Challenges in Hybrid DSP/FPGA Implementations of
Optimal Beamforming Bogdan Vacaliuc, Sundance
DSP, Inc.
2

Overview

• Company Highlights and Background
• BF1 System Requirements
• Top Level Design
• Partitioning
• Case Studies
• Current Status
• Future Expansion Options

3
Sundance

• Established 1989, Privately held Company Assets
  in excess of 2M
• Sundance Design, Manufacturing, Test in England
  and USA Sales Offices around the World
• Sundance is ISO9100-2000 compliant company and
  has been since 1998.

4
World Leading Users

• Michigan Tech University
• SPAWAR Systems Center - Charleston
• Lockheed Martin
• Cymer
• NASA
• Raytheon
• TRW
• General Dynamics
• Philips Medical
• Motorola
• L3-Communication
• Lucent Technologies
• MIT
• Rolls Royce
• ...

5
Concept of Modular Design
6
Processing modules
SMT398
SMT318-SX55
SMT361Q
SMT374-300

• Dual 300 MHz TI C6713
• Xilinx Virtex II XC2V2000-4
• 256MB SDRAM
• 920MB/s I/O bandwidth

• Xilinx Virtex II XC2V8000-4
• 4MB ZBT SRAM
• 2MB QDR SRAM
• 1.6GB/s I/O bandwidth

• Dual Xilinx XC4VSX55-12
• 1024 XtremeDSP
• 1.6GB/s inter-FPGA I/O
• 2.5GB/s I/O bandwidth

• Quad TI C6416
• Xilinx Virtex II XC2V2000-4
• 4MB internal memory
• 920MB/s I/O bandwidth

7
Platforms
cPCI SMT300Q
PCI SMT310Q
Embedded SMT180
VME SMT328
8

• Company Highlights and Background
• BF1 System Requirements
• Top Level Design
• Partitioning
• Case Studies
• Current Status
• Future Expansion Options

9
BF1 System Requirements

• Digital System for processing 8 element ULA or
  UCA (receiver only)
• Target Signal Family Radio Service (FRS)
• 462.5625MHz to 467.7125MHz
• 25KHz channel separation
• Intermediate Frequency
• 21.4MHz Center
• 22.5MHz Bandwidth
• Able to separate talkers on the same frequency
• USB 2.0 Interface to HOST

10
BF1 System Requirements (cont.)

• Flexibility in implementing different beamforming
  algorithms
• Flexibility in implementing different channel
  (de)modulation algorithms
• Multi-Channel operation required
• The more channels, the better

11

• Company Highlights and Background
• BF1 System Requirements
• Top Level Design
• Partitioning
• Case Studies
• Current Status
• Future Expansion Options

12
Top Level Design
Channelizer




Beamformer
Demodulator

• A tuner for each antenna
• An ADC for each tuner
• One channelizer
• A beamformer/demodulator for each channel

Output to Host
13
ADC Selection

• Fs gt 75MHz
• Fs gt 2(IFcenter(IFspan/2)Guard)
• Ideal Fs is 102.4MHz
• Fs FcM M FFT points
• Fc 25KHz
• M is gt 3000 for Fs gt 75MHz
• Pick 4096 point FFT, Fs 102.4MHz
• Maximize ADC per module
• Maximize ADC resolution
• Pick SMT364
• Quad 105MSPS ADC
• 14-bit resolution

14
CLOCK Selection

• Need to synchronize 8 ADCs (or more)
• On board clock is not synchronized between all
  ADCs
• Each pair of ADCs are clocked together
• SMT364 requires two external clocks per module
• For beamforming it is essential to have high
  stability clock sources that do not drift over
  time
• MOST IMPORTANT component

15
CLOCK Selection (cont.)

• Evaluate oscillator performance by considering
  phase noise tables
• Estimate RMS jitter and compute absolute maximum
  SNR
• Make sure maximum SNR gtgt ADC specification

1 Computed from the on-line calculator at
http//www.raltron.com/cust/tools/osc.asp 2
SNR 20log10(1/(2PIFsignalTjitter)) as
described in http//www.analog.com/en/content/0,
2886,760255F788255F91502,00.html
16
SMT399-F102.4 Module
External Clock (build option)
4-way Power Splitter lt 3 phase variance
Amplifier with phase adjustment
MMBX or SMA (build option)
On-board linear regulator and power filter
MMCX (build option)
Fine Frequency adj. for calibration
Flexible power input (TIM or EXT)

• Fixed Frequency Clock Source
• Frequency Stability 50ppb
• Aging 300ppb/year
• Option for external clock input

17
System Level Analog Connections
18
ADC Correction and Normalization

• Parameters (offset, gain, delay)
• Offset
• For BF1 System each ADC is channelized
  independently, so offset not a problem
• For systems that interleave ADC to increase the
  effective sampling rate it is critical
• Gain
• Can be adjusted by ADC parameter
• Can be adjusted numerically
• Numerical adjustment is easier
• Delay
• ADCs can start at slightly different clock edges
  (even with a trigger pulse distribution)

19
Design Level ADC block detail
FC201 for ADC channel correction
FC202 for quadrature conversion

• Common handling (in FPGA firmware) of all
  channels
• Prepares data stream for channelization

20

• Company Highlights and Background
• BF1 System Requirements
• Top Level Design
• Channelization
• Case Studies
• Current Status
• Future Expansion Options

21
Channelization

• Polyphase Filter
• Each channel represents a frequency band
• M is chosen with respect to Fs (102.4MHz) and
  channel spacing (25KHz)
• In the BF1 System
• Fs is 102.4MHz
• M is 4096
• Provides 4096 channels _at_25KSPS

22
Channel Partitioning and Distribution

• Bandwidth problem
• 8 4 102.4MHz is 3.2GB/sec
• No module has that amount of I/O capacity
• Separate channels based on region of interest.
• Beamforming is done on each channel separately
• Combine output from all ADCs
• On different FPGAs in our system

23
Channel Partitioning (cont.)

• Use an FC108 block for each ADC input
• FC108-D is a double-data rate version of FC108
• Fits onto XC4VSX55
• 220MHz with -12 part
• FC203A exchanges high/low channels and ADC
  streams
• FC203B formats the selected channels into a
  multiplexed frequency domain highway

24
FDMA Highway

• Enables distribution of multiple channels from
  all ADCs to other modules
• 40us frame time represents the channel spacing
  (25KHz)
• (FC202 decimated Fs by 2 with no loss of spectral
  information)

25
Putting it all together
26
Software and Firmware Development
-Simulink/Matlab -C Reference Models
Modeling
-PARS -System Generator -Diamond CCS ISE
Code Build
-Debugger,Simulator -Data I/O, Scripting -Hardware
In The Loop
Debug
-Real Time Analysis -Profiling (CCS) -Timing
(GPIO)
Analyze Tune
27
Tasks Channels
Develop System Model
28
Map onto hardware
Generate System Firmware
29
Software
Level 2 Level 1 Sundance Target Hardware
SMT319 with Xilinx Virtex II XC2V2000-4
30
Photo of Initial Prototype System
31
Roadmap
?

• System-System Interconnects
• Expand on number of ADC channels
• Enable additional antennas
• PARS Enhancements
• Use HDL Coder to enable Simulink-gtFPGA
• Increasingly automatic code generation
• Sundance will lead in modular, deployable signal
  processing
