used to obtain credit,
  merchandise, and services in the name of the
  victim or to provide the thief with false
  credentials
• Identity Theft and Assumption Deterrence Act of
  1998

93
Data Alteration and Destruction

• Virus a computer program capable of attaching to
  disks or other files and replicating itself
  repeatedly, typically without the users
  knowledge or permission
• Worm an independent program that replicates its
  own program files until it interrupts the
  operation of networks and computer systems

94
Data Alteration and Destruction 2

• Trojan horse a program that appears to be useful
  but actually masks a destructive program
• Logic bomb an application or system virus
  designed to explode or execute at a specified
  time and date

95
Using Antivirus Programs

• Antivirus program program or utility that
  prevents viruses and recovers from them if they
  infect a computer
• An antivirus software should be run and updated
  often

96
Privacy Issues

• With information systems, privacy deals with the
  collection and use or misuse of data
• Privacy and the federal government
• Privacy at work you dont have any
• E-mail privacy doesnt exist
• Privacy and the Internet caveat emptor

97
Privacy The Basic Issue

• Information about the individual may or may not
  belong to the individual as property
• English common law, the basis of our general law,
  recognizes property rights as inherent and
  inviolable (in general)
• Intellectual assets differ in many ways from
  physical property
• Eg. Copyable without damage
• Eg. Valuable only for brief period of time
• Eg. Can cause damage as well as be an asset

98
Information about Oneself

• In general this does NOT belong to the individual
• Example public figure
• Example customer records
• Example Employee records
• Example Ones image (visual or audio)
• Information in general is inherent in an activity
  and belongs to that activity the owner of the
  activity is the owner of the information.
• This is not a well-developed field with clear-cut
  principles that juries and judges adhere to.

99
Corporate Privacy Policies

• Should address a customers knowledge, control,
  notice, and consent over the storage and use of
  information
• May cover who has access to private data and when
  it may be used
• A good database design practice is to assign a
  single unique identifier to each customer

100
Individual Efforts to Protect Privacy

• Find out what is stored about you in existing
  databases
• Be careful when you share information about
  yourself
• Be proactive to protect your privacy
• When purchasing anything from a Web site, make
  sure that you safeguard your credit card numbers,
  passwords, and personal information

101
Foreign Language Guide Book
What you want to express What
to say in ITish

• Its cute but it doesnt do what its supposed
  to do.
• I know YOU think its great technology, but it
  doesnt meet my needs.
• Wow! This is really going to make me look good
  on the job!

• IT DOESNT WORK!
• I DONT WANT IT!
• THANKS!
