Biol 155 Human Physiology

1
(No Transcript)
2
Biol 155Human Physiology

• Instructor Dr. Robert Harris
• Office 1354 Biological Sciences
• Phone [phone]
• Email harris_at_zoology.ubc.ca

3
Course requirements

• Texts Fundamentals of Anatomy and
  Physiology 6th ed. Frederic H. Martini
• Anatomy Physiology Coloring Workbook, 7th
  ed. Elaine Marieb
• Read course synopsis!!! Failure to read it, or
  failure to listen to what I say does not
  constitute an excuse
• Lecture Notes and synopsis are posted at
  http//www.zoology.ubc.ca/biomania/biol153/
• lecture/main01.htm

4
Mark Breakdown

• Biol 153 Lecture 60
• Lab 40
• Course Total 100
• The lecture mark is based on
• One mid-term exam in each term 20 (10 each)
• Winter exam 20
• Final exam 20
• Total 60

5
Mark Breakdown cont.

• Biol 155
• marks will be based solely on the lecture exams,
  which will be weighted as follows
• One mid-term exam in each term 30 (15
  each)
• Anatomy colouring book 5
• Winter exam 30
• Final exam 35
• Total 100

6
Atomic structure and elements

• An element is a substance that retains its
  chemical and physical characteristics even when
  it is broken down into its smallest units.
• The smallest practical unit, for our purposes is
  the atom.

7
The chemical characteristics are determined by
the number of protons

• These are the three forms of hydrogen
• All three have one electron
• All three have one proton

8
Electron orbits

• Number of electrons generally equals number of
  protons.
• There are specific orbits (or shells), that
  contain a specific maximum number of electrons

9
Charged atoms

• Atoms are most stable when there are 8 electrons
  in the outermost shell.
• In order for the outermost shell to be filled,
  atoms will either take in or give off electrons.
  When this happens there is a change in net
  charge.
• Charged atoms (ions) can be electrically
  attracted (opposite charges attract)
• This is known as ionic bonding
• Ionic bonds are fairly weak

10
Covalent bonds

• Another way atoms can fill their outer shell is
  to share electrons with another atom
• The electrons orbit around BOTH nuclei
• This is known as a covalent bond
• Covalent bonds are much stronger than ionic bonds

11
Molecular dipoles

• When covalent bonds are formed, the electrons may
  not be shared equally between the atoms
• This unequal sharing can result in an uneven
  distribution of electrical charges on the
  molecule
• This is known as a partial charge, or a dipole

12
Hydrogen bonding

• Water molecules interact with each other
  electrically
• The partial negative charge around the oxygen is
  attracted to the partial positive charge around
  the hydrogen
• These very weak electrical attractions are called
  hydrogen bonds

13
Ions in aqueous solution

• Water molecules can form hydrogen bonds with ions
• Ions in solution have a layer of tightly bound
  water molecules around them
• This layer of water molecules is known as the
  hydration sphere
• Water can form hydrogen bonds with uncharged
  molecules as well (providing there is a partial
  charge)

14

• pH is the negative log (the small p) of the
  hydrogen concentration (the large H)
• In pure water, some of the H2O molecules will
  dissociate into H and OH-
• The H concentration in pure water is 0.1 mM, or
  1x10-7 moles/L (hence pH 7)

15
(No Transcript)
16
Molecular Representations

• There are several ways or representing molecular
  structures
• Here are three representations of glucose
• Linear model
• Structural model
• Space-filling model

17
Synthetic and Lytic Reactions

• Smaller organic molecules can be linked together
• Often this involves the production of H2O
• Larger organic molecules can be broken down into
  subunits
• This often consumes H2O, hence the term
  Hydrolysis

18
Energetics of chemical reactions

• In order for chemicals to react, they must first
  overcome an energy barrier
• This is known as the activation energy
• Some bonds are easily reorganized, resulting in a
  lower activation energy

19
Enzyme catalyzed reactions

• Enzyme has binding sites for the reactants
• The active region will attack the bonds in the
  precursors
• Once bonds have been reorganized, product is
  released

20
Polymers in organic systems

• A polymer is a chain made up of repeating
  subunits
• Useful compounds are often stored in the form of
  a polymer
• For example, glycogen is a branched polymer of
  glucose
• Glycogen molecules can have different numbers of
  glucose subunits
• Proteins are also polymers

21
Fatty acids and lipids
22
Phospholipids in aqueous solutions

• Phospholipids and glycolipids are amphipathic
• Meaning they have a hydrophillic region and a
  hydrophobic region
• When they are in solution, they form micelles

23
Structure of Amino Acids

• All amino acids have the same basic structure
• A carboxylic acid side
• An amino group side
• A side group on the central carbon
• The side group is referred to as the R-group

24
Primary protein structure
25
Secondary protein structure

• The chain of amino acids can form folds and coils
  in different regions, depending on the amino acid
  sequence

26
Tertiary protein structure

• The tertiary structure of a protein is the 3D
  shape of a single subunit.
• This is a combination of all the folds, coils and
  sheets.
• This is usually dictated by hydrophobic and
  hydrophilic interactions with water

27
Tertiary and Quaternary protein structure

• The quaternary structure of a protein is the
  interactions between the different subunits
• If a protein is only composed of a single
  subunit, there is no quaternary structure

28
DNA and RNA structure
29
Adenosine triphosphate (ATP)

• Adenosine backbone
• Three phosphate groups attached in a chain
• Last two have high energy bonds

30
(No Transcript)
31
Characteristics of a lipid bilayer

• At normal temperatures, a lipid bilayer is
  liquid.
• This means that the phospho- and glycolipids
  which make it up can move freely, within the
  bilayer.
• Because of the hydrophobic layer in the centre,
  a bilayer is impermeable to water.
• Because of the hydrophilic and hydrophobic
  interactions, a bilayer is structurally quite
  strong.

32
Membrane fluidity
33
(No Transcript)
34
Membrane proteins
35
(No Transcript)
36
(No Transcript)
37
(No Transcript)
38
(No Transcript)
39
(No Transcript)
40
(No Transcript)
41
(No Transcript)
42
(No Transcript)
43
(No Transcript)
44
(No Transcript)
45
Diffusion
46
(No Transcript)
47
(No Transcript)
48
Effect of osmotic concentration on cells

• Cell membranes are semipermeable, and thus
  subject to osmotic forces.
• Animal cell membranes are flexible, and allow for
  inflation and deflation depending on the movement
  of water

49
Transport of solutes through cell membranes

• Cell membranes are made up of phospholipids
  arranged in a bilayer.
• The centre of the bilayer is hydrophobic, which
  means that hydrophilic molecules cant penetrate.
• Hydrophobic and lipid-soluble molecules can
  penetrate cell membranes.
• In order for hydrophilic molecules to be taken
  up, a transport mechanism is needed.
• These transport mechanisms are integral membrane
  proteins.

50
Ion channels

• Ions are fairly small molecules.
• Specialized proteins in the membrane form aqueous
  pores, which allow ions through.
• The driving force is the chemical gradient
• These pores can be quite selective.
• Most of these pores are regulated
• Example CFTR

51
Facilitated diffusion

• Molecules that are slightly larger need more help
  in getting into or out of cells.
• Rather than a pore, molecules are actually bound
  to carrier protein, which translocates molecule.
• Driving force is still the chemical gradient

52
(No Transcript)
53
(No Transcript)
54
Active transport

• In order to move ions against a concentration
  gradient, energy must be used.
• Energy is supplied by the hydrolysis of the
  terminal high-energy bond of ATP.
• Example Na-K-ATPase

55
Active secondary transport

• ATPases only pump ions, nothing bigger.
• Larger molecules are transported by coupling them
  to movement of an ion down its concentration
  gradient.
• Ions can also be transported in this way.
• Example Na-coupled glucose uptake.

56
Membrane transport and cycling

• Molecules can bind to cell surface receptors and
  then be internalized.
• This same mechanism can be used to recycle
  membrane.

57
(No Transcript)
58
Phagocytosis

• Phagocytosis also involves membrane invagination.
• This process does not involve clathrin.
• Pseudopods extend around a particle, forming a
  phagosome.
• Phagosome will fuse with a lysosome, containing
  digestive enzymes.
• There are smaller transport mechanisms in the
  wall of the secondary lysosome.

59
Cellular organelles

• Most intracellular organelles are membrane-bound.
• Since membranes are barriers to diffusion of
  aqueous solutes, they allow for partitioning of
  cellular components
• Such partitioning allows for the generation of
  gradients and/or the segregation of specific
  compounds inside the cell, a process that is
  essential for life.

60
Endoplasmic reticulum

• The endoplasmic reticulum consists of a series of
  interconnected membrane-bound tubes and lamina
  that are all continuous.
• It is essential in the production of membrane
  proteins.
• It also serves as a Ca2 storage organelle.

61
Ribosomes

• Ribosomes are enzymes made up of two subunits.
• Ribosomes are the enzyme that synthesize
  proteins, based on an mRNA template
• Some ribosomes are attached to the ER and some a
  free in the cytoplasm.

62
Translation
63
(No Transcript)
64
(No Transcript)
65
Golgi apparatus

• The Golgi apparatus is a contiguous system of
  lamellae and cisternae.
• It is responsible for post-translation
  modifications of proteins, formation of secretory
  vesicles and membrane formation and trafficking.

66
Membrane flow

• Transport vesicles bud off the ER and are
  transported to the forming face of the Golgi.
• Membrane-bound proteins and secretory proteins
  then move through the Golgi, where they are
  modified, usually by glycosylation.
• The proteins and membranes are then packaged into
  specific vesicles, which are targeted.

67
Mitochondria

• Mitochondria actually have two membranes,
  separated by a small space.
• Mitochondria also have their own DNA.
• Mitochondria are essential for oxidative
  phosphorylation.

68
Nucleus

• Nucleus also has two membranes.
• Nucleus protects the DNA and maintains a specific
  environment for the DNA.
• Nuclear pores allow for transport into and out of
  nucleus.

69
(No Transcript)
70
Library tutorial

• http//toby.library.ubc.ca/ereserve/er-coursepage.
  cfm?id1416
• For the Biol 153 students Lee Ann Bryant
  (from the library) will be here at the end of
  the lecture to give a short talk about the
  library assignment.

71
(No Transcript)
72
(No Transcript)
73
Cell cycle
74
DNA condensation
75
(No Transcript)
