Title: Configuring ISDN


1
Configuring ISDN
2
Integrated Services Digital Network (ISDN)
  • Conceived as a means of replacing the PSTN with
    an all digital network
  • Although more successful in other parts of the
    world, ISDN has never achieved a high level of
    adoption

3
Standards
  • E-Series
  • Telephone network standards (e.g. E.163
    International telephone numbering plan)
  • I-Series
  • Concepts, terminology and general methods (e.g.
    I.100 General ISDN concepts, structures, and
    terminology)
  • Q-Series
  • Switching and signaling operation (e.g. Q.921
    LAPD ISDN data link processes or Q.931 OSI
    Layer 3 functions of ISDN)

4
ISDN Channels
  • D Channel
  • Operate at 16 or 64 Kbps
  • Used for network signaling
  • B Channel
  • Operate at 64 Kbps (DS-0)
  • H Channel
  • H0 384 Kbps, H1 1.536 Mbps, H2 1.92 Mbps

5
ISDN Services
  • Basic Rate Interface (BRI)
  • 2 B Channels 1 D Channel (2BD)
  • Up to 128 Kbps (sometimes up to 144 Kbps)
  • Primary Rate Interface (PRI)
  • Usually 23 B Channels 1 (64 Kbps) D Channel
    (23BD)
  • Up to 1.544 Mbps

6
Function Groups
  • Terminal Equipment 1 (TE1)
  • ISDN compatible DTE
  • Router with a BRI interface
  • Terminal Equipment 2 (TE2)
  • Non-ISDN compatible DTE
  • Router without a BRI interface
  • Network Terminal Adapter (TA)
  • ISDN Modem used to connected non-ISDN compatible
    device (TE2) to ISDN network
  • Network Termination Type 1 and 2 (NT1 or NT2)
  • Terminate ISDN local loop at customer premise

7
Reference Points
  • R between non-ISDN equipment (TE2) and a TA
  • Usually a physical layer connection like TIA/EIA
    232 or V.35
  • S between router and an NT2 device
  • T between NT1 and NT2 devices
  • When no NT2 is present then the S and T reference
    points are combined into the S/T reference point
  • U between NT1 device and carriers DCE
  • Outside North America the NT1 is provided by the
    carrier so the U reference point is irrelevant

8
Reference Points and Function Groups
TA
NT2
NT1
S
T
U
R
TE2
NT2
NT1
TE1
S
T
U
The U reference point is only relevant in North
America
When no NT2 is used then the CPE-to-carrier
interface is called an S/T interface
9
Service Profile Identifiers (SPIDs)
  • SPIDs may or may not be required by the carrier
  • Less common outside North America
  • SPIDs identify the setup and configuration
    information of an ISDN BRI

SPID LDN
Interface BRI0 Isdn spid1 0835866201 8358662 Isdn
spid2 0835866401 8358664
10
Encapsulation
  • ISDN uses HDLC by default but can use PPP or LAPD
  • PPP should be used for its superior
    authentication, compression and mutliprotocol
    support
  • Multilink PPP allows combining D channels

11
Configuring Multilink PPP
  • Dialer-map command associates remote IP addresses
    (next hop) with ISDN LDNs for making outgoing
    calls
  • Dial load-threshold command indicates what
    percentage of bandwidth triggers bringing up an
    additional link

dialer map ltprotocolgt ltaddressgt name lthostnamegt
broadcast ltLDNgt
dialer load-threshold lt1-255gt ltinboundoutboundei
thergt
12
Configuring Multilink PPP
Interface BRI0 ip address 172.19.1.6
255.255.255.252 encapsulation ppp dialer map
ip 172.19.1.5 name r2 broadcast 8358662 dialer
map ip 172.19.1.5 name r2 broadcast 8358664
dialer load-threshold 1 either isdn switch-type
basic-ni isdn spid1 0835866101 8358661 isdn
spid2 0835866301 8358663 ppp authentication
chap ppp multilink
13
Dial-on-Demand Routing
  • DDR allows a router to establish a connection on
    a switched network only when interesting traffic
    needs to be transmitted
  • Connection remains open as long as there is
    interesting traffic or until a idle timer expires
  • Uninteresting traffic is only transmitted if the
    connection is already established and there is no
    interesting traffic to transmit

14
Outbound Packet
No
No
Currently Connected?
Drop Packet
Interesting Traffic?
Drop Packet
Yes
No
No
Currently Connected?
Dial String Configured?
Yes
Yes
Yes
Reset Idle Timer
Dial Number
Send Packet
15
Dynamic or Static Routing
  • Dynamic routing has the disadvantage that routing
    updates will bring up the connection
    periodically
  • Static routing has the disadvantage that the
    router will not be able to determine when the
    connection is not available
  • If using static routes to connect to a central
    cite that uses dynamic routing you must
    redistribute static routes

Router RIP network 172.168.1.0 redistribute
static
16
Specifying Interesting Traffic
  • Interesting traffic is specified with a dialer
    list

dialer list ltnumbergt protocol ltprotocolgt
ltpermitdenylist access-list-numbergt Example
allows all IP traffic dialer list 1 protocol IP
permit interface BRI0 dialer-group 1
17
Controlling Connection
  • A map command for each protocol and destination
    must be specified
  • A threshold for establishing additional
    connections must be established if multilink PPP
    is used

dialer map ltprotocolgt ltaddressgt name lthostnamegt
broadcast ltLDNgt
dialer load-threshold lt1-255gt ltinboundoutboundei
thergt
18
Controlling Connection
  • The idle timer must be set

dialer idle-timeout ltsecondsgt
19
Legacy DDR
Dialer-list 1 protocol ip permit Interface
BRI0 ip address 10.1.0.1 255.255.0.0
encapsulation ppp Isdn switch-type basic ni1
dialer map ip 10.1.0.2 name r2 broadcast 8358661
dialer map ip 10.1.0.2 name r2 broadcast
8358663 dialer-group 1 dialer load-threshold
40 either dialer idle-timeout 300 isdn spid1
0835866101 8358661 isdn spid2 0835866301
8358663 ppp multilink
20
Dialer Profiles
  • A dialer profile is a logical interface that is
    bound to the physical BRI interface when a call
    is made
  • Dialer profiles dont use static dialer maps, the
    dialer map is created dynamically
  • The physical interface is assigned to a dialer
    pool

21
First Configure the Physical Interface
interface BRI0 no ip address encapsulation
ppp ppp authentication chap dialer
pool-member 1
dialer pool-member ltnumbergt priority priority
min-link minimum max-link maximum
22
Next Configure the Dialer Interface
interface Dialer0 ip address 172.19.1.5
255.255.255.252 encapsulation ppp dialer
remote-name r2 dialer string 8358661 dialer
pool 1 dialer-group 2 ppp authentication
chap Dialer-list 2 protocol ip permit
