Data-parallel Abstractions for Irregular Applications

1
Data-parallel Abstractionsfor Irregular
Applications

• Keshav Pingali
• University of Texas, Austin

2
Motivation

• Multicore processors are here
• but no one knows how to program them
• A few domains have succeeded in exploiting
  parallelism
• Databases billions of SQL queries are run in
  parallel everyday
• Computational science
• Both these domains deal with structured data
• Databases relations
• Computational science mostly dense and sparse
  arrays
• Universal parallel computing
• Unstructured data is the norm graphs, trees,
  lists,
• What can we do to make it easier for programs
  that manipulate unstructured data to exploit
  multicore parallelism?

3
Organization of talk

• Two case studies
• Delaunay mesh refinement
• Agglomerative clustering
• ? Irregular programs have generalized
  data-parallelism
• Galois system exploiting generalized
  data-parallelism
• Programming model
• Implementation
• Experimental evaluation
• Ongoing work
• Exploiting locality
• Scheduling

4
Two case studies
5
Delaunay Mesh Refinement

• Meshes useful for
• Finite element method for solving PDEs
• Graphics rendering
• Delaunay meshes (2-D)
• Triangulation of a surface, given vertices
• Delaunay property circumcircle of any triangle
  does not contain another point in the mesh
• In practice, want all triangles in mesh to meet
  certain quality constraints
• (e.g.) no angle gt 120
• Mesh refinement
• fix bad triangles through iterative refinement

6
Refinement Algorithm
while there are bad triangles

• pick a bad triangle
• add new vertex at center of circumcircle
• gather all triangles that no longer satisfy
  Delaunay property into cavity
• re-triangulate affected region, including new
  point
• // some new triangles may be bad
  themselves

7
Sequential Algorithm
Mesh m / read in mesh / WorkList
wl wl.add(mesh.badTriangles()) while (true)
if ( wl.empty() ) break Element e
wl.get() if (e no longer in mesh)
continue Cavity c new Cavity(e)//determine
new cavity c.expand() c.retriangulate()//re-tr
iangulate region m.update(c)//update
mesh wl.add(c.badTriangles())
8
Refinement Example
Original Mesh
Refined Mesh
9
Properties of algorithm

• Actual code is far more complex
• boundaries, especially non-convex boundaries are
  a pain
• Average work per triangle (measured on Itanium)
• 1M instructions, 100K floating-pt instructions
• Dont-care non-determinism
• Cavities of bad triangles may overlap
• Therefore final mesh may depend on order in which
  bad triangles are processed
• Any order will end up with a good mesh (in 2-D)
• Number of bad triangles fixed by algorithm may be
  different for different orders
• Heuristics for ordering bad triangles for
  processing are known
• Not widely used

10
Parallelization Opportunities

• Unit of work fixing a bad triangle
• Data-parallelism bad triangles with
  non-overlapping cavities can be processed in
  parallel
• No obvious way to tell if cavities of two bad
  triangles will overlap without actually building
  cavities
• ? compile-time parallelization will not work

11
Agglomerative Clustering

• Input
• Set of data points
• Measure of distance (similarity) between them
• Output dendrogram
• Tree that exposes similarity hierarchy
• Applications
• Data mining
• Graphics lightcuts for rendering with large
  numbers of light sources

12
Clustering algorithm

• Sequential algorithm iterative
• Find two closest points in data set
• Cluster them in dendrogram
• Replace pair in data set with a supernode that
  represents pair
• Placement of supernode use heuristics like
  center of mass
• Repeat until there is only one point left

13
Key Data Structures

• Priority queue
• Elements are pairs ltp,ngt where
• p is point in data set
• n is its nearest neighbor
• Ordered by increasing distance
• kdTree
• Answers queries for nearest neighbor of a point
• Convention if there is only one point, nearest
  neighbor is point at infinity (ptAtInfinity)
• Similar to a binary search tree but in higher
  dimensions

14
Clustering algorithm implementation
kdTree new KDTree(points) pq new
PriorityQueue() for each p in points
(pq.add(ltp,kdTree.nearest(p)gt)) while (true) do
if (pq.size() 0) break pair ltp,ngt
pq.get() //get closest pair . Cluster c
new Cluster(p,n) //create supernode
dendrogram.add(c) kdTree.remove(p) //update
kdTree kdTree.remove(n) kdTree.add(c)
Point m kdTree.nearest(c) //update priority
queue . pq.add(ltc,mgt)
15
Clustering algorithm details
kdTree new KDTree(points) pq new
PriorityQueue() for each p in points
(pq.add(ltp,kdTree.nearest(p)gt) while (true) do
if (pq.size() 0) break pair ltp,ngt
pq.get() if (p.isAlreadyClustered())
continue if (n.isAlreadyClustered())
pq.add(ltp, kdTree.nearest(p)gt) continue
Cluster c new Cluster(p,n)
dendrogram.add(c) kdTree.remove(p)
kdTree.remove(n) kdTree.add(c) Point m
kdTree.nearest(c) if (m! ptAtInfinity)
pq.add(ltc,mgt)
16
Parallelization Opportunities

• Natural unit of work processing of a pair in PQ
• Algorithm appears to be sequential
• pair enqueued in one iteration into PQ may be the
  pair dequeued in next iteration
• However, in example, lta,bgt and ltc,dgt can be
  clustered in parallel
• Cost per pair in graphics app
• 100K instructions, 4K floating-point operations

17
Take-away lessons

• Irregular programs have data-parallelism
• Data-parallelism has been studied in the context
  of arrays
• For unstructured data, data-parallelism arises
  from work-lists of various kinds
• Delaunay mesh refinement list of bad triangles
• Agglomerative clustering priority queue of pairs
  of points
• Maxflow algorithmslist of active nodes
• Boykov-Kolmogorov algorithm for image
  segmentation
• Preflow-push algorithm
• Approximate SAT solvers
• .
• Data-parallelism in irregular programs is
  obscured within while loops, exit conditions,
  etc.
• Need transparent syntax similar to FOR loops for
  structured data-parallelism

18
Take-away lessons (contd.)

• Parallelism may depend on data values
• whether or not two potential data-parallel
  computations conflict may depend on input data
• (e.g.) Delaunay mesh generation depends on shape
  of mesh
• Optimistic parallelization is necessary in
  general
• Compile-time approaches using points-to analysis
  or shape analysis may be adequate for some cases
• In general, runtime conflict-checking is needed
• Handling of conflicts depends on the application
• Delaunay mesh generation roll back all but one
  conflicting computation
• Agglomerative clustering must respect priority
  queue order

19
Current approachesto optimistic parallelization
20
Manual approaches

• Time-warp (1986)
• Optimistic event-driven simulation
• Distributed-memory computing model
• Buffering of speculative state/roll-backs/commits
  implemented manually for particular application
• Pthreads hand-coded optimistic parallelization
• Most current implementations of Delaunay mesh
  refinement use this approach
• Writing correct fine-grain locking code is tricky

• code tends to be very unstructured and complex
• tripled software costs for Unreal game engine

21
System support

• Hardware/software support for
• buffering speculative state
• detecting dependence violations by tracking
  reads and writes to memory locations
• rollback/commit
• Implementations
• Thread-level speculation (TLS)
• Transactional memory
• TLS
• Speculative execution of DO-loops with irregular
  array accesses (Padua/Rauchwerger/Torrellas/)
• Most implementations do not target while loops
• Only data speculation, no control speculation
• Hardware support can be fairly complex
• Mis-speculations limit speed-up (SUIF study)
• Transactional memory
• Leverage cache-coherence hardware (Herlihy/Moss)
• Support for optimistic synchronization in
  explicitly parallel programming model

22
Limitations of TLS/TM

• Applications require unbounded while-loops
• Most algorithms involve a work-list of some kind
• Detect more work as you traverse data structure
  to perform work
• Detecting dependence violations by tracking reads
  and writes to memory locations results in lots of
  spurious conflicts
• Example Delaunay mesh refinement
• Regardless of how worklist is implemented, there
  must be a location head that points to next bad
  triangle in list
• Every thread must read and write this location to
  get work
• When should update made a thread be made visible
  to other threads?
• As soon as thread pulls work from worklist
  cascading roll-backs are possible
• Only after thread finishes its work only one bad
  triangle can be processed at time
• Other data structure manipulations
  (PQ,kdTree,graph) may have similar problems

23
Galois programming model and implementation
24
Beliefs underlying Galois system

• Optimistic parallelism is the only general
  approach to parallelizing irregular apps
• Static analysis can be used to optimize
  optimistic execution
• Concurrency should be packaged within syntactic
  constructs that are natural for application
  programmers and obvious to compilers and runtime
  systems
• Libraries/runtime system should manage
  concurrency (cf. SQL)
• Application code should be sequential
• Crucial to exploit abstractions provided by
  object-oriented languages
• in particular, distinction between abstract data
  type and its implementation type
• Concurrent access to shared mutable objects is
  essential

25
Components of Galois approach

1. Two syntactic constructs for packaging optimistic
   parallelism as iteration over sets
2. Assertions about methods in class libraries
3. Runtime system for detecting and recovering from
   potentially unsafe accesses by optimistic
   computations

26
Concurrency constructs two set iterators

• for each e in Set S do B(e)
• evaluate block B(e) for each element in set S
• sequential implementation
• set elements are unordered, so no a priori order
  on iterations
• there may be dependences between iterations
• set S may get new elements during execution
• for each e in PoSet S do B(e)
• evaluate block B(e) for each element in set S
• sequential implementation
• perform iterations in order specified by poSet
• there may be dependences between iterations
• set S may get new elements during execution

27
Galois version of mesh refinement
Mesh m / read in mesh / Set
wl wl.add(mesh.badTriangles()) //
non-deterministic order for each e in Set wl do
//unordered iterator if
(e no longer in mesh) continue Cavity c new
Cavity(e) //determine new cavity c.expand() /
/determine affected triangles c.retriangulate()
//re-triangulate region m.update(c) //update
mesh wl.add(c.badTriangles()) //add new bad
triangles to workset
28
Observations

• Application program has a well-defined sequential
  semantics
• No notion of threads/locks/critical sections etc.
• Set iterators
• SETL language was probably first to introduce set
  iterators
• However, SETL set iterators did not permit the
  sets being iterated on to grow during execution,
  which is important for our applications

29
Parallel computational model

• Object-based shared-memory model
• Computation performed by some number of threads
• Threads can have their own local memory
• Threads must invoke methods to access internal
  state of objects
• mesh refinementshared objects are
• worklist
• Mesh
• agglomerative clustering
• priority queue
• kdTree
• dendrogram

30
Parallel execution of iterators

• Master thread and some number of worker threads
• master thread begins execution of program and
  executes code between iterators
• when it encounters iterator, worker threads help
  by executing some iterations concurrently with
  master
• threads synchronize by barrier synchronization at
  end of iterator
• Key technical problem
• Parallel execution must respect sequential
  semantics of application program
• result of parallel execution must appear as
  though iterations were performed in some
  interleaved order
• for poSet iterator, this order must correspond to
  poSet order
• Non-trivial problem
• each iteration may access mutable shared objects

31
Implementing semantics of iterators

• Concurrent method invocations that modify object
  should not step on each other (mutual exclusion)
• Library writer uses locks or some other mutex
  mechanism
• Locks acquired during method invocation and
  released when method invocation ends
• Uncontrolled interleaving may violate iterator
  semantics
• In (a), contains?(x) must always return false but
  some interleavings will violate this (e.g.,
  add(x),contains?(x),remove(x)
• Sometimes, interleaving is OK and is needed for
  concurrency
• In (b) (motivated by Delaunay mesh refinement),
  method invocations can be interleaved provided
  result of get() is not argument of add()

32
(II) Assertions on methods
Shared Memory

• Concurrent accesses to a mutable object by
  multiple threads are OK provided method
  invocations commute

Objects
get()
get()
add()
add()
get() add() get() add()
get() get() add() add()
get()
get()
add()
add()
33
Assertions on methods (contd.)
get() add() get() add()
get() get() add() add()
?

• Semantic commutativity vs. concrete commutativity
• for most implementations of workset, concrete
  data structure will be different for these two
  sequences, so commutativity fails
• however, at semantic level, these set operations
  commute provide they operate on different set
  elements
• Conclusion
• semantic commutativity is crucial
• class implementor must specify this information
• Commutativity of method invocations, not methods
• get() commutes with add() only if element
  inserted by add() is not the same as the element
  inserted by get()

34
Assertions on methods (contd.)
Shared Memory

• Updates to objects happen before iteration
  completes (eager commit)
• So we need a way of undoing the effect of a
  method invocation
• Class implementer must provide an inverse
  method
• As before, semantic inverse is key, not concrete
  inverse

m1
m2
m3
35
Example set
Class SetInterface void add (Element x)
conflicts - add(x) - remove(x)
- contains?(x) - get() x
inverse remove(x) void remove(Element x)
conflicts - add(x) -
remove(x) - contains?(x) - get()
x inverse add(x)
36
Remarks

• Commutativity information is optional
• No commutativity information for a mutable object
  means only one iteration can manipulate the
  object at a time
• Inverse method is more or less essential
• for a class w/o commutativity information,
  inverse methods can be implemented by data
  copying
• Difficulty of writing specifications
• in our apps, most shared objects are collections
  (sets, bags, maps)
• (e.g.), kdTree is simply a set with a
  nearestNeighbor operation
• writing specifications is quite easy
• Relationship to Abelian group axioms
• commutativity, inverse, identity

37
(III) Runtime system commit pool

• Maintains iteration record for each ongoing
  iteration in system
• Status of iteration
• running
• ready-to-commit (RTC)
• aborted
• Life-cycle of iteration
• thread goes to commit pool for work
• commit pool
• obtains next element from iterator
• assigns priority to iterator based on priority of
  element in set
• creates an iteration record with status running
• when iteration completes
• status of iteration record is set to RTC
• when that record has highest priority in system,
  it is allowed to commit
• if commutativity conflict is detected
• commit buffer arbitrates to determine which
  iteration(s) should be aborted
• commit buffer executes undo logs of aborted
  iterations
• Role of commit pool is similar to that of reorder
  buffer in out-of-order execution microprocessors

38
(III) Runtime systemconflict logs

• Each object has a conflict log
• Contains sequence of method invocations that have
  been performed by ongoing iterations
• Each thread has undo log that contains sequence
  of inverse method invocations it must execute if
  it aborts
• When thread invokes method m on object O
• Check if m commutes with method invocations and
  their inverses in conflict log of object O
• If so, add m to conflict log of object O, and
  m-1 to undo log of thread and execute method
• Otherwise, iteration aborts
• When thread commits iteration
• Remove its invocations from conflict logs of all
  objects it has touched
• Zero out its undo log
• Easy to extend this to support nested method
  invocations

39
Experiments
40
Experimental Setup

• Machines
• 4-processor 1.5 GHz Itanium 2
• 16 KB L1, 256 KB L2, 3MB L3 cache
• no shared cache between processors
• Red Hat Linux
• Dual processor, dual core 3.0 GHz Xeon
• 32 KB L1, 4 MB L2 cache
• dual cores share L2
• Red Hat Linux

41
Delaunay mesh generation

• Mesh implemented as a graph
• each triangle is a node
• edges in graph represent triangle adjacencies
• used adjacency list representation of graph
• Input mesh
• from Shewchucks Triangle program
• 10,156 triangles of which 4,837 were bad
• Galois work-set implementation
• used STL queue first high abort ratio
• Sequential code 21,918 completed0 aborted
• Galois(q) 21,736 completed28,290 aborted
• replaced queue with arrayrandom choice
• Galois(r) 21,908 completed49 aborted

42
Code versions

• Three versions
• reference sequential version without
  locks/threads/etc.
• FGL handwritten code that uses fine-grain locks
  on triangles
• meshgen Galois version

43
Results
44
Performance Breakdown
4 processor numbers are summed over all
processors
45
Agglomerative clustering

• Two versions
• reference sequential version w/o locks/threads
• treebuild Galois version
• Data structures
• priority queue
• kd-tree
• dendrogram
• Data set
• from graphics scene with roughly 50,000 light
  sources

46
Speedups

• sequential version is best on 1 processor
• self-relative speed-up of almost 2.75 on 4
  processors

47
Abort ratios and CPI
Committed iterations Aborted iterations
1 proc 57486 n/a
4 proc 57861 2528

• Sequential and treebuild perform almost same
  number of instructions
• As before, cycles/instruction (CPI) is higher for
  treebuild mainly because of L3 cache misses
• mainly from kdTree

48
Degree of speculation

• Measured number of iterations ready to commit
  (RTC) whenever commit pool creates/aborts/commits
  an iteration
• Histogram shown above
• X-axis in figure is truncated to show detail near
  origin
• maximum number of RTC iterations is 120
• Most of the time, we do not need to speculate too
  deeply to keep 4 threads busy
• but on occasion, we do need to speculate deeply

49
Take-away points

• Support for ordering speculative computations is
  very useful for some apps
• hard to do agglomerative clustering otherwise
• May need to speculate deeply in some apps
• Domain-specific information is very useful for
  proper scheduling
• workset implementation made a huge difference in
  performance
• will probably need to provide hooks for user to
  specify scheduling policy
• Reducing cache traffic is important to improve
  performance further

50
Ongoing work
51
Improving Performance

• Locality enhancement
• Galois approach can expose data-parallelism in
  irregular applications
• Scalable exploitation of parallelism requires
  attending to locality
• Specifying scheduling strategies
• Delaunay mesh refinement example shows that
  scheduling of iterations can be critical to lower
  abort ratios
• needed domain knowledge to fix problem

52
Galois methodology

• How easy is it to specify commutativity of method
  invocations?
• How important is the distinction between semantic
  and concrete commutativity?
• How easy is it to write inverse methods?
• Given a specification of the ADT, can we check
  commutativity and inverse directives?

53
Benchmarks

• Existing benchmarks are useless
• Wirth Program Algorithm Data structure
• current benchmarks are programs
• we need algorithms and data structures
• experience with Delaunay mesh generation STL
  queue
• variety of input data sets to illustrate range of
  behavior

54
Conclusions

• Irregular programs have data-parallelism
• Work-list based iterative algorithms over
  irregular data structures
• Data-parallelism may be inherently data-dependent
• Pointer/shape analysis cannot work for these apps
• Optimistic parallelization is essential for such
  apps
• Analysis might be useful to optimize parallel
  program execution
• Exploiting abstractions provided by OO is
  critical
• Only CS people still worry about F77 and C
  anyway.
• Exploiting high-level semantic information about
  programs is critical
• Galois knows about sets and ordered sets
• Commutativity information is crucial
• Support for ordering speculative computations
  important
• Concurrent access to mutable objects is important
• Benchmark programs are bad
• Programs ?
• Algorithmsdata structures ?

55
Current approaches to parallelization
56
Pessimistic parallelization

• Use compiler (static) analyses to produce
  parallel schedule
• (e.g.) points-to/shape analysis
• Problem
• Any static technique must produce a parallel
  schedule that is valid for all inputs to the
  program
• In our applications, parallelism is very
  dependent on input data
• Conclusion static techniques must serialize all
  iterations
• accuracy of analysis is not the issue

57
Semi-static techniques

• Inspector-executor technique
• inspector small, fast program that uses input
  data to produce parallel schedule
• executor runs actual program using input data
  and parallel schedule from inspector
• Inspector generated by hand or by compiler
• Applications
• Parallel sparse matrix factorization
• Communication schedules for parallel sparse
  direct solvers
• Problem
• data-sets in our problems change as programs
  execute
• Inspector must do all the work of the executor

58
Take-away lessons (contd.)

• Updates to data structures by one computation
  must be visible to other computations before
  first one terminates
• (e.g.) worklist
• thread grabs a bad triangle from worklist
• before bad triangle processing is done, another
  thread may want a bad triangle from worklist
• modifications to worklist made by first thread
  must be visible to second thread before first
  thread completes
• similar issues arise with priority queue and
  kdTree
• But how do we prevent cascading roll-backs?
